©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. Training for the logistics solution Pick-to –Light / Put-to-Light mOOnTAG® Ref.: E.04.TRA.737.EN.PTL_User Training V4 ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. •The solution •DPD mOOnTAG® •Architecture •Mission •Lokeos •Connection •The different models •Users •Logs •Equipments •Locations •mOOnTAG •Monitor •Configuration •Supervision •Events •Tests •(Re)configuration –Initialization •Configure DPDs for an area •Check the configuration –Installation •Install the DPDs on the supports in the area –Use •How the DPDs work •Process a mission •Problem solving –FCC notice Summary ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. •DPD mOOnTAG® •Architecture •Mission The Solution ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. •Physical equipments –mOOnTAG® SENSORs and IDs –mBASEs –IOBox –Thin clients •Software : –Lokeos P2L + licence –UHF Tablet + DPD Encoder application (.apk) •External systems –An MES PTL client for mission creation Lokeos MES Logistic system Missions Acquittances INTRANET mBASE Thin clients mOOnTAG UHF Tablet 1.The solution - Architecture ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. LED (7 couleurs) Trappe piles DPD or mOOnTAG® = mOOnTAG® SENSOR (active RFID) + mOOnTAG® ID (passive RFID) E-paper screen Bouton sensitif (compatible port de gant) + support polyvalent ID 1.The solution - DPD or mOOnTAG® ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. 1.The solution - DPD or mOOnTAG® When changing batteries, remove the old ones and wait 20sec before inserting the new ones into the sensor. ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. mOOnTAG ID-W Coiled wire mOOnTAG-W chain mOOnTAG Master of the chain 1.The solution – mOOnTAG W ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. DPDT DPDs 1.The solution - Mission ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. •Connection •The different models •Users •Logs •Equipments •Locations •mOOnTAG •Monitor •Configuration •Supervision •Events •Tests Lokeos ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. 2.Lokeos •From a web browser (Chrome or Firefox), open the page Lokeos: http[s]://<server adress> - Select language -Enter your user account and password : Connection ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. 2.Lokeos > modules 11 Delete an item Edit an item Add an item ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. 2.Lokeos > modules Rights are defined by the profile type •SUPERVISOR •ADMIN •MONITOR •WRITER •READER Depending on the user's rights, the pages have the following functions: •Creation •Modification •Suppression •Reset password «User» module ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. 2.Lokeos > modules •All fields are editable •A user assigned to a zone must be located in the zone •Assigning an IP address allows you to automate the connection «User» module ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. 2.Lokeos > modules •Allows you to view the activities of Lokeos. •Options : –Number of lines displayed (100 by default) –Text filtering on 2 values •Actions –Downloading the current log file –Downloading the complete log directory «Logs» module ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. •Line 157756: 2020/07/17 06:46:24:470 CEST [INFO] SimpleLog --5 -INFO com.editag.tbox.application.pick2light.web-Received MQTT PAHO message on topic MU/FABRICATION/PICKTOLIGHT/IOT: }10000 4948202007170646244610MSG___SISI______IOT__HPO0101CHG_ETATIOT__HPO-- NBTR0005--DPD_27081---BFI--DPD_2703-1--BFI--DPD_2707--1-BFI--DPD_2702---1BFI--DPD_2700***4***-- Example of logs 2.Lokeos > modules ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. 2.Lokeos > modules •Usage –View the active log of Lokeos –Allows you to download all logs for transmission to the support team –Please note that the syntax and content of the log files are likely to change with the versions •Important keywords in the filters –«opened» checks the opening of the link with the mBASEs –«DPD_» checks the sending/receiving of frames with the MES PickToLight –«backup» checks the synchronisationstatus with the backup mBASE –«ERROR» to see the errors –«simple|full command» trace les demandes l’allumage –«<zone>_<n° DPD>» traces the actions on a given DPD 16 «Logs» module ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. «Equipments» module 2.Lokeos > modules ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. Leader/Backup link mBASE/location link Turn on/off mBASE mBASE Configuration «Equipments» module 2.Lokeos > modules ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. Radio frequency areaPossible areas of supervision 0 (or 4)4, 8, 12, 24, ..., 240, 252 11, 5, 9, 13, 25, ..., 241, 254 22, 6, 10, 14, 26, ..., 242, 254 33, 7, 11, 15, 27, ..., 243, 255 1616, 28, ..., 244 1717, 29, ..., 245 1818, 30, ..., 246 1919,31, ..., 247 2020,32, ..., 248 2121,33, ..., 249 2222,34, ..., 250 2323,35, ..., 251 «Equipments» module 2.Lokeos > modules ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. •SITE •Radio area •Picking area •Section •DPDs Dynamic Static «Locations» module 2.Lokeos > modules ©2023 EDITAG – All rights reserved –circulation restricted to the receiving entity only. •Correct selection •Incorrect selection •Each element has a right-cli…

Text truncated - open the document above for the full version.

EDITAG SAS au capital de 145.073 € SIRET : 498 063 510 00032 T : +33(0)484250919 Europarc Ste Victoire – Bât. 12 APE : 2611Z F : +33(0)972327290 13590 MEYREUIL – France TVA : FR20498063510 [email protected] CERTIFICATIONS CONCERNING “COVERED” EQUIPMENT Date: January 11, 2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2BDZ8-0411U Model name: mOOnTAG To Whom It May Concern: As required by section 2.911(d)(5)(i), EDITAG, FRN: 0032727968 (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. As required by section 2.911(d)(5)(ii), EDITAG, FRN: 0032727968 (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Thank you for your attention to this matter. Sincerely yours, Signature by applicant Printed Name: Yannick BACHELET Company: EDITAG Address: Europarc Sainte-Victoire Bât 12 Route de Valbrillant 13590 Meyreuil - France FRN: 0032727968 Job Title: CTO Email: [email protected] Telephone: +33 484 250 924

EDITAG SAS au capital de 145.073 € SIRET : 498 063 510 00032 T : +33(0)484250919 Europarc Ste Victoire – Bât. 12 APE : 2611Z F : +33(0)972327290 13590 MEYREUIL – France TVA : FR20498063510 [email protected] LETTER OF AGENCY Date: January 11, 2024 Element Materials Technology 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK FCC ID: 2BDZ8-0411U Model name: mOOnTAG To Whom It May Concern: SMEE (Mr. Laurent Chapus, 385 Rue René Rambaud, ZA Le Parvis 2, F-38500 Voiron, France) is authorized to act on our behalf, until otherwise notified, for applications to Element Materials Technology. We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application, is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you for your attention to this matter. Yours faithfully. Signature by applicant Printed Name: Yannick BACHELET Company: EDITAG Address: Europarc Sainte-Victoire Bât 12 Route de Valbrillant 13590 Meyreuil - France FRN: 0032727968 Job Title: CTO Email: [email protected] Telephone: +33 484 250 924

EDITAG SAS au capital de 145.073 € SIRET : 498 063 510 00032 T : +33(0)484250919 Europarc Ste Victoire – Bât. 12 APE : 2611Z F : +33(0)972327290 13590 MEYREUIL – France TVA : FR20498063510 [email protected] REQUEST FOR CONFIDENTIALITY Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Date: January 11, 2024 FCC ID: 2BDZ8-0411U Model name: mOOnTAG To Whom it may concern: We hereby request the exhibits listed below to be held confidential: • Schematics • Block Diagram • Operational Description These exhibits contain trade secrets and proprietary information not customarily released to the public. The public disclosure of the material in these exhibits might provide unjustified benefits to our competitors and be harmful to our operations. Model name: Sincerely yours, Signature by applicant Printed Name: Yannick BACHELET Company: EDITAG Address: Europarc Sainte-Victoire Bât 12 Route de Valbrillant 13590 Meyreuil - France FRN: 0032727968 Job Title: CTO Email: [email protected] Telephone: +33 484 250 924

Page 1/2 EXTERNAL PHOTOS OF TESTED EUT Applicant: EDITAG Device PMN: mOOnTAG Model: mOOnTAG Page 2/2

Page 1/1 PRODUCT LABELING Applicant: EDITAG Device PMN: mOOnTAG Model: mOOnTAG

Page 1/2 INTERNAL PHOTOS OF TESTED EUT Applicant: EDITAG Device PMN: mOOnTAG Model: mOOnTAG UHF antenna (902-928MHz) Page 2/2

COORDONNEES SMEE TEL : 04 76 65 76 50 385, Rue Renè Rambaud, ZA le Parvis 2 FAX : 04 76 66 18 30 38500 VOIRON - France SAS au capital de 50 000 € / RC Grenoble B534 796 453 / SIRET 534 796 453 00023 / code APE 7490B / n° TVA : FR 59 534 796 453 RF Exposure Considerations for FCC ID: FCC ID: 2BDZ8-0411U The calculation of the MPE is as following: Prediction of MPE limit at a prediction distance: S= ² . . 4 . R G P  = ² . . 4 . . . R P R I E  S: Power density (mW/cm²) P: Peak output power at antenna terminal (mW) G: Numerical Antenna gain R: Distance of radiation to antenna (cm) MPE calculation (1): Power value is taken from EIRP (Conducted power + antenna gain) (2): No simultaneous RF transmission Conclusion: Therefore, the device complies with FCC’s RF radiation exposure limits for general population for a mobile device. Certified By Laurent CHAPUS (Agent for this device) SMEE 385, Rue René Rambaud ZA Le Parvis 2 38500 Voiron - France [email protected] FCC Registration Number: 0020356952 (FRN) Applicant for this device: EDITAG Europarc Sainte-Victoire Bât 12 Route de Valbrillant 13590 Meyreuil – France FRN: 0032727968 Frequency (MHz) Maximum E.I.R.P. (mW) (1) R (cm) Power Density S (mW/cm²) MPE limit (mW/cm²) % of limit Limit (%) Verdict 905.25- 925.25 26.9 20 0.00535 0.6 0.89 100% Below MPE limit for uncontrolle d exposure Simultaneous transmissions SUM = N/A (2) 100%

Page 1/1 ANTENNA DESCRIPTION Applicant: EDITAG Model / HVIN: mOOnTAG Product name / PMN: mOOnTAG 1.1 RF antenna 1 (868-915MHz) Description: PCB antenna (dipole) Antenna gain: 3.6dBi Photo:

Rapport d’essais / Test Report N° : 10021-FCC-ISED-2 Page 1 / 26 COORDONNEES SMEE TEL : 04 76 65 76 50 385, Rue René Rambaud, ZA Le Parvis 2 FAX : 04 76 66 18 30 38500 VOIRON - France SAS au capital de 50 000 € / RC Grenoble B534 796 453 / SIRET 534 796 453 00015 / code APE 7490B / n° TVA : FR 59 534 796 453 FCC Test Firm Designation Number: FR0014 ISED Wireless Device Testing Laboratory CAB Number: FR0004 Matériel testé : Equipment under test: EDITAG / mOOnTAG (Trademark / Marketing name or product reference) Demandeur de certification : Applicant for certification: EDITAG Europarc Sainte-Victoire Bât 12, Route de Valbrillant, 13590 Meyreuil – France Client : Customer: ALWAYS WIRELESS Batiment Epicentre, 38660 Saint-Vincent-de-Mercuze – France Numéro d’affaire : Work number : OF-10021 Référence de la proposition : Proposal number: 012022-25243-1 Date de l’essai : Date of test: Le 11 janvier 2024 January 11 th , 2024 Objectif des essais : Test purpose: EMC qualification accordingly to following standards: - CFR 47, FCC Part 15, Subpart C (Chapter 15.247 - Operation within the bands 902–928 MHz, 2400–2483.5 MHz, and 5725–5850 MHz) - Industry Canada RSS-247, Issue 3 (Digital Transmission Systems Operating in the Bands 902–928 MHz) Measurement standards: ANSI C63.10 (2013) Lieu du test: Test location: SMEE - 385 rue René Rambaud, ZA le Parvis 2 38500 VOIRON - France Test réalisé par : Test realized by: Chemseddine KERMICHE Conclusion : Conclusion: L’équipement satisfait aux prescriptions et essais des normes citées en référence. The appliance complies with requirements and tests of above mentioned standards. Ed. Date Modifications / Pages Written by : Visa Approved by: Visa 1 January 23, 2024 Initial Edition Chemseddine KERMICHE Test operator Laurent Chapus Technical Manager La copie de ce document n'est permise que sous sa forme intégrale. Ce document est le résultat d’essais effectués sur un échantillon. Il ne préjuge pas de la conformité de l’ensemble des produits fabriqués à l’objet essayé. Pour la déclaration de conformité de l'équipement, il n'est pas tenu compte de l'incertitude de mesure. Cette nouvelle édition de ce rapport annule et remplace l’édition précédente. Les modifications apportées à une nouvelle édition de ce rapport sont signalées par un trait vertical à gauche de la page. L’utilisation de la marque d’accréditation COFRAC est interdite. This document shall not be reproduced, except in full. This document contains results related only to the item tested. It does not imply the conformity of the whole production to the item tested. For the declaration of conformity of the equipment, the measurement uncertainty is not taken into account. This new edition of this report cancels and replaces the previous edition. Changes made to a new edition of this report are indicated by a vertical line to the left of the page. The use of the COFRAC accreditation mark is prohibited. Accréditation N° 1-6356 Portée disponible sur : Scope available on : www.cofrac.fr Page 2 / 26 Rapport d’essai / Test Report N° : 10021-FCC-ISED-2 Page 2 / 26 Contents 1. NORMATIVES REFERENCES ......................................................................................................... 3 2. TEST SYNTHESIS ........................................................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) .................................................................................................. 5 4. TEST CONDITIONS ......................................................................................................................... 6 5. MODIFICATIONS OF THE EUT ....................................................................................................... 6 6. SPECIAL ACCESSORY ................................................................................................................... 6 7. MEASUREMENT UNCERTAINTY .................................................................................................... 6 8. FIELD STRENGTH CALCULATION ................................................................................................. 6 9. TEST SETUP DIAGRAM .................................................................................................................. 7 10. TEST EQUIPMENT LIST .............................................................................................................. 9 11. 6DB BANDWIDTH ...................................................................................................................... 10 12. FUNDAMENTAL EMISSION OUTPUT POWER ......................................................................... 12 13. MAXIMUM POWER SPECTRAL DENSITY LEVEL IN THE FUNDAMENTAL EMISSION .......... 14 14. UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS (RADIATED EMISSIONS) .......................................................................................................................................... 16 15. UNWANTED EMISSIONS IN RESTRICTED FREQUENCY BANDS .......................................... 19 16. OCCUPIED BANDWIDTH (99%) ................................................................................................ 25 Page 3 / 26 Rapport d’essai / Test Report N° : 10021-FCC-ISED-2 Page 3 / 26 1. Normatives References FCC qualification according to: Standards Applied Title ANSI C63.10 (2013) X American National Standard for Testing Unlicensed Wireless Devices CFR47, Part 15 (January 2024) X Telecommunication – Federal Communication Commission – Radio frequency devices, Sections 15.109 / 15.209 / 15.247 ISED qualification according to: Standards Applied Title RSS-Gen (Issue 5/2018, amendments 2019 and 2021) X General Requirements and Information for the Certification of Radio Apparatus RSS-247 (Issue3/2023) X Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence-Exempt Local Area Network (LE-LAN) Devices Note: Following guidance a…
