TYMO® G6 INSTRUCTIONS FOR USE Issue date of instructions for use 2024-03-13, Rev. 3 EN-1 Contact information: Manufacturer: Tyromotion GmbH Bahnhofgürtel 59 8020 Graz AUSTRIA PHONE +43 316 908 909 FAX +43 316 231123 9144 EMAIL [email protected] WEB www.tyromotion.com SUPPORT [email protected] Distributor (Germany, Switzerland, USA): Tyromotion GmbH Bahnhofgürtel 59 8020 Graz AUSTRIA PHONE +43 316 908 909 FAX +43 316 231123 9144 EMAIL [email protected] WEB www.tyromotion.com SUPPORT [email protected] Swiss Authorized Representative CMC Medical Devices GmbH Rigistrasse 3 CH-6300 Zug SWITZERLAND UK Responsible Person CMC Medical Devices Ltd. Office 32 19-21 Crawford Street London, W1H 1PJ UNITED KINGDOM Declaration of Conformity This product conforms to the requirements of the Medical Devices Regulation (2017/745). The CE mark must be removed when rebuilding the product or when using other than original TYMO® accessories. EN-2 Table of contents 1 Introduction 7 1.1 Training concept 7 1.2 Symbols 7 1.2.1 Symbols in the instructions for use 7 1.2.2 Symbols on TYMO® 7 1.3 Content 9 1.4 Intended use 9 1.5 Warranty and legal disclaimer 9 2 Technology 11 2.1 Overview 11 2.2 Area of application 12 3 Clinical application 17 3.1 Indications/Contraindications 17 3.2 Safety 19 3.2.1 Safety concept 19 3.2.2 Residual risk 20 4 TYMO® 20 4.1 First steps 20 4.1.1 Charging TYMO® 20 4.1.2 Installation of the Software 21 4.1.3 Installation of the Bluetooth adapter 21 4.1.4 Connecting TYMO® to the PC 21 4.1.5 Deactivate the integrated Bluetooth adapter 22 4.2 Use of TYMO® 22 4.2.1 TYMO® Application 22 4.2.2 TYMO® Rolling Element 1D and 2D 24 4.2.2.1 TYMO® Rolling Element 1D 24 4.2.2.2 TYMO® Rolling Element 2D 25 4.2.3 LED Status TYMO® 26 4.2.4 Battery 26 5 Hardware Configuration 27 5.1 Hardware test 27 5.2 Calibrating the sensors 27 6 Service information 28 6.1 Monthly functionality check 28 EN-3 6.2 Periodic check 29 6.3 Lifetime 29 6.4 Cleaning instructions 29 6.4.1 Disinfection 30 6.4.2 Cleaning process 30 6.5 Repair 30 6.6 Disposal 30 EN-4 Figure 1 Figure 2 + Figure 3 Figure 4 Figure 5 Figure 6 < 180 kg < 396.8 lbs < 180 kg < 396.8 lbs EN-5 Figure 7 Figure 8 Figure 9 EN-6 Figure 10 EN-7 1 Introduction We appreciate your choice of a new product from Tyromotion GmbH. To fully benefit from the options offered by this product read these instructions for use and save it for future use. 1.1 Training concept TYMO® is a complex technical device. Users of TYMO® are required to complete a training course and read the user manual in order to ensure the safety of patients, users and the device itself. Merely reading the present manual does not convey sufficient competence for operating TYMO®. Prospective users are also required to have basic medical training (e.g. physiotherapy/ergotherapy). Tyromotion GmbH rejects all liability for damages resulting from therapy that was performed by an untrained user. Prospective users are trained after delivery of the TYMO®. Users can perform initial and repeated therapies training with TYMO®. Users are not permitted to instruct other persons in the usage of TYMO®. Users are trained by a member of Tyromotion GmbH or by another trainer delegated by Tyromotion GmbH. 1.2 Symbols 1.2.1 Symbols in the instructions for use Warnings: This symbol indicates a possible risk of injury to your own health or to the health of others. Be especially mindful of these notices! 1.2.2 Symbols on TYMO® Follow the instructions for use Applied part, type BF EN-8 Do not discard with household waste CE mark Information about the manufacturer of TYMO®, including the manufacturer's full mailing address is displayed next to the factory symbol. Date of manufacture Serial number of the device Medical device The UKCA mark is a product label used for medical devices marketed in the United Kingdom (England, Wales, Scotland) and shows the conformity. Shows CH Authorized Representative On-switch for TYMO® Therapy plate EN-9 1.3 Content TYMO® consists of the following components, included in the delivery: • 1x TYMO® Therapy plate • 1x TYMO® Rolling Element 1D • 1x TYMO® Rolling Element 2D • 1x TYMO® Multipad X • 1x TYMO® power supply • 1x USB charging cable • 1x USB extension • 1x Bluetooth adapter • 1x USB-Stick (TyroS Software) 1.4 Intended purpose TYMO® is a monitoring and therapy device for the rehabilitation of patients suffering from motoric dysfunctions; it is primarily used for neurological rehabilitation purposes. The target group not only comprises neurological, but also orthopedic and pediatric patients with dysfunctional motion- and force control, accuracy, coordination, body control and balance. Depending on national variances, TYMO® is typically used in ergotherapy and/or physiotherapy as therapeutic support, enhancement and intensification in addition to conventional therapy forms. 1.5 Warranty and legal disclaimer Tyromotion GmbH issues a warranty to the original medical device purchaser that it shall be free of material and qualitative processing defects for a period of 12 months under normal usage conditions from the date of installation on the owner's premises and that the product complies with the mechanical and electrical specifications published by Tyromotion (unless the warranty term is extended by an optional service contract). This warranty is granted under the provision that the medical device is installed, operated, and maintained in accordance with the user manual. The customer must submit all warranty claims to Tyromotion in written form within 60 days of the occurrence of the problem and before the expiry of the warranty. Tyromotion is exclusively obligated to repair, exchange or correct faulty or non-compliant parts at its own discretion in accordance with the warranty. Tyromotion has no further obligations to the owner in regard to these parts after the repair or exchange of faulty or non-compliant parts. All repairs or maintenance work must be performed by an authori…
