2BE9Z-POM1GPS tracker

PEEQ LLC

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Apr 07, 2024
Application Purpose: Original Equipment
Date of Application: Apr 03, 2024
Equipment Note: GPS tracker
Frequency Range: 703.00000000 - 711.00000000
Company: PEEQ LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 LTECatM1TRACKER. <GNSS+GPRS+LTECATM1+GPIO> POM1 UserManual -Real-TimeVehicleTrackingSystem-- 2 CATLOG I.ProductFeatures .............................4 II.ComponentsandAccessories .....6 III.SIMcardInstallation .....................7 IV.applicationofequipment .............9 4.1Installdevice...........................9 V.PowerOn/Off .............................10 5.1Poweron...............................10 5.2LEDIndicators......................10 5.3Poweroff...............................12 VI.Troubleshooting .........................12 6.1Cannotconnectplatform.......13 Welcometouseourdevice，pleasereadthis manualcarefullytoinstallandoperatedevice 3 exactly.Thisusermanualisforreferenceonly. Ifsomecontentsandoperationstepsare inconsistentwiththosefortheactualproduct, thelatterwillprevail. 4 I.ProductFeatures ■SupportsGSM/LTECATM1. ■GPSprecisepositioning,SupportA-GPS, uploadedbyLTE/GPRSregularly,real-time trackingandhistorytrackplayback. ■Serialport. ■Built-inG-sensor,vibration,alarm. ■Built-inL-sensor,Brightnessalarm. ■Built-inT-sensor,Recordtemperature 5 BasicSpecifications Voltage3.3~4.2VDC StandbyCurrentIDLE([email protected]) GPSAccuracy5-15m GPSBand1575MHz GSMBand850/900/1800/1900MHz WIFIBand 2.4GHz(receiveonly) LTEBand(catm1) B1/B2/3/4/5/8/12/13/20/ 25/26/28/66/85 WorkingTemperature Arrange-20°C~75°C Hot/warm/coldStart <3s，<15s，<60s Dimensions(mm) 69.8x82.5x24（mm） WorkHumidity 20% ～ 80%RH NetWeight152g 6 II.Components ■Components -TopFront- (Towardssky) -Bottom- 7 III.SIMCardInstallation Openthepackingcase,checkifdeviceisOK andaccessoriesareintact, YouneedasuitableSIMcardforusingdevice, contactyourdealerifanyquestion; SIMcardinstallationrequiresthecasetobe disassembled 8 Note: ●Pleasecutoffthepowerbeforeinstallingor uninstallingSIMcard. ●SIMcardshouldhaveGPRS/LTEfunction. 9 IV.applicationofequipment 4.1Installdevice 4.1.1Pleaseplacethedeviceintheitemthatneeds tobemonitored 4.1.2InstallationNotice ●KeepdeviceawayfromRFemissionsources. ●DeviceBuilt-inGSM/LTEantennaandGPS antenna,Pleaseensurethatsignalreceivingsideis facingup(towardsthesky)whendoinginstallation, withoutanymetalmaterialcoveredonthetop.It mayweakensignalandresultsinnotworkproperly. 10 V.PowerOn/Off 5.1Poweron Poweron:InsertavalidSIMcard,thenopenthe plugandusethecardpintogentlytouchthekeyfor 2seconds. 5.2LEDIndicators TheredLEDblinksquicklywhenthedeviceis searchingforaGSM/LTEnetwork,and intermittentlywhenthedevicesuccessfullyregisters foraGSM/LTEnetwork. TheblueLEDflickersfastwhendeviceissearching fortheGPSsatellitesignal,itflickersintermittently whendevicehassearchedthesatellitesandcanbe positioned. thedeviceentersthechargingstate,theredlightis on.Whentheexternalbatteryofthedeviceisfullor notinthechargingstate,theredlightisoff. 11 1.RedLED(IndicatingchargingandGSM/LTE workingstatus) lightupbecharging OFF Thebatteryisinthe fullorunchargedstate fastblink Searching GPRS/CATMnetwork Slowflicker TheGPRS/CATM networkisconnected 2.BlueLED(indicatesGPSsignalstate) fastblink SearchingGPS Satellites Slowflicker GPSworksnormally 12 5.3Poweroff Usethecardneedletolightlytouchthebuttonfor1- 2seconds 13 VI.Troubleshooting 6.1Cannotconnectplatform deviceisneveronlineonthepositionserverwhen installedatthefirsttime.Pleasecheckdevice: 1）Checkifthebatterylevelissufficient? 2）IfSIMcardisinstalledcorrectly?Pleasereferto theinstallationinstructions. 3）CheckthestatusofLEDindicators.Ifdeviceis OK,GreenLEDandblueLEDwillintermittentlyflick. 4）Inquiryparametersofdeviceviadealersupport team. 14 FCCStatement 1.ThisdevicecomplieswithPart15oftheFCC Rules.Operationissubjecttothefollowingtwo conditions: (1)Thisdevicemaynotcauseharmfulinterference. (2)Thisdevicemustacceptanyinterference received,includinginterferencethatmaycause undesiredoperation. 2.Changesormodificationsnotexpresslyapproved bythepartyresponsibleforcompliancecouldvoid theuser'sauthoritytooperate theequipment. NOTE: Thisequipmenthasbeentestedandfoundto complywiththelimitsforaClassBdigitaldevice, pursuanttoPart15oftheFCCRules. Theselimitsaredesignedtoprovidereasonable protectionagainstharmfulinterferenceina residentialinstallation. Thisequipmentgeneratesusesandcanradiate radiofrequencyenergyand,ifnotinstalledand usedinaccordancewiththe instructions,maycauseharmfulinterferenceto radiocommunications.However,thereisno guaranteethatinterferencewillnotoccur 15 in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. To comply with RF exposure requirements, a minimum separation distance of 20 cm must be maintained between the user.s body and the device, including the antenna.

Attestation Statements

PEEQLLC * theapplicantmustdesignateacontactlocatedintheUnitedStatesforpurposesofactingasthe applicant’sagentforserviceofprocess,regardlessofwhethertheapplicantisadomesticorforeign entity.AnapplicantlocatedintheUnitedStatesmaydesignateitselfastheagentforserviceofprocess. U.S.AgentDesignationforServiceofProcess- CertificationAttestationLetter 4/1/2024 TO:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ATTN: FCCID:2BE9Z-POM1 Persection2.911(d)(7)oftheFCCrules,PEEQLLCandFRN：0034868299(“theapplicant”) certifiesthattheequipmentforwhichauthorizationissoughtisdesignatedtothefollowingU.S. agent*forserviceofprocess: CompanyName:PEEQLLC FCCRegistrationNumber(FRN):0034868299CompanyAddress:215SBroadwayUnit253 Salem,NH03079 ， USA ContactPerson:JosephMartin AgentEmailAddress:[email protected] Theabovecontactpersonacceptstheobligationforserviceofprocess. Theapplicantacceptstomaintainanagentfornolessthanoneyearafterthegranteehas terminatedallmarketingandimportationortheconclusionofanyCommission-related proceedinginvolvingtheequipment. ApplicantSigned: Signed: Printedname: JosephMartin Title: Manager CompanyName:PEEQLLC Date:4/1/2024 AgentSigned(ifdifferentfromApplicant): Signed: Printedname:Clickheretoentertext. Title:Manager CompanyName:Clickheretoentertext. Date:4/1/2024

Attestation Statements

PEEQ LLC Covered Equipment Certification Attestation Letter 4/1/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: FCC ID: 2BE9Z-POM1 PEEQ LLC (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. PEEQ LLC (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Joseph Martin Title: Senior Director Company Name: Date:

Cover Letter(s)

Date 2024/4/1 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, Signed： Name :Joseph Martin Title : Senior Director Applicant Company : PEEQ LLC

Cover Letter(s)

PEEQ LLC DATE :2024-3-21 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BE9Z-POM1 Product Name: GPS tracker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics Block diagram Operation description Bom Tune up These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2024-4-1 By: Joseph Martin SignaturePrinted Title: Senior Director On behalf of : PEEQ LLC Telephone: +1 9783195647

External Photos

Internal Photos

JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 1 of 7 EUT Internal Photos JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 7 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 7 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 4 of 7 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 5 of 7 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 6 of 7 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 7 of 7 ------End------

RF Exposure Info

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R12-2400255 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in above the application standard version. Test results reported herein relate only to the item(s) tested. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Cover Page RF Exposure Evaluation Report Report No.: JYTSZ-R12-2400255 Applicant: PEEQ LLC Address of Applicant: 215 S Broadway Unit 253 Salem, NH 03079, USA Equipment Under Test (EUT) Product Name: GPS tracker Model No.: POM1 Trade mark: N/A FCC ID: 2BE9Z-POM1 Applicable standards: FCC CFR Title 47 Part 2 (§2.1091) Date of sample receipt: 12 Mar., 2024 Date of Test: 13 Mar., to 25 Mar., 2024 Date of report issue: 26 Mar., 2024 Test Result: PASS Project by: Date: 26 Mar., 2024 Project Engineer Reviewed by: Date: 26 Mar., 2024 Senior Engineer Approved by: Date: 26 Mar., 2024 Manager Report No.: JYTSZ-R12-2400255 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-177-C Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 7 Version 1 Version No. Date Description 00 26 Mar., 2024 Original Report No.: JYTSZ-R12-2400255 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-177-C Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 7 Contents 2 Page Cover Page ............................................................................................................................................................. 1 Version ........................................................................................................................................................... 2 1 Contents ......................................................................................................................................................... 3 2 General Information ...................................................................................................................................... 4 3 Client Information ................................................................................................................................... 4 3.1 General Description of E.U.T. ................................................................................................................ 4 3.2 Operating Modes .................................................................................................................................... 4 3.3 Additions to, deviations, or exclusions from the method ........................................................................ 4 3.4 Laboratory Facility .................................................................................................................................. 5 3.5 Laboratory Location ................................................................................................................................ 5 3.6 Technical Requirements Specification ....................................................................................................... 6 4 Limits ...................................................................................................................................................... 6 4.1 Test Procedure ....................................................................................................................................... 6 4.2 Result ..................................................................................................................................................... 7 4.3 Conclusion .............................................................................................................................................. 7 4.4 Report No.: JYTSZ-R12-2400255 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-177-C Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 4 of 7 General Information 3 Client Information 3.1 Applicant: PEEQ LLC Address: 215 S Broadway Unit 253 Salem, NH 03079, USA Manufacturer: PEEQ LLC Address: 215 S Broadway Unit 253 Salem, NH 03079, USA Factory: KONKA Smart Technology Co.,Ltd. Address: No.12, West Section of Gangyuan Road, Guoxing Avenue, Lingang Economic Development ZoneYibin, Sicuan, P.R.CHINA General Description of E.U.T. 3.2 Product Name: GPS tracker Model No.: POM1 Operation Frequency: GSM850: 824.2 MHz - 848.8 MHz PCS1900: 1850.2 MHz - 1909.8 MHz LTE band 2: 1850 MHz - 1910 MHz LTE band 4: 1710 MHz - 1755 MHz LTE band 5: 824 MHz - 849 MHz LTE band 12: 699 MHz - 716 MHz LTE band 13: 777 MHz - 787 MHz LTE band 14: 788 MHz - 798 MHz LTE band 25: 1850 MHz - 1915 MHz LTE band 26: 814 MHz - 849 MHz LTE band 66: 1710 MHz - 1780 MHz LTE band 85: 698 MHz - 716 MHz Modulation technology: QPSK, 16QAM Antenna Type: Internal Antenna Antenna gain: GSM 850: -0.2 dBi; PCS1900: 0.8 dBi LTE band 2: 0.8 dBi; LTE band 4: 1.52 dBi; LTE band 5: -0.2 dBi LTE band 12: -3.11 dBi; LTE band 13: -0.28 dBi; LTE band 14: -0.28 dBi LTE …

Text truncated - open the document above for the full version.

Test Report

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R12-2400227 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in above the application standard version. Test results reported herein relate only to the item(s) tested. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Cover Page FCC RF Test Report (GSM) Report No.: JYTSZ-R12-2400227 Applicant: PEEQ LLC Address of Applicant: 215 S Broadway Unit 253 Salem, NH 03079, USA Equipment Under Test (EUT) Product Name: GPS tracker Model No.: POM1 Trade Mark: N/A FCC ID: 2BE9Z-POM1 Applicable Standards: FCC CFR Title 47 Part 2, 22H, 24E Date of Sample Receipt: 12 Mar., 2024 Date of Test: 13 Mar., to 25 Mar., 2024 Date of Report Issued: 26 Mar., 2024 Test Result: PASS Tested by: Date: 26 Mar., 2024 Project Engineer Reviewed by: Date: 26 Mar., 2024 Senior Engineer Approved by: Date: 26 Mar., 2024 Manager Report No.: JYTSZ-R12-2400227 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-150-C Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 13 Version 1 Version No. Date Description 00 26 Mar., 2024 Original Report No.: JYTSZ-R12-2400227 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-150-C Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 13 Contents 2 Page Cover Page ............................................................................................................................................................. 1 Version ........................................................................................................................................................... 2 1 Contents ......................................................................................................................................................... 3 2 General Information ...................................................................................................................................... 4 3 Client Information ................................................................................................................................... 4 3.1 General Description of E.U.T. ................................................................................................................ 4 3.2 Test Mode and Environment .................................................................................................................. 5 3.3 Description of Test Auxiliary Equipment ................................................................................................ 5 3.4 Measurement Uncertainty ...................................................................................................................... 5 3.5 Additions to, Deviations, or Exclusions from the Method ....................................................................... 5 3.6 Laboratory Facility .................................................................................................................................. 5 3.7 Laboratory Location ................................................................................................................................ 6 3.8 Test Instruments List .............................................................................................................................. 6 3.9 Measurement Setup and Procedure ........................................................................................................... 7 4 Test Channel .......................................................................................................................................... 7 4.1 Test Setup .............................................................................................................................................. 7 4.2 Test Procedure ....................................................................................................................................... 9 4.3 Test Results ................................................................................................................................................. 10 5 Summary .............................................................................................................................................. 10 5.1 Clause and Data Summary .............................................................................................................. 10 5.1.1 Test Limit .......................................................................................................................................... 11 5.1.2 Field Strength of Spurious Radiation Measurement ............................................................................ 12 5.2 Report No.: JYTSZ-R12-2400227 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-150-C Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 4 of 13 General Information 3 Client Information 3.1 Applicant: PEEQ LLC…

Text truncated - open the document above for the full version.

Test Report

Report No.: JYTSZ-R12-2400227 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 1 of 2 Appendix A: Effective (Isotropic) Radiated Power Output Data Test Result Band Channel PCL Slot Conducted Power (dBm) ERP/EIRP (dBm) ERP/EIRP Limit (dBm) Verdict GPRS850 128 5 1 31.69 29.34 38.45 PASS GPRS850 128 5 2 30.82 28.47 38.45 PASS GPRS850 128 5 3 29.34 26.99 38.45 PASS GPRS850 128 5 4 28.79 26.44 38.45 PASS GPRS850 190 5 1 31.32 28.97 38.45 PASS GPRS850 190 5 2 30.68 28.33 38.45 PASS GPRS850 190 5 3 29.32 26.97 38.45 PASS GPRS850 190 5 4 27.20 24.85 38.45 PASS GPRS850 251 5 1 31.48 29.13 38.45 PASS GPRS850 251 5 2 30.65 28.3 38.45 PASS GPRS850 251 5 3 29.46 27.11 38.45 PASS GPRS850 251 5 4 27.57 25.22 38.45 PASS GPRS1900 512 0 1 25.38 26.18 33.00 PASS GPRS1900 512 0 2 24.13 24.93 33.00 PASS GPRS1900 512 0 3 22.62 23.42 33.00 PASS GPRS1900 512 0 4 20.9 21.7 33.00 PASS GPRS1900 661 0 1 25.85 26.65 33.00 PASS GPRS1900 661 0 2 24.81 25.61 33.00 PASS GPRS1900 661 0 3 23.57 24.37 33.00 PASS GPRS1900 661 0 4 22.08 22.88 33.00 PASS GPRS1900 810 0 1 25.84 26.64 33.00 PASS GPRS1900 810 0 2 24.45 25.25 33.00 PASS GPRS1900 810 0 3 21.68 22.48 33.00 PASS GPRS1900 810 0 4 20.27 21.07 33.00 PASS Band Channel PCL Slot Conducted Power (dBm) ERP/EIRP (dBm) ERP/EIRP Limit (dBm) Verdict EGPRS850 128 8 1 24.84 22.49 38.45 PASS EGPRS850 128 8 2 24.05 21.7 38.45 PASS EGPRS850 128 8 3 22.38 20.03 38.45 PASS EGPRS850 128 8 4 21.08 18.73 38.45 PASS EGPRS850 190 8 1 23.99 21.64 38.45 PASS EGPRS850 190 8 2 23.19 20.84 38.45 PASS Report No.: JYTSZ-R12-2400227 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 2 EGPRS850 190 8 3 21.55 19.2 38.45 PASS EGPRS850 190 8 4 20.21 17.86 38.45 PASS EGPRS850 251 8 1 24.09 21.74 38.45 PASS EGPRS850 251 8 2 23.31 20.96 38.45 PASS EGPRS850 251 8 3 21.66 19.31 38.45 PASS EGPRS850 251 8 4 20.25 17.9 38.45 PASS EGPRS1900 512 2 1 25.08 25.88 33.00 PASS EGPRS1900 512 2 2 24.02 24.82 33.00 PASS EGPRS1900 512 2 3 22.25 23.05 33.00 PASS EGPRS1900 512 2 4 21.03 21.83 33.00 PASS EGPRS1900 661 2 1 25.11 25.91 33.00 PASS EGPRS1900 661 2 2 24.15 24.95 33.00 PASS EGPRS1900 661 2 3 22.5 23.3 33.00 PASS EGPRS1900 661 2 4 21.43 22.23 33.00 PASS EGPRS1900 810 2 1 25.06 25.86 33.00 PASS EGPRS1900 810 2 2 24.3 25.1 33.00 PASS EGPRS1900 810 2 3 22.42 23.22 33.00 PASS EGPRS1900 810 2 4 21.17 21.97 33.00 PASS Remark: EIRP (dBm) = Conducted power (dBm) + Antenna Gain (dBi). (For GSM1900) ERP (dBm) = EIRP (dBm) - 2.15 (dB). (For GSM850)

Test Report

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R12-2400254 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in above the application standard version. Test results reported herein relate only to the item(s) tested. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Cover Page FCC RF Test Report (LTE) Report No.: JYTSZ-R12-2400254 Applicant: PEEQ LLC Address of Applicant: 215 S Broadway Unit 253 Salem, NH 03079, USA Equipment Under Test (EUT) Product Name: GPS tracker Model No.: POM1 Trade Mark: N/A FCC ID: 2BE9Z-POM1 Applicable Standards: FCC CFR Title 47 Part 2, 22H, 24E, 27L&F&H, 90S&R Date of Sample Receipt: 12 Mar., 2024 Date of Test: 13 Mar., to 25 Mar., 2024 Date of Report Issued: 26 Mar., 2024 Test Result: PASS Tested by: Date: 26 Mar., 2024 Project Engineer Reviewed by: Date: 26 Mar., 2024 Senior Engineer Approved by: Date: 26 Mar., 2024 Manager Report No.: JYTSZ-R12-2400254 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-151-C Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 27 Version 1 Version No. Date Description 00 26 Mar., 2024 Original Report No.: JYTSZ-R12-2400254 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-151-C Project No.: JYTSZR2403014 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 27 Contents 2 Page Cover Page ............................................................................................................................................................. 1 Version ........................................................................................................................................................... 2 1 Contents ......................................................................................................................................................... 3 2 General Information ...................................................................................................................................... 4 3 Client Information ...........................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Joseph Martin(Director of Operations)

[email protected]9783195647Fax: 9783195647

Test Firm

JianYan Testing Group Shenzhen Co., Ltd.Bruce Zhang

[email protected]+86 (0) 755 23118282

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
35	27	703 MHz - 711 MHz	105.90 mW	990KW7D	0.01 ppm

Confidentiality

Long Term

Grant Notes

Output Power is EIRP and ERP for above and below 1 GHz, respectively, and conducted for Part 90 operations. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures, or as evaluated in this filing. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
