2BEB6-T100projector

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. -This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVMUNITEDINC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: Chengdu Singularity View Technology Co.,Ltd Grantee code: 2BEB6 FCC ID: 2BEB6-T100 FRN: 0034685966 Contact Name: Dean Guo Address: No.102, Zone 17, Huayin Industrial Port, No. 618 Kexing West Road, Tianfu Street, Wenjiang District, Chengdu City Telephone: 18906679427 Fax: 18906679427 E-mail: [email protected] [Chengdu Singularity View Technology Co.,Ltd] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVMUNITEDINC] is our designated US agent for service of process for the above referenced FCC ID. [Chengdu Singularity View Technology Co.,Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK-LVMUNITEDINC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/12/29 Applicant’s Name: Dean Guo US Agent for Service of Process’s Name: Jimmychen Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Chengdu Singularity View Technology Co.,Ltd Grantee code: 2BEB6 FCC ID: 2BEB6-T100 FRN: 0034685966 Contact Name: Dean Guo Address: No.102, Zone 17, Huayin Industrial Port, No. 618 Kexing West Road, Tianfu Street, Wenjiang District, Chengdu City Telephone: 18906679427 Fax: 18906679427 E-mail: [email protected] i. [Chengdu Singularity View Technology Co.,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Chengdu Singularity View Technology Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Chengdu Singularity View Technology Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2023/12/29 Applicant’s Name: Dean Guo Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Chengdu Singularity View Technology Co.,Ltd 1/1 Letter of Authorization Company: Chengdu Singularity View Technology Co.,Ltd Address: No.102, Zone 17, Huayin Industrial Port, No. 618 Kexing West Road, Tianfu Street, Wenjiang District, Chengdu City Product Name: projector Model Number: T100 FCC Identifier: 2BEB6-T100 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Dean Guo Date: 2023-12-29 Title: Manager Signature of applicant:

Chengdu Singularity View Technology Co.,Ltd 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-12-29 Subject: Request for Confidentiality FCC ID: 2BEB6-T100 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Name: Dean Guo Date: 2023-12-29 Title: Manager Signature of applicant: ☒

Size: 18*14mm M/N: T100 FCC ID: 2BEB6-T100 Label location

WIFI ANT BT ANT

FCC ID: 2BEB6-T100 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi 2.4G mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 16.554 45.2272 0.00900 1.0 PASS 802.11g 13.126 20.5400 0.00409 1.0 PASS 802.11n HT20 14.234 26.5094 0.00527 1.0 PASS 802.11n HT40 13.502 22.3975 0.00446 1.0 PASS Remark: antenna gain=0dBi EIRP=EMeas+20log(dMeas)-104.7 EIRP is the equivalent isotropically radiated power, in dBm EMeas is the field strength of the emission at the measurement distance, in dBμV/m dMeas is the measurement distance, in m For BT Field strength (dBuV/m) EIRP (dBm) Max tune-up (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 84.68 -10.5 0.0891 0.00002 1.0 PASS Remark: antenna gain=0dBi For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits =0.00900/1 + 0.00002/1 = 0.00902< 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations.

Product specification Quick Reference Date FPC 天线 Model GDT-SL--70 Frequency 2400~2500， Ant. Port Input Pwr. (dBm) 0 Tot. Rad. Pwr. (dBm) -2.3 (Input pwr – loss pwr) Peak EIRP(dBm) 1.3 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) -2.3 (58.5%) Gain (dBi) 0 (Peak Gain XY-plane) Maximum Power (dBm) 0 (XY-plane) Minimum Power (dBm) -4(XY-plane) Avg. Power (dBm) -0.5(XY-plane) Average Gain (dB) -0.5 (Avg Gain XY-plane) Manufacturer: Becool Technology (Shenzhen) Co., Ltd. Address 3F, Building E, Fenda High-tech Park, Sanwei Community, Hangcheng Baoan Dist., Shenzhen, Guangdong Province, China All the technical data and information contained herein are subject to change without prior notice Antenna layout on the Module board(mm) Antenna Gain Gain Table Unit in dBi @2400~2500MHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg. Peak Avg. Peak Avg. Module board 0.0 -0.5 -0.3 -0.9 -1.3 -2.7 58.5% XY-plane Far-field Power Distribution(H+V) on X-Y Plane Plot Peak Gain(H+V)= 0 dBi; Plot AvgGain(H+V)=-0.50dBi @2400 MHz Far-field Power Distribution(H+V) on X-Y Plane Plot Peak Gain(H+V)= -0.70 dBi; Plot AvgGain(H+V)=-2.73dBi @2450 MHz XY-plane Far-field Power Distribution(H+V) on X-Y Plane Plot Peak Gain(H+V)= -1.15 dBi; Plot AvgGain(H+V)=-1.14dBi @2500 MHz XZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-0.30 dBi; Plot AvgGain(H+V)=-0.90dBi @2400 MHz) XZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-1.89 dBi; Plot AvgGain(H+V)=-2.54dBi @2450 MHz) XZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-1.67 dBi; Plot AvgGain(H+V)=-2.68dBi @2500 MHz) YZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-1.3 dBi; Plot AvgGain(H+V)=-2.70dBi @2400 MHz) YZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-1.76 dBi; Plot AvgGain(H+V)=-2.87dBi @2450 MHz) YZ-plane Far-field Power Distribution(H+ V) on X-Z Plane Plot Peak Gain(H+V)=-2.17 dBi; Plot AvgGain(H+V)=-3.32dBi @2500 MHz)

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 56 FCC Part 15C Test Report FCC ID: 2BEB6-T100 Applicant: Chengdu Singularity View Technology Co.,Ltd Address: No.102, Zone 17, Huayin Industrial Port, No. 618 Kexing West Road, Tianfu Street, Wenjiang District, Chengdu City Manufacturer: Chengdu Singularity View Technology Co.,Ltd Address: No.102, Zone 17, Huayin Industrial Port, No. 618 Kexing West Road, Tianfu Street, Wenjiang District, Chengdu City EUT: projector Trade Mark: N/A Model Number: T100 Date of Receipt: Dec. 04, 2023 Test Date: Dec. 04, 2023 - Dec. 14, 2023 Date of Report: Dec. 14, 2023 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20231214058E Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 56 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 14 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 16 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 17 3.2.8 TEST RESULTS (1GHZ~25GHZ) 19 3.3 RADIATED BAND EMISSION MEASUREMENT 23 3.3.1 TEST REQUIREMENT: 23 3.3.2 TEST PROCEDURE 23 3.3.3 DEVIATION FROM TEST STANDARD 23 3.3.4 TEST SETUP 24 3.3.5 EUT OPERATING CONDITIONS 24 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 29 3.4.1 APPLICABLE STANDARD 29 3.4.2 TEST PROCEDURE 29 3.4.3 DEVIATION FROM STANDARD 29 3.4.4 TEST SETUP 29 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 56 Table of Contents Page 3.4.5 EUT OPERATION CONDITIONS 29 3.4.6 TEST RESULTS 29 4 . AVERAGE OUTPUT POWER 33 4.1 APPLIED PROCEDURES / LIMIT 33 4.1.1 TEST PROCEDURE 33 4.1.2 DEVIATION FROM STANDARD 33 4.1.3 TEST SETUP 33 4.1.4 EUT OPERATION CONDITIONS 33 4.1.5 TEST RESULTS 34 5 . POWER SPECTRAL DENSITY TEST 37 5.1 APPLIED PROCEDURES / LIMIT 37 5.1.1 TEST PROCEDURE 37 5.1.2 DEVIATION FROM STANDARD 37 5.1.3 TEST SETUP 37 5.1.4 EUT OPERATION CONDITIONS 37 5.1.5 TEST RESULTS 38 6 . 6DB BANDWIDTH TEST 41 6.1 APPLIED PROCEDURES / LIMIT 41 6.1.1 TEST PROCEDURE 41 6.1.2 DEVIATION FROM STANDARD 41 6.1.3 TEST SETUP 41 6.1.4 EUT OPERATION CONDITIONS 41 6.1.5 TEST RESULTS 42 7 . ANTENNA REQUIREMENT 45 7.1 STANDARD REQUIREMENT 45 7.2 EUT ANTENNA 45 8 . TEST SEUUP PHOTO 46 9 . EUT PHOTO 48 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 56 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.205, 15.209, 15.247(d) Radiated Spurious Emission PASS 15.205, 15.247(d) Band Edge Emission& Conducted Spurious Emissions PASS 15.247(b) Average Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2MHz Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 56 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: projector Trademark N/A Model No.: T100 Model Difference N/A Operation Frequency: 2412~2462 MHz for 802.11b/g/nHT20 2422~2452 MHz for 802.11nHT40 Channel numbers: 11 Channels for 802.11b/g/n(HT20) 7 channels for 802.11nHT40 Channel separation: 5MHz Modulation technology: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n(20/40): OFDM(QPSK, BPSK, 16-QAM, 64-QAM) Rate of Transmitter 802.11b: 11/5.5/2/1Mbps 802.11g: 54/48/36/24/18/12/9/6Mbps 802.11n: up to 150Mbps Antenna Type: Internal Antenna Antenna gain: 0 dBi Power supply: 100-240V~ 50/60Hz Note: 1.Fo…

Text truncated - open the document above for the full version.

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 41 of 56 6. 6DB BANDWIDTH TEST 6.1 APPLIED PROCEDURES / LIMIT FCC Part15 (15.247) , Subpart C Section Test Item Limit Frequency Range(MHz) Result 15.247(a)(2) Bandwidth >= 500KHz (6dB bandwidth) 2400-2483.5 PASS 6.1.1 TEST PROCEDURE 1. Set RBW = 100 kHz. 2. Set the video bandwidth (VBW) ≥RBW. 3. Detector = Peak. 4. Trace mode = max hold. 5. Sweep = auto couple. 6. Allow the trace to stabilize. 7. Measure the maximum width of the emission that is constrained by the frequencies associated with the two outermost amplitude points (upper and lower frequencies) that are attenuated by 20 dB relative to the maximum level measured in the fundamental emission. 6.1.2 DEVIATION FROM STANDARD No deviation. 6.1.3 TEST SETUP 6.1.4 EUT OPERATION CONDITIONS The EUT tested system was configured as the statements of 2.3 Unless otherwise a special operating condition is specified in the follows during the testing. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 42 of 56 6.1.5 TEST RESULTS Test Channel 6dB Bandwidth (MHz) Limit (MHz) Result 802.11b Low 8.102 0.5 Pass Middle 7.64 0.5 Pass High 7.253 0.5 Pass 802.11g Low 16.388 0.5 Pass Middle 15.697 0.5 Pass High 15.075 0.5 Pass 802.11n HT20 Low 16.3 0.5 Pass Middle 15.883 0.5 Pass High 15.884 0.5 Pass 802.11n HT40 Low 28.808 0.5 Pass Middle 33.868 0.5 Pass High 35.068 0.5 Pass Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 43 of 56 802.11b 802.11g 2412MHz 2412MHz 2437MHz 2437MHz 2462MHz 2462MHz Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 44 of 56 802.11n HT20 802.11n HT40 2412MHz 2422MHz 2437MHz 2437MHz 2462MHz 2452MHz Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 45 of 56 7. ANTENNA REQUIREMENT 7.1 STANDARD REQUIREMENT 15.203 requirement: For intentional device, according to 15.203: an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. 7.2 EUT ANTENNA The EUT antenna is Internal Antenna, It comply with the standard requirement. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 46 of 56 8. TEST SEUUP PHOTO Radiated Measurement Photos Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 47 of 56 Conducted Measurement Photos Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 48 of 56 9. EUT PHOTO Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 49 of 56 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 50 of 56 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 51 of 56 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 52 of 56 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 53 of 56 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 54 of 56 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 55 of 56 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20231214058E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 56 of 56 ※※※※※ END OF REPORT ※※※※※

Radiated Measurement Photos Conducted Measurement Photos
