INTRODUCTION Thank you for choosing HengludaMODEL handheld Radio. Please read all instructions carefully before using the OS-E36 TWO WAY RADIO OS-E36 USER GUIDE CONTROLS & BUTTON FUNCTIONS 1. Fixed antenna 2. Push to Talk (PTT) 3. Channel [-]/FM 4. Channel [--]/Scanning 5. Speaker 6. Microphone 7. Battery charging indicator 8.Transmit/Receive indicator 9. Power/Volume knob 10. Charging port 11. Accessory port It is recommended to check inbox items upon unboxing. If any of these items are lost or damage, please contact your place of purchase immediately. Inbox items： CHECK THE PACK CONTENTS •1xRadio •1xBattery •1xBeltclip •1xPowersupply •1xChargingcable •1xUserguide GETTING STARTED ChargingTheBattery Connect Type-C charge cable to the charger traycharging port and the USB end to a standard 5V USB charging point or a 5V 1A or above USB wall adaptor. Plug the adaptor into a wall outlet. Place the radio onto the charger tray. The charging battery charging indicator red meaning the battery is charging, blue when fully charged. Note: •Charge only at room temperatures. •Battery may corrode over time and cause permanent damage to your radio. •Remove radio as soon it is fully charged for optimized battery life. Installing the Battery Withthebackoftheradioisfacingup,pressandslideinthebattery untilyouheartheclicksound. Press Slide Installing Belt Clip To attach: Place the belt clip as shown in picture. Slide and press the belt clip toward until it snap into place. To remove: Pinch and hold belt clip latch and slide the belt clip upward. Low Battery Alert If the battery level becomes low,the device will voice prompted low battery. Recharge the radio immediately to continue using the radio. Battery Save The radio has a circuit that is specifically designed to reduce power consumption and significantly prolong the battery life. If there is no transmission or receive call within 60 seconds, the radio automatically enters Battery Save mode. The radio is still able to receive transmissions in this mode. To attach To remove Latch Step 1 Step 2 Step 3 PTT Time Out Timer (TOT) The TOT is designed to prevent accidentally transmissions for an extended period. If the [PTT] button is press for continuous 60 seconds, the radio will stop transmission and emit warning tone. Scanning Use scan to monitor channels for transmissions or to locate someone in your group who has accidentally changed channels. [--] button is preprogrammed with scanning function, press & hold [--]button to enter scanning mode. Repeat step to exit scanning mode. Important:Remember to turn the scan function off after scan. The scan function will drain more power if keep running in background. FM Mode [-]button is preprogrammed with FM mode, press & hold [-]button to enter FM mode. Press [-] or [--] to scan next available FM channels. Press & hold [-]buttonto exit scanning mode. To talk, pressand hold the[PTT]button. Hold the radio3~7cm away from your mouthwhen speaking.Thetransmitting indicator will show red.Once finish speaking, release thePTT buttonto stop transmission. Note:Do not press the [PTT] button when others are talking. Thecommunication is interrupted. Listening/ Receiving The radio speaker receives signal automatically if radio is set to thesame channel and subcode as the transmitting radio. Ensure the speaker volume is set to an appropriate level. Power/Volume On/Off To turn the radio on or off, rotate the knob clockwise until you hear the voice announcement and display turns on or off.Turn the knob counterclockwise to power off. Display Back Light Your radio has an automatic display back light which remains on for about 6seconds after a button pressand 8 seconds after PTT button is press. Channel Selection Press [-] or [--] button to switch to desired channel. Talking/Transmitting Note:To communicate, all radios in the group must be set to the same channel and same CTCSS/DCS subcode if it is set. RADIO OPERATIONS Radio Password Setting Note:Password need to have 6 characters include any combination ofupper-and lower-caseletters and numbers (0-9).Use the designed Type-C programming cable for programming radio. 1.To add a new password, enter a 6-character password in the [Change Password] field and write it to the radio. 2.If a password has already been set, enter the password in the [R/W Password] field to read and write to the radio. 3.To change the password, enter the existing password in the [R/W Password] field and the new password in the [Change Password] field, then write it to the radio. The password will be updated to the new password. 4.To remove the password, enter the current password in both the [R/W Password] and [Change Password] fields, then write it to the radioto remove the password. Time Out Timer (TOT) To prevent accidental transmissions and save battery life, the radio will stop transmitting and emit beep tone if you press PTT for continuous 60 seconds. You may customize the TOT setting through programming software. FUNCTIONS INTRODUCTION Voice Operated Transmission(VOX) Transmission is initiated by speaking into the microphone of the radio instead of pushing the PTT key. You may customize the VOXsetting through programmingsoftware. Note:VOX levels-OFF by default, from 1 (low sensitivity) to 9 (high sensitivity). Wireless Cloning (Pairing all channels) Wireless Cloning is a function that allows you to easily copy all channels from one radio (the master) to all other radios within range without the use of wires or cables. To clone the channels and subcode, radios and the master radio must: 1.Ensure that the radios of the same model are on Channel 2 and turn radio power off. 2.Press and hold +button andturn the knob clockwise simultaneouslyto turn on the radio.Blue light in pulses indicate the radio enters pairing mode. 3.Shortpress the [PTT] button to clonethe Master channels and subcodes to radios. Steady red light indicates cloning in progress. Red light indicator turned offwhen completed. Restart to use the …
