2BEDL-JD01Intelligent connected aromatherapy machine

感谢您购买及使用本产品！ 为了给您带来更好的使用体验，在使用产品前请仔细阅读本说 明书，并请妥善保管，以便日后参考。 由于产品的更新与升级，产品的实物和参数可能略有差异，请 以产品实物为准。 ① 取出香水瓶，拧开瓶盖，将瓶口封口保护膜撕掉。 ② 取出棉棒，把棉棒垂直插入瓶中，确保棉棒插至瓶底。 内嵌式安装： 一只手持机器，另一只手将香水瓶口在机器后背面对准设备安装接口， 按压瓶子底端，听到“啪”的响声，瓶子和机身紧密贴合即可。 注意事项： 1、机器开机后是以分钟为单位定时自动喷雾，定时时间可能 略有偏差。 2、安装精油瓶的过程中以及装好精油瓶后，切勿将香薰机倾斜、倒置、 侧放。否则精油漏液会造成机器损坏! 3、香精油不可食用，请远离儿童和宠物，以免误食发生意外。 4、香精油避免接触皮肤和眼睛，如不慎入眼，请用清水冲洗或及时就医。 5、香精油避免滴洒到油性漆面/皮革/织物表面，以免造成腐蚀破坏。如 不慎洒落，请立即清洁干净。 6、严禁使用非本公司配方香精油，以免造成喷雾口堵塞，损坏产品功能。 7、使用过程中，遇到任何问题请先咨询客服，有专业的售后人员为您处 理!严禁私自拆开维修或清洗。 8、请勿用尖锐的物体捅雾化口，以免损坏雾化片，造成无法喷雾。 一、产品参数二、按键功能和操作指导三、精油瓶的安装和拆卸方法 四、米家APP控制 产品名称 工作电压 额定充电输入 电池容量 雾化面积 材质 工作原理 产品清单 香薰机x1、充电线x1 说明书x1、无痕挂贴x1 智能互联香薰机 3.7-5V 5V 0.5A 1200mAh锂电池 50㎡ ABS/PP 采用超声波雾化 开机/关机 1、长按开/关机,(开机时屏显示:ON， 关机显示:OF）首次开机进入1档模式( 开机状态下实现手机远程控制)，二 次开机默认最后一次使用状态； 2、短按按键,循环切换喷雾档位； 切换档位时：先显示档位，间隔1秒 后显示电量2秒（如50%），再间隔1 秒显示温度2秒（如：25°C）。 1档 常喷3秒;每间隔5分钟喷雾一次;切换 档位时数码管显示1（亮5秒），喷雾 图标及浓香图标亮5秒； 工作指示：30秒闪烁浓香图标及喷 雾图标，表示当前正工作在1档 2档 常喷3秒:每间隔15分钟喷雾一次:切换 档位时数码管显示2（亮5秒），喷雾 图标及清香图标亮5秒； 工作指示：30秒闪烁清香图标及喷 雾图标，表示当前正工作在2档 3档 常喷3秒:每间隔30分钟喷雾一次:切 换档位时数码管显示3（亮5秒），喷 雾图标及淡香图标亮5秒； 工作指示：30秒闪烁淡香图标及喷 雾图标，表示当前正工作在3档 4档 持续喷雾，切换档位时数码管显示4 （亮5秒） 工作指示：喷雾图标及常喷图标常亮， 表示当前正工作在4档 指示灯 1、充电时：插入充电器，充电电池 图标（闪烁）（表示充电器已经连接 ）充电的整个过程，数码管实时显示 电量百分比。 2、充满电时：充电图标常亮，电量 显示100% 3、低电量：数码管连续闪烁00，提 醒用户低电量需要充电。 定时操作 APP可以设定定时工作，定时生效后， 如果操作本地按键，会取消所有定时 设置。 智能互联香薰机说明书 感谢信任 不负厚望 特别注意：【纳米陶瓷雾化片】 喷雾口内是雾化片，切勿用东西去 捅、划或者戳破(人为戳破/划伤不 保售后) 本产品已接入米家,可通过米家APP控制。 “已接入米家”(works with miiia)仅做软 件层面的验证。小米不对改产品及企 业的生产制造、标准执行、质量监管 等方面负责。 安装米家APP 扫描产品二维码,或在应用商店搜索“米 家”,下载并安装米家APP;已安装米家 APP的用户将被引导至设备连接页。 蓝牙连接使用说明 第一步： 手机扫描二维码，或在应用市场搜索 米家，下载安装App并注册。 第二步： 如图1 所示：长按按键2秒开机，开机 后默认为1档， 如图2 所示：用细针插入复位孔，长按 按键1秒以上，显示屏“8”闪烁提示蓝 牙复位成功！ 第三步： 打开App，首页点“+”选择“添加设备”， App将扫描待配置的智能设备。 图示 1 图示 2 添加设备 1.开启手机蓝牙和APP权限。(需要在设置里打开米家APP的必要应 用权限；安卓系统需同时开启蓝牙和GPS定位；iOS系统需要开启 蓝牙) 2.打开米家APP，首次使用时,请根据APP指引注册/登录小米账号。 3.进去APP首页“设备”，点击“+”选择“添加设备”，APP将扫描待配置 的智能设备。 ※如果未扫描到设备，请点击“手动添加”根据界面 提示手动添加设备。 4.在扫描的设备列表中，点击需要添加的设备。 根据界面提示连接设备。 5.设备绑定手机后，可根据使用者自身情况调整档位。 ※ 添加成功后，智能设备将出现在米家App的首页“设备”。 在APP首页点击设备，进入设备控制界面对设备进行控制。 提示：在无障碍物的情况下:蓝牙连接有效传输距离通常在10米内, 建议您在10米以内进行蓝牙设备的连接与操作。 Thank you for purchasing and using this product! In order to bring you a better experience, please read this manual carefully before using the product, and please keep it in a safe place for future reference. Due to product updates and upgrades, the physical product and parameters may vary slightly, please refer to the physical product. ① Remove the perfume bottle, unscrew the cap and remove the protective film from the bottle seal. ② Remove the cotton swab and insert the swab vertically into the bottle, making sure the swab is inserted to the bottom of the bottle. Insertion: One hand holding the machine, the other hand will be the mouth of the perfume bottle in the back of the machine on the back of the equipment to install the interface, press the bottom of the bottle, hear the "pop" sound, the bottle and the body of the machine can be tightly affixed. Notes: 1, the machine is timed in minutes after the start of the automatic spray unit, timing time may be slightly off. 2, the process of installing the essential oil bottle and the bottle, do not tilt the aromatherapy machine, inverted, side put. Otherwise the essential oil leakage will cause damage to the machine! 3, the essential oil is not edible, please keep away from children and pets to avoid accidental ingestion of accidents. 4, essential oils to avoid contact with the skin and eyes, such as accidentally into the eyes, please rinse with water or seek medical attention in a timely manner. 5, the essential oil to avoid dripping into the oily paint / leather / fabric surface, so as not to cause corrosion damage. If accidentally spilled, please clean up immediately. 6, strictly prohibit the use of non-company formulations of essential oils, so as not to cause clogging of the spray port, damage to the function of the product. 7, the use of the process, encountered any problems please consult customer service first, there are professional after-sales staff for you to deal with! It is strictly prohibited to privately dismantle the maintenance or cleaning. 8, please do not poke the atomization mouth with sharp objects, so as not to damage the atomization piece, resulting in the inability to spray. 1、Product Parameters2、Key functions and operating instructions3、Essential oil bottle installation and disassembly methods 4、Mijia APP control Product Name Working Voltage Rated Power Battery capacity Atomizing area Material Working Principle Product List Aroma Diffuser x1, Charging Cable x1 Instruction manual x1, no trace hanging sticker x1 Smart Connected Aromatherapy Diffuser 3.7-5V 5V 0.5A 1200mAh lithium battery 50 square meters ABS/PP Adopt ultrasonic atomization Power on/off 1, long press on/off, (on screen display: ON, off display: OF) the first boot into the 1-speed mode (boot state to achieve cell phone remote control), the second boot default last use state; 2, short press the button, cycle switch spray gear; When switching gears: display the gear first, display the power for 2 seconds after an interval of 1 second (e.g., 50%), and then display the temperature for 2 seconds after an interval of 1 second (e.g., 25°C). 1st gear Spraying for 3 seconds; spraying every 5 minutes; when switching gears, the digital tube displays 1 (bright for 5 seconds), and the spray icon and aroma icon are bright for 5 seconds; Work instructions: 30 seconds flashing aroma icon and spray icon, indicating that the current work in the first gear 2nd gear Spray 3 seconds: spray every 15 minutes: digital tube display 2 (light 5 seconds) when switching gears, spray icon and fragrance icon light 5 seconds; Work instructions: 30 seconds blinking fragrance icon and spray icon, that is currently working in the 2-speed 3rd gear Spray for 3 seconds: Spray every 30 minutes: When switching gears, the digital tube displays 3 (light for 5 seconds), and the spray icon and fragrance icon light for 5 seconds; Work instructions: 30 second…

Text truncated - open the document above for the full version.

1/1 USAgentforServiceofProcessLETTEROFATTESTATION TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USAgentforServiceofProcess: CompanyName:ChenyueZhonglianInternationalTradeServiceLLC FRN:0035336668 ContactName:yongchaoli Address:522WRIVERSIDEAVESTENSPOKANE,WA99201 TelephoneNo:+18788880902 Email:[email protected] Applicant: Companyname:ShenzhenAlouattaTechnologyCo.,Ltd ProductDescription:Intelligentconnectedaromatherapymachine Granteecode:2BEDL FCCID:2BEDL-JD01 ContactName:TaoDeng Address:3301,BlockA,Building3,HengmingwanChuanghuiCenter,Huilongpu Community,LongchengStreet,LonggangDistrict,ShenzhenCity TelephoneNo:15112879145 Email:[email protected] FRN:0034698035 [ShenzhenAlouattaTechnologyCo.,Ltd]certifiesthat,asofthedateofthisfilingof theapplicationwiththeTCB,[ChenyueZhonglianInternationalTradeServiceLLC]is ourdesignatedUSagentforserviceofprocessfortheabovereferencedFCCID. [ShenzhenAlouattaTechnologyCo.,Ltd]acceptstomaintainanagentfornoless thanoneyearafterthegranteehasterminatedallmarketingandimportationorthe conclusionofanycommissionrelatedproceedinginvolvingequipment.[Chenyue ZhonglianInternationalTradeServiceLLC]accepts,asofthedateofthefilingofthe application,theobligationofthedesignatedUSagentforserviceofprocessforthe abovereferenceFCCID. TheUSAgentforServiceofProcessisawareofandagreestocomplywiththerequirements outlinedintheFCCEquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause §2.911. TheApplicantisawareofandagreestocomplywiththerequirementsoutlinedintheFCC EquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause§2.911. Date:2024/05/31 Applicant’sName:TaoDengUSAgent’sName:yongchaoli Title:ManagerTitle:ceo SignatureSignature

C5266091_X24_Ed.2 1/1 Shenzhen Alouatta Technology Co., Ltd “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Alouatta Technology Co., Ltd FRN：0034698035 Grantee code: 2BEDL FCC ID: 2BEDL-JD01 Contact Name: Tao Deng Address: 3301, Block A, Building 3, Hengmingwan Chuanghui Center, Huilongpu Community,Longcheng Street, Longgang District, Shenzhen City Telephone No: 15112879145 Fax No: / Email: [email protected] i. [Shenzhen Alouatta Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Alouatta Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Alouatta Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2024/06/06 Applicant’s Name: Tao Deng Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist C5266091_X24_Ed.2 1/1

C5266091_X8_Ed.1 1/1 Letter of Authorization Shenzhen Alouatta Technology Co., Ltd Company: Shenzhen Alouatta Technology Co., Ltd Address: 3301, Block A, Building 3, Hengmingwan Chuanghui Center, Huilongpu Community,Longcheng Street, Longgang District, Shenzhen City Product Name: Intelligent connected aromatherapy machine Model Number: JD01 FCC Identifier: 2BEDL-JD01 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Tao Deng Date: 2024.06.06 Title: Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 Shenzhen Alouatta Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024.6.6 Subject: Request for Confidentiality FCC ID: 2BEDL-JD01 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: Name: Tao Deng Title: Manager 2024.06.06

Page1of3ReportNo.:FCS202405273 Externalphotos Photo1 Photo2 Page2of3ReportNo.:FCS202405273 Photo3 Photo4 Page3of3ReportNo.:FCS202405273 Photo5 Photo6

LabelandLabelLocation FCCID:2BEDL-JD01

Page1of2ReportNo.:FCS202405273 Internalphotos Photo1 Photo2 Page2of2ReportNo.:FCS202405273 Photo3 PCBANT

Page1of2ReportNo.:FCS202405273 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.FCS-lab.com FCCRFExposure EUTDescription:Intelligentconnectedaromatherapymachine Testtype.:JD01 Seriesmodel:N/A FCCID:2BEDL-JD01 Equipmenttype:Mobileequipment Testproceduresaccordingtothetechnicalstandards:KDB447498D01V06andFCC2.1091. 1.Limits Thecriterialistedinthefollowingtableshallbeusedtoevaluatetheenvironmentimpactof humanexposuretoradiofrequency(RF)radiationasspecifiedin1.1307(b) LimitsforMaximumPermissibleExposure(MPE) F=frequencyinMHz Formula:Pd=(Pout*G)/(4*π*r 2 ) Where: Pd=powerdensityinmW/cm 2 , Pout=outputpowertoantennainmW; G=gainofantennainlinearscale, π=3.14; R=distancebetweenobservationpointandcenteroftheradiatorincm PdidthelimitofMPE,1mW/cm2.Ifweknowthemaximumgainoftheantennaandthetotal powerinputtotheantenna,throughthecalculation,wewillknowthedistancerwheretheMPE limitisreached. Page2of2ReportNo.:FCS202405273 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.FCS-lab.com 2.TestProcedure SoftwareprovidedbyclientenabledtheEUTtotransmitandreceivedataatlowest,middleand highestchannelindividually. 3.TestResultofRFExposureEvaluation Modulation Channel Freq. (MHz) Conduct edpower (dBm) Max tune-up power (mW) Antenna Gain (dBi) Antenna gainnumeric Evaluation result (mW/cm2) Power density Limits (mW/cm2) GFSK 24022.491.771.351.360.000479141 24402.411.741.351.360.0004710191 24802.94 1.97 1.351.36 0.00053328 1 Conclusion:themaxresult:0.00053328≤1.0compliancewithFCC'sRFExposure. Conclusion:NoSARisrequired

1，PCBonboardantennadimensions 2，Simulationparameters 2DGainpattern: Manufacture's NameShenzhen Alouatta Technology Co., Ltd 2.5mm 6.2mm 3.1mm 6.5mm 3DGainpattern: 1 (dBi)

FCCTestReport ReportNo:FCS202405273W01 Issuedfor Applicant: ShenzhenAlouattaTechnologyCo.,Ltd Address: 3301,BlockA,Building3,HengmingwanChuanghui Center,HuilongpuCommunity,LongchengStreet, LonggangDistrict,ShenzhenCity ProductName: Intelligentconnectedaromatherapymachine BrandName: N/A ModelName: JD01 SeriesModel: N/A FCCID: 2BEDL-JD01 IssuedBy:FluxComplianceServiceLaboratory Add:Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-Tech Industrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.FCS-lab.com Page 2 of38ReportNo.:FCS202405273W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.FCS-lab.com TESTRESULTCERTIFICATION Applicant’sName......................:ShenzhenAlouattaTechnologyCo.,Ltd Address......................................: 3301,BlockA,Building3,HengmingwanChuanghuiCenter, HuilongpuCommunity,LongchengStreet,LonggangDistrict, ShenzhenCity Manufacture'sName................:ShenzhenAlouattaTechnologyCo.,Ltd Address......................................: 3301,BlockA,Building3,HengmingwanChuanghuiCenter, HuilongpuCommunity,LongchengStreet,LonggangDistrict, ShenzhenCity ProductDescription ProductName ........................... :Intelligentconnectedaromatherapymachine BrandName ............................... :N/A ModelName..............................:JD01 SeriesModel..............................:N/A TestStandards..........................:FCCRulesandRegulationsPart15SubpartC,Section247 TestProcedure..........................:ANSIC63.10:2013 ThisdevicedescribedabovehasbeentestedbyFluxComplianceServiceLaboratory,thetestresults showthattheequipmentundertest(EUT)isincompliancewiththeFCCrequirements.Anditis applicableonlytothetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofFluxCompliance ServiceLaboratory,thisdocumentmaybealteredorrevisedbyFluxComplianceServiceLaboratory, personalonly,andshallbenotedintherevisionofthedocument.. DateofTest..................................: Date(s)ofperformanceoftests . :May16,2024~May25,2024 DateofIssue ................................. :May27,2024 TestResult....................................:Pass Testedby: (ScottShen) Reviewedby : (DukeQian) Approvedby: (JackWang) Page 3 of38ReportNo.:FCS202405273W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.FCS-lab.com TableofContentsPage 1.SUMMARYOFTESTRESULTS...........................................................................................6 1.1TESTFACTORY............................................................................................................7 1.2MEASUREMENTUNCERTAINTY.................................................................................7 2.GENERALINFORMATION...................................................................................................8 2.1GENERALDESCRIPTIONOFTHEEUT.......................................................................8 2.2BLOCKDIGRAMSHOWINGTHECONFIGURATIONOFSYSTEMTESTED............10 2.3DESCRIPTIONOFNECESSARYACCESSORIESANDSUPPORTUNITS...............11 2.4EQUIPMENTSLIST.....................................................................................................12 3.CONDUCTEDEMISSIONMEASUREMENT.......................................................................13 4.6DBBANDWIDTH...............................................................................................................17 4.1Limit..............................................................................................................................17 4.2TestProcedure.............................................................................................................17 4.3Testsetup.....................................................................................................................17 4.4Testresults...................................................................................................................17 4.5OriginalTestData.........................................................................................................18 5.CONDUCTEDOUTPUTPOWER........................................................................................21 5.1LIMIT............................................................................................................................21 5.2TESTPROCEDURE.....................................................................................................21 5.3TESTSETUP...............................................................................................................21 5.5TESTRESULTS...........................................................................................................21 6.BANDEDGEANDSPURIOUS(CONDUCTED)..................................................................22 6.1LIMIT............................................................................................................................22 6.2TESTPROCEDURE.....................................................................................................22 6.3TESTSETUP...............................................................................................................22 6.4TESTRESULTS...........................................................................................................23 6.5Originaltestdata..........................................................................................................23 7.POWERSPECTRALDENSITY...........................................................................................25 7.1LIMIT............................................................................................................................25 7.2TESTPROCEDURE..............................................................................…

Text truncated - open the document above for the full version.

Page 1 of1ReportNo.:FCS202402087 Blow1GHzforradiatedemissiontestsetup Above1GHzforradiatedemissiontestsetup Page 2 of1ReportNo.:FCS202402087 ConductedEmissions
