2BEHS-LV-M10PROBluetooth glasses

PC Frame Polarized Sunglass Lens Multi-function key Built-in Mic and Charging Indicator light Multi-function key Magnetic Charging Port Built in Speaker  Smart Glasses User Manual M10 Pro Product Specification Packing Lists： Product Overview Operating Instructions 1. Power On/Off 2. Play/Pause 3.Volume Up /Down 4. Switch Songs 5. Answer/Hang up the call 6. Call Rejection 7. Activate Voice Assistant 8. Low Battery Alert Pairing Method Charging Operation Tips Cautions Important Safety Information Warranty and Customer Support                  M10 Pro PC 镜框 偏光太阳镜镜片 多功能按键 内置麦克风和充电指示灯 多功能按键 磁性充电接口 内置扬声器 声音聚焦硅胶套 智能眼镜 说明书 M10 Pro 产品规格 包装清单： 产品概览 操作说明 1. 电源打开/关闭 2. 播放/暂停 3.增大/减小音量 4. 切换歌曲 5. 接听/挂断电话 6. 拒接来电 7. 激活语音助手 8. 低电量提示 配对方法 充电操作 提示 注意事项 重要安全信息 保修和客户支持   M10 Pro FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. * RF warning for Portable device: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

ShenZhen LVTEL Communication Equipment Co.,Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 11-24-2024 FCC ID: 2BEHS-LV-M10PRO Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing (ShenZhen LVTEL Communication Equipment Co.,Ltd) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing (ShenZhen LVTEL Communication Equipment Co.,Ltd) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: ShenZhen LVTEL Communication Equipment Co.,Ltd Address: 2105A 2105, 21st Floor, Building 1, Yagang Industry and Trade Building, No. 18 Fu'an Avenue Pinghu Street, Longgang District, Shenzhen, China Contact Person: Shiqiang Lu Tel.: 755-29688879 Email: [email protected] Sincerely, Signature:

- ShenZhen LVTEL Communication Equipment Co., Ltd - The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 11/29/2024 U.S. Agent Designation ShenZhen LVTEL Communication Equipment Co., Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: [ 2BEHS-LV-M10PRO ]): Name and company of U.S. agent: Linkwld LLC Physical U.S. address of agent: 1942 Broadway St. STE 314C, Boulder, CO, 80302, US FRN of U.S. agent: 0033625682 Email address of U.S. agent: [email protected] Tel.: (716) 963-4572 Linkwld LLC acknowledges their obligation to accept service of process on behalf of ShenZhen LVTEL Communication Equipment Co., Ltd. ShenZhen LVTEL Communication Equipment Co., Ltd with the FRN [0034729269] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). Sincerely, Signature [Name]:Shiqiang Lu [Title]：Business Assistant [Company]ShenZhen LVTEL Communication Equipment Co., Ltd Signature [Name of U.S. agent] Timothy Zhu [Title of U.S. agent] Manager [Company of U.S. agent] Linkwld LLC 48_[model] US_Agent_2.911(d)(7) - U, V04

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 ShenZhen LVTEL Communication Equipment Co.,Ltd Date：11/24/2024 Product Model Number: M10 Pro, M10 Pro A, M10 Pro B, M10 Pro C, M10 Pro D, M7 Pro, M11 Pro, M12 Pro, M20 Pro, M30 Pro FCC ID：2BEHS-LV-M10PRO To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Shiqiang Lu Contact Listed on FCC Wesbite Title: Business Assistant Email: [email protected] On behalf of: ShenZhen LVTEL Communication Equipment Co.,Ltd

ShenZhen LVTEL Communication Equipment Co.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: November 25, 2024 Subject; Request for Confidentiality FCC ID: 2BEHS-LV-M10PRO To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Shiqiang Lu Title: Business Assistant

Differences Description We ShenZhen LVTEL Communication Equipment Co.,Ltd state: Product： Bluetooth glasses Model(s) Name： M10 Pro, M10 Pro A, M10 Pro B, M10 Pro C, M10 Pro D, M7 Pro, M11 Pro, M12 Pro, M20 Pro, M30 Pro Brand Name： N/A FCC ID： 2BEHS-LV-M10PRO All models have the same circuit schematic, construction, PCB Lavout and critical components. Only different of model name and appearance. Sincerely, Name: Shiqiang Lu Tel.: 755-29688879 Email: [email protected]

2.4GHz 1608 Chip Antenna: RANT1608F245C01 _ Application: WLAN,802.11b/g,Bluetooth,WLAN,etc... Features SMD,highreliability,ultraImpact,Omni-directional... PartnumberInformation RANT1608F245C (A)(B)(C)(D)(E) ElectricalSpecificatio 01 (F) n DimensionandTerminalConfiguration No.TerminalName 1Feeding/GNG 2GND/Feeding (A)ProductTypeChipAntenna (B)SizeCode 1.6x0.8mm( ± 0.1mm) (C)MaterialHighKmaterial (D)Frequency2.4~2.5GHz (E)FeedingmodePIFA&SingleFeeding (F)AntennatypeType=01 WorkingFrequencyRange2400~2500MHz Bandwidth120MHz(Min.) PeakGain2.7dBi(Typ.) Impedance50Ohm Returnloss10dB(Min) PolarizationLinear AzimuthBeamwidthOmni-directional OperationTemperature( °C )-40~85 °C ResistancetoSolderingHeats 10sec.(@280 °C ) TerminationNi/Au(Leadless) Dimension(mm) L 1.60±0.10 W 0.80 ± 0.10 T 0.80 ± 0.10 Add:Room 707, Building F, Tongan Zhichuangyuan, xixiang street, Baoan District, Shenzhen. 2.4GHz 1608 Chip Antenna: RANT1608F245C01 _ 1 EvaluationBoardReference PCBDimensionAntennaLayoutReference Unit:mm ElectricalCharacteristics ReturnLoss&Radiation ELECTRICALCHARACTERISTICSS11 Radiation ElectricalCharacteristics Freque ncy EfficPercenGain 2400-1.6472.27%2.38 2450-1.3375.34%2.7 2500-1.5972.98%2.59 Add:Room 707, Building F, Tongan Zhichuangyuan, xixiang street, Baoan District, Shenzhen. 2.4GHz 1608 Chip Antenna: RANT1608F245C01 _ TapingSpecifications ReelandTapingSpecification ReelSpecification TYPESIZEABCD 16087”4K/Reel 4.0±0.5 4.0±213.5±0.5178±2 TappingSpecification PackagingTypeABWEFGHTψDP PaperType1608 1.90±0.203.50±0.208.0±0.201.75±0.103.5±0.054.0±0.102.0±0.050.75±0.10 1.50±0.10 4.0±0.1 Add:Room 707, Building F, Tongan Zhichuangyuan, xixiang street, Baoan District, Shenzhen. _ 2.4GHz 1608 Chip Antenna: RANT1608F245C01 Reliability Table TestItemProcedure Requirements CeramicType Remark (Reference) Electrical Characterization Fulfilltheelectrical specification UserSpec. Thermal Shock 1.Preconditioning: 50±10°C/1hr,thenkeepfor24±1hrsatroomtemp. 2.Initialmeasure:Spec:referInitialspec. 3.Rapidchangeoftemperaturetest: -30°Cto+85°C;100cycles; 15minutesatLowercategorytemperature; 15minutesatUppercategorytemperature. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 107 Temperature Cycling 1.Initialmeasure:Spec:referInitialspec. 2.100Cycles(-30°Cto+85°C),SoakMode=1(2Cycle/hours). 3.Measurementat24±2Hoursaftertestcondition. NoVisibleDamage. Fulfilltheelectrical specification. JESD22 JA104 HighTemperature Exposure 1.Initialmeasure:Spec:referInitialspec. 2.Unpowered;500hours@T=+85°C. 3.Measurementat24±2hoursaftertest. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 108 LowTemperature Storage 1.Initialmeasure:Spec:referInitialspec. 2.Unpowered:500hours@T=-30°C. 3.Measurementat24±2hoursaftertest. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 108 Solderability (SMDBottomSide) Dippingmethod: a.Temperature:235±5°C b.Dippingtime:3±0.5s Thesoldershouldcover over95%ofthecritical areaofbottomside. IEC60384-21/22 4.10 SolderingHeat Resistance (RSH) Preheatingtemperature:150±10°C. Preheatingtime:1~2min. Soldertemperature:260±5°C. Dippingtime:5±0.5s NoVisibleDamage.IEC60384-21/22 4.10 Vibration5g'sfor20min.,12cycleseachof3orientations Note:Use8"X5"PCB.031"thick7securepointson,onelong sideand2securepointsatcornersofoppositesides.Parts mountedwithin2"fromanysecurepoint.Testfrom10-2000 Hz. NoVisibleDamage.MIL-STD-202 Method204 Mechanical Shock Threeshocksineachdirectionshallbeappliedalongthethree mutuallyperpendicularaxesofthetestspecimen(18shocks) Peakvalue:1,500g’s Duration:0.5ms Velocitychange:15.4ft/s Waveform:Half-sine NoVisibleDamage.MIL-STD-202 Method213 Humidity Bias 1.Humidity:85%R.H.,Temperature:85±2°C. 2.Time:500±24hours. 3.Measurementat24±2hrsaftertestcondition. NoVisibleDamage. Fulfilltheelectrical specification. MIL-STD-202 Method106 Add:Room 707, Building F, Tongan Zhichuangyuan, xixiang street, Baoan District, Shenzhen. 2.4GHz 3216 Chip Antenna: RANT1608F245C01 _ Board Flex (SMD) 1.Mountingmethod: IR-Reflow.PCBSize(L:100×W:40×T:1.6mm) 2.Applytheloadindirectionofthearrowuntilbendingreaches 2mm. NoVisibleDamage.AEC-Q200 005 AdhesionForceof1.8Kgfor60seconds.NoVisibleDamage Magnificationof20Xor greatermaybeemployed forinspectionofthe mechanicalintegrityofthe devicebodyterminalsand body/terminaljunction. AEC-Q200 006 Physical Dimension Anyapplicablemethodusingx10magnification,micrometers, calipers,gauges,contourprojectors,orothermeasuring equipment,capableofdeterminingtheactualspecimen dimensions. Inaccordancewith specification. JESD22 JB100 RevisionHistory RevisionDateContent 12019/03/01NewDatasheet 22020/02/22Add2Dradiationcharacteristic Add:Room 707, Building F, Tongan Zhichuangyuan, xixiang street, Baoan District, Shenzhen.

Page 1 of 19 Report No.: FCS202411320 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: M10 Pro Photo 1 Photo 2 Page 2 of 19 Report No.: FCS202411320 Photo 3 Photo 4 Page 3 of 19 Report No.: FCS202411320 Photo 5 Photo 6 Page 4 of 19 Report No.: FCS202411320 Photo 7 Photo 8 Page 5 of 19 Report No.: FCS202411320 Photo 9 Photo 10

Label Size: 20mm * 5mm The label is silk-screen on the sample FCC ID: 2BEHS-LV-M10PRO

Page 1 of 16 Report No.: FCS202411320 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: M10 Pro Photo 1 Photo 2 Page 2 of 16 Report No.: FCS202411320 Photo 3 Photo 4 BT Antenna Page 3 of 16 Report No.: FCS202411320 Photo 5 Photo 6 Page 4 of 16 Report No.: FCS202411320 Photo 7

FCC Test Report Report No: FCS202411320H01 Issued for Applicant: ShenZhen LVTEL Communication Equipment Co.,Ltd Address: 2105A 2105, 21st Floor, Building 1, Yagang Industry and Trade Building, No. 18 Fu'an Avenue Pinghu Street, Longgang District, Shenzhen, China Product Name: Bluetooth glasses Brand Name: N/A Model Name: M10 Pro Series Model: M10 Pro A, M10 Pro B, M10 Pro C, M10 Pro D, M7 Pro, M11 Pro, M12 Pro, M20 Pro, M30 Pro FCC ID: 2BEHS-LV-M10PRO Test Standard: FCC 47CFR §2.1093 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Page 2 of 8 Report No.: FCS202411320H01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com TEST RESULT CERTIFICATION Applicant’s Name ................... : ShenZhen LVTEL Communication Equipment Co.,Ltd Address ................................. : 2105A 2105, 21st Floor, Building 1, Yagang Industry and Trade Building, No. 18 Fu'an Avenue Pinghu Street, Longgang District, Shenzhen, China Manufacture's Name .............. : ShenZhen LVTEL Communication Equipment Co.,Ltd Address ................................. : 2105A 2105, 21st Floor, Building 1, Yagang Industry and Trade Building, No. 18 Fu'an Avenue Pinghu Street, Longgang District, Shenzhen, China Product Description Product Name ....................... : Bluetooth glasses Brand Name .......................... : N/A Model Name .......................... : M10 Pro Series Model ......................... : M10 Pro A, M10 Pro B, M10 Pro C, M10 Pro D, M7 Pro, M11 Pro, M12 Pro, M20 Pro, M30 Pro Test Standards ...................... : FCC 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 This device described above has been tested by Flux Compliance Service Laboratory, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of Flux Compliance Service Laboratory, this document may be altered or revised by Flux Compliance Service Laboratory, personal only, and shall be noted in the revision of the document. Date of Test ............................... : Date (s) of performance of tests . : Nov. 11, 2024 ~ Nov. 24, 2024 Date of Issue .............................. : Nov. 24, 2024 Test Result ................................. : Pass Tested by : (Scott Shen) Reviewed by : (Duke Qian) Approved by : (Jack Wang) Page 3 of 8 Report No.: FCS202411320H01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1093 REQUIREMENT 7 2.1 TEST STANDARDS 7 2.2 LIMIT 7 2.3 TEST RESULT 8 Page 4 of 8 Report No.: FCS202411320H01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Revision History Rev. Issue Date Contents 00 Nov. 24, 2024 Initial Issue Page 5 of 8 Report No.: FCS202411320H01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Bluetooth glasses Brand N/A Model Number M10 Pro Series Model(s) M10 Pro A, M10 Pro B, M10 Pro C, M10 Pro D, M7 Pro, M11 Pro, M12 Pro, M20 Pro, M30 Pro Model Difference Only different of model name and appearance. Product Description The EUT is Bluetooth glasses Operation Frequency: BT: 2402~2480MHz Modulation Type: GFSK, π/4-DQPSK, 8DPSK Antenna gain: BT: 2.7 dBi Antenna Designation: Chip Antenna Power Supply Input: DC 5V Battery Rated Voltage: DC 3.7V Capacity: 55mAh * 2 Hardware Version V01 Software Version V01 Page 6 of 8 Report No.: FCS202411320H01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com 1.2 TEST FACTORY Company Name: Flux Compliance Service Laboratory Address: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Telephone: +86-769-27280901 Fax: +86-769-27280901 FCC Test Firm Registration Number: 514908 Designation number: CN0127 A2LA accreditation number：5545.01 ISED Number：25801 CAB ID ：CN0097 Page 7 of 8 Report No.: FCS202411320H01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 D01v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2.2 LIMIT According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulat…
