便携式智能一体机（简称一体机）-用户指南 Ai Dual Camera Device (Referred to as All-in-One Machine) - User Guide ⚫ 直播间搭建、一体机使用说明、直播参数设置等基础内容说明 ⚫ Explanation of basic content such as live streaming room construction,all-in-one machine usage instructions, live streaming parameter settings, etc ⚫ 本手册及其内容仅用于操作和使用本产品，不得用作其他用途。 ⚫ This manual and its contents are only for the operation and use of this product and cannot be used for any other purposes. 一、直播前准备 Preparation before live streaming ⚫ 室内常规直播间搭建 Indoor routine live streaming room construction ⚫ 针对室内场景下各实景电商直播的直播间解决方案，一体机处于直播间下需与各补光灯保持及把控 最佳合适位置和亮度，我们调研分类，一般 2 颗补光灯和 4 颗补光灯可分别覆盖不同 面积大小的 室内实景直播间搭建方案。 ⚫ For live streaming room solutions for various real-life e-commerce live streaming in indoor scenes, the all-in-one machine is located in the live streaming room and needs to be maintained and controlled for the best suitable position and brightness with each fill light. We conducted research and classification, and generally, two fill lights and four fill lights can cover different sizes of indoor real-life live streaming room construction plans. ⚫ 2 颗补光灯直播间搭建解决方案，如下图： ⚫ The solution for building a live streaming room with 2 fill lights is shown in the following figure: ⚫ 4 颗补光灯直播间搭建解决方案，如下图： ⚫ The solution for building a live streaming room with 4 fill lights is shown in the following figure: ⚫ 室内常规直播间搭建的设备说明 ⚫ Equipment Description for Building Indoor Regular Live Streaming Rooms 设备 Equipment 规格 Specifications 说明 Illustration 备注 Notes 便携式智能一体 机 Ai Dual Camera Device 6.36 寸 OLED 高清显示屏/内 置 麦 克 风 和 扬 声 器 / 内 置 10020mAH 电池/双摄 /直播/Vlog 便携式智能一体机 6.36-inch OLED high-definition display screen/built-in microphone and speaker/built-in 10020mAH battery/dual camera/live streaming/ Vlog Ai Dual Camera Device 可定制版本 Customizable version 标配（含机身保 护膜） Standard configuration (including body protective film) 数据线 Data cable Type-C 数据线 /USB2.0/3A/1.5 米白色 Type-C data cable/USB2.0/3A/1.5 meters white 标配 Standard configuration 说明书 Instructions 纸质档产品说 明书 Paper Instructions 标配 Standard configuration BT 蓝牙戒指 BT Bluetooth Ring 蓝牙切换戒指 Bluetooth switching ring 相机模式切换 Camera mode switching 选配 Optional 相机三脚架 Camera tripod 三脚架可伸缩高度 160左右 The tripod has a stretchable height of about 160cm 固定一体机 Fixed the all-in-one machine 选配 Optional 直播补光灯 Live broadcast fill light 专业直播补光灯 Professional live streaming fill light 含三脚架 Including tripod 选配 Optional 灯罩 Shade 顶灯 Overhead light WiFi 随身带 WiFi portable 5G WiFi 随身带设备 5G WiFi portable device 选配 Optional type-c+3.5mm 声卡 转接 hub Type-C+3.5mm sound card adapter hub Type-c 转接头耳机声卡直 播一号游戏充电二合一双 type-c 转换器手机连麦 Type-C adapter, headphone, sound card, live streaming, game charging, 2-in-1, dual Type-C converter, and microphone connection 可选 Optional 选配 Optional ⚫ * 以上标配产品为标准出货设备，选配产品均为第三方适配设备，涉及各项功能及规格等均为参考 建议，请根据实际直播需求选择设备或增加设备等。 ⚫ * The above standard configuration products are standard shipping equipment, and the optional products are all third-party adaptive devices. The various functions and specifications involved are reference suggestions. Please choose devices or add devices according to actual live streaming needs. 二、一体机使用说明 Instructions for using the all-in-one machine ⚫ 开箱清单（塑封袋全封包装盒） ⚫ Unpacking list (plastic sealed bags with fully sealed packaging Box） ⚫ 开机即开播，操作简单，手机操作逻辑 ⚫ Start broadcasting immediately upon startup, simple operation, and logical phone operation ⚫ 长按 “ 电源按键 ” 进行开/关机，首次开机后请配置有效的无线连接，WiFi 连接成功后即 可 进入一体机正常直播使用状态。 ⚫ Hold the "power button" to turn on/off the device. After the first power on, please configure a valid wireless connection. Once the WiFi connection is successful, the all-in-one machine can enter normal live streaming usage. ⚫ 一体机与配件产品的连接说明 ⚫ Connection instructions for all-in-one machine and accessory products ⚫ 1、一体机开机后，可与 BT 蓝牙戒指配件进行蓝牙连接，连接成功后，蓝牙戒指可正常远程 控 制一体机，最佳方便了一体机直播过程中的相关功能操作的便捷性。 ⚫ After the all-in-one machine is turned on, it can be connected to the BT Bluetooth ring accessory via Bluetooth. After a successful connection, the Bluetooth ring can remotely control the all-in-one machine, providing the best convenience for the operation of related functions during the live streaming process of the all-in-one machine. ⚫ 2、在无 WiFi 环境下，一体机开机后，可与 WiFi 随身带配件产品进行 WiFi 无线连接，保 障 了在没有无线网络的室内、外环境下可正常最佳使用一体机直播。 ⚫ In a WiFi free environment, after the all-in-one machine is turned on, it can be wirelessly connected to the WiFi portable accessory products, ensuring the normal and optimal use of the all-in-one machine for live streaming in indoor and outdoor environments without wireless networks. ⚫ 3、直播间下主播的顶灯及主、辅补光灯均可单独独立使用，尽可能使用与一体机已兼容的 补光 灯。 ⚫ The overhead light, main and auxiliary fill lights of the host in the live streaming room can be used independently. Try to use fill lights that are compatible with the all-in-one machine as much as possible. ⚫ 4、一体机的充电线材请使用出厂标配的数据充电线。 ⚫ Please use the factory standard data cable for the all-in-one machine's charging cable. 三、一体机直播参数设置 Live streaming parameter settings for all-in-one machines 一体机开播前可提前对直播效果的一些参数设置，相关所有参数设置主要通过一体机的自 研 的“直播助手 ”应用来完成。 Before the all-in-one machine starts broadcasting, some parameters of the live streaming effect can be set in advance. All related parameter settings are mainly completed through the self-developed "Live Assistant" application of the all-in-one machine. ⚫ “直播助手”应用主页 ⚫ “Live Assistant”application homepage ⚫ 主页下可对直播前或直播进行时的相机影像模式、直播主题、直播各状态等常规设置。 ⚫ In the homepage, you can set the camera image mode, live streaming theme, and various states of the live streaming before or during the live streaming. ⚫ ⚫ ⚫ ⚫ Parameters Settings ⚫ 参数下 4 种相机输出模式（主摄模式、特写模式、画中画模式、 上下分屏模式）是直播过程中常用设置，更是一体机的独特特 性。 ⚫ The four camera output modes under the parameters (main camera mode, close-up mode, picture in picture mode, and up and down split screen mode) are commonly used settings during live streaming and are unique features of all-in-one cameras. Parameter settings Camera mode Switch main camera Live streaming theme Live streaming sales AWB lock Manual color calibration…
