FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2BEP8-A4 Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna,R=20cm Test Result of RF Exposure Evaluation 2.4GWIFI+5GWIFI supported simultaneous transmission: 2.4GWIFI+5GWIFI MIMO : ∑MPE Ratio =0.0072+0.0170=0.0242≤1, So passed. Modes& Channel Freq. (MHz) Tune up Produce power Maximu m peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW / cm2 ) Result 2.4GWIFI 802.11n20 &2412 13±1 14 39.8107 1.4421 (1.59dBi) 0.0072 1 Pass 5.2GWIFI 802.11n20 &5240 14±1 15 31.6228 2.6977 (4.31dBi) 0.0170 1 Pass

ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 1 AntennaApproval Sheet For K803Project CustomerHUAXINZHIYINGProject K803 BandWiFi2.4GHZ/5GHZ ZCPNHA040-CA-93 VersionR:AData2024-8-2 RFME CheckedBy ConfirmedBy CustConfirm ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 2 1.Manufacturer information Company name：Shenzhen Zhongcheng communication products Co., Ltd Address: 5th floor, building C, Huafeng Industrial Zone, Liuxian Road, 71 District, Bao'an, Shenzhen 2. Summary of the DUT K803 Pict ure Antenna Picture 3. Electrical Specification: Antenna typesBuilt-in WIFI Antenna Frequency2400-2500 MHz,5150-5350MHZ，5725-5850MHz Impedance 50 Ω VSWR< 2.0 Gain2.4GHZ 1.73dbi, 5.1GHZ 4.31dbi, 5.8GHZ 4.45dbi Antenna Material FPCB+CoaxialCable Connector Type0.81 MHF-2-Plug ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 3 4. Test Condition 4.1TEST ITEMTESTING INSTRUMENTREMARKS PASSIVE TEST 1.RadiationPattern 2.AntennaGain 3.ReturnLoss 4.S.W.R 1.SatimoSG24(3D) 2.Agilent8960E5515C 3.R&SZVL6 4.2Antenna installation diagram: 5. RFPerformance 5.1 Passive parameters Freq.(MHz)24002410242024302440245024602470248024902500 Gain(dBi)0.580.661.11.021.171.590.720.080.721.191.73 Freq.(MHz)51505170519052105230525052705290531053305350 Gain(dBi) 3.133.453.564.114.314.214.13.823.283.193.04 Freq.(MHz)572057405760578058005820584058605880 Gain(dBi)2.514.453.324.182.544.011.412.471.09 5.2 S Parameter Frequency (MHz)240024502480 Return Loss(dB)-20.58-22.74-15.39 VSWR1.631.281.81 ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 4 5.3 Radiation Gain:0.58(dBi) Gain:1.59(dBi) Gain:1.73(dBi) ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 5 Gain:3.13(dBi) Gain:4.31(dBi) Gain:3.04(dBi) ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 6 Gain:2.51(dBi) Gain:4.45(dBi) Gain:2.47(dBi) ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 7 6. ME Drawing for the antenna
