2BEQO-J50SmartWatch

Quick use instructions for watches Component introduction Instruction for Charging Scan the following QR codes or go to the major download and install the APP Install bracelet APP Touch display Charging contact Hear t rate sensor Note: Press and hold t h e button to turn on the watch. “ Dee Fit ” 10.0 5.0 Heart rate interface Switch to the heart rate test interface to enter the heart rate real time Monitoring, measurement data can be synchronized to the APP in time. And have a test report. Stopwatch Click the stopwatch icon to enter the stopwatch function. Swipe right Weather interface The weather interface will display the current weather, Weather information needs to be connected to the app. Can get data, if disconnected for a long time, weather letterThe information will not be updated. Message interface On the main interface, slide into the message interface and click the message icon to view the message.Click to turn the page, view the message to exit or right to exit. Spor ts interface Press the button on the main interface to enter the motion interface, right slide back to the main int erface. Click on the motion map The target can enter the motion mode detection. Running, cycling , skipping, table tennis, badminton,tennis. Press the button on the main interface to enter, slide up and down to switch, click to star t calculation, right slide to exit the current Spor ts mode. Setting function interface In the main interface, slide down to enter the setting function interface, you can choose "Find phone" "Brightness adjustment" "About" "Settings"Item. Click the icon to enter the corresponding function settings. (4) buongiorno, vi ringrazio per aver scelto il nostro smart health wind, per facilitare l’uso di questo dispositivo la prima volta, leggete attentamente le istruzioni per l’uso e le istruzioni per l’uso. FCC Statement Changes or modifications not expressly approved by the party responsiblefor compliance could void the user's authority to operate the equipment.T-his equipment has been tested and found to comply with the limits for a Cla-ss B digital device, pursuant to Part 15 of the FCc Rules. These limits aredesigned to provide reasonable protection against harmful interferenceina residentialinstallation, This equipment generates uses and can radiateradio frequency energy and, ifnot installed and used in accordance with theinstruc- tions, may cause harmful interference to radio communications. Ho-wever, there is no guarantee that interlerence will not occur in a particularinstallation.lf this equipment does cause harmful interference to radio ortelevision reception,which can be determined by turning the equipment offand on, the user is encouraged to try to correct the interference by one ormore of the following measures:--Reorient or relocate the receiving antenna...increase the separation between the equipment and receiver.--Connect the equipment into an outlet on a circuit different from that towhich thereceiveris connected.--Consult the dealer or an experienced radio/TV technician for helpThis device complles with part 15 of the F©C rules,Operatlon is subject tothe following two conditions (1jthis device may not cause harmful interference, and (2) this device must accept any interference recelved,includinginterference that may cause undesired operation. IC Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. The term “IC: “ before the certification/registration number only signifies that the Industry Canada technical specifications were met. This product meets the applicable Industry Canada technical specifications. Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont conformes aux normes CNR exemptes de licence d’Innovation, Sciences et Développement économique Canada. Son fonctionnement est assujetti aux deux conditions suivantes : (1) Cet appareil ne doit pas causer d’interférences. (2) Cet appareil doit accepter toute interférence, y compris celles qui peuvent entraîner un fonctionnement indésirable de l’appareil. Per controllare il numero di passi compiuti durante la giornata, la distanza di percorso e le calorie usate, potete sincronizzarle con l’app e visualizzare i dati di movimento: Requisiti delle apparecchiature: 10.0 e più; Android 5.0 e più, suppl. Bluetooth 5.2. Accendete il vostro telefono cellulare e create i vostri dati personali Clicca il vostro dispositivo sulla lista delle apparecchiature che avete scannerizzato Adozione da parte del consiglio «affari generali» in data 19 dicembre. Passare alla pagina «dispositivo» cliccando sul dispositivo legante Il primo impiego di un apparecchio di controllo richiede l’attivazione di caricamento, con un caricatore magnetoas- sorbitore munito di dispositivi di assorbimen- to, che si adsorbisce al punto metallico della superficie dell’orologio, mentre il caricatore si collega a una testa di caricamento USB o a un’interfaccia USB al computer. Per ulteriori informazioni, rivolgersi a: commissione europea Alla lunga dell’interfaccia principale entra uno schermo sensibile al tatto, mentre lo scivolamento a destra e a sinistra viene sostituito con quello definitivo. Il quadrante ha 7 stili. Tocca lo schermo Nota: la macchina può essere smontata sulla base di un orologio sincrono laterale Punti di contatto per le imposte Sensori del battito cardiaco Istruzioni per l’uso rapido degli orologi Principali interfacce funzionali osservazioni domande e risposte Montaggio di un orologio Introduzione dei componenti Caricamento e attivazione degli orologi Misura passo/distanza/calorie Scivolando sull’interfaccia principale per accedere al messaggio cliccando sulle icone del messaggio, c…

Text truncated - open the document above for the full version.

2.911 (d)(5)(i) Equipment Type Attestation v1.2 SHENZHEN HAOCHENG TECHNOLOGY CO., LTD Section 2.9 11(d)(5)(i) Certification – EquipmentType Company name: SHENZHEN HAOCHENG TECHNOLOGY CO., LTD Address: 501, Main Building, Qiaocheng No.1 Plaza, No.2 shenyun Road, Gaofa Community, Shahe Street, Nanshan District, Shenzhen cit y, 518000 China Product Name: SmartWatch FCC ID: 2BEQO-J50 Model(s): J50 2.911(d)(5)(i) EquipmentType We, [SHENZHEN HAOCHENG TECHNOLOGY CO., LTD] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Charles Zha Date: 2024-09-04 Title and Company name: Manager / SHENZHEN HAOCHENG TECHNOLOGY CO., LTD NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

2.911 (d)(5)(ii) Applicant Attestation v1.3 SHENZHEN HAOCHENG TECHNOLOGY CO., LTD Section 2.9 11(d)(5)(ii) Certification – Applicant (Covered Lis t) Company name: SHENZHEN HAOCHENG TECHNOLOGY CO., LTD Address: 501, Main Building, Qiaocheng No.1 Plaza, No.2 shenyun Road, Gaofa Community, Shahe Street, Nanshan District, Shenzhen cit y, 518000 China Product Name: SmartWatch FCC ID: 2BEQO-J50 Model(s): J50 2.911(d)(5)(ii) Applicant filing We, [SHENZHEN HAOCHENG TECHNOLOGY CO., LTD] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours sincerely, Name: Charles ZhaDate: 2024-09-04 Title and Company name: Manager / SHENZHEN HAOCHENG TECHNOLOGY CO., LTD NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com SHENZHENHAOCHENGTECHNOLOGYCO.,LTD 2.911(d)(5)(ii)ApplicantAttestationv1.3 munications-supply-chain-through-the

SHENZHEN HAOCHENG TECHNOLOGY CO., LTD U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (Baihetian Innovative Solutions) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Sept 4, 2024 Signed by (Printed Name/Title): Kenneth Young The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: SHENZHEN HAOCHENG TECHNOLOGY CO., LTD FRN: 0034797076 Grantee Code: 2BEQO Contact Name: Charles Zha Street Address: 501, Main Building, Qiaocheng No.1 Plaza, No.2 shenyun Road, Gaofa Community, Shahe Street, Nanshan District City/Province/Zip: Shenzhen city, 518000 China Telephone No: 860755-83435131 Email: [email protected] Applicant Signature: Date:2024-09-04 Signed by (Printed Name/Title): Charles Zha / Manager FCC ID: 2BEQO-J50 Sept 2024

SHENZHEN HAOCHENG TECHNOLOGY CO., LTD Date: 2024.09.04 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject; Request for Long Term Confidentiality FCC ID: 2BEQO-J50 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Charles Zha Title: Manager

SHENZHEN HAOCHENG TECHNOLOGY CO.,LTD Agent Authorization Company: SHENZHEN HAOCHENG TECHNOLOGY CO.,LTD Address: 501, Main Building, Qiaocheng No.1 Plaza, No.2 shenyun Road, Gaofa Community, Shahe Street, Nanshan District Shenzhen city 518000 China Product Name: SmartWatch Model Number(s): J50 Product Description: SmartWatch We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature:Date: 2024-09-04 Name:Charles Zha Title:Manager Company:SHENZHEN HAOCHENG TECHNOLOGY CO.,LTD

Page 1 of 5 Appendix C: Photographs of EUT P Product: SmartWatch Model: J50 External Photos Page 2 of 5 Page 3 of 5 Page 4 of 5 Page 5 of 5

Label Artwork and Location Model: J50 Label: Step1, Click to Settings Step2, Click to About Step3, Click to Label

Page 1 of 4 Appendix C: Photographs of EUT Product: SmartWatch Model: J50 Internal Photos Antenna Page 2 of 4 Page 3 of 4 Page 4 of 4

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2BEQO-J50 Test Report No. ............... : TCT240822E035 Date of issue ................... : Aug. 28, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : SHENZHEN HAOCHENG TECHNOLOGY CO., LTD Address ........................... : 501, Main Building, Qiaocheng No.1 Plaza, No.2 shenyun Road, Gaofa Community, Shahe Street, Nanshan District, Shenzhen city, 518000 China Manufacturer's name ... : SHENZHEN HAOCHENG TECHNOLOGY CO., LTD Address ........................... : 501, Main Building, Qiaocheng No.1 Plaza, No.2 shenyun Road, Gaofa Community, Shahe Street, Nanshan District, Shenzhen city, 518000 China Standard(s) ..................... : KDB 447498 D01 General RF Exposure Guidance v06 Product Name ................. : SmartWatch Trade Mark ...................... : N/A Model/Type reference..... : J50 Rating(s).......................... : Rechargeable Li-ion Battery DC 3.7V Date of receipt of test item ......................................... : Aug. 22, 2024 Date (s) of performance of test ................................... : Aug. 22, 2024 ~ Aug. 28, 2024 Tested by (+signature) ... : Yannie ZHONG Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240822E035 Page 2 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 Report No.: TCT240822E035 Page 3 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : SmartWatch Model/Type reference........... : J50 Sample Number....................: TCT240822E012-0101 Operation Frequency ........... : 2402MHz~2480MHz Modulation Type ................... : For BT: GFSK, π/4-DQPSK For BLE: GFSK Antenna Type ........................ : Internal Antenna Antenna Gain ........................ : -2.42dBi Rating(s)................................ : Rechargeable Li-ion Battery DC 3.7V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. Report No.: TCT240822E035 Page 4 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage DC 3.7V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port of EUT, and the temporary antenna connector is listed in the Test Instruments. Report No.: TCT240822E035 Page 5 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, certified, or accredited by the following organizations: ● FCC - Registration No.: 645098 SHENZHEN TONGCE TESTING LAB Designation Number: CN1205 The testing lab has been registered and fully described in a report with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. ● IC - Registration No.: 10668A SHENZHEN TONGCE TESTING LAB CAB identifier: CN0031 The testing lab has been registered by Innovation, Science and Economic Development Canada for radio equipment test…

Text truncated - open the document above for the full version.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 31964-J50 Test Report No. ............... : TCT240822E013 Date of issue ................... : Jul. 29, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen Haocheng Technology Co., Ltd Address ........................... : 501, Main Building, Qiaocheng No.1 Plaza, No.2 shenyun Road, Gaofa Community, Shahe Street, Nanshan District, Shenzhen city, 518000 China Manufacturer's name ... : Shenzhen Haocheng Technology Co., Ltd Address ........................... : 501, Main Building, Qiaocheng No.1 Plaza, No.2 shenyun Road, Gaofa Community, Shahe Street, Nanshan District, Shenzhen city, 518000 China Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 Product Name ................. : SmartWatch Trade Mark ...................... : N/A Model/Type reference..... : J50 Rating(s).......................... : Rechargeable Li-ion Battery DC 3.7V Date of receipt of test item ......................................... : Aug. 22, 2024 Date (s) of performance of test ................................... : Aug. 22, 2024 ~ Aug. 28, 2024 Tested by (+signature) ... : Yannie ZHONG Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240822E013 Page 2 of 56 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 1.3. Operation Frequency ............................................................................................ 3 2. Test Result Summary .............................................................................. 4 3. General Information ................................................................................. 5 3.1. Test environment and mode ................................................................................. 5 3.2. Description of Support Units ................................................................................ 5 4. Facilities and Accreditations .................................................................. 6 4.1. Facilities ................................................................................................................. 6 4.2. Location ................................................................................................................. 6 4.3. Measurement Uncertainty ..................................................................................... 6 5. Test Results and Measurement Data ..................................................... 7 5.1. Antenna requirement ............................................................................................ 7 5.2. Conducted Emission ............................................................................................. 8 5.3. Conducted Output Power ................................................................................... 12 5.4. Emission Bandwidth ........................................................................................... 13 5.5. Power Spectral Density ....................................................................................... 14 5.6. Conducted Band Edge and Spurious Emission Measurement ....................... 15 5.7. Radiated Spurious Emission Measurement ...................................................... 17 Appendix A: Test Result of Conducted Test Appendix B: Photographs of Test Setup Appendix C: Photographs of EUT Report No.: TCT240822E013 Page 3 of 56 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : SmartWatch Model/Type reference........... : J50 Sample Number....................: TCT240822E012-0101 Bluetooth Version ................ : V5.2 (This report is for BLE) Operation Frequency ........... : 2402MHz~2480MHz Channel Separation ............. : 2MHz Data Rate............................... : LE 1M PHY, LE 2M PHY Number of Channel .............. : 40 Modulation Type ................... : GFSK Antenna Type ........................ : Internal Antenna Antenna Gain ........................ : -2.42dBi Rating(s)................................ : Rechargeable Li-ion Battery DC 3.7V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. 1.3. Operation Frequency Channel Frequency Channel Frequency Channel Frequency Channel Frequency 0 2402MHz 10 2422MHz 20 2442MHz 30 2462MHz 1 2404MHz 11 2424MHz 21 2444MHz 31 2464MHz ... ... ... ... ... ... ... ... 8 2418MHz 18 2438MHz 28 2458MHz 38 2478MHz 9 2420MHz 19 2440MHz 29 2460MHz 39 2480MHz Remark: Channel 0, 19 & 39 have been tested. Report No.: TCT240822E013 Page 4 of 56 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15…

Text truncated - open the document above for the full version.

ANWEIcommnuicationEquipmentCo.,Ltd APPROVALSHEET CustomerSpecs JL998 PartNumber AW006-JL998-021-A0 FrequencyBand 2.4GBT Color Black Edition REV:A0 Salesperson Zhangxu Design Huanghe Structure QINYUNLIN Confirm Date 2024/8/21 SigningDate Customerconfirmation: ANTManufacturers： ANWEIcommnuicationEquipmentCo.,Ltd Address:2ndFloor,EastBlock,Building5,YifenghuaInnovationIndustrialPark,HuaningRoad,DalangStreet,Longhua District,ShenzhenCity,GuangdongProvince Projectdevelopmentenvironment  （BTantenna）+（2.4G/BTantenna） （WorkingfrequencybandofBTantenna）：2400~2500 (Antennagain&Gain&Efficiency) BTantenna3D BTantenna2D TheEnd

Page 1 of 2 Appendix B: Photographs of Test Setup Product: SmartWatch Model: J50 Radiated Emission Page 2 of 2 Conducted Emission
