2BEWXSC305BSmart Camera

Zhejiang Lingzhu Technology Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 18, 2026
Application Purpose: Original Equipment
Equipment Note: Smart Camera
Frequency Range: 2402.00000000 - 2480.00000000
Company: Zhejiang Lingzhu Technology Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

图纸发布类别正式归档图纸版本 1.0 家用防水卡片机家用防水卡片机-中性海外版-说明书原始版本物料编号变更者变更时间版本升级原因描述 SC305-WBQ4B 中性风琴8折页，正反印刷 / 四色印刷 105g铜版纸子柳（徐涛）大川接合方式印刷色材质加工工艺 75*75mm 75x525mm 成品尺寸单位：mm 公差：展开图尺寸： ±1mm xxx-xxxx-xxxx What’s in the Box Thank you for purchasing Smart Camera. Get started using your new devices by downloading Smart Life, one convenient app that manages everything straight from your phone. Easily connect to your home Wi-Fi and control multiple devices from the touch of your fingertips *: Different products have different accessories, please refer to physical packing. Smart Camera ×1 USB Cable ×1 User Manual ×1 Mounting Bracket ×1 * Adapter ×1 * Screw bag ×1 * Please read the instruction manual carefully before using the product SMART CAMERA USER MANUAL Frequently Asked Questions Yes, you can share your cameras with family and friends who will have access to view the camera and control your bulbs, plugs, and other devices. In the app, press the Profile button and click on the “Home Management” button, and you will be able to give or revoke sharing permissions. In order to share, the other user should already have downloaded the app and registered a new account. Can I share with family and friends? 1 • Make sure the device is under the config status (indicator light is flashing quickly) • Make sure the Wi-Fi is available and not too far away from router • Make sure the Wi-Fi password you input is correct 3. 4. Align the bottom of the camera’s main body, and aim to the right angle. Then rotate and snap it into the base until it is completely fixed. Use the USB cable to connect the camera and the adapter, then connect the socket to power the camera, and see the camera indicator light on. English Warning Statement: “This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device." French Warning Statement: “Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement." Open “Smart Life” APP, Turn on the Bluetooth on your mobile phone, and grant the corresponding permission to the “Smart Life” APP. Click the “Add” button. Wait for the camera to automatically complete Enter Wi-Fi name and password, then click the “Next”(Camera support 2.4GHz or 5GHz). network configuration. If the dialog box does not pop up,you can click the “+” icon or “Add Device” button on the home page, and the camera will be searched, then click the “Add”. 1. 2. Take out all accessories and arrange them in order Refer to th bracket size,drill three holes on the installation area,such as the wall, ceiling etc., Fixed the mounting bracket on the installation area,Drive in three expansion screws in sequence to fully secure the base. My device can't be connected to network with App 4 Installation instructions 6 • Make sure the device is powered on • Make sure the network is stable and the Wi-Fi name and password not modified. If not, add device again. • If the network is normal, but it's still offline. Check if there are too many Wi-Fi connections. You can restart your router to check the status of the device. My device shows offline in my App 5 The range of your home Wi-Fi is heavily dependent on your home router and the conditions of the room. Check with your router specifications for exact range data. What’s the Wireless Range? 2 Smart Life app can control an unlimited amount of devices in an unlimited amount of locations. Your router may have a limit of how many devices can be connected to one router. How many cameras can I control? 3 Technical Specifications • Audio: Internal Speaker and Microphone • Storage: supports up to 128G Micro SD card (not included) • Power: General 5V Direct Current 1A • Wi-Fi: IEEE 802.11 b/g/n, 2.4GHz(compatible with 5GHz Wi-Fi networks) symbol “ ” means direct current • It is recommended that the camera only be used indoor. • Operating temperature -2050Operating humidity ≤95% • Frequency Range: 2.412-2.462GHz (US)2.412~2.472GHz (EU) warning Federal Communications Commission (FCC) Declaration of Conformity FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experien…

Text truncated - open the document above for the full version.

Attestation Statements

Zhejiang Lingzhu Technology Co., Ltd. 2026/02/24 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2BEWXSC305B [Zhejiang Lingzhu Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Name: Linyun Li / Manager Zhejiang Lingzhu Technology Co., Ltd. 2026/02/24 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2BEWXSC305B [Zhejiang Lingzhu Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Name: Linyun Li / Manager

Attestation Statements

Declaration on model difference We The main model and subsequent models tested in this test differ only in naming and color. All other aspects, including materials, other manufacturing processes, circuit design, and manufacturers, are exactly the same. We finally decided on the SC305-WBQ4B as the test model. FCCID: 2BEWXSC305B Production name Trade name Model no. Smart Camera N/A SC305-WBQ4B,SC305-WBQ4B-V1,SC305- WBQ4C-V1,SC305-WBQ4D-V1,SC305-WBQ4E- V1,SC305-WBQ4F-V1,SC305-WBQ4G-V1 Signature: Date: 2026/02/24 Name: Linyun Li Title: Manager Company: Zhejiang Lingzhu Technology Co., Ltd.

Cover Letter(s)

Zhejiang Lingzhu Technology Co., Ltd. 2026/02/24 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR Product Name: Smart Camera FCCID: 2BEWXSC305B Model(s): SC305-WBQ4B,SC305-WBQ4B-V1,SC305-WBQ4C-V1,SC305-WBQ4D- V1,SC305-WBQ4E-V1,SC305-WBQ4F-V1,SC305-WBQ4G-V1 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Linyun Li / Manager Contact information / address: Zhejiang Lingzhu Technology Co., Ltd. / Room 302,No 1 Building Huace Center,Xihu District, Hangzhou,China

Cover Letter(s)

Zhejiang Lingzhu Technology Co., Ltd. 2026/02/24 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION Product Name: Smart Camera FCCID: 2BEWXSC305B Model(s): SC305-WBQ4B,SC305-WBQ4B-V1,SC305-WBQ4C-V1,SC305-WBQ4D- V1,SC305-WBQ4E-V1,SC305-WBQ4F-V1,SC305-WBQ4G-V1 To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen STS Test Services Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Linyun Li / Manager Contact information / address: Zhejiang Lingzhu Technology Co., Ltd. / Room 302,No 1 Building Huace Center,Xihu District, Hangzhou,China

External Photos

ID Label/Location Info

Label location

Internal Photos

Internal Photos ANT

RF Exposure Info

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.:STS2601313H01 Issued for Zhejiang Lingzhu Technology Co., Ltd. Room 302,No 1 Building Huace Center,Xihu District Hangzhou China 310000 Product Name: Smart Camera Brand Name: N/A Model Name: SC305-WBQ4B Series Model(s): SC305-WBQ4B-V1,SC305-WBQ4C-V1,SC 305-WBQ4D-V1,SC305-WBQ4E-V1,SC30 5-WBQ4F-V1,SC305-WBQ4G-V1 FCC ID: 2BEWXSC305B Test Standard: FCC 47CFR §2.1091 Page 2 of 8 Report No.: STS2601313H01 TEST REPORT Applicant’s Name ................. : Zhejiang Lingzhu Technology Co., Ltd. Address ................................. : Room 302,No 1 Building Huace Center,Xihu District Hangzhou China 310000 Manufacturer's Name ........... : Zhejiang Lingzhu Technology Co., Ltd. Address ................................. : Room 302,No 1 Building Huace Center,Xihu District Hangzhou China 310000 Product Description Product Name ........................ : Smart Camera Brand Name ........................... : N/A Model Name .......................... : SC305-WBQ4B Series Model(s) ...................... : SC305-WBQ4B-V1,SC305-WBQ4C-V1,SC305-WBQ4D-V1,SC305- WBQ4E-V1,SC305-WBQ4F-V1,SC305-WBQ4G-V1 Test Standards ..................... : FCC 47CFR §2.1091 447498 D01 Interim General RF Exposure Guidance v06 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 2025-12-01 Date (s) of performance of tests ........................................................ : 2025-12-01 to 2025-12-31 Date of Issue .......................................... : 2025-12-31 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 8 Report No.: STS2601313H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Page 4 of 8 Report No.: STS2601313H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 2025-12-31 STS2601313H01 ALL Initial Issue Page 5 of 8 Report No.: STS2601313H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Smart Camera Brand Name N/A Model Name SC305-WBQ4B Series Model(s) SC305-WBQ4B-V1,SC305-WBQ4C-V1,SC305-WBQ4D-V1,SC305- WBQ4 E-V1,SC305-WBQ4F-V1,SC305-WBQ4G-V1 Model Difference The main model and subsequent models tested in this test differ only in naming and color. All other aspects, including materials, other manufacturing processes, circuit design, and manufacturers, are exactly the same. We finally decided on the SC305-WBQ4B as the test model. Product Description The EUT is Smart Camera Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: BLE(Support 1M, 2M) Number Of Channel: 40 Antenna Type: Internal antenna Antenna Gain (dBi) 2.23 Operation Frequency: 802.11b/g/n 20: 2412~2462 MHz 802.11n40:2422~2452MHz Modulation Type: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM Bit Rate of Transmitter: 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz): 65/58.5/52/39/26/19.5/13/6.5Mbps 802.11n(40MHz): 135/121.5/108/81/54/40.5/37/13.5Mbps Number of Channel: 802.11b/g/n20: 11CH 802.11n 40: 7CH Antenna Type: Internal antenna Antenna Gain (dBi): 2.23 Operation Frequency: IEEE 802.11a/ n(HT20): 5.180GHz-5.240GHz IEEE 802.11n(HT40): 5.190GHz-5.230GHz IEEE 802.11a/ n(HT20):5.260GHz-5.320GHz IEEE 802.11 n(HT40): 5.270GHz-5.310GHz IEEE 802.11a/ n(HT20):5.500GHz-5.700GHz IEEE 802.11 n(HT40):5.510GHz-5.670GHz IEEE 802.11a/ n(HT20):5.745GHz-5.825GHz IEEE 802.11 n(HT40):5.755GHz-5.795GHz Page 6 of 8 Report No.: STS2601313H01 Modulation Type: 802.11a(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11a Support SISO 802.11n Support SISO Antenna Type: Internal antenna Antenna Gain: 1.85 dBi Power Rating DC 5V/1A Adapter Input: AC 100-240V,50/60Hz,0.25A Output: DC 5V/1000mA, Battery N/A Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 3.0-30 1842/f 4.89/f *(900/f²) 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposu…

Text truncated - open the document above for the full version.

Test Report

R&DCenter：RoomD5 th FloorBuildingL,BlockE,71BaochengDistrict,BaoanDistrict,Shenzhen Factory：6Floor,GangHuaXingIndustrialPark,RongshuRoad2 nd ,Fuyong,Baoan,shenzhen Email:[email protected] ShenzhenSKYLinkTechnologyCo.,Ltd AntennaSpecificationforApproval CustomerName： ProductName：2.4G/5.8GWIFIAntenna PartNO.:TY06 WriteBy：DamonCui IssuedDate:2025.12.09 Customer R&DDeptBusinessDeptApprovedBy SKYLink R&DDeptEngineerDeptApproval R&DCenter：RoomD5 th FloorBuildingL,BlockE,71BaochengDistrict,BaoanDistrict,Shenzhen Factory：6Floor,GangHuaXingIndustrialPark,RongshuRoad2 nd ,Fuyong,Baoan,shenzhen Email:[email protected] SpecificationSummary A.ElectricalCharacteristics Frequency 2400MHz~2500MHz 5150MHz~5850MHz ReturnLoss<-10 Efficiency>50% PeakGain2.3dbi Impedance50Ohm PolarizationLine B.Material&MechanicalCharacteristics MaterialofRadiator/ CableType/ ConnectorType/ DimensionAtAttachment Heat-durability 280±5 ̊C ， 10sec. C.EnvironmentalCharacteristics OperationTemperature-20 ̊C~+80 ̊C StorageTemperature-30 ̊C~+85 ̊C R&DCenter：RoomD5 th FloorBuildingL,BlockE,71BaochengDistrict,BaoanDistrict,Shenzhen Factory：6Floor,GangHuaXingIndustrialPark,RongshuRoad2 nd ,Fuyong,Baoan,shenzhen Email:[email protected]  TestEquipment&Conditions 1．NetworkAnalyzers: Agilent8753D5071B CommunicationsTestSet: AgilentE5515CCMW500 2 ． 3DChamberTestSystem A 0 . 0 3 0 . 0 2 0 . 0 4 0 ～ 1 0 ± 0 . 0 5 1 0 ～ 1 8 ± 0 . 1 0 1 8 ～ 3 0 ± 0 . 1 2 ∅ 0 . 0 2 3 0 ～ 4 0 ± 0 . 1 5 R e m a r k R e v D a t e T h i r d A n g l e N e w d r a w i n g D e s c r i p t i o n 4 0 ～ ± 0 . 2 0 1 2 3 4 A p p r o v e d b y DCB 5 6 7 8 A 1 2 3 4 5 6 7 8 P a r t N o . D a t e D e s i g n e d b y C h e c k e d b y S c a l e R e v m m L o c a t i o n P r o j e c t M a t e r i a l P a r t N a m e U n i t R F M D A A n g l e ± 0 . 5 ° 1 : 1 DCBA S H E N Z H E N S K Y L i n k C O . , L T D R o H S P G C o m p l i a n t D W G N o . T Y 0 6 2 0 2 4 - 0 8 - 1 2 由 Autodesk 教育版产品制作由 A u t o d e s k 教育版产品制作由 Autodesk 教育版产品制作由 A u t o d e s k 教育版产品制作 R&DCenter：RoomD5 th FloorBuildingL,BlockE,71BaochengDistrict,BaoanDistrict,Shenzhen Factory：6Floor,GangHuaXingIndustrialPark,RongshuRoad2 nd ,Fuyong,Baoan,shenzhen Email:[email protected]  matchingcircuit  ReturnLoss R&DCenter：RoomD5 th FloorBuildingL,BlockE,71BaochengDistrict,BaoanDistrict,Shenzhen Factory：6Floor,GangHuaXingIndustrialPark,RongshuRoad2 nd ,Fuyong,Baoan,shenzhen Email:[email protected]  Gain&Efficiency R&DCenter：RoomD5 th FloorBuildingL,BlockE,71BaochengDistrict,BaoanDistrict,Shenzhen Factory：6Floor,GangHuaXingIndustrialPark,RongshuRoad2 nd ,Fuyong,Baoan,shenzhen Email:[email protected]  TRP&TIS R&DCenter：RoomD5 th FloorBuildingL,BlockE,71BaochengDistrict,BaoanDistrict,Shenzhen Factory：6Floor,GangHuaXingIndustrialPark,RongshuRoad2 nd ,Fuyong,Baoan,shenzhen Email:[email protected]  RadiationPattern R&DCenter：RoomD5 th FloorBuildingL,BlockE,71BaochengDistrict,BaoanDistrict,Shenzhen Factory：6Floor,GangHuaXingIndustrialPark,RongshuRoad2 nd ,Fuyong,Baoan,shenzhen Email:[email protected] R&DCenter：RoomD5 th FloorBuildingL,BlockE,71BaochengDistrict,BaoanDistrict,Shenzhen Factory：6Floor,GangHuaXingIndustrialPark,RongshuRoad2 nd ,Fuyong,Baoan,shenzhen Email:[email protected] R&DCenter：RoomD5 th FloorBuildingL,BlockE,71BaochengDistrict,BaoanDistrict,Shenzhen Factory：6Floor,GangHuaXingIndustrialPark,RongshuRoad2 nd ,Fuyong,Baoan,shenzhen Email:[email protected]  ReliabilityTest TestItemTestconditionEquipmentSpecificationResult 1 LowTemp.Storage Test Temperature:-30°C，Time:48hrs Testcondition:PlacingantennainaLow/High TemperatureChamber,keepthetempis25°C andhumidityis65%foronehour,thenstep-down thetemp.to-30°Cinonehour,storeantennafor 44hours;step-uptempto25°C,testantennaafter 2hours. Temp.&Humi. Tester Nomaterialdeformation isallowed. ElectronicPerformance isok. PASS 2 HighTemp./High Humid StorageTest Temperature:85°CHumidity:85%RHTime:48hrs Testcondition:PlacingantennainaLow/High TemperatureChamber,keepthetempis25°C andhumidityis65%foronehour,thenstep-upthe temp.to80°Candthehumidityupto85%inone hour,storeantennafor44hours;step-downtemp to25°C,testantennaafter2hours. Temp.&Humi. Tester Nomaterialdeformation isallowed. ElectronicPerformance isok. PASS 3Salt-Spray6prayTest PlacingantennaintheSalt-SprayTester,setthe testcondition，Temp:35±2°CHumidity:85% NaClsaltspray:5±1%.PHvalue:6.5~7.2Test time:24hours Salt-SprayTester Nocolorchange Noappearrusting PASS

Test Report

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.: STS2601313W01 Issued for Zhejiang Lingzhu Technology Co., Ltd. Room 302,No 1 Building Huace Center,Xihu District Hangzhou China 310000 Product Name: Smart Camera Brand Name: N/A Model Name: SC305-WBQ4B Series Model(s): SC305-WBQ4B-V1,SC305-WBQ4C-V1,S C305-WBQ4D-V1,SC305-WBQ4E-V1,SC 305-WBQ4F-V1,SC305-WBQ4G-V1 FCC ID: 2BEWXSC305B Test Standards: FCC Part15.247 Page 2 of 57 Report No.: STS2601313W01 TEST REPORT Applicant’s Name ................. : Zhejiang Lingzhu Technology Co., Ltd. Address ................................. : Room 302,No 1 Building Huace Center,Xihu District Hangzhou China 310000 Manufacturer's Name ..................................... : Zhejiang Lingzhu Technology Co., Ltd. Address ................................. : Room 302,No 1 Building Huace Center,Xihu District Hangzhou China 310000 Product Description Product Name ........................ : Smart Camera Brand Name ........................... : N/A Model Name .......................... : .. : SC305-WBQ4B Series Model(s) .................... : SC305-WBQ4B-V1,SC305-WBQ4C-V1,SC305-WBQ4D-V1,SC305-WBQ4E- V1,SC305-WBQ4F-V1,SC305-WBQ4G-V1 Test Standards ..................... : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the IC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 2025-12-01 Date (s) of performance of tests ........................................................ : 2025-12-01 to 2025-12-31 Date of Issue .......................................... : 2025-12-31 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 57 Report No.: STS2601313W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.6 EQUIPMENTS LIST 11 RF RADIATION TEST EQUIPMENT 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 EUT OPERATING CONDITIONS 13 3.5 TEST RESULTS 14 4. RADIATED EMISSION MEASUREMENT 16 4.1 RADIATED EMISSION LIMITS 16 4.2 TEST PROCEDURE 18 4.3 TEST SETUP 19 4.4 EUT OPERATING CONDITIONS 19 4.5 FIELD STRENGTH CALCULATION 20 4.6 TEST RESULTS 21 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 28 5.1 LIMIT 28 5.2 TEST PROCEDURE 28 5.3 TEST SETUP 28 5.4 EUT OPERATION CONDITIONS 28 5.5 TEST RESULTS 28 6. POWER SPECTRAL DENSITY TEST 29 6.1 LIMIT 29 6.2 TEST PROCEDURE 29 Page 4 of 57 Report No.: STS2601313W01 Table of Contents Page 6.3 TEST SETUP 29 6.4 EUT OPERATION CONDITIONS 29 6.5 TEST RESULTS 29 7. BANDWIDTH TEST 30 7.1 LIMIT 30 7.2 TEST PROCEDURE 30 7.3 TEST SETUP 30 7.4 EUT OPERATION CONDITIONS 30 7.5 TEST RESULTS 30 8. PEAK OUTPUT POWER TEST 31 8.1 LIMIT 31 8.2 TEST PROCEDURE 31 8.3 TEST SETUP 31 8.4 EUT OPERATION CONDITIONS 31 8.5 TEST RESULTS 31 9. ANTENNA REQUIREMENT 32 9.1 STANDARD REQUIREMENT 32 9.2 EUT ANTENNA 32 APPENDIX 1-TEST DATA 33 APPENDIX 2- EUT TEST PHOTO 57 Page 5 of 57 Report No.: STS2601313W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 2025-12-31 STS2601313W01 ALL Initial Issue Page 6 of 57 Report No.: STS2601313W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. (3) The EUT is powered by the DC only, the test item is not applicable. Page 7 of 57 Report No.: STS2601313W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 57 Report No.: STS2601313W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Linyun Li(Manager)

[email protected]Fax: 0571-86581786

Technical Contact

Tuya Smart lncJingchao Wang

[email protected]

160 Greentree Drive,Suite · DELAWRE, 19904 · United States

Test Firm

SHENZHEN STS TEST SERVICES CO.,LTD.Bovey Yang

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	1.00 mW
2	15C	2.41 GHz - 2.46 GHz	39.00 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. The device supports 20MHz and 40MHz bandwidths. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter device.
