2BEWXSC396QSmart Camera

图纸发布类别 正式归档图纸 75*75mm 75x600mm 成品尺寸 单位：mm 公差： 展开图尺寸： ±1mm xxx-xxxx-xxxx What’s in the Box Thank you for purchasing Smart Camera. Get started using your new devices by downloading Smart Life, one convenient app that manages everything straight from your phone. Easily connect to your home Wi-Fi and control multiple devices from the touch of your fingertips *: Different products have dif ferent accessories, please refer to physical packing. Smart Camera ×1 USB Cable ×1 User Manual ×1 Adapter ×1 * Please read the instruction manual carefully before using the product SMART CAMERA USER MANUAL Frequently Asked Questions Yes, you can share your cameras with family and friends who will have access to view the camera and control your bulbs, plugs, and other devices. In the app, press the Profile button and click on the “Home Management” button, and you will be able to give or revoke sharing permissions. In order to share, the other user should already have downloaded the app and registered a new account. Can I share with family and friends? 1 • Make sure the device is under the config status (indicator light is flashing quickly) • Make sure the Wi-F i is available and not too far away from router • Make sure the Wi-F i password you input is correct Open “Smart Life” APP, Turn on the Bluetooth on your mobile phone, and grant the corresponding permission to the “Smart Life” APP. Click the “Add” button. Enter Wi-Fi name and password, then click the “Next”(Camera support 2.4G/5GHz). Wait for the camera to automatically complete network configuration. If the dialog box does not pop up,you can click the “+” icon or “Add Device” button on the home page, and the camera will be searched, then click the “Add”. My device can't be connected to network with App 4 • Make sure the device is powered on • Make sure the network is stable and the Wi-F i name and password not modified. If not, add device again. • If the network is normal, but it's still o ffline. Check if there are too many Wi-F i connections. You can restart your router to check the status of the device. My device shows offline in my App 5 The range of your home Wi-Fi is heavily dependent on your home router and the conditions of the room. Check with your router specifications for exact range data. What’s the Wireless Range? 2 Smart Life app can control an unlimited amount of devices in an unlimited amount of locations. Your router may have a limit of how many devices can be connected to one router. How many cameras can I control? 3 Technical Specifications • Audio: Internal Speaker and Microphone • Storage: supports up to 128G Micro SD card (not included) • Wi-F i: IEEE 802.11 b/g/n/ax, 2.4GHz & 5GHz Wi-Fi networks • Power: General 5V Direct Current 2Asymbol “ ” means dir ect current • It is recommended that the camera only be used indoor. • Operating temperature -1045Operating hum idity ≤95% • Frequency Range: 2.412-2.462GHz (US)2.412~2.472GHz (EU) RF Output Power: 2.4G: 17.5 dBm, 5G: 11.5 dBm warning Federal Communications Commission (FCC) Declaration of Conformity FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment of f and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled rolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Declaration Of Conformity European Notice Hereby, Ningbo Lingzhu Technology CO., Ltd. declares that this product is in compliance with essential requirements and other relevant provisions of Directive 2014/53/EU,2011/65/EU. This product must not be disposed of as normal household waste, in accordance with EU directive for waste electrical and electronic equipment (WEEE- 2012/19/EU). Insteadit should be disposed of by returning it to the point of sale, or to a municipal recycling collection point. The device could be used with a separation distance of 20cm to the human body. Know your Wi-Fi network and password Make sure your mobile device is running iOS® 11 or higher or Android™ 6.0× or higher This device support a 2.4G/5GHz Wi-Fi network or BLE connection STEP 1. Enter your mobile phone number or email address. STEP 2. Enter the verification code and create a password. Register an account on your Smart Life app 2 Add device A.Quickly wayB.QR code way 4 Open “Smart Life” APP, click “+” on the top right corner of the page “HOME”, then select “Smart Camera (Wi-Fi) ”. *Please refer to the specific APP interface if there are any difference. * You can find much m…

Text truncated - open the document above for the full version.

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2BEWXSC396Q SC396-WBQ3, SC396-WBQ3A, SC396-WBQ3B, SC396-WBQ3C, SC396-WBQ4, SC396-WBQ4A, SC396-WBQ4B, SC396-WBQ4C We, Applicant Company Name: Zhejiang Lingzhu Technology Co., Ltd. Address: Room 302, No 1 Building Huace Center, Xihu District, Hangzhou, China Phone: +86-571-86581786 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. This includes the cybersecurity and anti-virus software produced or provided by Kaspersky Lab, Inc. or any of ist successors and assignees. We certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2026-07-08 Signature Date Name / Title: Linyun Li / Manager Company: Zhejiang Lingzhu Technology Co., Ltd. Address: Room 302, No 1 Building Huace Center, Xihu District, Hangzhou, China Phone: +86-571-86581786 Fax: N/A E-Mail: [email protected]

Due Diligence Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern FCC ID Model name 2BEWXSC396Q SC396-WBQ3, SC396-WBQ3A, SC396-WBQ3B, SC396-WBQ3C, SC396-WBQ4, SC396-WBQ4A, SC396-WBQ4B, SC396-WBQ4C Pursuant to KDB 986446 D01 Covered Equipment Guidance the evaluation of the product above shows compliance for the following reasons: Compliance Evaluation process Results Inherent compliance The chipset(s) used is not capable of running the cybersecurity and/or anti-virus software Compliance The memory used does not allow the running the cybersecurity and/or anti-virus software Compliance The storage capacity does not allow the running the cybersecurity and/or anti-virus software Compliance The operating system used is not capable of running the cybersecurity and/or anti-virus software Compliance No inherent compliance Based on software bill of material Based on scan for running software on the device Based on filesystem scan for cybersecurity and/or anti-virus software The equipment for which authorization is sought complies with the rules and fulfils the requirements as detailed in the above mentioned KDB. Evaluation performed by Company Name: Shenzhen Huaxia Testing Technology Co., Ltd Contact Name: Yoyo Zhou Address: 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China Phone: +86-755-26648642 Email: [email protected] Signature: Date: 2026-06-30

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2BEWXSC396Q SC396-WBQ3, SC396-WBQ3A, SC396-WBQ3B, SC396-WBQ3C, SC396-WBQ4, SC396-WBQ4A, SC396-WBQ4B, SC396-WBQ4C For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2026-07-08 Signature Date Name / Title: Linyun Li / Manager Company: Zhejiang Lingzhu Technology Co., Ltd. Address: Room 302, No 1 Building Huace Center, Xihu District, Hangzhou, China Phone: +86-571-86581786 Fax: N/A E-Mail: [email protected]

Externalphotos FCC ID: 2BEWXSC396Q

SN: SC396254900001 Model: SC396-WBQ3 FCC ID:2BEWXSC396Q Smart Camera 30*25mm 不干胶贴纸白底黑字过哑膜 Manufacturer: Zhejiang Lingzhu Technology CO., Ltd. Address: Room 302,No 1 Building Huace Center, Xihu District, Hangzhou City, Zhejiang Province,China SN: SC396254900100 Model: SC396-WBQ3 FCC ID:2BEWXSC396Q Smart Camera Manufacturer: Zhejiang Lingzhu Technology CO., Ltd. Address: Room 302,No 1 Building Huace Center, Xihu District, Hangzhou City, Zhejiang Province,China SN条码为变量，此批变量范围： SC396254900001~SC396254900100 SN: SC396254900001 Model: SC396-WBQ3 FCC ID:2BEWXSC396Q Smart Camera Manufacturer: Zhejiang Lingzhu Technology CO., Ltd. Address: Room 302,No 1 Building Huace Center, Xihu District, Hangzhou City, Zhejiang Province,China

Internalphotos FCC ID: 2BEWXSC396Q Antenna

SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD 102A,102B,Building2,ShanghenglangNewIndustrialZone,ShanghenglangCommunity, DalangStreet,LonghuaDistrict,Shenzhen,Guangdong,People’sRepublicofChina,518000 Telephone:+86-755-26648640 Fax:+86-755-26648637 Website:www.cqa-cert.com ReportTemplateVersion:V06 ReportTemplateRevisionDate:2026-01-30 RFExposureEvaluationReport Thetestreportiseffectiveonlywithbothsignatureandspecializedstamp,Theresult(s)showninthisreportreferonlyto thesample(s)tested.WithoutwrittenapprovalofCQA,thisreportcan’tbereproducedexceptinfull. ReportNo.:CQASZ20260100141E-05 Applicant: ZhejiangLingzhuTechnologyCo.,Ltd. AddressofApplicant: Room302,No1BuildingHuaceCenter,XihuDistrict,Hangzhou,China EquipmentUnderTest(EUT): EUTName:SmartCamera ModelNo.:SC396-WBQ3,SC396-WBQ3A,SC396-WBQ3B,SC396-WBQ3C, SC396-WBQ4,SC396-WBQ4A,SC396-WBQ4B,SC396-WBQ4C TestModelNo.:SC396-WBQ3 BrandName:N/A FCCID:2BEWXSC396Q Standards: 47CFRPart1.1307 47CFRPart1.1310 447498D04InterimGeneralRFExposureGuidancev01 DateofReceipt:2026-01-19 DateofTest:2026-01-19to2026-03-25 DateofIssue:2026-06-30 TestResult:PASS* *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove TestedBy: (LewisZhou) ReviewedBy: (TimoLei) ApprovedBy: (JackAi) SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260100141E-05 Page:2of12 1Version RevisionHistoryOfReport ReportNo.Version Description IssueDate CQASZ20260100141E-05Rev.01 Initialreport 2026-06-30 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260100141E-05 Page:3of12 2Contents Page 1VERSION............................................................................................................................................................................2 2CONTENTS........................................................................................................................................................................3 ..................................................................................................................................................................................................3 3GENERALINFORMATION..............................................................................................................................................4 3.1CLIENTINFORMATION...................................................................................................................................................4 3.2GENERALDESCRIPTIONOFEUT...................................................................................................................................4 3.3GENERALDESCRIPTIONOFBLECLASSIC.....................................................................................................................4 3.4GENERALDESCRIPTIONOF2.4GWIFICLASSIC...........................................................................................................5 3.5GENERALDESCRIPTIONOF5GWIFICLASSIC..............................................................................................................5 4MPEEVALUATION...........................................................................................................................................................7 4.1RFEXPOSURECOMPLIANCEREQUIREMENT.................................................................................................................7 4.1.1Limits....................................................................................................................................................................7 4.1.2TestProcedure...................................................................................................................................................7 4.1.3EUTRFExposure..............................................................................................................................................8 SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260100141E-05 Page:4of12 3GeneralInformation 3.1ClientInformation Applicant: ZhejiangLingzhuTechnologyCo.,Ltd. AddressofApplicant: Room302,No1BuildingHuaceCenter,XihuDistrict,Hangzhou,China Manufacturer: ZhejiangLingzhuTechnologyCo.,Ltd. AddressofManufacturer: Room302,No1BuildingHuaceCenter,XihuDistrict,Hangzhou,China Factory: ShenzhenInterthingsTechnologyCo.,Ltd. AddressofFactory: No.701,Unit1,Tower1,LeChuanghuiBuilding,1211GuanguangRd, GuihuaCommunity,GuanlanSub-district,LonghuaDistrict,Shenzhen, China 3.2GeneralDescriptionofEUT ProductName: SmartCamera ModelNo.: SC396-WBQ3,SC396-WBQ3A,SC396-WBQ3B,SC396-WBQ3C, SC396-WBQ4,SC396-WBQ4A,SC396-WBQ4B,SC396-WBQ4C TestModelNo.: SC396-WBQ3 TradeMark: N/A SoftwareVersion: V1.0 HardwareVersion: V1.0 EUTPowerSupply: PoweredbyDC5Vforadapter Adapter:TPA-418G050200UU01 Input:100-240v~50/60Hz0.3A Output:5.0V⎓2.0A10.0W 3.3GeneralDescriptionofBLEClassic OperationFrequency: 2402MHz~2480MHz BluetoothVersion: BluetoothSpec5.4 ModulationType: GFSK NumberofChannel: 40 TransferRate:1Mbps SampleType: MobilePortableFixLocation AntennaType:2.23dBi AntennaGain: PoweredbyDC5Vforadapter SHENZHENHUAXIATESTINGTECHNOLOGYCO.,LTD ReportNo.:CQASZ20260100141E-05 Page:5of12 3.4GeneralDescriptionof2.4GWIFIClassic OperationFrequency: 2412MHz~2462MHz TypeofModulation: IEEEfor802.11b:DSSS(CCK,DQPSK,DBPSK) IEEEfor802.11g:OFDM(64QAM,16QAM,QPSK,BPSK) IEEEfor802.11n(HT20andHT40):OFDM(64QAM,16QAM,QPSK,BPSK) IEEEfor802.11ax(HE20andHE40):OFDMA(1024QAM,256QAM,64QAM, 16QAM,QPSK,BPSK) NumberofChannel: IEEE802.11b/g,IEEE802.11nHT20/axHE20:11Channels IEEE802.11nHT40/axHE40:7Channels ChannelSeparation: 5MHz TransferRate: IEEEfor802.11b: 1Mbps/2Mbps/5.5Mbps/11Mbps IEEEfor802.11g: 6Mbps/9Mbps/12Mbps/18Mbps/24Mbps/36Mbps/48Mbps/54Mbps IEEEfor802.11n(HT20): 6.5Mbps/13Mbps/19.5Mbps/26Mbps/39Mbps/52Mbps/58.5Mbps/65Mbps IEEEfor802.11n(HT40): 13.5Mbps/27Mbps/40.5Mbps/54Mbps/81Mbps/108Mbps/121.5Mbps/135Mbps IEEEfor802.11ax(HE20): 8.6Mbps/17.2Mbps/25.8Mbps/34.4Mbps/51.6Mbps/68.8Mbps/77.4Mbps /86.7Mbps/103.3Mbps/114.7Mbps/129.0Mbps/143.4Mbps IEEEfor802.11ax(HE40): …
