EUT PHOTO(Internal Photos) ANT ※※※※※※※※※※ END OF REPORT

FCCID:2BEXI-WGCS01 RFExposureEvaluation AccordingtoKDB447498D01GeneralRFExposureGuidancev06andpart2.1093， UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone 1-gheadorbodyand10-gextremitySARevaluationforgeneralpopulationexposure conditions,bymeasurementornumericalsimulation,isnotrequiredwhenthe correspondingSARTestExclusionThresholdcondition(s),listedbelow,is(are)satisfied. For100MHzto6GHzandtestseparationdistances≤50mm,the1-gand10-gSARtest exclusionthresholdsaredeterminedbythefollowing: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f (GHz) ]≤3.0for1-gSAR,and≤7.5for10-gextremitySAR,where f (GHz) istheRFchanneltransmitfrequencyinGHz PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison Here, BLE ModeMax Power(dBm) Max Power(mW) Frequency(MHz)Min. distance(mm) Calc. thresholds limit GFSK-0.1370.97240250.303.0 SoaSARtestisnotrequired

Productspecification QuickReferenceDate Antennamoduleon thesystemboard FrequencRange 2400~ 2500MHz Ant.PortInputPwr.(dBm)0 (Typ.BTclass2 outputpower) Tot.Rad.Pwr.(dBm)- 1.2(Inputpwr- losspwr) PeakEIRP(dBm)1.68 Directivity(dBi) 1(all directionantenna) Efficiency(dB) 6 0.2% Gain(dBi)1.68(AvgGainXY-plane) MaximumPower(dBm)1.7(XY-plane) MinimumPower(dBm)-4(XY-plane) Avg.Power(dBm)-0.5(XY-plane) InputImpendence(ohm)50 PolarizationType Vertical&Horizontal V. S.W. R <1.4 Allthetechnicaldataandinformationcontainedhereinaresubjectto changewithout priornotice AntennaLayout& moduleon the system board AntennaGain Gain Table Unitin [email protected] -planeYZ-planeEfficiency Peak Avg. Peak Avg. Peak Avg. ModuleBoard 1.35-0.51.68-3.61.11-3.0 6 0.2% RetumLoss TheEnvironmentofAntennaRadiationPattem 3Dradiationpatterndiagram XY-planeXZ-planeYZ-plane

Project No.: ZKT-2401251241E Page 1 of 38 FCC TEST REPORT FCC ID:2BEXI-WGCS01 Report Number. .............................. : ZKT-2401251241E Date of Test ........................................ Jan. 25, 2024 to Jan. 31, 2024 Date of issue .................................... : Jan. 31, 2024 Total number of pages ...................... 38 Test Result ..................................... : PASS Testing Laboratory. ........................ : Shenzhen ZKT Technology Co., Ltd. Address .......................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Applicant's name ......................... : Shanghai Jin Jin E-commerce Co., LTD Address .......................................... : Building 78, No.4399, Wusi Road, Haiwan Town, Fengxian District, Shanghai City, China. Manufacturer's name ................... : Shanghai Jin Jin E-commerce Co., LTD Address .......................................... : Building 78, No.4399, Wusi Road, Haiwan Town, Fengxian District, Shanghai City, China. Test specification: Standard ........................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2013 Test procedure ................................. : / Non-standard test method ............. : N/A Test Report Form No. .................... : / Test Report Form(s) Originator .... : ZKT Testing Master TRF .................................... : Dated: 2020-01-06 This device described above has been tested by ZKT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ZKT, this document may be altered or revised by ZKT, personal only, and shall be noted in the revision of the document. Product name ................................. : arcade game console Trademark ...................................... : N/A Model/Type reference......................: WGC-S01 VGC-W20, BTH001, BTH002, BTH003, BTH004, BTH005, BTH006, BTH007, BTH008, BTH009 Project No.: ZKT-2401251241E Page 2 of 38 Testing procedure and testing location: Testing Laboratory ................................... : Shenzhen ZKT Technology Co., Ltd. Address ...................................................... :1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Jim Liu Tested by (name + signature) .................... : Jeff Fu Reviewer (name + signature) ..................... : Lake Xie Approved (name + signature) .................... : Project No.: ZKT-2401251241E Page 3 of 38 Table of Contents Page 1.VERSION ............................................................................................................... 5 2. SUMMARY OF TEST RESULTS ........................................................................... 6 2.1 TEST FACILITY ............................................................................................................... 7 2.2 MEASUREMENT UNCERTAINTY ................................................................................... 7 3. GENERAL INFORMATION ................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ................................................................................ 8 3.2 DESCRIPTION OF TEST MODES ................................................................................... 9 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED ............ 10 3.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) ...................................... 10 3.5 EQUIPMENTS LIST FOR ALL TEST ITEMS.................................................................. 11 4. EMC EMISSION TEST ........................................................................................ 13 4.1 CONDUCTED EMISSION MEASUREMENT ................................................................. 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS ..................................................... 13 4.1.2 TEST PROCEDURE .................................................................................................. 13 4.1.3 DEVIATION FROM TEST STANDARD ..................................................................... 13 4.1.4 TEST SETUP ............................................................................................................. 14 4.1.5 EUT OPERATING CONDITIONS .............................................................................. 14 4.2.1 RADIATED EMISSION LIMITS ................................................................................. 15 4.2.2 TEST PROCEDURE .................................................................................................. 16 4.2.3 DEVIATION FROM TEST STANDARD ..................................................................... 16 4.2.4 TEST SETUP ............................................................................................................. 16 4.2.5 EUT OPERATING CONDITIONS .............................................................................. 17 BETWEEN 30MHZ – 1GHZ .................................................................................... 18 1GHZ~25GHZ ......................................................................................................... 20 5.RADIATED BAND EMISSION MEASUREMENT ................................................. 22 5.1 TEST REQUIREMENT: ................................................................................................ 22 5.2 TEST PROCEDURE ..................................................................................................... 22 5.3 DEVIATION FROM TEST STANDARD ........................................................................ 22 5.4 TEST SETUP ........................................................…
