2BEZD-NIGSV04Novaterm Gateway

This guide refers to the following products: NOVATERM® IGS 868 MHz NOVATERM® IGS 921 MHz NOVATERM® BOX 868 MHz NOVATERM® BOX 921 MHz User manual & safety instructions Dear Customer, Thank you for choosing Novaterm® from Groupe Berkem. For safe use, we advise you to read its quick start guide very carefully and follow all instructions. The contents of this quick start guide cannot exhaustively describe all aspects related to the use of the product. It is based on our own experience and remains non-binding. It does not evade compliance with the information indicated in the Safety Data Sheet available on request. The information in this documentation is indicated in the current state of the regulations. Any changes to these regulations will result in an update of this document. If you have any questions, your sales representative is available to answer them and take note of any suggestions you may have. Contents Manufacturer ........................................................................................................................... Caution .................................................................................................................................... Contents of the box ................................................................................................................. Presentation of the product .................................................................................................... Maintenance and Cleaning ..................................................................................................... 868 MHz or 921 MHz NOVATERM® IGS .................................................................................. 868 MHz or 921 MHz NOVATERM® BOX ................................................................................. Technical characteristics ........................................................................................................ 868 MHz or 921 MHz NOVATERM® IGS .................................................................................. 868 MHz or 921 MHz NOVATERM® BOX ................................................................................. Main electrical power adapter included with the NOVATERM® BOX ..................................... Operating conditions .............................................................................................................. 868 MHz or 921 MHz NOVATERM® IGS .................................................................................. 868 MHz or 921 MHz NOVATERM® BOX ................................................................................. Certification and regulatory information ............................................................................... CE certification ........................................................................................................................ FCC Statement ......................................................................................................................... Safety ....................................................................................................................................... Definition of symbols............................................................................................................... Important safety instructions.................................................................................................. Precautions for use of the device ............................................................................................ User safety ............................................................................................................................... Safety of persons ..................................................................................................................... Storage..................................................................................................................................... Environment ............................................................................................................................ After-sales service and warranty ............................................................................................ After-sales service ................................................................................................................... Manufacturer NOVATERM® products are manufactured by GROUPE BERKEM Address: 20, rue Jean DUVERT - 33290 BLANQUEFORT - France Telephone: +33 5 64 31 06 60 Web site: https://hygiene.groupeberkem.com and novaterm.com Contents of the box Please carefully read the manual and the “Safety” chapter before use. 868 MHz or 921 MHz NOVATERM® IGS868 MHz or 921 MHz NOVATERM® BOX • One user manual and safety instructions • 16 NOVATERM® IGS • 16 main units or boxes • 16 loops or cartridges supports • 16 reclosable covers • One user manual and safety instructions • One main electrical power adapter SIMSUKIAN ESCM01T8-050 • One NOVATERM® BOX Presentation of the product The NOVATERM® IGS and NOVATERM® BOX are intended to be used by professionals to deal with subterranean termites. The NOVATERM® IGS are installed in the ground approximately 50 cm to 1 meter from the edges of buildings, approximately every 3 meters. Two anti-termite bait cartridges can be inserted in a loop in the interior cavity of the NOVATERM® IGS. The NOVATERM® IGS features a proprietary 868 MHz or 921 MHz radio telecommunication and measurement system, depending on the country. When the system is installed, the NOVATERM® IGS stations are paired with one or more NOVATERM® BOX units. The NOVATERM® BOX has a range of about 50 m, which may be reduced due to obstacles (concrete walls, metal partitions, etc.). The measurements are transmitted to the NOVATERM® BOX, which then sends them to a server over an LTEM / NB-IOT type telecommunication network for analysis. 868 MHz or 921 MHz NOVATERM® IGS 1. Pairing and ON button 2. Status LED 3. Pa…

Text truncated - open the document above for the full version.

BERKEM DEVELOPPEMENT SAS Siège Social 20, Rue Jean Duvert 33290 Blanquefort FRANCE Tel : +33 (0)5 64 31 06 60 Fax : +33 (0)5 56 15 24 97 RCS Bordeaux B 481 604 197 SIRET 48160419700055 APE 7010Z Capital : 2.055.153,80 € www.groupe-berkem.com Date: 03-22-2024 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2BEZD-NIGSV04 FRN of applicant: 0034903377 BERKEM DEVELOPPEMENT (“the applicant”) certifies that, as of the date of the filing of the application, BERKEM, Inc (U.S Agent) is our designated U.S. agent for service of process for the above referenced FCC ID. BERKEM DEVELOPPEMENT accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. BERKEM, Inc accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: BERKEM, Inc FRN: 0035271220 Address: C/O Guibert, 445 Park Avenue, 9th Floor,, New York, NY 10022 Contact Person: Miss Nancy Kleperis Email: [email protected] Sincerely, BERKEM DEVELOPPEMENT BERKEM, Inc M. Mathias Boutin [email protected] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA

BERKEM DEVELOPPEMENT SAS Siège Social 20, Rue Jean Duvert 33290 Blanquefort FRANCE Tel : +33 (0)5 64 31 06 60 Fax : +33 (0)5 56 15 24 97 RCS Bordeaux B 481 604 197 SIRET 48160419700055 APE 7010Z Capital : 2.055.153,80 € www.groupe-berkem.com Date: 22-03-2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BEZD-NIGSV04 BERKEM DEVELOPPEMENT certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Additionally, the applicant is not a named entity or any of its subsidiaries or affiliates. Sincerely, March 22, 2024 By Mathias Boutin - Chief project Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA

BERKEM DEVELOPPEMENT SAS Siège Social 20, Rue Jean Duvert 33290 Blanquefort FRANCE Tel : +33 (0)5 64 31 06 60 Fax : +33 (0)5 56 15 24 97 RCS Bordeaux B 481 604 197 SIRET 48160419700055 APE 7010Z Capital : 2.055.153,80 € www.groupe-berkem.com Date: 22-03-2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BEZD-NIGSV04 BERKEM DEVELOPPEMENT (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, March 22, 2024 By Mathias Boutin - Chief project Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA

BERKEM DEVELOPPEMENT SAS Siège Social 20, Rue Jean Duvert 33290 Blanquefort FRANCE Tel : +33 (0)5 64 31 06 60 Fax : +33 (0)5 56 15 24 97 RCS Bordeaux B 481 604 197 SIRET 48160419700055 APE 7010Z Capital : 2.055.153,80 € www.groupe-berkem.com March 22, 2024 SUBJECT: FCC Application for FCC ID: 2BEZD-NIGSV04 To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the supplier Declaration of Conformity procedure to the Class B digital devices portion of this composite filing. Note: We understand that devices subject to the SDoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to- government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telecom MRA are not recognized by the FCC to test for the SDoC procedure. Regards, March 22, 2024 By M. Mathias Boutin, Chief project Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA

BERKEM DEVELOPPEMENT SAS Siège Social 20, Rue Jean Duvert 33290 Blanquefort FRANCE Tel : +33 (0)5 64 31 06 60 Fax : +33 (0)5 56 15 24 97 RCS Bordeaux B 481 604 197 SIRET 48160419700055 APE 7010Z Capital : 2.055.153,80 € www.groupe-berkem.com Confidentiality Request regarding application for certification of FCC ID: 2BEZD-NIGSV04 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name -Block Diagram -Schematics -Operational Description -BlkDia.pdf -Schem.pdf -OpDes.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, March 22, 2024 By Mathias Boutin - Chief project TIMCO Engineering Inc. 13146 NW 86 th Drive Suite 400 Alachua, FL 32615

Berkem Inc C/O Guibert 445 Park Avenue, 9th Floor, New York, NY 10022 Authority to Act as Agent FCC ID: 2BEZD-NBOXV04 On our behalf, I appoint M. Sébastien LOUIS from Emitech Angers, 21 rue de la Fuye PA de Lanserre, 49610 Juigné sur Loire FRANCE, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unitmanufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by TIMCO Engineering Inc., still resides with BERKEM, Inc. This authorization is valid until further written notice from BERKEM, Inc. Date: August 2 nd , 2024 By Mathias Boutin – Chief project Signature TIMCO Engineering Inc. 13146 NW 86th Drive Suite 400 Alachua, FL 32615 USA

Page 1 sur 4 External Photos – FCCID : 2BEZD-NIGSV04 Page 2 sur 4 Page 3 sur 4 Page 4 sur 4

IGS 921 MHz Groupe Berkem – 20, rue Jean Duvert – FR-33290 Blanquefort – France This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos – FCCID : 2BEZD-NIGSV04

S 51 RTY 000 EMF 00006 [ 0 4 ] Siège Social : Emitech – 3 avenue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES B 344 545 645 - APE 7112B REM-EMIESS23G928ADK-01Av0 MPE test report According to the standard: CFR 47 FCC PART 15 Equipment under test: NOVATERM TRAP FCC ID: 2BEZD-NIGSV04 Company: BERKEM DEVELOPPEMENT Distribution: Mr BOUTIN (Company: BERKEM DEVELOPPEMENT) Number of pages: 5 Technical Verification and Quality Approval Ed. Date Modified Page(s) Name and Function Visa 0 4-Jul-24 Creation M. DUMESNIL, Radio Laboratory Manager Duplication of this document is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. Information in italics are declared by the manufacturer/customer and are under his responsibility REM-EMIESS23G928ADK-01Av0 Page 2/5 DESIGNATION OF PRODUCT: NOVATERM TRAP Serial number (S/N): 22-2FF-223 Reference / model (P/N): TRAP-V0.4 Firmware version: 0.0.0 MANUFACTURER: EOLANE SAS COMPANY CERTIFYING THE PRODUCT: Company: BERKEM DEVELOPPEMENT Address: 20, RUE JEAN DUVERT 33290 BLANQUEFORT FRANCE RESPONSIBLE: Mr BOUTIN COMPANY SUBMITTING THE PRODUCT: Company: ADKALIS SAS Address: 20, RUE JEAN DUVERT 33290 BLANQUEFORT FRANCE Responsible: Mr BOUTIN Person present during the tests: Mr KAMAL Ibrahim (Company: IKALOGIC) – (The first day) DATES OF TEST: From 9-Jan-24 to 10-Jan-24 TESTING LOCATION: EMITECH ANGERS laboratory at JUIGNE SUR LOIRE (49) FRANCE FCC Accredited under US-EU MRA Designation Number: FR0009 Test Firm Registration Number: 873677 TESTED BY: S. LOUIS VISA: WRITTEN BY: S. LOUIS REM-EMIESS23G928ADK-01Av0 Page 3/5 CONTENTS TITLE PAGE 1. INTRODUCTION ....................................................................................................................................... 4 2. PRODUCT DESCRIPTION ....................................................................................................................... 4 3. NORMATIVE REFERENCE ...................................................................................................................... 4 4. RF EXPOSURE ......................................................................................................................................... 5 REVISIONS HISTORY Revision Date Modified pages Modifications 0 29-Jan-24 / Creation REM-EMIESS23G928ADK-01Av0 Page 4/5 1. INTRODUCTION This report presents the results of radio test carried out on the following radio equipment: NOVATERM TRAP, in accordance with normative reference. The equipment under test integrates:  SRD Monofrequency transceiver operational in the band (902MHz – 928MHz) 2. PRODUCT DESCRIPTION Class: B Utilization: Residential Antenna type and gain: 0.01 dBi / integral antenna Operating frequency range: From 902 MHz to 928 MHz Frequency tested: 921MHz Number of channels: 1 Channel spacing: Not concerned Modulation: GFSK2 Power source: 3Vdc Lithium battery (CR2477X-HE / CR2477X-HO) Power level, frequency range and channels characteristics are not user adjustable. The details pictures of the product and the circuit boards are joined with this file. 3. NORMATIVE REFERENCE The standards and testing methods related throughout this report are those listed below. They are applied on the whole test report even though the extensions (version, date and amendment) are not repeated. CFR 47 (2024) Radio Frequency Devices ANSI C63.10 2013 Procedures for ComplianceTesting of Unlicensed Wireless Devices. 447498 D04 Interim General RF Exposure Pocedures and Equipment Authorization Policies for Mobile and RF Exposure Guidance v01 Portable Devices REM-EMIESS23G928ADK-01Av0 Page 5/5 4. RF EXPOSURE In accordance with KDB 447498 D04 Interim General RF Exposure Guidance v01, paragraph 1.4.2 : Maximum Permissive Exemption according paragraph 1.1310(d)(2) of CFR 47 FCC Part 15 Maximum measured power = 90.1 dBμV/m = 0.003334W at 921 MHz with P = (E×d) 2 / (30×Gp) with d = 10 m and Gp = 1.02 PSD= EIRP/(4*π*R 2)  3.334/(4*π*(20 cm)²)= 0.000663 mW/cm² (limit = 0.614 mW/cm²) The equipment fulfils the requirements on power density for general population/uncontrolled exposure and therefore fulfils the requirements of 47 CFR §1.1310.

Design Note DN038 SWRA416 Page 1 of 24 Miniature Helical PCB Antenna for 868 MHz or 915/920 MHz By Richard Wallace Keywords  Miniature Helical PCB Antenna  Optimized for compact designs  868 or 915/920 MHz ISM Bands  CC11xx  CC12xx 1 Introduction This document describes a compact PCB helical antenna that has been specifically designed for 868 MHz or 915/920 MHz ISM bands. The PCB helical antenna requires two matching components for matching to a 50-ohm load. When a large PCB area (38 mm x 24 mm) is available for the antenna then the recommended antenna is DN024 [1] since the impedance is closer to 50 ohm without any external matching components (868 MHz: 30+j11; VSWR 1.8) and the bandwidth is around 90 MHz. The miniature PCB helical antenna is more compact (19 mm x 11 mm) with approximately quarter of the size of the DN024 [1] but requires matching components since the impedance is far from 50 ohms (868 MHz: 10-j88; VSWR 22). When the miniature helical antenna is matched then the bandwidth is around 40 MHz and has similar efficiency as DN024 [1] antenna when measured on the TRXEB platform. All measurement results presented in this document are based on measurements performed on the CC110L EM Rev 1.0 Reference Design [3], shown in Figure 1. Figure 1. CC110L EM 868 / 915 MHz Design Note DN038 SWRA416 Page 2 of 24 Table of Contents KEYWORDS .............................................................................................................................. 1 1 INTRODUCTION ............................................................................................................. 1 2 ABBREVIATIONS ........................................................................................................... 2 3 ANTENNA DESIGN ........................................................................................................ 3 3.1 PHYSICAL DIMENSIONS .............................................................................................. 3 3.2 ANTENNA MATCH NETWORK ...................................................................................... 4 3.3 ANTENNA BANDWIDTH MEASUREMENT........................................................................ 7 3.4 ANTENNA OTA MEASUREMENT .................................................................................. 7 3.4.1 868 MHz OTA Measurement Summary ............................................................................ 7 4 CONCLUSION ................................................................................................................ 9 5 REFERENCES .............................................................................................................. 10 6 GENERAL INFORMATION ........................................................................................... 10 6.1 DOCUMENT HISTORY ............................................................................................... 10 7 APPENDICES ............................................................................................................... 11 7.1 CTIA OTA REPORT – 868 MHZ (ANTENNA MATCHED AT 868 MHZ) ........................... 11 7.1.1 OTA Evaluation Results .................................................................................................. 11 7.1.2 RP_868.000_tot .............................................................................................................. 12 7.1.3 RP_868.000_hor ............................................................................................................. 13 7.1.4 RP_868.000_ver ............................................................................................................. 14 7.1.5 Theta = 0, Phi = 0 .......................................................................................................... 15 7.1.6 Theta = 180, Phi = 0 ...................................................................................................... 15 7.1.7 Theta = 90, Phi = 0 ........................................................................................................ 16 7.1.8 Theta = 90, Phi = 180 .................................................................................................... 16 7.1.9 Theta = 90, Phi = 270 .................................................................................................... 17 7.1.10 Theta = 90, Phi = 90 ...................................................................................................... 17 7.2 CTIA OTA REPORT – 915 MHZ (ANTENNA MATCHED AT 868 MHZ) ........................... 18 7.2.1 OTA Evaluation Results: ................................................................................................ 18 7.2.2 RP_915.000_tot .............................................................................................................. 19 7.2.3 RP_915.000_hor ............................................................................................................. 20 7.2.4 RP_915.000_ver ............................................................................................................. 21 7.2.5 Theta = 0, Phi = 0 .......................................................................................................... 22 7.2.6 Theta = 180, Phi = 0 ...................................................................................................... 22 7.2.7 Theta = 90, Phi = 0 ........................................................................................................ 23 7.2.8 Theta = 90, Phi = 180 .................................................................................................... 23 7.2.9 Theta = 90, Phi = 270 .................................................................................................... 24 7.2.10 Theta = 90, Phi = 90 ...................................................................................................... 24 2 Abbreviations ANT Antenna CTIA Cellular Telephone Industry Association DC Direct Curre…

Text truncated - open the document above for the full version.

Siège Social : Emitech - 3, rue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES 344 545 645 - APE 7112B S51 RTY 000 INT 00015 [ 04] LIST OF ACCREDITED SITES AND SCOPE AVALAIBLE ON WWW.COFRAC.FR TESTING ACCREDITATIONS N° 1-0826, 1-0827, 1-1925, 1-2069,1-2070, 1-2206, 1-2376 & 1-6086 RRA-EMIESS23G928ADK-01Av0 Certification Radio test report According to the standard: CFR 47 FCC PART 15 Equipment under test: NOVATERM TRAP FCC ID: 2BEZD-NIGSV04 Company: BERKEM DEVELOPPEMENT Distribution: Mr BOUTIN (Company: BERKEM DEVELOPPEMENT) Number of pages: 25 with 2 appendixes Technical Verification and Quality Approval Ed. Date Modified Page(s) Name and Function Visa 0 3-Jul-24 Creation M. DUMESNIL, Radio Laboratory Manager Duplication of this document is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. Information in italics are declared by the manufacturer/customer and are under his responsibility RRA-EMIESS23G928ADK-01Av0 Page 2/25 DESIGNATION OF PRODUCT: NOVATERM TRAP Serial number (S/N): 22-2FF-223 Reference / model (P/N): TRAP-V0.4 Firmware version: 0.0.0 MANUFACTURER: EOLANE SAS COMPANY CERTIFYING THE PRODUCT: Company: BERKEM DEVELOPPEMENT Address: 20, RUE JEAN DUVERT 33290 BLANQUEFORT FRANCE RESPONSIBLE: Mr BOUTIN COMPANY SUBMITTING THE PRODUCT: Company: ADKALIS SAS Address: 20, RUE JEAN DUVERT 33290 BLANQUEFORT FRANCE Responsible: Mr BOUTIN Person present during the tests: Mr KAMAL Ibrahim (Company: IKALOGIC) – (The first day) DATES OF TEST: From 9-Jan-24 to 10-Jan-24 TESTING LOCATION: EMITECH ANGERS laboratory at JUIGNE SUR LOIRE (49) FRANCE FCC Accredited under US-EU MRA Designation Number: FR0009 Test Firm Registration Number: 873677 TESTED BY: S. LOUIS VISA: WRITTEN BY: S. LOUIS RRA-EMIESS23G928ADK-01Av0 Page 3/25 CONTENTS TITLE PAGE 1. INTRODUCTION ....................................................................................................................................... 4 2. PRODUCT DESCRIPTION ....................................................................................................................... 4 3. NORMATIVE REFERENCE ...................................................................................................................... 5 4. TEST METHODOLOGY ............................................................................................................................ 5 5. TEST EQUIPMENT CALIBRATION DATES ............................................................................................ 6 6. TESTS RESULTS SUMMARY .................................................................................................................. 8 7. MEASUREMENT UNCERTAINTY ............................................................................................................ 9 8. OCCUPIED BANDWIDTH .......................................................................................................................10 9. BAND EDGE ............................................................................................................................................13 10. PEAK CONDUCTED OUTPUT POWER .................................................................................................15 11. RADIATED SPURIOUS EMISSIONS ......................................................................................................17 12. PEAK CONDUCTED POWER SPECTRAL DENSITY ............................................................................19 APPENDIX 1: TEST EQUIPMENT LIST ........................................................................................................................... 21 APPENDIX 2: RADIATED TEST SETUP .......................................................................................................................... 24 REVISIONS HISTORY Revision Date Modified pages Modifications 0 29-Jan-24 / Creation RRA-EMIESS23G928ADK-01Av0 Page 4/25 1. INTRODUCTION This report presents the results of radio test carried out on the following radio equipment: NOVATERM TRAP, in accordance with normative reference. The equipment under test integrates:  SRD Monofrequency transceiver operational in the band (902MHz – 928MHz). The host device of certified module(s) shall be properly labeled to identify the module(s) within. 2. PRODUCT DESCRIPTION Class: B Utilization: Residential Antenna type and gain: 0.01 dBi / integral antenna Operating frequency range: From 902 MHz to 928 MHz Frequency tested: 921MHz Number of channels: 1 Channel spacing: Not concerned Modulation: GFSK2 Power source: 3Vdc Lithium battery (CR2477X-HE / CR2477X-HO) Power level, frequency range and channels characteristics are not user adjustable. The details pictures of the product and the circuit boards are joined with this file. RRA-EMIESS23G928ADK-01Av0 Page 5/25 3. NORMATIVE REFERENCE The standards and testing methods related throughout this report are those listed below. They are applied on the whole test report even though the extensions (version, date and amendment) are not repeated. CFR 47 FCC Part 15 (2024) Radio Frequency Devices ANSI C63.10 2013 Procedures for ComplianceTesting of Unlicensed Wireless Devices. 558074 D01 15.247 Meas Guidance v05r02 Guidance for compliance measurements on digital transmission system, frequency hopping spread spectrum system, and hybrid system devices operating under section 15.247 of the FCC rules. 4. TEST METHODOLOGY Radio performance tests procedures given in CFR 47 part 15: Subpart C – Intentional Radiators Paragraph 203: Antenna requirement Paragr…

Text truncated - open the document above for the full version.

Page 1 sur 11 FCC ID : 2BEZD-NIGSV04 Anechoic chamber setup Above 1 GHz 1: Equipment Under Test 2: Measurement antenna 3: Measurement equipment 1 2 1.5 m 3 Distanc…

Text truncated - open the document above for the full version.
