2BEZN-AL03GB00AlterLock Gen3

Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with Innovation, Science, and Economic Development Canad licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d' Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil nedoit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment complies with FCC/ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. L'appareil est conforme aux limites d'exposition aux rayonnements spécifiées par la FCC/ISED pour les environnements non contrôlés. La distance entre le radiateur et le corps doit être d'au moins 20 cm lors de l'installation et du fonctionnement de l'appareil. Cet émetteur ne doit pas coexister ou fonctionner conjointement avec toute autre antenne ou émetteur.

NEXTSCAPE Inc. Add: 16 Floor, Toranomon Hills Moritower Building, 1-23-1 Toranomon Minato-ku, Tokyo, Japan Tel: 81-3-5325-1301 Email: [email protected] Date: 2024-02-29 Attestation letter FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, Our product AlterLock Gen3, model: AL03GB, FCC ID: 2BEZN-AL03GB00, for marketing purpose, this product only supports LTE Cat-M1 Band 2/4/5/12, BLE 1M, 2.4G Wi-Fi( 2412-2462MHz, RX). The other functions, bands and modes were disabled to use by manufacture in the software, the end user has no capability to activate it. Sincerely, Signature: Printed name: Kiyotake Teruyama Title: Product Manager

NEXTS Add: 16 Japan Tel: 81 - Email: t Date: 20 FEDER Authori 7435 O Colum b Ref: A t FCC I D NEXT S “covere 2.903 o Sincer e Signat u Printed Title: P SCAPE Inc. 6 Floor, Tor -3-5325-130 teruyama@ 024-02-29 RAL COMM ization and akland Mil l bia, MD 210 ttestation St D: 2BEZN-A SCAPE Inc ed” equipme of the FCC r ely Yours, ure: name: Kiy o roduct Man . ranomon Hi 01 @nextscape.n MUNICATI Evaluation ls Road 046 tatements C AL03GB00 c. certifies t ent prohibit rules. otake Teruy nager ills Moritow net
Att IONS COM Division FR 47 §2.9 0 that the equi ted from rec yama wer Building testation L MMISSIONS 11(d)(5)(i) ipment for w ceiving an e g, 1-23-1 T C Letter S Filing which autho equipment a oranomon M CFR 47 §2.91 orization is authorization Minato-ku, 1(d)(5)(i) Atte sought, is n n pursuant t Tokyo, estation Letter not to section r

NEXTS Add: 16 Japan Tel: 81 - Email: t Date: 20 FEDER Authori 7435 O Colum b Ref: A t FCC I D NEXT S not iden Sincer e Signat u Printed Title: P SCAPE Inc. 6 Floor, Tor -3-5325-130 teruyama@ 024-02-29 RAL COMM ization and akland Mil l bia, MD 210 ttestation St D: 2BEZN-A SCAPE Inc ntified on th ely Yours, ure: name: Kiy o roduct Man . ranomon Hi 01 @nextscape.n MUNICATI Evaluation ls Road 046 tatements C AL03GB00 c. certifies t he Covered otake Teruy nager ills Moritow net
Att IONS COM Division FR 47 §2.9 0 that as of the List as an e yama wer Building testation L MMISSIONS 11(d)(5)(ii) e date of the entity produ g, 1-23-1 T CF Letter S ) Filing e filing of th ucing “cover oranomon M FR 47 §2.911 he applicati red” equipm Minato-ku, (d)(5)(ii) Atte ion, the app ment. Tokyo, estation Letter licant is r

U.S. AGENT LETTER OF ATTESTATION Date: 2024-02-29 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2BEZN-AL03GB00 NEXTSCAPE Inc. certifies that, as of the date of the filing of the application, Iconsigh Inc. is our designated U.S. agent for service of process for the above referenced FCC ID. NEXTSCAPE Inc. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Iconsigh Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Iconsigh Inc. Address: 2310 Homestead Road, Suite C1, Los Altos, CA, 94024, USA FRN: 0033398652 Tel.: +1 (408) 320-9867 Email: [email protected] Signed by (printed name): Benjamin Kaur Signature: Applicant: NEXTSCAPE Inc. Address: 16 Floor, Toranomon Hills Moritower Building, 1-23-1 Toranomon Minato-ku, Tokyo, Japan FRN: 0034879015 Tel: 81-3- 5325-1301 Email: [email protected] Signed by (printed name): Kiyotake Teruyama Signature:

NEXTSCAPE Inc. Add: 16 Floor, Toranomon Hills Moritower Building, 1-23-1 Toranomon Minato-ku, Tokyo, Japan Tel: 81-3- 5325-1301 Email: [email protected] QA-FR-170-B 7/29/2014 FCC Authorization Date: 2024-02-29 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We NEXTSCAPE Inc. the undersigned, hereby authorizes Bay Area Compliance Laboratories Corp. (Shenzhen) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. (Shenzhen) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Printed name: Kiyotake Teruyama Title: Product Manager

NEXTSCAPE Inc. Add: 16 Floor, Toranomon Hills Moritower Building, 1-23-1 Toranomon Minato-ku, Tokyo, Japan Tel: 81-3-5325-1301 Email: [email protected] FCC Confidential Authorization Date: 2024-02-02 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2BEZN-AL03GB00 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, NEXTSCAPE Inc. hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description  Part list/Tune up Procedure The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature: Printed name: Kiyotake Teruyama Title: Product Manager

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 1 of 4 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 2 of 4 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 3 of 4 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 4 of 4

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 1 of 9 EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 2 of 9 ANT BLE ANT LTE ANT GNSS ANT Wi-Fi ANT (RX only) Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 3 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 4 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 5 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 6 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 7 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 8 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 9 of 9

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: SZ1231225-78191E-RF TR-EM-RF011 Page 13 of 54 Version 1.0 (2023/10/07) FCC §1.1307(b) & 2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart 15.247 (i) and subpart 2.1091 systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (Minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Result Calculated Formulary: Predication of MPE limit at a given distance S = 2 4R PG π S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: SZ1231225-78191E-RF TR-EM-RF011 Page 14 of 54 Version 1.0 (2023/10/07) Result For worst case: Mode Frequency (MHz) Antenna Gain # Tune up conducted power # Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric)(dBm)(mW) BLE 2402-2480 2.45 1.76 1.0 1.26 20 0.0004 1 LTE Band 2(Onl y for FCC) 1850-1910 2.59 1.82 21.0 125.89 20 0.045 1 LTE Band 4 1710-1755 2.5 1.78 21.0 125.89 20 0.045 1 LTE Band 5 824-849 -1.72 0.67 21.5 141.25 20 0.019 0.549 LTE Band 12 699-716 -3.17 0.48 21.0 125.89 20 0.012 0.466 Note: The tune-up power and antenna gain was declared by the applicant. Simultaneous transmitting consideration (worst case): The ratio=MPE BLE /limit BLE + MPE LTE Band 2 /limit LTE Band 2 = 0.0004/1+0.045 /1=0.045＜1.0 To maintain compliance with the FCC’s RF exposure guidelines, place the equipment at least 20cm from nearby persons. Result: Compliant.

Note: The information marked # is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Customer model name, addresses, names, trademarks etc. are included. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP or any agency of the U.S. Government. This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “▼”. Bay Area Compliance Laboratories Corp. (Shenzhen) 5F(B-West) , 6F, 7F, the 3rd Phase of Wan Li Industrial Building D, Shihua Rd, FuTian Free Trade Zone, Shenzhen, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn TR-EM-RF011 Page 1 of 54 Version 1.0 (2023/10/07) TEST REPORT Applicant Name: NEXTSCAPE Inc. Address: 16 Floor, Toranomon Hills Moritower Building, 1-23-1 Toranomon Minato-ku, Tokyo, Japan Report Number: SZ1231225-78191E-RF FCC ID: 2BEZN-AL03GB00 IC: 32046-AL03GB00 Test Standard (s) FCC PART 15.247; RSS-GEN ISSUE 5, FEBRUARY 2021 AMENDMENT 2; RSS-247 ISSUE 3, AUGUST 2023 Sample Description Product Type: AlterLock Gen3 Model No.: AL03GB Multiple Model(s) No.: N/A Trade Mark: Date Received: 2024/01/25 Report Date: 2024/02/05 Test Result: Pass ▲ ▲ In the configuration tested, the EUT complied with the standards above. Prepared and Checked By: Approved By: Black Chen Nancy Wang RF Engineer RF Supervisor Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: SZ1231225-78191E-RF TR-EM-RF011 Page 2 of 54 Version 1.0 (2023/10/07) TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 4 GENERAL INFORMATION ....................................................................................................................................... 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 5 OBJECTIVE ................................................................................................................................................................... 5 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 TEST FACILITY ............................................................................................................................................................. 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 7 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 EUT EXERCISE SOFTWARE .......................................................................................................................................... 7 DUTY CYCLE ................................................................................................................................................................ 7 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 8 EXTERNAL I/O CABLE .................................................................................................................................................. 8 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 9 SUMMARY OF TEST RESULTS ............................................................................................................................. 10 TEST EQUIPMENT LIST ......................................................................................................................................... 11 FCC §1.1307(B) & 2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) ...................................................... 13 APPLICABLE STANDARD ............................................................................................................................................ 13 RSS-102 § 4 –EXPOSURE LIMITS ........................................................................................................................... 15 APPLICABLE STANDARD ............................................................................................................................................ 15 FCC §15.203 & RSS-GEN §6.8 – ANTENNA REQUIREMENT............................................................................ 17 APPLICABLE STANDARD ............................................................................................................................................ 17 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 17 FCC § 15.207 (A) & RSS-GEN §8.8 AC LINE CONDUCTED EMISSIONS ........................................................ 18 APPLICABLE STANDARD .....................................................................................................................................…

Text truncated - open the document above for the full version.

Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 Advanced Technology & Communications Alterlock_Antenna Report 2023.12.15 Antenna Model: 14-008-0128 AT&C TECHNOLOGIES(SHENZHEN)CO.,LTD. 201, Building C, Building 5, Skyworth Innovation Valley, Tangtou 1 Road, Tangtou Community, Shiyan Street, Bao'an District, Shenzhen Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 ● Alterlock Antenna Info（天线信息） 1.Type of the antenna（天线类型） : LDS 2.Placement of the antenna（天线位置） : as shown below（如下图示意） 3.The name of the antenna （天线名字）: ATC GEN-V3 4.Coverage （覆盖范围）:4G/WIFI/BLE/GPS LTE WIFI GPSBLE Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 ● Alterlock _Environmental Treatment（环境处理） 1.Extend the ground of the main board by increasing the copper skin .（通过贴铜皮的方式，延长主板地） 2.The copper skin is connected to the USB board using a copper wire .（铜皮使用铜线和USB板连接在一起） 3.By pasting conductive cloth, the shielding effect is increased .（通过粘贴导电布，增加屏蔽效果） ① ② ③ Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 ● Alterlock _Impedance Matching（天线阻抗匹配） LTE RFLTE RF Switch C4012nhC3010NH R154.7PFC290Ω C9NAC244.2NH R10ΩC18NA C7NAC21NA WIFI+BLE+GPS match remains unchanged Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 ● Alterlock LTE _S11/VSWR（LTE天线网分图） RF1 RF2 RF3 BANDFrequency RF1B1/B2/B3/B4/B8/B66880-960/1710-2175MHz RF2B5/B18/B19/B20790-890MHz RF3B12/B13/B28690-800MHz Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 7 ● Alterlock WIFI+BLE+GPS _S11/VSWR（WIFI+BLE+GPS天线网分图) WIFI BLE GPS Frequency WIFI2400-2500MHz BLE2400-2500MHz GPS1575MHz Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 8 ● Alterlock LTE _Performance : Efficiency & Gain（无源效率和增益） LTE-RF1 Passive Test ResultsLTE-RF2 Passive Test ResultsLTE-RF3 Passive Test Results Frequency(MHz)Efficiency(%)Max Gain(dBi)Frequency(MHz)Efficiency(%)Max Gain(dBi)Frequency(MHz)Efficiency(%)Max Gain(dBi) 88031%-1.6279023%-2.3369016%-3.64 89031%-1.5880025%-2.1770017%-3.40 90031%-1.8781026%-2.1471017%-3.31 91030%-2.0982027%-2.0772018%-3.17 92029%-2.0983029%-1.7273019%-3.04 93028%-2.1284029%-1.7674018%-3.12 94026%-2.4385029%-1.9575018%-3.18 95023%-3.0586027%-2.1876018%-3.19 96021%-3.4087025%-2.2977019%-3.10 171035%1.3388023%-2.7378019%-3.11 173036%1.6789020%-3.2479019%-3.03 175039%2.5080020%-2.82 177038%2.19 179040%2.54 181041%2.32 183044%2.64 185043%2.59 187040%2.43 189038%1.81 191036%2.02 193032%1.38 195032%1.32 197029%1.23 199028%0.57 211027%0.71 213027%0.94 215027%0.93 217025%0.87 1.switch on the ground foot and complete the piecewise through debugging and matching（690-960MHz的带宽对于天线来说太大了，所以需要在地脚上增加 一个开关，通过调试匹配分段完成） 2.The performance of the low-frequency antenna obtained by debugging the swi tch will decrease with the decrease of frequency（通过调试开关得到的低频天 线的性能会随着频率的降低而降低) Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 9 ● Alterlock WIFI/BLE/GPS _Performance : Efficiency & Gain（无源效率和增益） WiFi Passive Test ResultsBLE Passive Test ResultsGPS Passive Test Results Frequency(MHz)Efficiency(%)Max Gain(dBi)Frequency(MHz)Efficiency(%)Max Gain(dBi)Frequency(MHz)Efficiency(%)Max Gain(dBi) 240052%2.89240040%1.34156142%-0.032 241053%2.84241042%1.65157541%0.285 242054%2.84242043%1.91 243055%2.80243043%2.28 244057%2.91244043%2.45 245057%3.15245043%2.40 246056%3.35246042%2.35 247055%3.46247041%2.41 248054%3.62248040%2.34 249055%3.83249038%2.18 250054%3.82250035%1.79 Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 ● Alterlock GPS _Performance : GPS 实测结果 Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 E2 H E1 ● Alterlock LTE _Performance : 3D/2D Radiation Pattern（3D/2D辐射方向图） 1.Azimuth Pattern H-Plane（水平方向图为H平面） : “H”, X-Y plane 2.Elevation Pattern E1, E2-Plane（垂直方向图为E1, E2-平面） : “E1”, “E2”, X-Z plane(E1), Y-Z plane(E2) 3.It is a structure that supplements the distortion of the horizontal plane in the vertical plane and has a gentle sphere shape in three d imensions.（它是三维球面方向图，在二维水平和垂直的剖面） 880MHz 1710MHz 1810MHz 1910MHz Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 E2HE1 ● Alterlock WIFI _Performance : 3D/2D Radiation Pattern（3D/2D辐射方向图） 1.Azimuth Pattern H-Plane（水平方向图为H平面） : “H”, X-Y plane 2.Elevation Pattern E1, E2-Plane（垂直方向图为E1, E2-平面） : “E1”, “E2”, X-Z plane(E1), Y-Z plane(E2) 3.It is a structure that supplements the distortion of the horizontal plane in the vertical plane and has a gentle sphere shape in three d imensions.（它是三维球面方向图，在二维水平和垂直的剖面） 2450MHz Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 E2HE1 ● Alterlock BLE _Performance : 2D Radiation Pattern（2D辐射方向图） 1.Azimuth Pattern H-Plane（水平方向图为H平面） : “H”, X-Y plane 2.Elevation Pattern E1, E2-Plane（垂直方向图为E1, E2-平面） : “E1”, “E2”, X-Z plane(E1), Y-Z plane(E2) 3.It is a structure that supplements the distortion of the horizontal plane in the vertical plane and has a gentle sphere shape in three d imensions.（它是三维球面方向图，在二维水平和垂直的剖面） 2450MHz Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 E2HE1 ● Alterlock GPS _Performance : 2D Radiation Pattern（2D辐射方向图） 1.Azimuth Pattern H-Plane（水平方向图为H平面） : “H”, X-Y plane 2.Elevation Pattern E1, E2-Plane（垂直方向图为E1, E2-平面） : “E1”, “E2”, X-Z plane(E1), Y-Z plane(E2) 3.It is a structure that supplements the distortion of the horizontal plane in the vertical plane and has a gentle sphere shape in three d imensions.（它是三维球面方向图，在二维水平和垂直的剖面） 1575MHz Confidential ⓒ2015 AT&C Corporation All Rights Reserved 개정일 : 15.11.16 - V1.0 ● Alterlock Antenna Summary（天线总结） 1. The performance of the antenna is basically OK.（天线性能基本达标） 2. Pay attention to the environmental treatment of the antenna（注意天线的环境处理） 3. TheThe low frequency 690-800MHz/790-890MHz is achieved through switch debugging matching, so the antenna performan ce will be attenuated（低频690-800MHz/790-890…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 1 of 3 EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions - Front View Conducted Emissions - Side View Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 2 of 3 Radiated Emissions View (Below 30MHz) Radiated Emissions View (Below 1 GHz) Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1231225-78191E-RF Page 3 of 3 Radiated Emissions View (Above 1 GHz)
