TV SOUND-DT20S Speaker accessories: Conponents function description Infrared remote control function Wireless function NOTE: short press “炜瀲” button to volume adjustment, long press "炜瀲" button to the preview/next songs. USER MANUAL TV SOUND-DT20S USER MANUAL User manual*1 Power adapter*1 1. Volume up/previous song 3. Music play/pause button 5. Power on/off button 7.DC12V IN interface 9. Coaxial digital audio input socket 11.U-disk/USB interface 2. Volume down/next song Sleep/Wake Udisk mode Volume up Previous song Volume down HDMI ARC mode Treble adjustment Silent AUX input mode Play/pause Next song Coaxial digital audio input mode Scene sound effect selection Bass adjustment Please put in two AAA batterys before use NOTE: 1.Please use the treble and bass adjustment kevs with caution, over-adjustment may cause sound distortion, you can press the scene sound effect mode key(MOVE/MUSIC/DIALOG) to reset. 2.Without disconnecting the power, the speaker will remember the mode before the last shutdown when it is turned on next time. 3.In COAX/HDMIARC/AUX modes, the button has no function, press button is the mute function. 4. Mode switching button 6. Indicator light 8. 3.5 mmAUX input socket 10. HDMlARC input interface 12. Wall-mount Dimension Coaxial audio cable*1 3.5mm AUX cable*1 Remote control*1 52mm        “ ” “ ” 1. When the speaker is used for the first time, after the speaker is connected to the power adapter, it will automatically turn on and enter to wireless mode, the blue light will be flashing , and accompanied by voice prompt. then the speaker has been in standby search status. 2.Open the phone's wireless function, searched the speaker's wireless name : "SOUND-DT20L" and paired, when the speaker connected successfully, a promot sound will beep, at the same time, the blue liaht stop flashing, you can start using the speaker to play music ; the next time with the same device matching, the speaker will automatically to connected. DC IN AUX COAX HDMI ARC USB DC IN AUX COAX HDMI ARC USB DC IN AUX COAX HDMI ARC USB Speaker connect to TV'S SPDIF/ COAXIAL interface Coaxial COAXIAL INPUT MODE 1. As shown, use the coax audio cable connected your device and the speaker. 2. in the boot state ,you can press the "COAX" button on the remote control enter to the coaxial mode or press the mode switching button once to the coaxial audio mode on speaker, at the speaker changed successful you can hear the voice prompt of this mode and the indicator light is red. 3. Set sound source output from your TV first (setting--sound advanced audio output select digital audio output) . 4. Short press “+” “-” button to volume up/down. 5. Short press “ ” button to mute. NOTE: Please select audio source output of the TV, can not be used directly. DC IN AUX COAX HDMI ARC USB Connect the TV’s HDMI ARC interface HDMI ARC INPUT MODE ARC Tips: 1. The HDMl ARC interface of the speaker must be connected to the TV’S HDMl ARC (the interface with audio return function). if it is a normal HDMI interface, it may not be used to connect the speaker. 2. Please use the HDMl cable in the TV accessories or other high-quality HDMI cables, Low-quality HDMl cables may not be available. 3.Due to the different processing chips of the TV, the response time of the HDMl mode may be different. so some TVs use the HDMl interface to connect to the speakers for the first time, the sound output time may be delayed by about 10 seconds. please know that. thanks! 1. In the boot state .as shown, use the HDMl audio cable connected your device and the speaker. 2. You can press the "HDMI" button on the remote control enter to the HDMl mode or press the mode switching button twice to the HDMl audio mode on speaker. at the speaker changed successful you can hear the voice prompt and the indicator light is purple. 3. Set digital audio output from your TV first (setting--sound advanced audio output select HDMl ARC audio output) . 4. Short press “+” “-” button to volume up/down. 5. Short press “ ” button to mute. NOTE: Please select audio source output of the TV, can not be used directly. Play Udisk function In the boot state, when inserted the Udisk, the speaker will automatically converted to Udisk mode, and with a prompt voice, the music will be played automatically after In the boot state, the external devices (such as mobile phones, computers/MP3 and other audio output devices) with the 3.5mm audio cable connected to the speaker, this time the speaker will automatically switch to the AUX input mode, there will be a tone, then the speaker can play the audio from the device. 2 seconds, short press “炜瀲” button to volume adjustment, long press "炜瀲" button to the preview/next songs. NOTE: the Udisk must have Mp3 audio files or WAV format files . External audio AUX input function Audio output from Mobile Phones Audio output from TV or Other Devices Using the environment and storage environment 1. Operating environment Temperature: 0 ~ 40 DEG C, humidity: 0% ~ 85%RH 2. Storage environment Temperature -30 ~ 60 DEG C, humidity:0% ~ 90%RH Troubleshooting 1.No sound in HDMI ARC mode Please confirm the speaker whether HDMl mode is currently entered ,press the “HDMI" button of the remote control to enter the coaxial mode; short press the “M” button to enter the HDMl mode, when the speaker enter to HDMl mode ,the indicator light will turn purple and you can hear the voice prompt. Set digital audio output from your TV first (setting--sound advanced audio output-select HDMl ARC output) , devices compatibility will be vary, see your device's documentation for more information to set. Please read carefully the precautions in the manual about the HDMlARC function. 2.No sound in Coaxial audio mode Please confirm the speaker whether Coaxial mode is currently entered ,press the “COAX" button of the remote control to enter the coaxial mode ; short press the “M” button to enter the coaxial mode, when the speaker enter to COAX mode ,the indica…
