2BF3S-FS-R306Portable Wireless Speaker System

1. > : Press briefly to play the previous song; in FM mode, press briefly to switch to the previous channel. 2. : Press and hold this button to turn on, press and hold again to turn off. 3. : Rotate to adjust volume. During music playback, press down to pause, press again to resume. 4. : In other modes, press briefly to enter BT mode. In Parámetro 1234 67 5 8910 Portable Wireless Speaker System Model: FS-306 Operation Manual Button function description. Functional panel diagram BT mode, press briefly to search for and pair with another speaker in TWS mode. Press and hold to disconnect BT. 5. < : Press briefly to play the next song; in FM mode, press briefly to switch to the next channel. 6. M : When powered on, automatically enters BT mode. Press to cycle through USB-FM-AUX modes, press again to return to BT. In any mode, USB playback takes priority if a USB drive is inserted. 7. : While playing music, press and hold to cycle through 7 lighting display modes. 8. LINE IN auxiliary port. 9. USB input. 10.AC charging cable input 120-220V 50/60Hz Specifications Accessories Speaker Size: 5.25 "+2.25 "x2 Frequency Response: 40Hz-20KHz S/N Ratio:≥78dB Output Power: 60W+15Wx2 Power: IN 120-220V 50/60Hz Battery Capacity:7.4V 8000mAh It can play for 17 hours. Power cable 1 pc Instruction manual 1 pc FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

Dongguan Faraoou Electric Appliance Co., Ltd No. 46, Chang'antang Village, Dongkeng Town Dongguan, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2026/04/14 U.S. Agent Designation Dongguan Faraoou Electric Appliance Co., Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID:2BF3S-FS-R306): Name and company of U.S. agent: GLOCERTS TECHNOLOGY INC Physical U.S. address of agent: 19784 SUNKISSED RIDGE DR RIVERSIDE, CA 92507 United States FRN of U.S. agent: 0036339737 Phone of U.S. agent: (626) 588-8039 Email address of U.S. agent: [email protected] GLOCERTS TECHNOLOGY INC acknowledges their obligation to accept service of process on behalf of Dongguan Faraoou Electric Appliance Co., Ltd with the FRN [0035336080] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. An expiration date for this letter does not exist. Sincerely, Signature Vivian Li Manager Dongguan Faraoou Electric Appliance Co., Ltd Signature Huiying Fan Director GLOCERTS TECHNOLOGY INC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

FCC ID:2BF3S-FS-R306 External Photos of the EUT FCC ID:2BF3S-FS-R306 FCC ID:2BF3S-FS-R306

Label and Location Size: L: 4.0cm*W: 3.0cm Label and Location FCC ID : 2BF3S-FS-R306

FCC ID:2BF3S-FS-R306 Internal Photos of the EUT FCC ID:2BF3S-FS-R306 FCC ID:2BF3S-FS-R306 FCC ID:2BF3S-FS-R306 FCC ID:2BF3S-FS-R306 FCC ID:2BF3S-FS-R306 BT ANT

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure evaluation Report Reference No. ..................... : FCC ID............................................. : CTA26040101202 2BF3S-FS-R306 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Apr. 10, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : Dongguan Faraoou Electric Appliance Co., Ltd Address............................................ : No. 46, Chang'antang Village, Dongkeng Town Dongguan, China Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Portable Wireless Speaker System Trade Mark ....................................... : , Manufacturer .................................... : Dongguan Faraoou Electric Appliance Co., Ltd Model/Type reference ...................... : FS-R306 Listed Models ................................... : FS-R306M, FS-R360L, FS-R306LM Rating ............................................... : Input: 120-220V~, 50/60Hz Battery: 7.4V 8000mAh Result ............................................... : PASS Report No.: CTA26040101202 Page 2 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Portable Wireless Speaker System Model /Type : FS-R306 Listed Models : FS-R306M, FS-R360L, FS-R306LM Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. Applicant : Dongguan Faraoou Electric Appliance Co., Ltd Address : No. 46, Chang'antang Village, Dongkeng Town Dongguan, China Manufacturer : Dongguan Faraoou Electric Appliance Co., Ltd Address : No. 46, Chang'antang Village, Dongkeng Town Dongguan, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26040101202 Page 3 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks ..................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................. 5 2.4 Modifications ............................................................................................................ 5 3 TEST ENVIRONMENT ....................................................................................................... 6 3.1 Address of the test laboratory .................................................................................. 6 3.2 Test Facility .............................................................................................................. 6 3.3 Statement of the measurement uncertainty ............................................................. 6 4 Test limit .............................................................................................................................. 7 4.1 Requirement ............................................................................................................ 7 4.2 Conducted Power Results ....................................................................................... 7 4.3 Manufacturing tolerance .......................................................................................... 7 4.4 Evaluation Result ..................................................................................................... 8 4.5 Simultaneous Transmission for SAR Exclusion ...................................................... 8 5 Conclusion ........................................................................................................................... 8 Report No.: CTA26040101202 Page 4 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuha…

Text truncated - open the document above for the full version.

1 FCC Appendix RF Test Data for BT FCC ID : 2BF3S-FS-R306 Company : Dongguan Faraoou Electric Appliance Co., Ltd EUT : Portable Wireless Speaker System Model Number : FS-R306 Report No. : CTA26040101201 Reviewed By : Eric Wang 2 Appendix A: 20dB Emission Bandwidth Test Result TestMode Antenna Freq(MHz) 20dB EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.951 2401.547 2402.498 --- --- 2441 0.954 2440.541 2441.495 --- --- 2480 0.942 2479.550 2480.492 --- --- 2DH5 Ant1 2402 1.284 2401.376 2402.660 --- --- 2441 1.284 2440.379 2441.663 --- --- 2480 1.332 2479.346 2480.678 --- --- 3 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 4 2DH5_Ant1_2402 2DH5_Ant1_2441 5 2DH5_Ant1_2480 6 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.87705 2401.5734 2402.4505 --- --- 2441 0.86673 2440.5776 2441.4443 --- --- 2480 0.86501 2479.5751 2480.4401 --- --- 2DH5 Ant1 2402 1.1818 2401.4157 2402.5975 --- --- 2441 1.1864 2440.4159 2441.6023 --- --- 2480 1.1941 2479.4139 2480.6080 --- --- 7 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 8 2DH5_Ant1_2402 2DH5_Ant1_2441 9 2DH5_Ant1_2480 10 Appendix C: Maximum conducted output power Test Result Peak Test Mode Antenna Freq(MHz) Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict DH5 Ant1 2402 0.06 ≤20.97 PASS 2441 -0.51 ≤20.97 PASS 2480 -0.75 ≤20.97 PASS 2DH5 Ant1 2402 -0.86 ≤20.97 PASS 2441 -1.35 ≤20.97 PASS 2480 -1.60 ≤20.97 PASS 11 Appendix D: Carrier frequency separation Test Result TestMode Antenna Freq(MHz) Result[MHz] Limit[MHz] Verdict DH5 Ant1 Hop 1.004 ≥0.954 PASS 2DH5 Ant1 Hop 1.244 ≥0.888 PASS 12 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 13 Appendix E: Time of occupancy Test Result TestMode Antenna Freq(MHz) BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH1 Ant1 Hop 0.405 318 0.129 ≤0.4 PASS DH3 Ant1 Hop 1.662 164 0.273 ≤0.4 PASS DH5 Ant1 Hop 2.910 103 0.3 ≤0.4 PASS 2DH1 Ant1 Hop 0.415 317 0.132 ≤0.4 PASS 2DH3 Ant1 Hop 1.668 164 0.274 ≤0.4 PASS 2DH5 Ant1 Hop 2.916 104 0.303 ≤0.4 PASS 14 Test Graphs DH1_Ant1_Hop DH3_Ant1_Hop 15 DH5_Ant1_Hop 16 2DH1_Ant1_Hop 2DH3_Ant1_Hop 17 2DH5_Ant1_Hop 18 19 Appendix F: Number of hopping channels Test Result TestMode Antenna Freq(MHz) Result[Num] Limit[Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 20 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 21 Appendix G: Band edge measurements Test Result TestMode Antenna ChName Freq(MHz) RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 -1.06 -57.32 ≤-21.06 PASS High 2480 -1.14 -52.39 ≤-21.14 PASS Low Hop_2402 -4.51 -53.59 ≤-24.51 PASS High Hop_2480 -5.77 -57.55 ≤-25.77 PASS 2DH5 Ant1 Low 2402 -5.47 -56.95 ≤-25.47 PASS High 2480 -4.57 -57.22 ≤-24.57 PASS Low Hop_2402 -7.73 -58.76 ≤-27.73 PASS High Hop_2480 -7.52 -57.79 ≤-27.52 PASS 22 Test Graphs DH5_Ant1_Low_2402 DH5_Ant1_High_2480 DH5_Ant1_Low_Hop_2402 23 DH5_Ant1_High_Hop_2480 2DH5_Ant1_Low_2402 24 2DH5_Ant1_High_2480 2DH5_Ant1_Low_Hop_2402 2DH5_Ant1_High_Hop_2480 25 26 Appendix H: Conducted Spurious Emission Test Result TestMode Antenna Freq(MHz) FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 Reference -1.07 -1.07 --- PASS 30~1000 -1.07 -67.98 ≤-21.07 PASS 1000~26500 -1.07 -43.44 ≤-21.07 PASS 2441 Reference -1.70 -1.70 --- PASS 30~1000 -1.70 -55.93 ≤-21.7 PASS 1000~26500 -1.70 -46.57 ≤-21.7 PASS 2480 Reference -2.13 -2.13 --- PASS 30~1000 -2.13 -59.04 ≤-22.13 PASS 1000~26500 -2.13 -44.56 ≤-22.13 PASS 2DH5 Ant1 2402 Reference -7.20 -7.20 --- PASS 30~1000 -7.20 -54.4 ≤-27.2 PASS 1000~26500 -7.20 -49.48 ≤-27.2 PASS 2441 Reference -5.98 -5.98 --- PASS 30~1000 -5.98 -59.4 ≤-25.98 PASS 1000~26500 -5.98 -47.74 ≤-25.98 PASS 2480 Reference -6.42 -6.42 --- PASS 30~1000 -6.42 -58.69 ≤-26.42 PASS 1000~26500 -6.42 -48.08 ≤-26.42 PASS 27 Test Graphs DH5_Ant1_2402_0~Reference DH5_Ant1_2402_30~1000 DH5_Ant1_2402_1000~26500 28 DH5_Ant1_2441_0~Reference DH5_Ant1_2441_30~1000 29 DH5_Ant1_2441_1000~26500 DH5_Ant1_2480_0~Reference DH5_Ant1_2480_30~1000 30 DH5_Ant1_2480_1000~26500 2DH5_Ant1_2402_0~Reference 31 2DH5_Ant1_2402_30~1000 2DH5_Ant1_2402_1000~26500 2DH5_Ant1_2441_0~Reference 32 2DH5_Ant1_2441_30~1000 2DH5_Ant1_2441_1000~26500 33 2DH5_Ant1_2480_0~Reference 2DH5_Ant1_2480_30~1000 2DH5_Ant1_2480_1000~26500 34 35 Appendix I: Duty Cycle Test Result TestMode Antenna Freq(MHz) ON Time [ms] Period [ms] DC [%] xFactor Limit Verdict DH5 Ant1 2402 2.92 3.76 77.66 1.10 --- --- 2441 2.91 3.75 77.60 1.10 --- --- 2480 2.92 3.76 77.66 1.10 --- --- 2DH5 Ant1 2402 2.92 3.75 77.87 1.09 --- --- 2441 2.92 3.75 77.87 1.09 --- --- 2480 2.91 3.75 77.60 1.10 --- ---

36 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 37 2DH5_Ant1_2402 2DH5_Ant1_2441 38 2DH5_Ant1_2480 39 Appendix J: Emissions in Restricted Bands Test Result TestMode Antenna ChName Freq(MHz) Detector Freq [MHz] Result [dBm] Gain [dB] DC Factor [dB] Result [dBuV/m] Limit [dBuV/m] Verdict DH5 Ant1 Low 2402 AV 2310.000 -59.69 2.00 1.10 38.61 ≤54 PASS AV 2388.305 -58.55 2.00 1.10 39.75 ≤54 PASS AV 2390.000 -59.69 2.00 1.10 38.61 ≤54 PASS Peak 2310.000 -51.9 2.00 0.00 45.30 ≤74 PASS Peak 2370.245 -48.73 2.00 0.00 48.47 ≤74 PASS Peak 2390.000 -50.91 2.00 0.00 46.29 ≤74 PASS High 2480 AV 2483.500 -58.53 2.00 1.10 39.77 ≤54 PASS AV 2484.400 -58 2.00 1.10 40.30 ≤54 PASS AV 2500.000 -59 2.00 1.10 39.30 ≤54 PASS Peak 2483.500 -49.83 2.00 0.00 47.37 ≤74 PASS Peak 2485.120 -47.53 2.00 0.00 49.67 ≤74 PASS Peak 2500.000 -50.56 2.00 0.00 46.64 ≤74 PASS 2DH5 Ant1 Low 2402 AV 2310.000 -60.97 2.00 1.09 37.32 ≤54 PASS AV 2363.420 -58.66 2.00 1.09 39.63 ≤54 PASS AV 2390.000 -59.53 2.00 1.09 38.76 ≤54 PASS Peak 2310.000 -52.09 2.00 0.00 45.11 ≤74 PASS Peak 2374.340 -47.33 2.00 0.00 49.87 ≤74 PASS Peak 2390.000 -51.42 2.00 0.00 45.78 ≤74 PASS High 2480 AV 2483.500 -58.66 2.00 1.10 39.64 ≤54 PASS AV 2499.840 -58.3 2.00 1.10 40.00 ≤54 PASS AV 2500.000 -59.22 2.00 1.10 39.08 ≤54 PASS Peak 2483.500 -50.22 2.00 0.00 46.98 ≤74 PASS Peak 2493.600 -48.54 2.00 0.00 48.66 ≤74 PASS Peak 2500.000 -52.09 2.00 0.00 45.11 ≤74 PASS Note： The limit in dBm for average detector is conversion from 54dBuV/m, according to 15.209(a). The limit in dBm for peak detector is 20dB above the limit of average detector in dBm. 40 Test Graphs DH5_Ant1_Low_2402_AV DH5_Ant1_Low_2402_Peak DH5_Ant1_High_2480_AV 41 DH5_Ant1_High_2480_Peak 2DH5_Ant1_Low_2402_AV 42 2DH5_Ant1_Low_2402_Peak 2DH5_Ant1_High_2480_AV 2DH5_Ant1_High_2480_Peak 43

Inverted F Antenna Specification Summary ANT SPECITEM 2.4G ANTModel Name VerticalHorizontal 2500MHz2400MHz2500MHz2400MHz Center Frequency -1.86-2.46-5.25-0.58-0.76-1.26 -0.58dBiMAX. Gain Horizontal and VerticalPolarization Azimuth Beam Pattern Omni-directional 50 OhmImpedance 38.20mmAntenna Length Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Address No. 333 Kexing Road, Xiangzhou District, Zhuhai City 2450MHz2450MHz Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dBi) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dBi) Frequency (MHz) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 -1.86120 -29.5214 -9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd.

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. ........................................... : CTA26040101201 2BF3S-FS-R306 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Apr. 10, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : Dongguan Faraoou Electric Appliance Co., Ltd Address ............................................ : No. 46, Chang'antang Village, Dongkeng Town Dongguan, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Portable Wireless Speaker System Trade Mark ....................................... : , Manufacturer .................................... : Dongguan Faraoou Electric Appliance Co., Ltd Model/Type reference ...................... : FS-R306 Listed Models ................................... : FS-R306M, FS-R360L, FS-R306LM Modulation ....................................... : GFSK, Π/4DQPSK Frequency ........................................ : From 2402MHz to 2480MHz Ratings ............................................. : Input: 120-220V~, 50/60Hz Battery: 7.4V 8000mAh Result ............................................... : PASS Report No.: CTA26040101201 Page 2 of 41 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Portable Wireless Speaker System Model /Type : FS-R306 Listed Models : FS-R306M, FS-R360L, FS-R306LM Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. Applicant : Dongguan Faraoou Electric Appliance Co., Ltd Address : No. 46, Chang'antang Village, Dongkeng Town Dongguan, China Manufacturer : Dongguan Faraoou Electric Appliance Co., Ltd Address : No. 46, Chang'antang Village, Dongkeng Town Dongguan, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26040101201 Page 3 of 41 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description ........................................................................................................................... 5 2.3 Equipment Under Test ....................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ...................................................................... 5 2.5 EUT configuration .............................................................................................................................. 5 2.6 EUT operation mode ......................................................................................................................... 6 2.7 Block Diagram of Test Setup ............................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) ......................................................................................................... 6 2.9 Modifications ...................................................................................................................................... 6 3 TEST ENVIRONMENT ................................................................................................................................. 7 3.1 Address of the test laboratory ........................................................................................................... 7 3.2 Test Facility........................................................................................................................................ 7 3.3 Environmental conditions ..…

Text truncated - open the document above for the full version.

FCC ID:2BF3S-FS-R306 Test Setup Photos of the EUT FCC ID:2BF3S-FS-R306
