2BF4LM4042XDUAV with built-in a WLAN IEEE802.11 b/g/n chipset used for Remote ID operation

1 EBEE VISION - USER MANUAL VERSION 3.4.3 | 07.2024 AGEAGLE | ROUTE DE GENÈVE 38, 1033 CHESEAUX-SUR-LAUSANNE, SWITZERLAND eBee VISION - User manual 2024-08-06 Version 3.4.3 2 TABLE OF CONTENTS 1 eBee VISION system description .............................................................................................................................................................. 6 1.1 DRONE ............................................................................................................................................................................................................................. 6 1.2 GCS ................................................................................................................................................................................................................................ 7 1.3 PAYLOAD.........................................................................................................................................................................................................................8 1.4 COLLECTED DATA ........................................................................................................................................................................................................9 1.4.1 SD CARD ................................................................................................................................................................................................................................... 9 1.4.2 GCS INTERNAL MEMORY ................................................................................................................................................................................................... 9 2 System assembly and disassembly .....................................................................................................................................................9 2.1 DRONE .............................................................................................................................................................................................................................9 2.1.1 BATTERY ASSEMBLY................................................................................................................................................................................................................ 9 2.1.2 WINGS ASSEMBLY ................................................................................................................................................................................................................ 12 2.1.3 BATTERY DISASSEMBLY ..................................................................................................................................................................................................... 14 2.1.4 WINGS DISASSEMBLY ........................................................................................................................................................................................................ 15 2.2 GCS ............................................................................................................................................................................................................................. 17 2.2.1 SHORT RANGE ANTENNA ASSEMBLY ............................................................................................................................................................................ 17 2.2.2 SHORT RANGE SETUP DISASSEMBLY .......................................................................................................................................................................... 19 2.2.3 ULTRA COMPACT ANTENNA SETUP ASSEMBLY ....................................................................................................................................................... 21 2.2.4 ULTRA COMPACT ANTENNA SETUP DISASSEMBLY .............................................................................................................................................. 25 2.2.5 EXTERNAL ANTENNA SETUP ASSEMBLY..................................................................................................................................................................... 26 2.2.6 EXTERNAL ANTENNA SETUP DISASSEMBLY .............................................................................................................................................................. 30 2.3 BATTERIES ................................................................................................................................................................................................................... 33 2.3.1 DRONE BATTERY ................................................................................................................................................................................................................. 33 2.3.1.1 DRONE BATTERY PROPERTIES ..................................................................................................................................................................................... 33 2.3.1.2 DRONE BATTERY CHARGING ..................................................................................................................................................................................... 33 2.3.1.3 DRONE BATTERY STORAGE ........................................................................................................................................................................................ 35 2.3.2 GCS BATTERY ................................................................................................................................................................................................................... 36 2.3.2.1 GCS BATTERY PROPERTIES .......................................................…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: 2BF4LM4042XD To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the supplier Declaration of Conformity procedure to the Class B digital devices portion of this composite filing. Note: We understand that devices subject to the SDoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to- government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telecom MRA are not recognized by the FCC to test for the SDoC procedure. Regards, Date: June 18, 2024 By Brent Pope, EVP of Operations

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 18 2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BF4LM4042XD AgEagle Aerial Systems (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, AgEagle Aerial Systems Brent Pope, EVP of operations

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 18 2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BF4LM4042XD AgEagle Aerial Systems (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, AgEagle Aerial Systems Brent Pope, EVP of operations

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 18-2024 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code: 2BF4LM4042XD AgEagle Aerial Systems (“the applicant”) certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0035338482 Name: AgEagle Aerial Systems Address: 8201 E 34th St n Ste 1307 67226 Wichita – Kansas Contact Person: Brent Pope Tel.: 316 202 2533 Email: [email protected] Sincerely, AgEagle Aerial Systems Brent Pope, EVP of operations

Attn: TIMCO Engineering Inc. 13146 NW 86 th Drive Suite 400 Alachua, FL 32615 Confidentiality Request regarding application for certification of FCC ID: 2BF4LM4042XD Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Operational Description Schematics BlkDia_eBee VISION.pdf BlkDia_radio_eBee VISION.pdf BlkDia_WLAN_eBee VISION.pdf OpsDes_eBee VISION.pdf Schem_eBee VISION.zip The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Internal photos IntPho_eBee VISION.zip For 180 days pursuant to KDB 726920 D01. Sincerely, June 18, 2024 By Brent Pope EVP of Operations

Attn: TIMCO Engineering Inc. 13146 NW 86 th Drive Suite 400 Alachua, FL 32615 Authority to Act as Agent FCC ID: 2BF4LM4042XD IC ID: 32643-M4042XD On our behalf, I appoint M. Thomas LEDRESSEUR from Emitech Chassieu, 7 rue Georges MELIES, 69680 Chassieu FRANCE, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by TIMCO Engineering Inc., still resides with senseFly SA. This authorization is valid until further written notice from senseFly SA. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862.” June 18, 2024 By Brent Pope, EVP of Operations

Final result

S 51 RTY 000 EMF 00006 [ 0 4 ] Siège Social : Emitech – 3 avenue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES B 344 545 645 - APE 7112B REM-EMIESS24B405SEN-03Av0 MPE test report According to the standard: CFR 47 FCC PART 15 Equipment under test: Fixed Wing –UAV eBee VISION FCC ID: 2BF4LM4042XD Company: senseFly LTD Distribution: Mr RENARD (Company: senseFly LTD) Number of pages: 8 Technical Verification and Quality Approval Ed. Date Modified Page(s) Name and Function Visa 0 22-Jul-24 Creation J.C. BOGA, Laboratories Manager Duplication of this document is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. Information in italics are declared by the manufacturer/customer and are under his responsibility REM-EMIESS24B405SEN-03Av0 Page 2/8 DESIGNATION OF PRODUCT: Fixed Wing - UAV Serial number (S/N): 1587A50001 Reference / model (P/N): eBee VISION Firmware version: Master1360 Trade Mark: AgEagle MANUFACTURER: senseFly LTD COMPANY CERTIFYING THE PRODUCT: Company: AgEagle Aerial Systems Address: 8201 E 34th St N Ste 1307 Wichita, KS 67226 United States Responsible: Mr POPE COMPANY SUBMITTING THE PRODUCT: Company: senseFly LTD Address: Route de Genève 38 1033 Cheseaux sur Lausanne Switzerland Responsible: Mr RENARD Persons present during the tests: Mr RUCHAT (first day) DATE(S) OF TEST: From 18-Mar-24 to 25-Mar-24 TESTING LOCATION: EMITECH LYON laboratory at CHASSIEU (69) FRANCE FCC Accredited under US-EU MRA Designation Number: FR0013 Test Firm Registration Number: 807590 TESTED BY: T. LEDRESSEUR VISA: WRITTEN BY: T. LEDRESSEUR REM-EMIESS24B405SEN-03Av0 Page 3/8 CONTENTS TITLE PAGE 1. INTRODUCTION ....................................................................................................................................... 4 2. PRODUCT DESCRIPTION ....................................................................................................................... 5 3. NORMATIVE REFERENCE ...................................................................................................................... 7 4. RF EXPOSURE ......................................................................................................................................... 7 REVISIONS HISTORY Revision Date Modified pages Modifications 0 16-Jul-24 / Creation REM-EMIESS24B405SEN-03Av0 Page 4/8 1. INTRODUCTION This report presents the results of radio test carried out on the following radio equipment: eBee Vision, in accordance with normative reference. The equipment under test integrates:  Wi-Fi 2.4 GHz transceiver radio function not already certified,  Proprietary transceiver radio module already certified at 2.4 GHz (pMDDL2450),  GNSS multifrequencies receiver. This report concerns only Wi-Fi radio part. The Wi-Fi functions possess four identical antennas identified as: Front Left, Front Right, Back Left, Back Right The product can only emit on the two chains simultaneously among: - Front Left + Front Right - Rear Left + Rear Right - Front Left + Rear Left - Front Right + Rear Right On the report the different configuration are defined as follow: - Front Left + Front Right => Front - Back Left + Back Right => Back - Front Left + Back Left => Left - Front Right + Back Right => Right REM-EMIESS24B405SEN-03Av0 Page 5/8 2. PRODUCT DESCRIPTION Class: B Utilization: Residential Power source: 12 – 17.6 Vdc by internal battery During the charge of the battery the product is not functional. Wi-Fi characteristics Antenna type and gain: (2.14 dBi) 4 integral identical antennas: PCB antennas Front Left, Front Right, Back Left, Back Right Directionnal gain: For power measurements: 2.14 dBi For PSD measurements: 5.14 dBi Operating frequency range: From 2412 MHz to 2462 MHz Number of channels: 11 Channel spacing: 5 MHz Channel bandwidth: 20 MHz Power setting 24 dBm Modulation: DBPSK OFDM: BPSK OFDM: 64-QAM Mode tested: 802.11b 802.11g 802.11n Data rate tested: For 802.11b: 1Mbit/s For 802.11g: 6Mbit/s For 802.11n: MCS0 Channel tested: Channel 1: 2412 MHz Channel 6: 2437 MHz Channel 11: 2462 MHz Correlated signal: For mode b/g/n the signals are considered as correlated, the mode cyclic delay diversity (CDD) is used. (IEEE 802.11) The product is not using spatial multiplexing or intentional beamforming. REM-EMIESS24B405SEN-03Av0 Page 6/8 pMDDL2450 characteristics Operational Frequency band used: Band from 2400 MHz to 2483.5 MHz (a) Nominal Channel bandwidth: 4 MHz Nominal Operating Frequencies: Sample N°= 1  2405 MHz Limited tests (Lowest channel) Sample N°= 1  2440 MHz Limited tests (Middle channel) Sample N°= 1  2479 MHz Limited tests (Highest channel) Maximum antenna gain used with the equipment: 2.12 dBi (declared by the applicant) Power level, frequency range and channels characteristics are not user adjustable. The details pictures of the product and the circuit boards are joined with this file. REM-EMIESS24B405SEN-03Av0 Page 7/8 3. NORMATIVE REFERENCE The standards and testing methods related throughout this report are those listed below. They are applied on the whole test report even though the extensions (version, date and amendment) are not repeated. CFR 47 (2024) Radio Frequency Devices ANSI C63.10 2013 Procedures for ComplianceTesting of Unlicensed Wireless Devices. 447498 D01 General RF RF Exposure procedures and equipment authorization policies for mobile and Exposure Guidance v06 portable equipment 447498 D04 Interim General RF Exposure Pocedures and Equipment Authorization Policies for Mobile and RF Exposure Guidance v01 Portable D…

Text truncated - open the document above for the full version.

Siège Social : Emitech - 3, rue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES 344 545 645 - APE 7112B S51 RTY 000 INT 00015 [ 04] RRA-EMIESS24B405SEN-05Av0 Certification Radio test report According to the standard: CFR 47 FCC PART 15 RSS GEN – Issue 5 RSS 247 – Issue 3 Equipment under test: Fixed Wing –UAV eBee VISION FCC ID: 2BF4LM4042XD IC NUMBER: 32643-M4042XD Company: senseFly LTD Distribution: Mr RENARD (Company: senseFly LTD) Number of pages: 125 with 2 appendixes Technical Verification and Quality Approval Ed. Date Modified Page(s) Name and Function Visa 0 22-Jul-24 Creation J.C. BOGA, Laboratories Manager Duplication of this document is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. Information in italics are declared by the manufacturer/customer and are under his responsibility LIST OF ACCREDITED SITES AND SCOPE AVALAIBLE ON WWW.COFRAC.FR TESTING ACCREDITATIONS N° 1-0826, 1-0827, 1-1925, 1-2069,1-2070, 1-2206, 1-2376 & 1-6086 RRA- SS24B405SEN-05Av0 Page 2/125 DESIGNATION OF PRODUCT: Fixed Wing - UAV Serial number (S/N): 1587A50001 Reference / model (P/N): eBee VISION Firmware version: Master1360 Trade Mark: AgEagle MANUFACTURER: senseFly LTD COMPANY CERTIFYING THE PRODUCT: Company: AgEagle Aerial Systems Address: 8201 E 34th St N Ste 1307 Wichita, KS 67226 United States Responsible: Mr POPE COMPANY SUBMITTING THE PRODUCT: Company: senseFly LTD Address: Route de Genève 38 1033 Cheseaux sur Lausanne Switzerland Responsible: Mr RENARD Persons present during the tests: Mr RUCHAT (first day) DATE(S) OF TEST: From 18-Mar-24 to 25-Mar-24 TESTING LOCATION: EMITECH LYON laboratory at CHASSIEU (69) FRANCE FCC Accredited under US-EU MRA Designation Number: FR0013 Test Firm Registration Number: 807590 ISED Accredited under CANADA-EU MRA Designation Number: FR0007 Industry Canada Registration Number: 4379D TESTED BY: T. LEDRESSEUR VISA: WRITTEN BY: T. LEDRESSEUR RRA- SS24B405SEN-05Av0 Page 3/125 CONTENTS TITLE PAGE 1. INTRODUCTION ....................................................................................................................................... 4 2. PRODUCT DESCRIPTION ....................................................................................................................... 4 3. NORMATIVE REFERENCE ...................................................................................................................... 6 4. TEST METHODOLOGY ............................................................................................................................ 7 5. TEST EQUIPMENT CALIBRATION DATES ............................................................................................ 8 6. TESTS RESULTS SUMMARY .................................................................................................................. 9 7. MEASUREMENT UNCERTAINTY ...........................................................................................................10 8. OCCUPIED BANDWIDTH .......................................................................................................................11 9. BAND EDGE ............................................................................................................................................48 10. CONDUCTED OUTPUT POWER ............................................................................................................52 11. RADIATED SPURIOUS EMISSIONS ......................................................................................................56 12. CONDUCTED POWER SPECTRAL DENSITY .......................................................................................94 APPENDIX 1: TEST EQUIPMENT LIST ......................................................................................................................... 123 APPENDIX 2: RADIATED TEST SETUP ........................................................................................................................ 125 REVISIONS HISTORY Revision Date Modified pages Modifications 0 22-Jul-24 / Creation RRA- SS24B405SEN-05Av0 Page 4/125 1. INTRODUCTION This report presents the results of radio test carried out on the following radio equipment: eBee Vision, in accordance with normative reference. The equipment under test integrates:  Wi-Fi 2.4 GHz transceiver radio function not already certified,  Proprietary transceiver radio module already certified at 2.4 GHz (pMDDL2450),  GNSS multifrequencies receiver. This report concerns only Wi-Fi radio part. The Wi-Fi functions possess four identical antennas identified as: Front Left, Front Right, Back Left, Back Right The product can only emit on the two chains simultaneously among: - Front Left + Front Right - Rear Left + Rear Right - Front Left + Rear Left - Front Right + Rear Right On the report the different configuration are defined as follow: - Front Left + Front Right => Front - Back Left + Back Right => Back - Front Left + Back Left => Left - Front Right + Back Right => Right 2. PRODUCT DESCRIPTION Class: B Utilization: Residential Antenna type and gain: (2.14 dBi) 4 integral identical antennas: PCB antennas Front Left, Front Right, Back Left, Back Right Directionnal gain: For power measurements: 2.14 dBi For PSD measurements: 5.14 dBi Operating frequency range: From 2412 MHz to 2462 MHz Number of channels: 11 Channel spacing: 5 MHz Channel bandwidth: 20 MHz Power setting 24 dBm RRA- SS24B405SEN-05Av0 Page 5/125 Modulation: DBPSK OFDM: BPSK OFDM: 64-QAM Mode tested: 802.11b 802.11g 802.11n Data rate…

Text truncated - open the document above for the full version.

© 2024 AgEagle ageagle.com Route de Genève 38, 1033 Cheseaux-sur-Lausanne Switzerland eBee WLAN Antenna Technical Data Sheet Description: 2400 – 2500MHz PCB Dipole Antenna + META reflector Revision 1.1 PART NUMBER: SF_EBZ_ANT_WLAN_HW01 Mini PCB Embedded Wireless Antenna The AgEagle internal wireless antenna features a thin dipole PCB with Meta reflector that supports C2 applications. The antennas are specifically designed to be embedded inside AgEagle UAVs for better integration. Features: • Frequency 2400 – 2500MHz • Omnidirectional patterns • Gain 2.14 dBi • VSWR < 2.5:1 • Length 34 mm straight position • 1.13 mm ∅ coaxial cable with MHF connector • Cable length: 285mm (Front) / 90mm (Rear) • Conformance to European RoHS Applications: • 2.4GHz ISM band radios: WLAN, 802.11a/b/g/n/ac AgEagle WLAN Antenna Technical Data Sheet SF_EBZ_ANT_WLAN © 2024 senseFly ageagle.com ELECTRICAL SPECIFICATIONS MECHANICAL SPECIFICATIONS Antenna Type PCB Dipole Frequency 2.437 GHz Peak Gain 2.14 dBi VSWR max. 2.5:1 Average Efficiency > 75% Polarization Linear Vertical Radiation Pattern Omnidirectional Nominal Impedance 50 Ohms Power Handling 2 Watt CW Mechanical Size 34 mm x 13.85 mm x 12 mm Weight 1.8 g Color Black Connector Type IPEX U.FL - MHF AgEagle WLAN Antenna Technical Data Sheet SF_EBZ_ANT_WLAN © 2024 senseFly ageagle.com ENVIRONMENTAL SPECIFICATIONS RETURN LOSS / VSWR RADIATION PATTERNS Operating Temperature -40 ~ +85°C Storage Temperature -40 ~ +85°C RoHS Compliant

Ground plane FCC ID: 2BF4LM4042XD IC NUMBER: 32643-M4042XD Anechoic chamber setup Between 30 MHz and 1 GHz Turntable 1: Equipment Under Test 2: Measurement antenna 3: Measurement equipment Above 1 GHz 1: Equipment Under Test 2: Measurement antenna 3: Measurement equipment Distance : 3 m 2 1 Antenna mast with range 1 m to 4 m 1.5 m 3 Turntable 1 2 Antenna mast with range 1 m to 4 m 0.8 m 3 Distance : 3 m Radiated measurement setup between 30 MHz to 200 MHz Radiated measurement setup between 200 MHz to 1000 MHz Radiated measurement setup above 1 GHz Installation of Equipment Under Test Position 1 Position 2 Position 3
