Asita H www.asita.net Brand/Manufacturer: ASITA APP Address: 8F, Building 1, 199 Huanbao West Road, Tianxin District, Changsha, Hunan, China National service hotline : 400-611-2811 Email: [email protected] Official website: www.asita.net For technical support and troubleshooting information and to download the latest Asita App, please visit the Asita official website Changsha Asita Technology Co., Ltd. User's Guide Asita Hunter Safety Instructions 01 Thank you for purchasing our products. Correct use of training equipment is the guarantee of your safety and convenience. Please read the following carefully before using the training equipment: If you have any of the following conditions, please consult your doctor first to see if you are suitable for using this product for related training courses: Not suitable for the following people This product is not waterproof and should be installed in a dry and ventilated environment by professionals. This product is only suitable for general household indoor use. Do not use this product outdoors or in harsh environments such as rain, lightning, dust, ice and snow, hail, strong wind, high temperature, etc. This product is prohibited from being used in environments where corrosive gases or flammable and explosive gases (such as large amounts of dust, oil fume particles or methane, etc.) may be generated. Before use, please ensure that there are no debris, heavy objects, objects that may collapse, or other objects that may affect the stable installation of the product or damage the screen around the product. Avoid using any object or any external force to impact, hit, press or scratch the screen of this product to avoid screen damage. Please ensure that minors do not play, fight, chase, run or jump around this product, use scissors or other sharp objects to cut the drawstring, or push, pull or hit this product to avoid injuries to minors and damage to this product. Please ensure that pets at home cannot come into contact with this product to avoid damage to it. Please ensure that the socket you use is a product that has passed national safety certification, and do not overload the power socket. Please make sure to use the original power cord of this product and do not use power supply equip- ment of other brands to power this product. Please check whether the power cord and plug are damaged before use. Do not bend or pull the power cord to avoid breaking or damaging the power cord. In case of thunderstorms, power outages, or when the device is unattended or not used for a long period of time, please turn off the power switch and unplug the power plug. When using this product, please stay away from high electromagnetic interference environments. Before using this product, please adjust the arm of the product to a suitable position, check whether the arm is firm and whether there are any bends or cracks. Do not lean on or hang heavy objects on the arm; when exercising , please keep no people or objects under the arm. Before using this product, please check whether the drawstring is damaged to avoid slipping and causing accidental injury. When the drawstring is completely pulled out, do not continue to pull it. After use, please fold the arms and place them on both sides of the machine before shutting down to prevent the arms from standing up and the ropes from being pulled out. Please wear the anti-pinch arm protective cover correctly. During the arm adjustment process, when adjusting the pitch angle with both hands, do not put your fingers or other people (be careful of the elderly and children) to the inside of the arm adjustment gear to avoid pinching your hands during the adjustment process and causing personal injury. Since this product is not a fully enclosed product, there are heat exhaust holes on both sides of the machine body. It is strictly forbidden to insert any foreign objects into the machine through the holes on the machine body, and it is also forbidden to place clothing, wool yarn and other items that may be sucked into the machine around the machine to avoid damage to the machine, electric shock or fire. When using this product, if there is any odor or smoke, or if you can clearly feel that the rope is not pulled smoothly during resistance training , please stop using it immediately, turn off the power switch and unplug the power plug in time, and contact Asita customer service, or call the customer service number 400-611-281 1 . regnant women; Minors under the age of 18; Elderly persons aged 65 and above; People who are taking medication; Suffering from any chronic illness or injury, including but not limited to: Hypertension, heart disease, cerebral infarction, cerebral ischemia and other cardiovascular and cerebrovascular diseases; Users who have a pacemaker, defibrillator or other medical device installed in their body, if they suspect that this product is interfering with your pacemaker, defibrillator or any other medical device, please stop using it immediately; Diabetes, hypoglycemia, gout and other metabolic diseases; Asthma and other respiratory diseases or any other chronic disease; Muscle, ligament injuries, myofascial injuries, joint inflammation and injuries, connective tissue diseases; Soft tissue injuries and other orthopedic injuries or any acute or chronic physical injury (including during the recovery period); Product Installation 02 Operation Guide 03 1. Do not turn on the Asita H Lite before the installation is complete ! Do not pull the cord during the startup process! 2. When the input voltage is 110V, the equipment power supply needs to be routed separately from the main distribution box ! Note : Asita H Lite requires professional Asita after-sales service personnel to install and disassemble. If you need to install, disassemble or relocate the product, please contact Asita after-sales service department. Installation or disassembly of this product by non-Asita after-sales service personnel may affect the norma…
