2BF9G-BMS04Battery Monitor System

Device Power Up BMS04 will power up by applying voltage between 8V ~ 72 V, because device has rectifier inside to allow no polarity issue of input voltage, therefore user can connect power to device in ease. After power up, BMS04 show logo and then display the first information on LCD ( figure 1 ), device will store the date and time before no power into the non volatile memory Figure 1 Device then checking some hardware resource like the flash memory and SIM card installation ( figure 2 ) Figure 2 If both checking pass then device will start running, first show the current firmware version ( as figure 3 ) then start collect data and display ( as figure 4 ) Figure 3 Figure 4 SIM – X -> Sim installation fail SIM – OK -> Sim installation OK GPS – X -> Not yet locking GPS GPS – OK -> Found GPS RSSI – X -> Not yet connect to APN RSSI + Level -> how Signal Strength No WiFi Mark -> Not connect to WiFi hotspot WiFi Mark On -> Connect to WiFi hotspot Web Server 1. Finding device in mobile WiFi list 2. Select device to connect, ( maybe need enter password according to mobile, default is 12345678 ) 3. Use any brower, type in “setup.local” and then click, mobile will enter BMS04 web server page 4. User can setup device information by clicking “Setup”, inside “Setup” page can enter the WiFi hotspot SSID and password, rename device ID Prefix and number, adjust sending interval and Web Server password etc, in this example, device ID will change to BMS-05, and device will connect to APN ( need turn WiFi to On on front page ) with SSID Macdonald and password is abc123456. 5. Press “Update” button to confirm data, device restart to use the new setting to run 6. User can calibrate device by clicking “Calibration”, inside “Calibration” page can calibrate current sensor offset, voltage offset and temperature offset, please unload any current loading on current sensor and device will get the zero offset, in this example, 1786 is the offset data, then enter the battery voltage measure by multimeter, in this example is 13.2V, and use thermometer of the surrounding temperature, in this example is 28 degree Celsius, then press “Set” button to confirm entry, on next page, “Set” button will disappear and press “Next” button, entry data will show on page 2 7. User can read device data by clicking “Reading”, inside “Reading” page can view most of the device data as shown FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm between the radiator and your body, and fully supported by the operating and installation
