2BF9I-T16Signal detector

T16智能探测器使用说明书 一 产品功能 1），具有自动侦测功能、主机随身携带、当身处 环境有偷听器、针孔摄影机 2），具有讯号强弱指显示灯、能够快速找到讯号 来源处。 3），调节功能按键可调整灵敏度。（提高灵敏度 拉大侦测范围或降低灵敏度缩短 二 适用人群： 4、常去公共娱乐场所消费的人士； 5、常去各种商场试穿的人士； 6、尊重自己个人稳私与他人稳私的人士； 7、接触、保管商业机密的人士； 8、商业机密与技术机密场所的安保人员； 9、反偷拍、反偷听的专业人士； 三 适用范围: 探测您的汽车或办公室是否被安装无线偷听器、 无线窃听器。 探测手机是否被窃听或异常（待机时无缘无故向 外发射信号）。 探测您的汽车是否被安装GPS跟踪，GPS定位跟踪 器。 探测手机短信收发信号、手机上网信号、手机开 关及通话信号。 ◇ 探测无线网络信号、手机基站信号、无线监 视系统之场强。 ◇ 检查酒店、洗手间、宾馆、娱乐场所、更 衣室防无线摄影机。 ◇ 商务谈判、学校监考场所、工厂、军事设 施或政府机关。 四 产品使用说明 1.全频段信号探测,频率侦测范围[1MHz-6.58HZ]. 长按[ ]3到5秒,听到滴声松开手指,指 示灯亮,开机默认全频段探测模式. 2.上下左右移动本仪器,有声音提示,表示有发射 源.白灯信号指示灯越多,表示信号越强. 3.短按[ ],白灯越多,灵敏度越高, 可扩大搜索范围. 4.循环调节[ ]可减少白灯数量, 灵敏度降低,减少探测范围,可最终找到发射源. 五 探测摄像头 1.长按[ ]3到5秒,听到滴声松开手指, 指示灯亮. 短按[ ]机器后部6颗红外 夜视灯亮起,短按[ ]可控制红灯的 闪烁快慢,每按一次灵敏度按键闪烁频率会快一 个级别,共6级选择,可适应各类人群. 2.上下左右移动本仪器,对周围环境进行激光扫 描.眼睛通过本仪期红色滤光片观察,如前方有 摄像机镜头,你会发现有极强的亮点在闪烁. 3.在按一下[ ],可关闭激光扫描功能. 进入全频段信号探测. 五充电指示 把包装盒里的数据线插入仪器连接充电器,充电时 红灯长亮,充满电绿灯长亮. 六基本参数. 七 常见问题 1为什么没有探测到静默休眠定位器？ 答；常用休眠定位器一天工作一次，一次工作5到 7分钟，所以探测器正常探测无线信号时，定位器 有可能没有发出信号。 2为什么没有精确的探测到实时定位器的位置？ 答；实时定位器一般10秒左右发一次信号，探测 试请不要来回移动，最好固定在一个位置5分钟 以上，再换一个位置继续探测。 充电接口 Micr oUSB 安卓 工作时间 连续5小时 天线增益 -56db 充电电源 DC5V/ 1A 电池 3.7 V/2 00ma 聚合物 锂电池 灵敏度 4级可 调 接受频率 范围 1MHz-6.5 GHz 信号接受 范围 5厘米-10米 光学镜片 特殊专用 滤镜 激光探测 距离 10厘米-10米 材质 PC 3为什么探测器终端“滴滴”乱叫？ 答；请净空周边的环境，由于周边干扰信号太多 太强。第二把灵敏度调低。 4为什么房子窗户边探测器叫得特别厉害？ 答；窗户是铝合金，组成一个回路天线，接受信 号特别好。 5为什么没有探测到摄像头？ 答；有可能摄像头没有在工作，有可能摄像头是 有线摄像，这时候改用红色滤光片红外灯光探测。 FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

Shenzhen Qishi Ruiting industrial Co., Ltd 2nd Floor, No. 568-4, Bulong Road, Yangmei Community, Bantian Street,Longgang District, Shenzhen China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-8-23 To whom it may concern: We, Shenzhen Qishi Ruiting industrial Co., Ltd, hereby certify that the equipment for which authorization is sought (FCC ID: 2BF9I-T16) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Chong He Manager Shenzhen Qishi Ruiting industrial Co., Ltd 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

Shenzhen Qishi Ruiting industrial Co., Ltd 2nd Floor, No. 568-4, Bulong Road, Yangmei Community, Bantian Street, Longgang District Shenzhen China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024/08/20 U.S. Agent Designation Shenzhen Qishi Ruiting industrial Co., Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BF9I-T16): Name and company of U.S. agent: GSS SERVICE INC Physical U.S. address of agent: 6547 N Academy Blvd #2266 Colorado Springs COLORADO 80918 United States FRN of U.S. agent: 0033402082 Email address of U.S. agent: [email protected] GSS SERVICE INC acknowledges their obligation to accept service of process on behalf of Shenzhen Qishi Ruiting industrial Co., Ltd Shenzhen Qishi Ruiting industrial Co., Ltd with the FRN [0035396258] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Chong He Manager Shenzhen Qishi Ruiting industrial Co., Ltd Signature Michoux Logan PM GSS SERVICE INC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-8-23> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BF9I-T16 T16 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Chong He/Manager Company: Shenzhen Qishi Ruiting industrial Co., Ltd Address: 2nd Floor, No. 568-4, Bulong Road, Yangmei Community, Bantian Street,Longgang District, Shenzhen China Phone: 13538214502 Fax: N/A E-Mail: [email protected]

Shenzhen Qishi Ruiting industrial Co., Ltd 2nd Floor, No. 568-4, Bulong Road, Yangmei Community, Bantian Street,Longgang District, Shenzhen China Date: 2024-8-23 FCC ID: 2BF9I-T16 Model Number: T16 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Shenzhen Qishi Ruiting industrial Co., Ltd, declare that this EUT (FCC ID: 2BF9I-T16) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Chong He/Manager Company: Shenzhen Qishi Ruiting industrial Co., Ltd Address: 2nd Floor, No. 568-4, Bulong Road, Yangmei Community, Bantian Street,Longgang District, Shenzhen China Phone: 13538214502 Fax: N/A E-Mail: [email protected]

Shenzhen Qishi Ruiting industrial Co., Ltd 2nd Floor, No. 568-4, Bulong Road, Yangmei Community, Bantian Street,Longgang District, Shenzhen China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-8-23 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BF9I-T16 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Chong He/Manager Company: Shenzhen Qishi Ruiting industrial Co., Ltd Address: 2nd Floor, No. 568-4, Bulong Road, Yangmei Community, Bantian Street,Longgang District, Shenzhen China Phone: 13538214502 Fax: N/A E-Mail: [email protected]

FCC ID: 2BF9I-T16 External Photos of the EUT FCC ID: 2BF9I-T16 FCC ID: 2BF9I-T16

Label and Location Size: L: 2.0cm*W: 0.5cm Label and Location FCC ID : 2BF9I-T16

FCC ID: 2BF9I-T16 Internal Photos of the EUT FCC ID: 2BF9I-T16 FCC ID: 2BF9I-T16 ANT FCC ID: 2BF9I-T16

RF Exposure evaluation FCC ID: 2BF9I-T16 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance 802.11b (Peak) Channel Channel 01 Channel 06 Channel 11 Target (dBm) 7.5 7.0 6.0 Tolerance ±(dB) 1.0 1.0 1.0 802.11g (Peak) Channel Channel 01 Channel 06 Channel 11 Target (dBm) 7.0 7.0 6.0 Tolerance ±(dB) 1.0 1.0 1.0 802.11n(H20) (Peak) Channel Channel 01 Channel 06 Channel 11 Target (dBm) 7.0 6.0 6.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW 2.4GWIFI 2.450 5 8.5 7.0795 2.2162<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................
