2BFHJ-GYW-W112Wireless phone charger 10W photo frame

1 5 6 2 1 2 Wireless charger x1 Manual x1 Type-C cable x1 Product schematic diagram: Wireless charging area LED light Type-C input Picture Frame 3 4 Manual 5 6 Type-C cable 3 654 Instruction manual GYW-W112 Product name: Wireless phone charger 10W photo frame Input DC 5V/2A; 9V/2A Output5W,7.5W,10W MaterialBamboo Size215x181x15mm 1. This product has 1 LED indicator lamp. When the power comes on, the LED lights come on and then go out. 2. Once connected, place the supporting wireless charging mobile device in the wireless charging area. During charging, the LED lights are always on. Packing list: Product parameters: Charging method: Attention: When using the wireless charging function, if the LED indicator flashes, the device does not support wireless charging or there is foreign body interference between the device and the wireless charging surface, or overheating. Points to note: Before using this product, please be sure to read the product manual carefully, and according to the instructions of the use of the correct operation. Do not disassemble the device by yourself. This product is not equipped with any self-disassembly/maintenance parts. The wireless charger has multiple protection functions. When the charging is abnormal, check the status of the mobile phone and place the mobile phone again after handling. In order to give full play to the best charging performance, the use of the company's Charger is recommended. If the mobile phone is not placed correctly, it may lead to the mobile phone can not be charged properly. Don't put anything between the phone and the charger. Note: If you place a magnetic stand, protective case, metal or room card, bus card, bank card, passport, etc. with an NFC or RFID chip between the phone and the Charger, it may degrade the charger, cause heat, or even damage the product. Please stop using the product immediately if there is any abnormal fever. Security information: Please read and follow the following notes before using and operating the device. In medical and health-care settings where the use of wireless devices is explicitly prohibited, please comply with the site regulations and turn off the devices. When using this device, keep at least 30 cm away from the implanted medical device (such as pacemaker, cochlear implant, etc.) . Please keep the equipment dry. Please do not use the equipment in the dusty, damp place, in order to avoid causing equipment failure. Please do not use this equipment in the thunderstorm day, lest cause the equipment failure or the electric shock danger. Use the device at a temperature range of -10 ° C to 45 ° C, and store the device at a temperature range of -40 ° C to 70 ° C to avoid device faults. Do not expose your equipment to high temperatures or heat, such as sunlight, heaters, microwaves, ovens, or water heaters. Do not use this product beyond its maximum output parameters. Overload output may cause risk of fire or injury. Please treat the equipment according to the local regulations. Do not treat the equipment as domestic waste. Please comply with this equipment and its attachments for handling of local ordinances, and support recovery actions. Do not allow children or pets to swallow equipment as this may cause harm to them. This equipment and its accessories may contain some small parts, please put the equipment and its accessories in a place that children can not reach. Children may inadvertently damage the device and its accessories, or swallow small parts causing asphyxiation, asphyxiation, or other hazards. Please do not drop, squeeze or puncture equipment, so as to avoid causing equipment failure. Use of unauthorized or incompatible power supplies, chargers, or batteries can cause fire or other hazards. Wireless charger with multiple protection functions, charging abnormal, check the status of the mobile phone, re- processing the new placement of mobile phone. Made in China Warranty card Sincerely thank you for buying and using our products! This product has passed the strict quality inspection. According to the warranty card, we will be responsible for the free maintenance during the warranty period if the hardware malfunction is caused by the quality problem of the product. For more information, please consult US, thank you! 1. Customers who purchase our series products will enjoy after-sales service according to the relevant regulations of the state. 2. If there is a quality issue with the product you purchase. It can be replaced within 15 days without man-made damage, disassembly and repair, and packing intact. 3. Purchase this product to enjoy one year free maintenance service. Damaged by force majeure. Past expiration date. The Bar Code and the date of manufacture of the goods were torn (outer packing) . Without the product warranty card and valid purchase certificate, and unable to verify the user's information files. 4. The warranty shall expire and maintenance services shall be provided free of charge, provided that the corresponding accessories and manual repair fees shall be charged for the maintenance: The damage caused by human factors, including abnormal working conditions, not according to the use of the manual, caused by damage, etc. . The user disassembles the machine, repairs and refits by himself, and is maintained by a maintenance department of the company or by an unauthorized organization. *This warranty card is properly kept by the customer as the warranty certificate of the product without any alteration. Warranty description (warranty scope is limited to the main unit only, not including accessories and freebies) User Name： Contact Number： Model： Date Of Purchase： Sales Unit： Sales Address： Client Address： Form filling 1 2 3 4 5 6 No foreign bodies between the phone and the wireless charger! 3 2 4 1 CARD Wireless phone charger 10W photo frame FCC COMPLIANCE STATEMENT: FCC Radiation Exposure Statement • • • • This device complies with part 15 of the FCC Rules. Operation is subject …

Text truncated - open the document above for the full version.

Shenzhen Lechengjia Technology Co., Ltd. Product Similarity Declaration Product name: Wireless phone charger 10W photo Frame Model name: GYW-W112, GYW-W110, GYW-WXXX, AB0418 FCC ID: 2BFHJ-GYW-W112 We (Shenzhen Lechengjia Technology Co., Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), the only difference is the model number (if any difference). Signature: Name: May Huang Title: Manager Place, date Shenzhen Lechengjia Technology Co., Ltd. / 2024-03-27

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: FCC US Agent, LLC FRN: 0033402884 Contact Name: Tim Payne Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Telephone No: 708-571-3148 Email: [email protected] Applicant: Company name: Shenzhen Lechengjia Technology Co., Ltd. Product Description: Wireless phone charger 10W photo frame FRN: 0035143957 Grantee code: 2BFHJ FCC ID: 2BFHJ-GYW-W112 Contact Name: May Huang Address: Room 902, Building F, Mingyue Huadu, Xixiang Street, Bao'an District, Shenzhen Telephone No: 13823584275 Email: [email protected] [Shenzhen Lechengjia Technology Co., Ltd.] certifies that, as of the date of this filing of the application with the TCB, [FCC US Agent, LLC] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Lechengjia Technology Co., Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [FCC US Agent, LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024/03/27 Applicant’s Name: May Huang US Agent’s Name: Tim Payne Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Lechengjia Technology Co., Ltd. FRN: 0035143957 Grantee code: 2BFHJ FCC ID: 2BFHJ-GYW-W112 Contact Name: May Huang Address: Room 902, Building F, Mingyue Huadu, Xixiang Street, Bao'an District, Shenzhen Telephone No: 13823584275 Fax No: 13823584275 Email: [email protected] i. [Shenzhen Lechengjia Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Lechengjia Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Lechengjia Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment. Date: 2023-03-27 Applicant’s Name: May Huang Title: Manager Signature: 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhen Lechengjia Technology Co., Ltd. Address: Room 902, Building F, Mingyue Huadu, Xixiang Street, Bao'an District, Shenzhen Product Name: Wireless phone charger 10W photo frame Model Number: GYW-W112, GYW-W110, GYW-WXXX, AB0418 FCC Identifier: 2BFHJ-GYW-W112 We authorize LGAI Technological Center S.A., Ronda de la Fo nt del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. N ame: May Huang Date: 03/27/2024 T itle: Manager S ignature of applicant:

C5266091_X10_Ed.1 1/1 Shenzhen Lechengjia Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 03/27/2023 Subject: Request for Confidentiality FCC ID: 2BFHJ-GYW-W112 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: May Huang Title: Manager

FCC ID: 2BFHJ-GYW-W112 External photos FCC ID: 2BFHJ-GYW-W112 FCC ID: 2BFHJ-GYW-W112 FCC ID: 2BFHJ-GYW-W112

Wireless phone charger 10W photo frame Model: GYW-W112 TYPE-C Input: DC 5V/2A, 9V/2A Wireless Output: 5W, 7.5W,10W FCC ID: 2BFHJ-GYW-W112 Wireless phone charger 10W photo frame Model: GYW-W112 TYPE-C Input: DC 5V/2A, 9V/2A Wireless Output: 5W, 7.5W,10W FCC ID: 2BFHJ-GYW-W112

FCC ID: 2BFHJ-GYW-W112 Internal photos FCC ID: 2BFHJ-GYW-W112 RF Chip FCC ID: 2BFHJ-GYW-W112 RF Coil

Report No.: NTC2403236F-1 Dongguan Nore Testing Center Co., Ltd. Address: Building D, Gaosheng Science and Technology park, Hongtu road, Nancheng district, Dongguan city, Guangdong province, China Web: www.ntc-c.com Tel:+86-769-2202 2444 Fax:+86-769-2202 2799 Page 1 of 17 RF EVALUATION TEST REPORT Applicant.......................... : Shenzhen Lechengjia Technology Co., Ltd. Address............................ : Room 902, Building F, Mingyue Huadu, Xixiang Street, Bao'an District, Shenzhen Manufacturer..................... : Shenzhen Lechengjia Technology Co., Ltd. Address............................ : Room 902, Building F, Mingyue Huadu, Xixiang Street, Bao'an District, Shenzhen Factory............................. : Shenzhen Lechengjia Technology Co., Ltd. Address........................... : Room 902, Building F, Mingyue Huadu, Xixiang Street, Bao'an District, Shenzhen Product Name................... : Wireless phone charger 10W photo frame Brand Name...................... : N/A Model No. ........................ : GYW-W112, GYW-W110, GYW-WXXX, AB0418 (For model difference refers to section 2.) FCC ID........................... .. : 2BFHJ-GYW-W112 Measurement Standard....... : 47 CFR PART 2, Section 2.1091 Receipt Date of Samples.... : March 18, 2024 Date of Tested.................. : March 18, 2024 to March 26, 2024 Date of Report.................. : March 29, 2024 This report shows that above equipment is technically compliant with the requirements of the standards above. All test results in this report apply only to the tested sample(s). Without prior written approval of Dongguan Nore Testing Center Co., Ltd, this report shall not be reproduced except in full. Prepared by Jenny Liu / Project Engineer Approved by Iori Fan / Authorized Signatory Report No.: NTC2403236F-1 Page 2 of 17 Table of Contents 1. General Description of EUT ............................................................................................................................... 4 2. Test Facility and Location .................................................................................................................................. 6 3. Test Modes Detail .............................................................................................................................................. 7 4. Configuration of EUT .......................................................................................................................................... 7 5. Modification of EUT ............................................................................................................................................ 7 6. Description of Support Device............................................................................................................................ 8 7. Deviations and Abnormalities from Standard Conditions .................................................................................. 8 8. Applicable Standards and References............................................................................................................... 8 9. Measurement Uncertainty .................................................................................................................................. 9 10. Maximum Permissible Exposure .................................................................................................................... 10 11. Test Equipment List ....................................................................................................................................... 14 12. Test Photos .................................................................................................................................................... 15 Report No.: NTC2403236F-1 Page 3 of 17 Revision History Report Number Description Issued Date NTC2403236F-1 Initial Issue 2024-03-29 Report No.: NTC2403236F-1 Page 4 of 17 1. General Description of EUT Product Information Product Name: Wireless phone charger 10W photo frame Main Model Name: GYW-W112 Additional Model Name: GYW-W110, GYW-WXXX, AB0418 Model Difference: These models have the same circuit schematic, construction, PCB Layout and critical components. The difference is model number only due to trading purpose. X can be 0-9. S/N: 2403-1204 Brand Name: N/A Hardware Version: wirelesscharging-AB0418 Software Version: leader.2021.11 Rating: Input: DC 5V 2A, DC 9V 2A Output: 5W, 7.5W, 10W Typical Arrangement: Table-top I/O Port: Refer to user manual Accessories Information Adapter: N/A Cable: USB Line: 0.97m, unshielded, detachable Other: N/A Additional Information Note: According to the model difference and the requirements of the manufacturer, all tests were performed on model GYW-W112. Remark: All the information above are provided by the manufacturer. More detailed feature of the EUT please refers to the user manual. Report No.: NTC2403236F-1 Page 5 of 17 Technical Specification Frequency Range: 110.5-205KHz Modulation Type: FSK Antenna Type: Coil antenna Output power for coil: 5W, 7.5W, 10W Report No.: NTC2403236F-1 Page 6 of 17 2. Test Facility and Location Test Site : Dongguan Nore Testing Center Co., Ltd. (Dongguan NTC Co., Ltd.) Accreditations and Authorizations : The Laboratory has been assessed and proved to be in compliance with CNAS/CL01 Listed by CNAS, August 13, 2018 The Certificate Registration Number is L5795. The Certificate is valid until August 13, 2024 The Laboratory has been assessed and proved to be in compliance with ISO17025 Listed by A2LA, November 01, 2017 The Certificate Registration Number is 4429.01 Listed by FCC, November 06, 2017 Test Firm Registration Number: 907417 Listed by Industry Canada, June 08, 2017 The Certificate Registration Number. Is 46405-9743A Test Site Location : Building D, Gaosheng Science and Technology Park, Hongtu Road, Nancheng District, Dongguan City, Guangdong Province, China Report No.: NTC2403236F-1 Page 7 of 17 3. Test Modes Detail Test Mode Test…

Text truncated - open the document above for the full version.

Report No.: NTC2403236FV00 Dongguan Nore Testin g Center Co., Ltd. Address: Building D, Gaosheng Science and Technology park, Hongtu road, Nancheng district, Dongguan city, Guangdong province, China Web: www.ntc-c.com Tel:+86-769-2202 2444 Fax:+86-769-2202 2799 Page 1 of 30 FCC RADIO TEST REPORT Applicant.......................... : Shenzhen Lechengjia Technology Co., Ltd. Address............................ : Room 902, Building F, Mingyue Huadu, Xixiang Street, Bao'an District, Shenzhen Manufacturer..................... : Shenzhen Lechengjia Technology Co., Ltd. Address........................... : Room 902, Building F, Mingyue Huadu, Xixiang Street, Bao'an District, Shenzhen Factory............................. : Shenzhen Lechengjia Technology Co., Ltd. Address........................... : Room 902, Building F, Mingyue Huadu, Xixiang Street, Bao'an District, Shenzhen Product Name................... : Wireless phone charger 10W photo frame Brand Name...................... : N/A Model No. ........................ : GYW-W112, GYW-W110, GYW-WXXX, AB0418 (For model dif ference refers to section 2.) FCC ID............................. : 2BFHJ-GYW-W112 Measurement Standard....... : 47 CFR FCC Part 15, Subpart C Receipt Date of Samples...... : March 18, 2024 Date of Tested.................. : March 18, 2024 to March 26, 2024 Date of Report.................. : March 29, 2024 This report shows that above equipment is technically compliant with the requirements of the standards above. All test results in this report apply only to the tested sample(s). Without prior written approval of Dongguan Nore Testing Center Co., Ltd, this report shall not be reproduced except in full. Prepared by Jenny Liu / Project Engineer Approved by Iori Fan / Authorized Signatory Report No.: NTC2403236FV00 Page 2 of 30 Table of Contents 1. Summary of Test Result ...................................................................................................................................... 4 2. General Description of EUT ................................................................................................................................ 5 3. Test Channels and Modes Detail ........................................................................................................................ 7 4. Configuration of EUT ........................................................................................................................................... 7 5. Modification of EUT ............................................................................................................................................. 7 6. Description of Support Device ............................................................................................................................. 8 7. Test Facility and Location ................................................................................................................................... 9 8. Applicable Standards and References .............................................................................................................. 10 9. Deviations and Abnormalities from Standard Conditions ................................................................................. 10 10. Test Conditions ............................................................................................................................................... 10 11. Measurement Uncertainty ............................................................................................................................... 11 12. Sample Calculations ....................................................................................................................................... 12 13. Test Items and Results ................................................................................................................................... 13 13.1 Conducted Emissions Measurement ....................................................................................................................................... 13 13.2 Radiated Spurious Emissions and Restricted Bands Measurement ........................................................................................ 17 13.3 20dB Bandwidth Measurement................................................................................................................................................ 27 13.4 Antenna Requirement .............................................................................................................................................................. 29 14. Test Equipment List......................................................................................................................................... 30 Report No.: NTC2403236FV00 Page 3 of 30 Revision History Report Number Description Issued Date NTC2403236FV00 Initial Issue 2024-03-29 Report No.: NTC2403236FV00 Page 4 of 30 1. Summary of Test Result FCC Rules Description of Test Result Remarks §15.207 (a) AC Power Conduct ed Emission PASS --- §15.209 Radiated Emissions PASS --- §15.215(c) 20dB Bandwidth PASS --- §15.203 Antenna Requirement PASS --- Report No.: NTC2403236FV00 Page 5 of 30 2. General Description of EUT Product Information Product Name: Wireless phone charger 10W photo frame Main Model Name: GYW-W112 Additional Model Name: GYW-W110, GYW-WXXX, AB0418 Model Difference: These models have the same circuit schematic, construction, PCB Layout and critical components. The difference is model number only due to trading purpose. X can be 0-9. S/N: 2403-1204 Brand Name: N/A Hardware Version: wirelesscharging-AB0418 Software Version: leader.2021.11 Rating: Input: DC 5V 2A, DC 9V 2A Output: 5W, 7.5W, 10W Typical Arrangement: Table-top I/O Port: Refer to user manual Accessories Information Adapter: N/A Cable: USB Line: 0.97m, unshielded, detachable Other: N/A Additional Information Note: According to the model difference and the requirements …

Text truncated - open the document above for the full version.

Fine Page 1 of 4 承認書 SPECIFICATION FOR APPROVAL 客戶： CUSTOMER: 东莞市跃特电子科技有限公司 客 戶 料 號： CUST P/N: 诚详盛料 號： FIN E P/N: G511-6.8UH 单线圈0.08*105P*9TS 産 品 型 號： DESC: Φ50MMX5.0MMX1.0MM 日期： DAT E: 2022/6/5 版本： Ver sion: A.0 擬制 PREPARED BY 審核 CHECKED BY 批准 APPROVED BY 客戶承認 CUSTOMER APPROVE 向恭麟 深圳市诚祥盛智能科技有限公司 Shenzhen Chengxiangsheng Intelligent Technology Co., Ltd 工廠地址：深圳市宝安区福永街道白石厦东区永悦路9号2栋306 Factory Address: Rm 306, Building 2, No. 9 Yongyue Road, Baishixia East District, Fuyong Street, Bao'anDistrict, Shenzhen Gonglin Xiang TEL：18923715829 Fine Page 2 of 4 版本變更履歷 Version Change History 版本 Rev. 變 更 前 Before Change 變 更 後 After Change 更 改 日 期 Change Date 批 准 Approved By A.0 新发行 ---- 2022/06/05 Fine Page 3 of 4 SPECIFICATION 産 品 型 號： DESC 6.8uH-0.08x105-45mm-50C 版本 Rev： A.0 客戶CUST: XXX 客户料号CUST P/N: 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATIC DIAGRAM: A 50 B 39±1.5 C 48±1.5 D 2.2 Max E 5 注： 1.交叉出线; 2.出线位置缠8mm(ref)宽度高 温胶纸1-2 Ts; 3.线圈贴圆形硬磁片带槽，磁 片尺寸50±1mm,内孔5mm,厚 度为1.0±0.2mm。 三、绕线参数Winding Specification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 1 S F 丝包线0.08*105P 9Ts CCW 四、电气特性ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C, 湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. S-F 3.8uH ±20%单独线圈 100KHz/1.0V LCZ METER 1062B 2 IND. S-F 6.8uH ±10%加磁片 100KHz/1.0V LCZ METER 1062B 3 DCR S-F ≤50mΩ LCZ METER 502B 擬制/日期PREPARED BY/ D AT E 審核/日期CHECKED BY/ D AT E Fine Page 4 of 4 向恭麟20220605

FCC ID: 2BFHJ-GYW-W112 Test Photo Radiated emission (Below 30MHz) Radiated emission (30-1000MHz) FCC ID: 2BFHJ-GYW-W112 Conducted Emission
