157g铜版纸 76x130mm 折页 分割线无需印刷 Safety Instructions Read all instructions before you use this device. Do not make any changes or create settings that are not described in this manual. If physical damage, loss of data or damage is caused by failure to follow instructions, the warranty does not apply. 1. To reduce the risk of fire or electric shock, do not expose the device to rain or moisture. Objects filled with liquids, such as vases, should not be placed on this device. 2. Do not place this device on soft surfaces such as tablecloths or carpets, otherwise the device could be a fire hazard. 3. Do not place this device in areas susceptible to excessive dust and dirt or near any appliance generating a strong magnetic field. 4. To prevent overheating, do not block or clog the ventilation holes. 5. Never place this device in a confined space. Always leave enough space around this device for ventilation. 6. Protect this device from overexposure to direct sunlight, heat, large temperature fluctuations and moisture. Avoid extreme temperatures. 7. When this device is running for a long period of time, the surface may become hot. Shut it down immediately and unplug the charger. Resume operation after this device has cooled down. 8. Always handle this device with care. Avoid touching the lens. Do not allow children to handle the device without supervision. 9. Use attachments or accessories specified by the manufacturer only. 10. Avoid extreme vibration as it may damage the internal components. User Manual Package ListOverview Projector × 1Remote Control × 1 (Batteries are not included) Projector User Manual × 1 On / Off Power Cable × 1HDMI Cable × 1 IR receiver USB Input HDMl lnputIR receiver 3.5mm Stereo Jack Cleaning Entrance Power Socket Power Switch Focus Volume - Return Mute Right Volume + Remote Control Attention: 1. Do not submerge the remote control in the water. 2. Do not put the remote control near fire or in wet or hot places. 3. Do not use old and new batteries together in the remote control. 4. Please take the batteries out if not using the remote control for a long time to avoid battery leakage. 5. Please point the remote control toward the IR receiver. 6. Please use the remote control within 6 meters distance and 30 degree angle. Up Switch to mouse control Down Home Left Menu OK Clean Tool × 1 Getting Started Tips: Make sure the projector is horizontal to the projector screen. Plug the power cable to the projector. Press power button to turn on the projector. Use the manual focus by pressing the "Focus" button on the remote control. Cleaning Method Pry off the bottom cover. Clean the projector by the cotton swab. Reinstall the bottom cover after cleaning. Settings - Bluetooth- Bluetooth Settings > Turn on Bluetooth Switch. Click Search for Bluetooth devices and pair the device that you want to connect to. Settings - Network Settings- WiFi Switch > Turn on WiFi Switch. Choose the network and type the password that you want to connect to. Bluetooth Setting Network Setting Clear memory shortcut. When the system is stuck or too many applications are opened, click this icon, the background can be cleared. Wallpaper shortcut. Support to change the background picture. Bluetooth shortcut. Turn to Bluetooth settings. Network shortcut. Turn to network settings. Insert the U disk, click the FileManager icon on the homepage. The content of U disk could be read, such as video, audio, picture, etc. File Management Homepage status bar icon The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. X7260725 Settings - Projection Settings > Set the color temperature, installation mode, device mode, digital zoom, screen zoom, focus, keystone correction, screen recognition and intelligent obstacle avoidance. Projection Settings Settings - Other Settings > Set the external input at boot, button sound, screen saver, scheduled power off, restore factory settings, account settings. Settings - Language and Keyboard > Support to change language and input keyboard. Other Settings Language and Keyboard Settings - Application Settings > Check the app information and clear the app data. Settings - Date and time settings > Set the date, time, time zone, hour format. Application Settings Date and Time Settings Under the HDMI and USB video playing, you can set different image modes and display effects. Note: This display setting only applies to HDMI and USB video. Display SettingsAndroid Wireless Mirroring Enter transcreen app on the mobile phone, make sure the mobile phone and the projector connect the same network. Search the projector device name on your phone, click connect to share screen. Click “START”on the screen. Then will go to Miracast mirroring interface. Make sure the mobile phone and projector connect the same network. Follow the tips on the screen, according to your phone mirroring function to search the device for sharing screen. Miracast Mirroring Connect the Android mobile phone to the USB port of projector by USB cable. At the first connection, the mobile phone will come out the tips for downloading the mirroring app. After installation, accept the mirroring at the pop-up window and then share screen. Android Wired Mirroring Make sure the mobile phone and projector connect to the same network. Click “Screen Mirroring”on your phone. Find the projector device name and share screen. AirPlay Mirroring Connect the iOS mobile phone to USB port of projector by USB cable. After connection, input the passwords then share screen. Apple Wired Mirroring Follow the tips on the screen, go to https://transcreen.app and download transcreen app. Scan the QR code or download the APP from the URL. https://transcreen.app/linedisplay FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2…

Text truncated - open the document above for the full version.

FCC ID: 2BFIZ-X7AR Fig. 1 Fig. 2 FCC ID: 2BFIZ-X7AR Fig. 3 Fig. 4 Wifi Antenna 1 BT Antenna 2 FCC ID: 2BFIZ-X7AR Fig. 5 Fig. 6 FCC ID: 2BFIZ-X7AR Fig. 7 Fig. 8 FCC ID: 2BFIZ-X7AR Fig. 9 Fig. 10 FCC ID: 2BFIZ-X7AR Fig. 11

FCC ID:2BFIZ-X7AR _______________________________________________________________________________________________ Page 1 of 2 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID:2BFIZ-X7AR _______________________________________________________________________________________________ Page 2 of 2 Photo of Conducted Emission Measurement Fig. 4 Fig. 5

ShenzhenLxcElectronicsTechnologyCo.,Ltd SPECIFICATIONFORAPPROVAL PRODUCTNAME:2.4G+5Gbuilt-inFPCantenna Model:XBY240035 8Project: Author:Wang X7 Date: 2025-07-25 TEST: Language: Check: Zhong A English Shenzhen Lxc Electronics Technology Co ., Ltd - 2 - Revision History Date Revision Description of Changes 2025-07-25 RA Measured with SUS301 sample. Shenzhen Lxc Electronics Technology Co ., Ltd .................................................................................. 1 PROJECT ................................................................................................................. 2 ANTENNA COMPONENTST ..................................................................................... 3 1 TECHNICAL SUMMARY ...................................................................................... 3 2 GENERAL DESCRIPTION ................................................................................... 3 2.1 Components/Part revisions ....................................................................................................................... 3 3 MECHANICAL DESCRIPTION ............................................................................. 3 4 ELECTRICAL PERFORMANCE ........................................................................... 3 4.1 Set-up .......................................................................................................................................................... 3 4.1.1 VSWR ................................................................................................................................................. 3 4.1.2 Gain & Radiation Patterns ............................................................................................................... 3 4.1.3 Matching Circuit Description ........................................................................................................... 3 4.2 Measurement Data .................................................................................................................................... 3 4.2.1 Active result（ GSM） ........................................................................................................................ 3 6 Mechanical drawing .......................................................................................................................................... 5 7 RELIABILITY TESTS .......................................................................................... 11 7.1 Test content .............................................................................................................................................. 11 7.2 Test results ............................................................................................................................................... 11 8 CONCLUSION ...................................................................................................... 9 8Project: Author:Wang X7 Date: 20 25-07 -25 TEST : Language: Check: Zhong A English Shenzhen Lxc Electronics Technology Co ., Ltd - 3 - 1 Technical Summary This report summarizes the electrical results of the proposed antenna to support the program. We test the antenna with the latest version handset. And it seems to be acceptable. 2 General Description 2.1 Components/Part revisions VSWR: Voltage Standing Wave Rate. 3 Mechanical Description 4 Electrical Performance 4.1 Set-up 4.1.1 VSWR VSWR measurements (S11) were performed using an Agilent 8753D Network Analyzer and the previously described test fixture. Coaxial chokes were used to mitigate surface currents on the outside of the cabling. The testing was performed in free space. 4.1.2 Gain & Radiation Patterns The gain of the antenna was measured in the Lxc ’s anechoic chamber. Coaxial chokes on the feed cable were used to mitigate surface currents. The chamber provides less than –30 dB reflectivity from 800 MHz through 3 GHz and an 18” diameter spherical quite zone. The measurement results are calibrated using both dipole and leaky wave horn standards. 4.1.3 Matching Circuit Description 4.2 Measurement Data 4.2.1 Active result（WIFI） 8Project: Author:Wang X7 Date: 20 25-07 -25 TEST : Language: Check: Zhong A English Shenzhen Lxc Electronics Technology Co ., Ltd - 4 - 8Project: Author:Wang X7 Date: 20 25-07 -25 TEST : Language: Check: Zhong A English Shenzhen Lxc Electronics Technology Co ., Ltd - 5 - - 6 - 8Project: Author:Wang X7 Date: 2025-07-25 TEST: Language: Check: Zhong A English Shenzhen Lxc Electronics Technology Co ., Ltd - 7 - 8Project: Author:Wang X7 Date: 20 25-07 -25 TEST : Language: Check: Zhong A English Shenzhen Lxc Electronics Technology Co ., Ltd - 8 - 8Project: Author:Wang X7 Date: 2025-07-25 TEST: Language: Check: Zhong A English Shenzhen Lxc Electronics Technology Co ., Ltd - 9 - - 10 - 6 Mechanical drawing 8Project: Author:Wang X7 Date: 2025-07-25 TEST: Language: Check: Zhong A English Shenzhen Lxc Electronics Technology Co ., Ltd - 11 - 7Conclusion From the above test results, we can know the electrical performance of the antenna is seems good. Shenzhen Lxc Electronics Technology Co ., Ltd ,look forward to your confirmation, tha nk you for your cooperation！

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.407 Report Reference No. ..................... : FCC ID............................................. : GTS20250919018-2-12 2BFIZ-X7AR Compiled by ( position+printed name+signature) . : File administrators Peter Xiao Supervised by ( position+printed name+signature) . : Test Engineer Evan Ouyang Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Oct.29, 2025 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : Chengdu Hotack Technology Co., Ltd. Address ............................................ : 501-502, Unit 3, Building 13, No. 666 Jinfenghuang Avenue, High- tech Industry Park, Jinniu District, Chengdu City, Si Chuan Province,China. Test specification ........................... : Standard ........................................... : FCC Part 15.407: General technical requirements TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ...................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : PROJECTOR Trade Mark ....................................... : N/A Manufacturer .................................... : Chengdu Hotack Technology Co., Ltd. Model/Type reference ...................... : X7AR Listed Models .................................. : X7, X7PRO, S7AR ,HT1 ,HT2, HT3, HT4, HT5, HT6, HT7, HT8, HT9 Operation Frequency ........................ : From 5180MHz to 5240MHz/ 5745MHz to 5825MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : Input:100-240V~,50/60Hz, 2A Result ............................................... : PASS Report No.: GTS20250919018-2-12 Page 2 of 30 T E S T R E P O R T Test Report No. : GTS20250919018-2-12 Oct.29, 2025 ____________________________________________________________________________________ Date of issue Equipment under Test : PROJECTOR Model /Type : X7AR Listed model : X7, X7PRO, S7AR ,HT1 ,HT2, HT3, HT4, HT5, HT6, HT7, HT8, HT9 Applicant : Chengdu Hotack Technology Co., Ltd. Address : 501-502, Unit 3, Building 13, No. 666 Jinfenghuang Avenue, High-tech Industry Park, Jinniu District, Chengdu City, Si Chuan Province,China. Manufacturer : Chengdu Hotack Technology Co., Ltd. Address : 501-502, Unit 3, Building 13, No. 666 Jinfenghuang Avenue, High-tech Industry Park, Jinniu District, Chengdu City, Si Chuan Province,China. Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20250919018-2-12 Page 3 of 30 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 5 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 7 2.5. EUT operation mode .............................................................................................................................. 7 2.6. Block Diagram of Test Setup ................................................................................................................. 8 2.7. Related Submittal(s) / Grant (s) ............................................................................................................. 8 2.8. EUT Exercise Software .......................................................................................................................... 8 2.9. Special Accessories ............................................................................................................................... 8 2.10. External I/O Cable ................................................................................................................................ 8 2.11. Modifications ........................................................................................................................................ 8 3. TEST ENVIRONMENT ..................................................................................................................................... 9 3.1. Address of the test laboratory ....................................................................…

Text truncated - open the document above for the full version.

FCC ID:2BFIZ-X7AR 38 Appendix E.6:Band edge measurements Test Result B4 TestMode Antenna ChName Freq(MHz) FreqRange [MHz] Result [dBm] Limit [dBm] Verdict 11A Ant1 Low 5745 5650~5700 -39.85 ≤-26.96 PASS 5700~5720 -18.15 ≤14.98 PASS 5720~5725 -19.38 ≤16.87 PASS 5760~5650 -38.31 ≤-27 PASS High 5825 5850~5855 -20.69 ≤16.34 PASS 5855~5875 -23.99 ≤12.78 PASS 5875~5925 -37.88 ≤-26.21 PASS 5925~5935 -37.3 ≤-27 PASS 11N20SI SO Ant1 Low 5745 5650~5700 -38.43 ≤-25.85 PASS 5700~5720 -18.78 ≤13.73 PASS 5720~5725 -18.16 ≤16.60 PASS 5760~5650 -38.25 ≤-27 PASS High 5825 5850~5855 -21.03 ≤17.57 PASS 5855~5875 -20.67 ≤14.82 PASS 5875~5925 -38.34 ≤-26.71 PASS 5925~5935 -38.35 ≤-27 PASS 11N40SI SO Ant1 Low 5755 5650~5700 -32.49 ≤-25.90 PASS 5700~5720 -15.34 ≤15.05 PASS 5720~5725 -20.34 ≤16.04 PASS 5780~5650 -31.11 ≤-27 PASS High 5795 5850~5855 -23.64 ≤16.03 PASS 5855~5875 -25.21 ≤13.39 PASS 5875~5925 -39 ≤-26.59 PASS 5925~5935 -38.08 ≤-27 PASS 11AC20S ISO Ant1 Low 5745 5650~5700 -38.7 ≤-25.93 PASS 5700~5720 -18.15 ≤14.82 PASS 5720~5725 -20.03 ≤15.82 PASS 5760~5650 -38.55 ≤-27 PASS High 5825 5850~5855 -19.32 ≤20.03 PASS 5855~5875 -23.51 ≤10.97 PASS 5875~5925 -37.65 ≤-25.51 PASS 5925~5935 -37.57 ≤-27 PASS 11AC40S ISO Ant1 Low 5755 5650~5700 -32.71 ≤-25.61 PASS 5700~5720 -17.14 ≤11.99 PASS 5720~5725 -16.93 ≤16.66 PASS 5780~5650 -31.11 ≤-27 PASS FCC ID:2BFIZ-X7AR 39 High 5795 5850~5855 -26.62 ≤15.66 PASS 5855~5875 -25.88 ≤11.03 PASS 5875~5925 -38.53 ≤-26.95 PASS 5925~5935 -37.32 ≤-27 PASS 11AX20SI SO Ant1 Low 5745 5650~5700 -38.42 ≤-26.70 PASS 5700~5720 -18.23 ≤14.69 PASS 5720~5725 -18.78 ≤16.60 PASS 5760~5650 -38.16 ≤-27 PASS High 5825 5850~5855 -22.35 ≤15.73 PASS 5855~5875 -20.53 ≤13.39 PASS 5875~5925 -38.14 ≤-26.21 PASS 5925~5935 -37.59 ≤-27 PASS 11AX40SI SO Ant1 Low 5755 5650~5700 -31.1 ≤-25.01 PASS 5700~5720 -14.72 ≤13.05 PASS 5720~5725 -17.69 ≤16.66 PASS 5780~5650 -31.29 ≤-27 PASS High 5795 5850~5855 -24.49 ≤15.66 PASS 5855~5875 -22.59 ≤13.20 PASS 5875~5925 -37.96 ≤-26.46 PASS 5925~5935 -37.53 ≤-27 PASS FCC ID:2BFIZ-X7AR 40 Test GraphsB4 11A_Ant1_Low_5745 11A_Ant1_High_5825 11N20SISO_Ant1_Low_5745 FCC ID:2BFIZ-X7AR 41 11N20SISO_Ant1_High_5825 11N40SISO_Ant1_Low_5755 FCC ID:2BFIZ-X7AR 42 11N40SISO_Ant1_High_5795 11AC20SISO_Ant1_Low_5745 11AC20SISO_Ant1_High_5825 FCC ID:2BFIZ-X7AR 43 11AC40SISO_Ant1_Low_5755 11AC40SISO_Ant1_High_5795 FCC ID:2BFIZ-X7AR 44 11AX20SISO_Ant1_Low_5745 11AX20SISO_Ant1_High_5825 11AX40SISO_Ant1_Low_5755 FCC ID:2BFIZ-X7AR 45 11AX40SISO_Ant1_High_5795 FCC ID:2BFIZ-X7AR 46 Appendix E.7:Conducted Spurious Emission Test Result TestMode Antenna Freq(MHz) FreqRange [MHz] Max. Fre [MHz] Max. Level [dBm] Limit [dBm] Verdict 11A Ant1 5745 30~5650 5404.22 -40.88 ≤-27 PASS 5925~27000 24848.95 -32.44 ≤-27 PASS 5785 30~5650 5542.85 -38.78 ≤-27 PASS 5925~27000 24813.12 -31.73 ≤-27 PASS 5825 30~5650 2690.32 -40.19 ≤-27 PASS 5925~27000 26959.26 -31.41 ≤-27 PASS 11N20SISO Ant1 5745 30~5650 5499.76 -39.71 ≤-27 PASS 5925~27000 25552.85 -32.34 ≤-27 PASS 5785 30~5650 4957.99 -38.92 ≤-27 PASS 5925~27000 26098.69 -31.16 ≤-27 PASS 5825 30~5650 5452.74 -40.34 ≤-27 PASS 5925~27000 26413.41 -31.25 ≤-27 PASS 11N40SISO Ant1 5755 30~5650 5646.82 -37.69 ≤-27 PASS 5925~27000 24286.95 -31.42 ≤-27 PASS 5795 30~5650 3113.51 -40.16 ≤-27 PASS 5925~27000 26123.28 -30.47 ≤-27 PASS 11AC20SISO Ant1 5745 30~5650 5498.07 -39.62 ≤-27 PASS 5925~27000 24943.08 -31.47 ≤-27 PASS 5785 30~5650 2657.35 -40.57 ≤-27 PASS 5925~27000 24246.2 -31.56 ≤-27 PASS 5825 30~5650 3305.15 -38.63 ≤-27 PASS 5925~27000 23537.38 -31.43 ≤-27 PASS 11AC40SISO Ant1 5755 30~5650 5648.5 -35.48 ≤-27 PASS 5925~27000 24340.34 -32.14 ≤-27 PASS 5795 30~5650 5473.53 -39.68 ≤-27 PASS 5925~27000 26610.11 -30.68 ≤-27 PASS 11AX20SISO Ant1 5745 30~5650 5562.89 -39.45 ≤-27 PASS 5925~27000 25651.2 -30.89 ≤-27 PASS 5785 30~5650 3004.48 -39.48 ≤-27 PASS 5925~27000 24253.93 -30.74 ≤-27 PASS 5825 30~5650 5591.55 -39.25 ≤-27 PASS 5925~27000 24270.79 -30.8 ≤-27 PASS 11AX40SISO Ant1 5755 30~5650 5645.88 -34.75 ≤-27 PASS 5925~27000 24133.1 -31.68 ≤-27 PASS 5795 30~5650 5469.22 -39.91 ≤-27 PASS 5925~27000 26707.76 -31.34 ≤-27 PASS FCC ID:2BFIZ-X7AR 47 Test Graphs 11A_Ant1_5745_30~5650 11A_Ant1_5745_5925~27000 11A_Ant1_5785_30~5650 FCC ID:2BFIZ-X7AR 48 11A_Ant1_5785_5925~27000 11A_Ant1_5825_30~5650 FCC ID:2BFIZ-X7AR 49 11A_Ant1_5825_5925~27000 11N20SISO_Ant1_5745_30~5650 11N20SISO_Ant1_5745_5925~27000 FCC ID:2BFIZ-X7AR 50 11N20SISO_Ant1_5785_30~5650 11N20SISO_Ant1_5785_5925~27000 FCC ID:2BFIZ-X7AR 51 11N20SISO_Ant1_5825_30~5650 11N20SISO_Ant1_5825_5925~27000 11N40SISO_Ant1_5755_30~5650 FCC ID:2BFIZ-X7AR 52 11N40SISO_Ant1_5755_5925~27000 11N40SISO_Ant1_5795_30~5650 FCC ID:2BFIZ-X7AR 53 11N40SISO_Ant1_5795_5925~27000 11AC20SISO_Ant1_5745_30~5650 11AC20SISO_Ant1_5745_5925~27000 FCC ID:2BFIZ-X7AR 54 11AC20SISO_Ant1_5785_30~5650 11AC20SISO_Ant1_5785_5925~27000 FCC ID:2BFIZ-X7AR 55 11AC20SISO_Ant1_5825_30~5650 11AC20SISO_Ant1_5825_5925~27000 11AC40SISO_Ant1_5755_30~5650 FCC ID:2BFIZ-X7AR 56 11AC40SISO_Ant1_5755_5925~27000 11AC40SISO_Ant1_5795_30~5650 FCC ID:2BFIZ-X7AR 57 11AC40SISO_Ant1_5795_5925~27000 11AX20SISO_Ant1_5745_30~5650 11AX20SISO_Ant1_5745_5925~27000 FCC ID:2BFIZ-X7AR 58 11AX20SISO_Ant1_5785_30~5650 11AX20SISO_Ant1_5785_5925~27000 FCC ID:2BFIZ-X7AR 59 11AX20SISO_Ant1_5825_30~5650 11AX20SISO_Ant1_5825_5925~27000 11AX40SISO_Ant1_5755_30~5650 FCC ID:2BFIZ-X7AR 60 11AX40SISO_Ant1_5755_5925~27000 11AX40SISO_Ant1_5795_30~5650 FCC ID:2BFIZ-X7AR 61 11AX40SISO_Ant1_5795_5925~27000 FCC ID:2BFIZ-X7AR 62 Appendix E.8:Emissions in Restricted Bands Test Result TestMode Antenna ChName Freq(MHz ) Detector Freq [MHz] Result [dBm] Limit [dBm] Verdict 11A Ant1 Low 5745 Peak 5650.000 -38.879 ≤-27.00 PASS Peak 5700.000 -28.04 ≤10.00 PASS Peak 5720.000 -22.16 ≤15.60 PASS Peak 5725.000 -17.5 ≤27.00 PASS High 5825 Peak 5850.000 -19.674 ≤27.00 PASS Peak 5855.000 -21.02 ≤15.60 PASS Peak 5875.000 -29.25 ≤10.00 PASS Peak 5925.000 -36.39 ≤-27.00 PASS 11N20SIS O Ant1 Low 5745 Peak 5650.000 -37.779 ≤-2…

Text truncated - open the document above for the full version.

FCC ID:2BFIZ-X7AR 1 Case No. :GTS20250919018-2-12 Ambient Condition: 22 °C, 49 %RH According Standard: ■Part15E Test Date: 2025.9.30-2025.10.21 Test Engineer: Evan ouyang Appendix E.1: Occupied channel bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5745 18.299 5735.8921 5754.1911 --- --- 5785 18.370 5775.7352 5794.1052 --- --- 5825 18.408 5815.6898 5834.0978 --- --- 11N20SISO Ant1 5745 19.502 5735.1996 5754.7016 --- --- 5785 19.346 5775.2872 5794.6332 --- --- 5825 19.363 5815.2268 5834.5898 --- --- 11N40SISO Ant1 5755 38.221 5735.9831 5774.2041 --- --- 5795 38.189 5775.9134 5814.1024 --- --- 11AC20SISO Ant1 5745 19.449 5735.3627 5754.8117 --- --- 5785 19.366 5775.3127 5794.6787 --- --- 5825 19.280 5815.3350 5834.6150 --- --- 11AC40SISO Ant1 5755 38.527 5735.8512 5774.3782 --- --- 5795 38.209 5776.0030 5814.2120 --- --- 11AX20SISO Ant1 5745 19.700 5735.1836 5754.8836 --- --- 5785 19.718 5775.1589 5794.8769 --- --- 5825 19.785 5815.0910 5834.8760 --- --- 11AX40SISO Ant1 5755 38.756 5735.7089 5774.4649 --- --- 5795 38.717 5775.6617 5814.3787 --- --- FCC ID:2BFIZ-X7AR 2 Test Graphs 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 FCC ID:2BFIZ-X7AR 3 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 FCC ID:2BFIZ-X7AR 4 11N20SISO_Ant1_5825 11N40SISO_Ant1_5755 11N40SISO_Ant1_5795 FCC ID:2BFIZ-X7AR 5 11AC20SISO_Ant1_5745 11AC20SISO_Ant1_5785 FCC ID:2BFIZ-X7AR 6 11AC20SISO_Ant1_5825 11AC40SISO_Ant1_5755 11AC40SISO_Ant1_5795 FCC ID:2BFIZ-X7AR 7 11AX20SISO_Ant1_5745 11AX20SISO_Ant1_5785 FCC ID:2BFIZ-X7AR 8 11AX20SISO_Ant1_5825 11AX40SISO_Ant1_5755 11AX40SISO_Ant1_5795 FCC ID:2BFIZ-X7AR 9 FCC ID:2BFIZ-X7AR 10 Appendix E.2: Min emission bandwidth Test Result B4 TestMode Antenna Freq(MHz) 6db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5745 16.360 5736.800 5753.160 0.5 PASS 5785 16.400 5776.760 5793.160 0.5 PASS 5825 16.360 5816.800 5833.160 0.5 PASS 11N20SISO Ant1 5745 17.600 5736.160 5753.760 0.5 PASS 5785 17.600 5776.160 5793.760 0.5 PASS 5825 17.600 5816.160 5833.760 0.5 PASS 11N40SISO Ant1 5755 36.320 5736.840 5773.160 0.5 PASS 5795 36.320 5776.840 5813.160 0.5 PASS 11AC20SISO Ant1 5745 17.560 5736.200 5753.760 0.5 PASS 5785 17.600 5776.160 5793.760 0.5 PASS 5825 17.600 5816.160 5833.760 0.5 PASS 11AC40SISO Ant1 5755 36.320 5736.840 5773.160 0.5 PASS 5795 36.320 5776.840 5813.160 0.5 PASS 11AX20SISO Ant1 5745 19.040 5735.480 5754.520 0.5 PASS 5785 19.000 5775.480 5794.480 0.5 PASS 5825 19.040 5815.440 5834.480 0.5 PASS 11AX40SISO Ant1 5755 37.920 5736.120 5774.040 0.5 PASS 5795 38.080 5775.960 5814.040 0.5 PASS FCC ID:2BFIZ-X7AR 11 Test Graphs B4 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 FCC ID:2BFIZ-X7AR 12 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 FCC ID:2BFIZ-X7AR 13 11N20SISO_Ant1_5825 11N40SISO_Ant1_5755 11N40SISO_Ant1_5795 FCC ID:2BFIZ-X7AR 14 11AC20SISO_Ant1_5745 11AC20SISO_Ant1_5785 FCC ID:2BFIZ-X7AR 15 11AC20SISO_Ant1_5825 11AC40SISO_Ant1_5755 11AC40SISO_Ant1_5795 FCC ID:2BFIZ-X7AR 16 11AX20SISO_Ant1_5745 11AX20SISO_Ant1_5785 FCC ID:2BFIZ-X7AR 17 11AX20SISO_Ant1_5825 11AX40SISO_Ant1_5755 11AX40SISO_Ant1_5795 FCC ID:2BFIZ-X7AR 18 FCC ID:2BFIZ-X7AR 19 AppendixE.3: Duty Cycle Test Result TestMode Antenna Freq(MHz) Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] Duty Cycle Factor[dB] 1/T Factor[KHz] 11A Ant1 5745 1.39 1.44 96.53 0.15 0.72 5785 2.04 2.21 92.31 0.35 0.49 5825 2.03 2.20 92.27 0.35 0.49 11N20SISO Ant1 5745 1.90 2.07 91.79 0.37 0.53 5785 1.89 2.05 92.20 0.35 0.53 5825 1.89 2.03 93.10 0.31 0.53 11N40SISO Ant1 5755 0.93 1.17 79.49 1.00 1.08 5795 0.93 1.14 81.58 0.88 1.08 11AC20SISO Ant1 5745 1.31 1.35 97.04 0.13 0.76 5785 1.90 2.14 88.79 0.52 0.53 5825 1.90 2.08 91.35 0.39 0.53 11AC40SISO Ant1 5755 0.94 1.26 74.60 1.27 1.06 5795 0.94 1.15 81.74 0.88 1.06 11AX20SISO Ant1 5745 1.46 1.70 85.88 0.66 0.68 5785 1.47 1.79 82.12 0.86 0.68 5825 1.46 1.64 89.02 0.51 0.68 11AX40SISO Ant1 5755 0.77 0.96 80.21 0.96 1.30 5795 0.76 0.97 78.35 1.06 1.32 FCC ID:2BFIZ-X7AR 20 Test Graphs 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 FCC ID:2BFIZ-X7AR 21 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 FCC ID:2BFIZ-X7AR 22 11N20SISO_Ant1_5825 11N40SISO_Ant1_5755 11N40SISO_Ant1_5795 FCC ID:2BFIZ-X7AR 23 11AC20SISO_Ant1_5745 11AC20SISO_Ant1_5785 FCC ID:2BFIZ-X7AR 24 11AC20SISO_Ant1_5825 11AC40SISO_Ant1_5755 11AC40SISO_Ant1_5795 FCC ID:2BFIZ-X7AR 25 11AX20SISO_Ant1_5745 11AX20SISO_Ant1_5785 FCC ID:2BFIZ-X7AR 26 11AX20SISO_Ant1_5825 11AX40SISO_Ant1_5755 11AX40SISO_Ant1_5795 FCC ID:2BFIZ-X7AR 27 FCC ID:2BFIZ-X7AR 28 Appendix E.4: Maximum conducted output power Test Result Channel Power Test Mode Antenna Freq(MHz) Channel Powert [dBm] Duty Cycle [%] DC Factor [dBm] Result [dBm] Limit [dBm] Verdict 11A Ant1 5745 14.76 96.53 0.15 14.91 ≤30.00 PASS 5785 14.17 92.31 0.35 14.52 ≤30.00 PASS 5825 15.08 92.27 0.35 15.43 ≤30.00 PASS 11N20SISO Ant1 5745 14.15 91.79 0.37 14.52 ≤30.00 PASS 5785 14.38 92.20 0.35 14.73 ≤30.00 PASS 5825 14.71 93.10 0.31 15.02 ≤30.00 PASS 11N40SISO Ant1 5755 13.47 79.49 1.00 14.47 ≤30.00 PASS 5795 13.78 81.58 0.88 14.66 ≤30.00 PASS 11AC20SISO Ant1 5745 15.38 97.04 0.13 15.51 ≤30.00 PASS 5785 14.58 88.79 0.52 15.10 ≤30.00 PASS 5825 14.68 91.35 0.39 15.07 ≤30.00 PASS 11AC40SISO Ant1 5755 12.71 74.60 1.27 13.98 ≤30.00 PASS 5795 14.16 81.74 0.88 15.04 ≤30.00 PASS 11AX20SISO Ant1 5745 13.87 85.88 0.66 14.53 ≤30.00 PASS 5785 14.90 82.12 0.86 15.76 ≤30.00 PASS 5825 15.11 89.02 0.51 15.62 ≤30.00 PASS 11AX40SISO Ant1 5755 13.54 80.21 0.96 14.50 ≤30.00 PASS 5795 13.98 78.35 1.06 15.04 ≤30.00 PASS FCC ID:2BFIZ-X7AR 29 Appendix E.5: Maximum power spectral density Test Result TestMode Antenna Freq(MHz) Result [dBm/MHz] Limit[dBm/MHz] Verdict 11A Ant1 5745 0.53 ≤30.00 PASS 5785 1.15 ≤30.00 PASS 5825 1.05 ≤30.00 PASS 11N20SISO Ant1 5745 0.03 ≤30.00 PASS 5785 0.57 ≤30.00 PASS 5825 0.44 ≤30.00 PASS 11N40SISO Ant1 5755 -2.56 ≤30.00 PASS 5795 -2.25 ≤30.00 PASS 11AC20SISO Ant1 5745 0.87 ≤30.00 PASS 5785 0.57 ≤30.00 PASS 5825 0.40 ≤30.00 PASS 11AC40SISO Ant…

Text truncated - open the document above for the full version.

FCC ID:2BFIZ-X7AR 38 Appendix D.6:Band edge measurements Test Result B1 TestMode Antenna ChName Freq(MHz) Result[dBm] Limit[dBm] Verdict 11A Ant1 Low 5180 -32.33 ≤-27 PASS High 5240 -36.7…
