2BFPM-PERI-2Wearable Bio-sensor

Safety Manual General Use Wearing the device • The Peri device is worn under the breast on either the right or left side of the body. It is secured to the skin using the supplied adhesive patch only. The minimum recommended wear time for the patch is 7-10 days but it is designed to be worn for up to 14 days. • When removing the adhesive, pull the edge of the adhesive and peel off. Do not pull the device from the skin to remove the adhesive. • After removing the adhesive patch, gently cleanse the skin with mild soap and water. When reapplying the device, switch to the other side of the body, to allow the skin to rest. Avoid prolonged use without repositioning or replacing the adhesive patch. • For optimal results it is recommended to keep the patch on for at least 7 days. Removing the patch earlier than this can cause irritation and redness at the application site. • If the device needs to be removed earlier than 7 days, it is recommended to leave the adhesive in place and detach the device from the adhesive. Removing the patch in the shower under warm running water will make it easier to remove if needed. When re- attaching the device, use a new adhesive on the other side of the body. • Peri is designed for 24/7 usage and can be worn during showers and baths. It has been tested to an IPX8 rating, meaning it is dust-tight, providing full protection against dust ingress. The device is resistant to immersion in water up to a depth of 1 meter for a maximum of 60 minutes. Remove the device if swimming for longer than 60-mins, diving, snorkelling or other deep-water immersion. • Peri is designed to be worn in temperatures ranging from -10°C to 45°C (14°F to 113°F). Avoid exposing the device and batteries to excessive heat. Remove the device if using a sauna or other hot environment, as there is a risk the metal plates at the back of the device could heat up and cause pain or skin damage. Storage and maintenance • If the device and batteries are stored, they should be kept in a dry location between 0°C to 35°C (32°F to 95°F) • Do not use harsh chemicals, solvents, or abrasive cleaners, as these may damage the materials. Ensure the device is completely dry before reattaching or wearing. • This product contains small parts that could present a choking hazard. Keep out of reach of young children and pets when not in use. • When traveling, consult with your airline about their policy for lithium-ion batteries. Charging the device • This device comes with two interchangeable rechargeable lithium-ion batteries. The batteries provided with this product comply with applicable safety standards, including IEC 62133 (Safety requirements for portable sealed secondary lithium cells and batteries). These batteries are designed to last for the lifetime of the product under normal use. • Only manufacturer-approved batteries should be used. Use of unapproved batteries could present a fire hazard, risk of explosion, or device malfunction, and will void the warranty. Handle batteries with care when inserting or removing them from the device. • The Peri charger is not water resistant and is intended for indoor use only. Charging should be performed at 0°C to 45°C (32°F to 113°F) Do not use or store the charger in humid environments like bathrooms. Do not expose the charger to heat, such as in a vehicle or directly in the sun and do not charge Peri in such an environment. • Use only the charging cradle and USB cable provided with this product. The charging cradle is certified by the U.S. Department of Energy (DoE). This charging cradle is designed to be charged using a safety-certified power supply (power adapter) that meets applicable local regulatory requirements. The power supply should meet the energy efficiency requirements set by the U.S. DoE and provide an output of 5 volts DC (volts direct current) and a maximum output current of 1A (amperes) via a standard USB port. Using an unapproved power supply, or exceeding the recommended voltage or current, may result in overheating, fire, or damage to the product and void the warranty. • Do not puncture, crush, disassemble, or short-circuit the device or batteries • Do not expose the device or batteries to fire, explosion, or another hazard. If a battery or the device emits smoke, excessive heat, swelling, or a burning smell, stop using it immediately and contact the manufacturer. • The Peri charging cradle contains magnets. Keep away from items that may be sensitive to magnetic fields, such as credit cards, key cards, and implantable medical devices. Health Warnings • Peri is not a medical device and is not intended to diagnose, treat, cure, monitor, or prevent any medical condition or disease. The information provided by this device and its accompanying app is for informational purposes only and should not be considered medical advice. • If you have a pacemaker or other internal electronic device, consult your physician before using the Peri device. • If you make any changes to your lifestyle or behaviour based on data from Peri, you agree you do so at your own risk. You should always consult a physician if you have any questions regarding a medical condition or any changes you intend to make to your lifestyle choices based on information from Peri. Never disregard or delay in seeking professional medical advice because of something you’ve read from the Peri app. • Peri relies on sensors that track your motion, skin conductivity, temperature, blood volume changes, and other metrics. The translation of this data into menopausal symptoms is intended to be a close estimation of your activity and symptoms but may not be completely accurate. The information and guidance provided by Peri may be misleading if your physiological functions and responses differ significantly from population averages due to medical conditions or rare natural differences. The reporting of hot flushes, night sweats, sleep disturbance, anxiety and other readings are for reference only, and no …

Text truncated - open the document above for the full version.

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Signature: Signed by (Printed Name/Title): Tim Payne/Manager This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: identifyher Ltd FRN: 0035117084 Grantee Code: 2BFPM FCC ID: 2BFPM-PERI-2 Contact Name: Donal O'Gorman Address: 13 Adelaide Road Dublin Ireland Telephone No: 00353874735322 Email: [email protected] Date: 2026-01-27 Signed by (Printed Name/Title): Donal O'Gorman

identifyHer Ltd 13 Adelaide Rd Dublin D02P950 Ireland Phone: +353-87-4735322 Email: [email protected] www.myperi.co 2026-01-27 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2BFPM-PERI-2 To Whom It May Concern: identifyher Ltd certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber- security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Donal O'Gorman Cofounder and Chief Operating Office identifyHer Ltd 13 Adelaide Rd Dublin D02P950 Ireland Phone: +353-87-4735322 Email: [email protected] www.myperi.co 2026-01-27 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2BFPM-PERI-2 To Whom It May Concern: identifyher Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Donal O'Gorman Cofounder and Chief Operating Office

identifyHer Ltd 13 Adelaide Rd Dublin D02P950 Ireland Phone: +353-87-4735322 Email: [email protected] www.myperi.co 2026-01-27 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Letter of Agent Authorization To Whom It May Concern: We, the undersigned, hereby authorize (Eurofins Electrical Testing Service (Shenzhen) Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Donal O'Gorman Cofounder and Chief Operating Officer

identifyHer Ltd 13 Adelaide Rd Dublin D02P950 Ireland Phone: +353-87-4735322 Email: [email protected] www.myperi.co 2026-01-27 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Confidentiality request for Wearable Bio-sensor / IDH-AA-01, IDH-AA-06 / FCC ID: 2BFPM-PERI-2 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagrams, Schematics, Operational Descriptions) required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Donal O'Gorman Cofounder and Chief Operating Officer

identifyHer Ltd 13 Adelaide Rd Dublin D02P950 Ireland Phone: +353-87-4735322 Email: [email protected] www.myperi.co 2026-01-28 Declaration on model difference We, identifyher Ltd, the undersigned hereby declare that the device's schematics, PCB layout and all other electrical aspects of the device are identical. The only differences are the model name. Product name: Wearable Bio-sensor Model name: IDH-AA-01, IDH-AA-06 FCC ID: 2BFPM-PERI-2 Sincerely, Donal O'Gorman Cofounder and Chief Operating Officer

EFGX25120051-IE-01-External Photos 1 / 5 External Photos Model Name: IDH-AA-01, IDH-AA-06 EFGX25120051-IE-01-External Photos 2 / 5 EFGX25120051-IE-01-External Photos 3 / 5 EFGX25120051-IE-01-External Photos 4 / 5 EFGX25120051-IE-01-External Photos 5 / 5

EFGX25120051-IE-01-Internal Photos 1 / 5 Internal Photos Model Name: IDH-AA-01, IDH-AA-06 EFGX25120051-IE-01-Internal Photos 2 / 5 EFGX25120051-IE-01-Internal Photos 3 / 5 EFGX25120051-IE-01-Internal Photos 4 / 5 EFGX25120051-IE-01-Internal Photos 5 / 5

Radio frequency radiation exposure evaluation: portable devices RESULT : Pass Test Specification Test item : Wearable Bio-sensor Identification / Type No. : IDH-AA-01, IDH-AA-06 FCC ID : 2BFPM-PERI-2 Test standard : CFR47 FCC Part 2: Section 2.1093 FCC KDB Publication 447498 D04 Calculation Method according to KDB 447498 D04 and f is in GHz, d is the separation distance (cm), and ERP20cm is per Formula (B.1). The example values shown in Table B.2 are for illustration only. FCC Measurement Record: Test Mode Conducted Power (dBm) Conducted Power (mW) ERP (dBm) ERP (mW) Minimum Separation Distances (mm) Limit (mW) BLE -2.57 0.553 -2.02 0.628 5 2.72 Hence the EUT is excluded from SAR evaluation if the distance between the antenna and the human body is equal or above one of the minimum distances depicted in the tables above, depending on the wireless protocol in use, in accordance with FCC KDB Publication 447498 D04

EFGX25120051-IE-01-E01_appendix 26 / 51 BLE_2M_Ant1_2402_1000~26500 BLE_2M_Ant1_2440_0~Reference EFGX25120051-IE-01-E01_appendix 27 / 51 BLE_2M_Ant1_2440_30~1000 BLE_2M_Ant1_2440_1000~26500 EFGX25120051-IE-01-E01_appendix 28 / 51 BLE_2M_Ant1_2480_0~Reference BLE_2M_Ant1_2480_30~1000 EFGX25120051-IE-01-E01_appendix 29 / 51 BLE_2M_Ant1_2480_1000~26500 EFGX25120051-IE-01-E01_appendix 30 / 51 Appendix G: Duty Cycle Test Result TestMode Antenna Channel ON Time [ms] Period [ms] X DC [%] BLE_1M Ant1 2402 0.40 0.63 0.6349 63.49 2440 0.39 0.63 0.6190 61.90 2480 0.40 0.63 0.6349 63.49 BLE_2M Ant1 2402 0.21 0.63 0.3333 33.33 2440 0.21 0.63 0.3333 33.33 2480 0.21 0.63 0.3333 33.33 EFGX25120051-IE-01-E01_appendix 31 / 51 Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 EFGX25120051-IE-01-E01_appendix 32 / 51 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 EFGX25120051-IE-01-E01_appendix 33 / 51 BLE_2M_Ant1_2480 EFGX25120051-IE-01-E01_appendix 34 / 51 Appendix H: Emissions in Restricted Bands Test Result Mode: LE 1M Channel: 2402 MHz Antenna: / State: Tx Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 2390 36.43 39.38 2.95 74.00 34.62 145.4 140 PK Horizontal PASS 2 2483.5 37.55 41.01 3.46 74.00 32.99 145.4 270 PK Horizontal PASS EFGX25120051-IE-01-E01_appendix 35 / 51 Mode: LE 1M Channel: 2402 MHz Antenna: / State: Tx Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 2390 36.84 39.79 2.95 74.00 34.21 249.3 40 PK Vertical PASS 2 2483.5 37.76 41.22 3.46 74.00 32.78 249.3 200 PK Vertical PASS EFGX25120051-IE-01-E01_appendix 36 / 51 Mode: LE 1M Channel: 2480 MHz Antenna: / State: Tx Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 2390 37.59 40.54 2.95 74.00 33.46 145.4 120 PK Horizontal PASS 2 2483.5 36.80 40.26 3.46 74.00 33.74 145.4 240 PK Horizontal PASS EFGX25120051-IE-01-E01_appendix 37 / 51 Mode: LE 1M Channel: 2480 MHz Antenna: / State: Tx Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 2390 36.52 39.47 2.95 74.00 34.53 249.3 270 PK Vertical PASS 2 2483.5 37.98 41.44 3.46 74.00 32.56 249.3 50 PK Vertical PASS EFGX25120051-IE-01-E01_appendix 38 / 51 Mode: LE 2M Channel: 2402 MHz Antenna: / State: Tx Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 2390 37.32 40.27 2.95 74.00 33.73 145.4 270 PK Horizontal PASS 2 2483.5 36.98 40.44 3.46 74.00 33.56 145.4 230 PK Horizontal PASS EFGX25120051-IE-01-E01_appendix 39 / 51 Mode: LE 2M Channel: 2402 MHz Antenna: / State: Tx Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 2390 37.64 40.59 2.95 74.00 33.41 249.3 230 PK Vertical PASS 2 2483.5 37.23 40.69 3.46 74.00 33.31 249.3 50 PK Vertical PASS EFGX25120051-IE-01-E01_appendix 40 / 51 Mode: LE 2M Channel: 2480 MHz Antenna: / State: Tx Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 2390 36.45 39.40 2.95 74.00 34.60 145.4 320 PK Horizontal PASS 2 2483.5 37.05 40.51 3.46 74.00 33.49 145.4 320 PK Horizontal PASS EFGX25120051-IE-01-E01_appendix 41 / 51 Mode: LE 2M Channel: 2480 MHz Antenna: / State: Tx Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 2390 38.40 41.35 2.95 74.00 32.65 249.3 80 PK Vertical PASS 2 2483.5 36.96 40.42 3.46 74.00 33.58 249.3 40 PK Vertical PASS EFGX25120051-IE-01-E01_appendix 42 / 51 Appendix I: Spurious emissions The low frequency, which starts from 9 kHz to 30 MHz, is pre-scanned and the result which is 20 dB lower than the limit line is not reported. During the test, the Radiates Emission from 30MHz to 1GHz was performed in all modes with all channels. The test data of the worst-case (1M-2402MHz) condition was recorded in this report. The measurement results above 18GHz were greater than 20dB below the limit, so only the radiated spurious emissions from 30MHz to 18GHz are reported. QP Final Data List NO. Freq. [MHz] Factor [dB/m] QP Value [dBμV/m] QP Limit [dBμV/m] QP Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 55.9475 -14.53 14.20 40.00 25.80 100 209 Vertical PASS 2 147.8550 -14.05 16.38 43.50 27.12 100 236 Vertical PASS 3 297.1138 -13.92 16.29 46.00 29.71 200 327 Vertical PASS 4 448.5550 -9.94 20.22 46.00 25.78 100 13 Vertical PASS 5 595.2675 -6.92 23.54 46.00 22.46 100 147 Vertical PASS 6 828.6738 -2.38 30.48 46.00 15.52 100 310 Vertical PASS EFGX25120051-IE-01-E01_appendix 43 / 51 QP Final Data List NO. Freq. [MHz] Factor [dB/m] QP Value [dBμV/m] QP Limit [dBμV/m] QP Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 47.5812 -14.04 14.14 40.00 25.86 100 350 Horizontal PASS 2 125.3025 -15.20 16.55 43.50 26.95 200 298 Horizontal PASS 3 157.6762 -13.81 15.02 43.50 28.48 100 311 Horizontal PASS 4 223.1512 -17.16 14.26 46.00 31.74 200 96 Horizontal PASS 5 469.6525 -9.60 22.01 46.00 23.99 100 278 Horizontal PASS 6 809.0312 -2.83 26.95 46.00 19.05 100 111 Horizontal PASS EFGX25120051-IE-01-E01_appendix 44 / 51 Mode: LE 1M Channel: 2402 MHz Antenna: / State: Tx Test Graph Final Data List NO. Frequency [MHz] Factor [dB] PK Reading [dBμV/m] PK Value [dBμV/m] PK Limit [dBμV/m] PK Margin [dB] AV Limit [dBμV/m] Height [cm] Angle [°] Polarity Verdict 1 4804 -14.53 52.82 38.29 74.00 35.71 54.00 150 69 Vertical PASS 2 4804 -14.53 52.06 37.53 74.00 36.47 54…

Text truncated - open the document above for the full version.

EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC Compliance Test Report for Product name: Wearable Bio-sensor Model name: IDH-AA-01, IDH-AA-06 FCC ID: 2BFPM-PERI-2 Test Report Number: EFGX25120051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Phone: +86-0755-829118671 Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8 Fax: +86-0755-82910749 Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Page 1 of 26 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of applicant 4 1.4 Details of manufacturer 4 1.5 Application details 5 1.6 Test item 5 1.7 Test standards 5 2 Technical test 6 2.1 Summary of test results 6 2.2 Test environment 6 2.3 Measurement uncertainty 6 2.4 Test mode 7 2.5 Test equipment utilized 8 2.6 Auxiliary equipment used during test 9 2.7 Test software information 9 2.8 Test setup 10 2.9 Test results 12 3 Technical Requirement 13 3.1 Conducted emission AC power port 13 3.2 Duty cycle 14 3.3 6dB bandwidth 15 3.4 99% Occupied Bandwidth 16 3.6 Conducted Peak output power 17 3.7 Power spectral density 18 3.8 Conducted Spurious Emissions 19 3.9 Band edge 20 3.10 Spurious radiated emissions for transmitter 23 4 Test Setup Photos 26 5 External Photo 26 6 Internal Photos 26 7 Appendix 26 Test Report No.: EFGX25120051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Page 3 of 26 1 General Information 1.1 Notes The results of this test report relate exclusively to the item tested as specified in chapter “Description of test item” and are not transferable to any other test items. Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. is not responsible for any generalisations and conclusions drawn from this report. Any modification of the test item can lead to invalidity of test results and this test report may therefore be not applicable to the modified test item. The test report may only be reproduced or published in full. Reproducing or publishing extracts of the report requires the prior written approval of the Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. This document is subject to the General Terms and Conditions and the Testing and Certification System of Eurofins Electrical Testing Service (Shenzhen) Co., Ltd., available on request or accessible at www.eurofins.com. Operator: 2026-02-03 Bruce Zheng / Project Engineer Date Eurofins-Lab. Name / Title Signature Technical responsibility for area of testing: 2026-02-03 Albert Xu / Lab Manager Date Eurofins-Lab. Name / Title Signature Test Report No.: EFGX25120051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Page 4 of 26 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of applicant Name : IDENTIFYHER LTD Address : 13 ADELAIDE ROAD, DUBLIN D02P950, IRELAND Telephone : ./. Fax : ./. 1.4 Details of manufacturer Name : IDENTIFYHER LTD Address : 13 ADELAIDE ROAD, DUBLIN D02P950, IRELAND Telephone : ./. Fax : ./. Test Report No.: EFGX25120051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Page 5 of 26 1.5 Application details Date of receipt of application : 2025-12-02 Date of receipt of test item : 2025-12-02 Date of test : 2025-12-02 to 2026-02-03 Date of issue : 2026-02-03 1.6 Test item Product type : Wearable Bio-sensor Model name : IDH-AA-01, IDH-AA-06 Sample ID : 251202-15-001 Brand : PERI Serial number : ./. Ratings : Input : 5VDC, 1A; Battery: DC 3.8V Test voltage : 3.8V RadioTechnical data Frequency range : 2402MHz – 2480MHz Radio Tech. : Bluetooth Low Energy Frequency channel : 40 Channels Modulation : GFSK Antenna type : Internal antenna Maximum antenna gain : 2.70 dBi Additional information : 1. According to the declaration from the applicant, all models are identical except model name. Therefore model IDH-AA-01 was chosen to test full items. The above sample(s) and sample information was/were submitted and identified on behalf of the applicant. Eurofins assures objectivity and impartiality of the test, and fulfills the obligation of confidentiality for applicant’s commercial infor- mation and technical documents. 1.7 Test standards Test Standards FCC Part 15 Subpart C PART 15 - RADIO FREQUENCY DEVICES Subpart C - Intentional Radiators RSS-247 Digital Transmission Systems, Frequency Hopping Systems and Li- cence-Exempt Local Area Network Devices in 902-928 MHz, 2400- 2483.5 MHz, 5150-5350 MHz, and 5470-5895 MHz bands Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2020 + COR.1-2023, American National Standard for Testing Unlicensed Wireless Devices. 3: KDB558074 D01 15.247 Meas Guidance v05r02 Test Report No.: EFGX25120051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen)…

Text truncated - open the document above for the full version.

APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz/5GHz Ceramic SMT antenna Application Specification SHEET No. A EC No: 1 of 26 DATE: DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: 2119640001 Liu Hai 2018/12/24 Cooper Zhou 2018/12/24 Chris Zhong 2018/12/24 TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC TITLE 2.4GHZ/5GHZ CERAMIC SMT ANTENNA TABLE OF CONTENTS 1.0 SCOPE 2.0 PRODUCT DESCRIPTION 3.0 APPLICABLE DOCUMENTS 4.0 ANTENNA PERFORMANCE 5.0 MATCHING NETWORK DESRICPTION 6.0 RECOMMENDED REFLOW CONDITION 7.0 RF PERFORMANCE AS A FUNCTION OF IMPLEMENTATION APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz/5GHz Ceramic SMT antenna Application Specification SHEET No. A EC No: 2 of 26 DATE: DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: 2119640001 Liu Hai 2018/12/24 Cooper Zhou 2018/12/24 Chris Zhong 2018/12/24 TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC 2.4GHZ/5GHZ CERAMIC SMT ANTENNA 1.0 SCOPE This specification describes the antenna application and surrounding. The information in this document is for reference and benchmark purposes only. Antenna illustrations in this document are generic representations. They are not intended to be an image of any antenna listed in the scope. 2.0 PRODUCT DESCRIPTION 2.1 PRODUCT NAME AND SERIES NUMBER (S) Product name: 2.4GHz/5GHz Ceramic SMT antenna Series Number: 211964**** 2.2 DESCRIPTION 211964 is 2.4GHz/5GHz ceramic loop antenna. It works very well when being placed at PCB Center-edge. With applying different matching setup, it supports 2.4GHz single band or 2.4/5GHz dual band. 2.3 PRODUCT STRUCTURE INFORMATION Please refer to PS-2119640001 for full information. Molex 2119640001 2.4GHz/5GHz Ceramic SMT antenna 3D VIEW Size: 3.20(L) by 1.60(W) by 1.20(H)mm APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz/5GHz Ceramic SMT antenna Application Specification SHEET No. A EC No: 3 of 26 DATE: DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: 2119640001 Liu Hai 2018/12/24 Cooper Zhou 2018/12/24 Chris Zhong 2018/12/24 TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC 3.0 APPLICABLE DOCUMENTS DOCUMENT NUMBER DESCRIPTION Sale Drawing (SD) SD-2119640001 Mechanical Dimension of the product Product Specification (PS) PS-2119640001 Product Specification Packing Drawing (PK) PK-2119640001 Product packaging specifications 4.0 ANTENNA PERFORMANCE 4.1 RF TEST CONDITIONS All measurements are done of the antenna mounted on a reference PCB (40*20*0.8mm) with VNA Agilent E5071C and Over-The-Air (OTA) chamber. FIGURE4.1.1 ANTENNA LOADED WITH REFERENCE PCB TESTED WITH VNA E5071C DUT APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz/5GHz Ceramic SMT antenna Application Specification SHEET No. A EC No: 4 of 26 DATE: DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: 2119640001 Liu Hai 2018/12/24 Cooper Zhou 2018/12/24 Chris Zhong 2018/12/24 TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC FIGURE4.1.2 ANTENNA LOADED WITH REFERENCE PCB TESTED IN OTA CHAMBER 4.2 ANTENNA PERFORMANCE DESCRIPTION EQUIPMENT Requirements (For Configure 1) Requirements (For Configure 2) Frequency Range VNA E5071C 2.4-2.5GHz 2.4-2.5GHz 5.15-5.85GHz Return Loss VNA E5071C < -6 dB < -5 dB < -5 dB Peak Gain (Max) OTA Chamber 2.7dBi 2.1dBi 2.2dBi Average Total Efficiency OTA Chamber >80% >70% >65% Polarization OTA Chamber Linear Input Impedance VNA E5071C 50 ohms Note that the above antenna performance is measured with just the antenna mounted on a reference PCB to similar a free-space condition. When implement into the system, the frequency resonant might be off-tune due to the loading of surrounding components especially metal plane. This off-tune can be compensated through matching. Although module manufacturers specify a peak gain limit, it is based on free-space conditions. The peak gain will be degraded by 1 to 2dBi in the actual implementation as the radiation pattern will change due to the surround components. As such, during selection of antenna, you can select one with high peak gain to compensate for the loss. Molex can offer assistant to choose the best location and best tuning in-order to meet this peak gain requirement. DUT APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz/5GHz Ceramic SMT antenna Application Specification SHEET No. A EC No: 5 of 26 DATE: DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: 2119640001 Liu Hai 2018/12/24 Cooper Zhou 2018/12/24 Chris Zhong 2018/12/24 TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC 4.3 RETURN LOSS PLOT All measurements in this document are done on a reference PCB. FIGURE 4.3.1 RETURN LOSS OF ANTENNA AT 2.4GHZ IN FREE SPACE FOR CONFIGURE 1 FIGURE 4.3.2 RETURN LOSS OF ANTENNA AT 2.4/5GHZ IN FREE SPACE FOR CONFIGURE 2 APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz/5GHz Ceramic SMT antenna Application Specification SHEET No. A EC No: 6 of 26 DATE: DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: 2119640001 Liu Hai 2018/12/24 Cooper Zhou 2018/12/24 Chris Zhong 2018/12/24 TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC 4.4 EFFICIENCY PLOT All measurements in this document are done on a reference PCB. FIGURE 4.4.1 EFFICIENCY OF ANTENNA AT 2.4GHZ IN FREE SPACE FOR CONFIGURE 1 FIGURE 4.4.2 EFFICIENCY OF ANTENNA AT 2.4/5GHZ IN FREE SPACE FOR CONFIGURE 2 APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz/5GHz Ceramic SMT antenna Application Specification SHEET No. A EC No: 7 of 26 DATE: DOCUMENT NUMBER: CREATED …
