2BFQB-SW0203Smart Wall switch

Wifi&BlutoothSmartWallSwitchUserManual V1.0 Note: Whenpairing,theredlightwillflash. Whenthepairingissuccessful,theredlightwillbeoff. Theswitchstatusindicatesthegreenlightcanbesetaccordingtothe"light Modethe"canbe3kindsofindicationstatus SW02Series TechnicalParameters Workingvoltage:AC100—240V,50/60HZ Ratedload:Lessthan1100W WirelessType:Wi-Fi2.4GHz(NOTE:notsupport5GHz) Inputvoltage:AC100—240V,50/60HZ Powerconsumption:≤0.5W Workingtemperature:0°C~40°C Wifiindicatorblue,switchstatusindicatorgreen. Installationsteps ： 1)Neutralwire(Required),butnotalwayspresent.Youshouldtoget itbeforeInstallation. 2)Groundwire(Optional)suggesttoconnectup. 3)Line/Load*wire(Required).ConnecttheLoad*/Linewirescorrectly. Theyarenotinterchangeable.Ifyoucan’tensurewhichwiresisline andwhichisload,simplytryoneconfiguration. Note:verifyalltheconnectionsarecorrectlyandwirenutsarescrewed tightly. Whatisaneutralwire? Aneutralwireallowsourswitchtobepoweredwhilesimultaneouslyallowingthelightingcircuit connectedtoyourlightstobepoweroff. DoIhaveneutralwires? Ifyourhousewasbuiltinthemid-1980sorlater,thereisanexcellentchancethatyouhave neutralseverywhereinyourhome. Ifthereisanoutlet(wallreceptacle)neartheswitch,mostlikelythatswitchboxhasa neutral. Switchesthataregangedtogetherhaveamuchhigherlikelihoodofhavingneutrals,no matterwhatyear. Checkingtheswitchbox Thebestwayistochecktheactualwiresintheswitchboxwhereyouwanttoinstall. Pleaseobserveallsafetyprecautionsbeforehandlingtheelectricalwiringinyourswitch boxes. Turnoffyourbreakerbox. Takeoffthetrimplateovertheswitch. Removethescrewsfromyourswitchandpullouttheexistingswitchtolookatthewires. Ifyouseeawhitewire(orgroupofthem),itisVERYlikelythatyouhaveaneutral. Theonlywaytobeabsolutelysurethatyouhavefoundaneutralwireistocheckthevoltage (110V/120V)betweenthewhitewireandthe"hot"(usuallyblackincolor)wireinthebox.Ina standardswitch/dimmer,the"hot"isusingoneofthetwowiresconnectedtotheswitch. G r o u n d N e u t r a l L i n e L o a d 1 L o a d 2 L o a d 3 HowtodownloadApp? ScantheQRcodebeloworsearch"Smartlife"/"TuyaSmart"inIOS APPstoreorGoogleplaytodownload. Supportedsmartphonesystem:Android4.4above\IOS8.0above Step1:Registrationandlogin"Smartlife"APP. Ifyoudon'thavetheaccountof“Smartlife”APP,registeranaccountor signinwithcellphonenumber+verificationcode.Thispagedescribes theRegistrationprocess. Describes: 1.Tap"Register"intheupperright(Step1). 2.Thesystemautomaticallydeterminesyourcountry/area.Youcanalso selectyourcountrycodebyyourself.Enterthecellphonenumberor E-mailaddressandthentap“Next”(Step2). Step1 Step2 3.Ifyouentermobilecellphonenumber,youwillgetverificationcodein fewseconds,thenentertheverificationcodeinthemessage(Step3), enterpassword,tap"Done"tofinishyourregistration. 4.IfyouenterE-mailaddress,youwillgetverificationcodeinyour E-mailinfewseconds,andthenentertheverificationcodeinyour E-mail,enterpassword(Step4),tap"Done"tofinishyourregistration Step3 2 Step4 HowtoconnecttotheInternet ？ Thissmartswitchhasavarietyofparingnetworkmodes,mainlytalkingabout fastanddefaultparingnetworkmodes. A:Fastparingnetworkmode A-1.TurnonthephoneBluetooth A-2.Makesuretheredlightofthesmartswitchflashesquickly.(Ifitdoesnot flashquickly,pleasepressandholdanybuttonformorethan5secondsuntil theredlightflashesquickly.),Atthistime,thefactorysettingswillbe temporarilyrestored,iftheredlightblinkingstageisnotconnectedtothenew network,inordertopreventaccidentaldeletion,thesmartswitchwillbe connectedtothelastsuccessfulpairingnetwork A-3.Openthe"Smartlife"APPandclickonthe"+"intheupperrightcorner A-4.TheBluetoothofthemobilephoneandthesmartswitchwillautomatically communicate,theAPPwillpopupthedevicethatcanbeconfiguredwiththe network,click"gotoadd" A-5.Afterclicking"+"again,enterthenetworknameandpassword(butnot Smartlife’s)tobeconnectedto,andclick"confirm"toproceedtothenextstep A-6.Modifythenameofthesmartswitchtofacilitateidentification,click"Done". Atthispoint,thesmartswitchisconnectedtotheInternet,andyoucanusea third-partyAPPtocontrolit. A-7,Formorepersonalizedsettingsofthesmartswitch,pleaseenterandclick ""inthelowerrightcorner A-8,Multipleswitchescontrolonelightfunction Clickthe""iconintheupperrightcorner,select"Multi-ControlAssociation", selecttheswitchthatneedstobeassociated, ” B:defaultparingnetworkmodes B-1:Makesuretheredlightofthesmartswitchflashesquickly.(Ifitdoesnot flashquickly,pleasepressandholdanybuttonformorethan5secondsuntil theredlightflashesquickly.),thentheswitchenterthefactoryresetmodeand alsoparingnetworkmodes. B-2:MakesureyourmobilephoneisconnectedtoWiFi(Justsupport2.4GHz butnot5GHz)inyourhome.Click"+"intheupperrightcornerofthe homepage.Thenselect"Switch(WiFi)". B-3:EnteryourWiFipassword(butnotSmartlife’s)andthenclick"Next", APPwillentersearchingdevicemode. Note:Makesureyourphoneanddeviceareasclosetoyourrouteraspossible. B-4:Deviceaddedsuccessfully,thenrenamethedevicenameandchoosethe devicelocation.Tap’Done’enterthedevicepage. Longpresstheswitch1,switch2,switch3ontheAPP,thenyoucanmodify thename,youcanmodifythenameaccordingtoyourpreferences,easyto operate,ConvenientAlexaandGoogleassistantvoicecontrol. B-5.Formoresettings,seeA-7&A-8 FCCCaution. Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemust acceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation. AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliance couldvoidtheuser'sauthoritytooperatetheequipment. Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital device,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewith theinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereis noguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoes caus…

Text truncated - open the document above for the full version.

ShenzhenYoungzuthTechnologyCo.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 {June19,2024} U.S.AgentDesignation {ShenzhenYoungzuthTechnologyCo.,Ltd}acknowledgestheirconsentforthefollowingcontactlocatedin theUnitedStatestoactastheiragentforserviceofprocessfortheequipmentforwhichauthorizationissought (FCCID:2BFQB-SW0203): NameandcompanyofU.S.agent:UUXGROUPINC PhysicalU.S.addressofagent:36South18thAvenue,SuiteABrighton,COUSA80601 FRNofU.S.agent:0033701590 EmailaddressofU.S.agent:[email protected] {UUXGROUPINC}acknowledgestheirobligationtoacceptserviceofprocessonbehalfof{Shenzhen YoungzuthTechnologyCo.,Ltd}. {ShenzhenYoungzuthTechnologyCo.,Ltd}withtheFRN[0035247584]acceptsitsobligationtomaintainan agentforserviceofprocessintheUnitedStatesfornolessthanoneyearaftereitherthegranteehas permanentlyterminatedallmarketingandimportationoftheapplicableequipmentwithintheU.S.,orthe conclusionofanyCommission-relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheveris later. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirementslistedunder§ 2.911(d)(7). TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB 986446D01. Anexpirationdateforthisletterdoesnotexist.IncasetheU.S.agentchanges,thegranteeisobligatedtonotify theFCCwithin30daysviathegrantingTCB. Sincerely, Signature {XiaoqinHan} {CEO} {ShenzhenYoungzuthTechnologyCo.,Ltd} Signature {JackFu} {Manager} {UUXGROUPINC} 4 8 _ [ m o d e l ] U S _ A g e n t _ 2 . 9 1 1 ( d ) ( 7 ) - U , V 0 5

FCCID:2BFQB-SW0203 FCCID:2BFQB-SW0203 FCCID:2BFQB-SW0203 FCCID:2BFQB-SW0203

FCCID:2BFQB-SW0203 FCCID:2BFQB-SW0203 FCCID:2BFQB-SW0203 FCCID:2BFQB-SW0203 FCCID:2BFQB-SW0203 FCCID:2BFQB-SW0203

ReportNo.:PTC24010817401E-FC03 Page1of7 FCCTESTREPORT FCCID:2BFQB-SW0203 Product: SmartWallswitch ModelName: SW0203,SW0203**,GE-SM39**,SW0202**, GE-SM38**,SW0201**,GE-SM37** Brand : Youngzuth ReportNo.:PTC24010817401E-FC03 Preparedfor ShenzhenYoungzuthTechnologyCo.,Ltd D1,4/F,DatangTimesCommercialComplex,No.2203MeilongAvenue,Qinghua Community,LonghuaStreet,LonghuaDistrict,Shenzhen,China Preparedby PreciseTesting&CertificationCo.,Ltd. Building1,No.6,TongxinRoad,DongchengStreet,Dongguan,Guangdong,China. ReportNo.:PTC24010817401E-FC03 Page2of7 TESTRESULTCERTIFICATION Applicant’sname: ShenzhenYoungzuthTechnologyCo.,Ltd Address: D1,4/F,DatangTimesCommercialComplex,No.2203Meilong Avenue,QinghuaCommunity,LonghuaStreet,LonghuaDistrict, Shenzhen,China Manufacture'sname: ShenzhenYoungzuthTechnologyCo.,Ltd Address: D1,4/F,DatangTimesCommercialComplex,No.2203Meilong Avenue,QinghuaCommunity,LonghuaStreet,LonghuaDistrict, Shenzhen,China Productname: SmartWallswitch Modelname: SW0203,SW0203**,GE-SM39**,SW0202**, GE-SM38**,SW0201**,GE-SM37** Testprocedure:FCCCFR47Part1.1307(b)(1) TestDate:May28,2024toMay13,2024 DateofIssue:June29,2024 TestResult:PASS ThisdevicedescribedabovehasbeentestedbyPTC,andthetestresultsshowthatthe equipmentundertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicable onlytothetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofPTC,this documentmaybealteredorrevisedbyPTC,personalonly,andshallbenotedinthe revisionofthedocument. TestEngineer: Jackzhou/Engineer TechnicalManager: SimonPu/Manager ReportNo.:PTC24010817401E-FC03 Page3of7 Contents Page 2TESTSUMMARY...............................................................................................................................................4 3GENERALINFORMATION..............................................................................................................................5 3.1GENERALDESCRIPTIONOFE.U.T..........................................................................................................5 4RFEXPOSURE..................................................................................................................................................6 4.1REQUIREMENTS........................................................................................................................................6 4.2THEPROCEDURES/LIMIT........................................................................................................................6 4.3MPECALCULATIONMETHOD..................................................................................................................7 4.4TESTRESULT...........................................................................................................................................7 ReportNo.:PTC24010817401E-FC03 Page4of7 2TestSummary TestItemsTestRequirementResult MaximumPermissibleExposure (ExposureofHumanstoRFFields) 15.247(i)PASS Remark: N/A:NotApplicable ReportNo.:PTC24010817401E-FC03 Page5of7 3GeneralInformation 3.1GeneralDescriptionofE.U.T. ProductName : SmartWallswitch ModelName : SW0203 Additionalmodel : SW0203**,GE-SM39**,SW0202**,GE-SM38**,SW0201**,GE-SM37** Modeldifference: (*is"0-9"or"A-Z"or"a-z"orspace,*isusedonlytodistinguishbetween differentappearancecolors,customersandsalesregions),theproducthas differentnumberofbuttonsanddifferentoutputports,otherwisethesame. Specification: 802.11b/g/nHT20/HT40 OperationFrequency : 2412-2462MHzfor802.11b/g/n(HT20/HT40) 2402-2480MHz NumberofChannel : 11channelsfor802.11b/g/n(HT20/HT40) 40channelsForDTS TypeofModulation : DSSSwithDBPSK/DQPSK/CCKfor802.11b; OFDMwithBPSK/QPSK/16QAM/64QAMfor802.11g/n; Antennainstallation : PCBantenna AntennaGain : 1.37dBi Powersupply : Input：AC100-277V10A Output:AC100-277V HardwareVersion : N/A SoftwareVersion : N/A ReportNo.:PTC24010817401E-FC03 Page6of7 4RFExposure TestRequirement :FCCPart1.1307(b)(1) EvaluationMethod :KDB447498D01GeneralRFExposureGuidancev06 4.1Requirements Systemsoperatingundertheprovisionsofthissectionshallbeoperatedinamannerthatensuresthat thepublicisnotexposedtoradiofrequencyenergylevelsinexcesslimitformaximumpermissible exposure.Inaccordancewith47CFRFCCPart2SubpartJ,section2.1091thisdevicehasbeen definedasamobiledevicewherebyadistanceof0.2mnormallycanbemaintainedbetweentheuser andthedevice. 4.2Theprocedures/limit (A)LimitsforOccupational/ControlledExposure FrequencyRangeElectricFieldMagneticFieldPowerDensity(S)AveragingTime 0.3-3.06141.63(100)*6 3.0-301842/f4.89/f(900/f)*6 30-30061.40.1631.06 300-1500F/3006 1500-100,00056 (B)LimitsforGeneralPopulation/UncontrolledExposure FrequencyRangeElectricFieldMagneticFieldPowerDensity(S)AveragingTime 0.3-1.346141.63(100)*30 1.34-30824/f2.19/f(180/f)*30 30-30027.50.0730.230 300-1500F/150030 1500-100,0001.030 Note:f=frequencyinMHz;*Plane-waveequivalentpowerdensity ReportNo.:PTC24010817401E-FC03 Page7of7 4.3MPECalculationMethod E(V/m)＝ d GP30 PowerDensity:Pd(W/m²)＝ 377 2 E E＝Electricfield(V/m) P ＝ PeakRFoutputpower(W) G ＝ EUTAntennanumericgain(numeric) d＝Separationdistancebetweenradiatorandhumanbody(m) Theformulacanbechangedto Pd ＝ 2 377 30 d GP   θφ FromthepeakEUTRFoutputpower,theminimummobileseparationdistance,d=0.2m,aswellas thegainoftheusedantenna,theRFpowerdensitycanbeobtained 4.4TestResult Frequency(M Hz) Antenna Gain (numeric) Max.Peak OutputPower (dBm) Tuneup tolerance (dBm) MaxTuneUp Power(mW) PowerDensity (mW/cm2) LimitofPower Density (mW/cm2) Result TestMode 24021.375.435.43±14.3954160.0011991Pass BLE_1M 24121.3719.9219.92±1123.5947430.0337081Pass 802.11g ******THEENDREPORT******

1 AntennaSpecification Manufacture：TUYA ProductName：CB3SAntenna AntennaType：PCB TestDate：2021.04.16 Testedby：JianweiWang Approvedby：Licco Antenna TestReport 2 Content 1.GeneralDescription..................................................................................3 2.TestConfigurations..................................................................................4 2.1TestEnvironment............................................................................4 2.2TestEquipment................................................................................4 2.3TestPrinciple...................................................................................4 3.TestResults...............................................................................................5 3.1GainandEfficiency.........................................................................5 3.2RadiationPattern.............................................................................6 4.AntennaDimensions................................................................................9 5.EUTPhoto................................................................................................9 6.TestSetupPhoto.....................................................................................10 3 1.GeneralDescription ManufacturerHangzhouTuyaInformationTechnologyCo.,Ltd Address Room701,Building3,MoreCenter,No.87GuDunRoad, Hangzhou,Zhejiang,China TestLocation Room106,Building3,LetongSciencePark,No.500, QiuyiRoad,BinjiangDistrict,Hangzhou ProductNameCB3SAntenna Productmodel CB3S AntennaType PCBAntenna TestItems Gain;Efficiency;RadiationPattern TestFrequency 2400-2500MHz TestStandard ANSI/IEEEStd149-1979 4 2.TestConfigurations 2.1TestEnvironment Temperature(°C)25 Humidity(%RH)60 AtmosphericPressure(kPa)100.5 2.2TestEquipment TestSystemTEM24Multi-probeMicrowaveChamber TestInstrumentAgilentE5071B 2.3TestPrinciple 5 3.TestResults 3.1GainandEfficiency Frequency(MHz)PeakGain(dBi)Efficiency(%) 2400 0.4644.36 2410 0.7145.71 2420 0.9245.92 2430 0.9145.6 2440 0.9545.6 2450 0.9345.29 2460 1.2746.45 2470 1.3746.88 2480 1.2547.21 2490 1.2446.67 2500 1.0544.87 6 3.2RadiationPattern Phi0 7 Phi90 8 Theta90 9 4.AntennaDimensions 5.EUTPhoto 10 6.TestSetupPhoto

Page1 of 57 FCC TEST REPORT FCC ID: 2BFQB-SW0203 Product: SmartWall switch ModelName: SW0203,SW0203**,GE-SM39**,SW0202**,GE-SM38**, SW0201**,GE-SM37** Brand: Youngzuth ReportNo.: PTC24010817401E-FC01 Preparedfor ShenzhenYoungzuthTechnologyCo., Ltd D1, 4/F, DatangTimesCommercialComplex,No. 2203MeilongAvenue,Qinghua Community,LonghuaStreet,LonghuaDistrict,Shenzhen,China Preparedby PreciseTesting& CertificationCo., Ltd Building1, No. 6, TongxinRoad,DongchengStreet,Dongguan,Guangdong,China ReportNo.: PTC24010817401E-FC01 Page2 of 57 1 TEST RESULT CERTIFICATION Applicant’s name:ShenzhenYoungzuthTechnologyCo., Ltd Address: D1, 4/F, DatangTimesCommercialComplex,No. 2203Meilong Avenue,QinghuaCommunity,LonghuaStreet,LonghuaDistrict, Shenzhen,China Manufacture'sname:ShenzhenYoungzuthTechnologyCo., Ltd Address: D1, 4/F, DatangTimesCommercialComplex,No. 2203Meilong Avenue,QinghuaCommunity,LonghuaStreet,LonghuaDistrict, Shenzhen,China Productname:SmartWall switch Modelname: SW0203, SW0203**,GE-SM39**,SW0202**,GE-SM38**,SW0201**,GE-SM37** Standards:FCC CFR47Part 15 Section15.247 Test procedure:ANSIC63.10:2013 Test Date: May 28, 2024to May 13, 2024 Dateof Issue: June29, 2024 Test Result:Pass This devicedescribedabovehas beentestedby PTC,and the test resultsshowthat the equipmentundertest (EUT)is in compliancewith the FCC requirements.And it is applicableonly to the testedsampleidentifiedin the report. This reportshall not be reproducedexceptin full, withoutthe writtenapprovalof PTC,this document may be alteredor revisedby PTC,personalonly,and shall be notedin the revisionof the document. Test Engineer: Jackzhou/ Engineer TechnicalManager: SimonPu / Manager ReportNo.: PTC24010817401E-FC01 Page3 of 57 Contents Page 1 TEST RESULTCERTIFICATION.........................................................................................................................2 2 TEST SUMMARY..........................................................................................................................................................5 2.1 TESTSITE............................................................................................................................................................6 3 GENERALINFORMATION......................................................................................................................................7 3.1 GENERALDESCRIPTIONOFE.U.T....................................................................................................................7 3.2 CHANNELLIST.....................................................................................................................................................8 4 EQUIPMENTDURINGTEST...................................................................................................................................9 4.1 EQUIPMENTSLIST.............................................................................................................................................9 4.2 MEASUREMENTUNCERTAINTY.........................................................................................................................11 4.3 DESCRIPTIONOFSUPPORTUNITS...................................................................................................................12 5 CONDUCTEDEMISSION..........................................................................................................................................13 5.1 E.U.T.OPERATION...........................................................................................................................................13 5.2 EUT SETUP.......................................................................................................................................................13 5.3 TESTSET-UP(BLOCKDIAGRAMOFCONFIGURATION)................................................................................14 5.4 MEASUREMENTPROCEDURE...........................................................................................................................14 5.5 CONDUCTEDEMISSIONLIMIT...........................................................................................................................14 5.6 MEASUREMENTDESCRIPTION..........................................................................................................................14 5.7 CONDUCTEDEMISSIONTESTRESULT.............................................................................................................14 6 RADIATEDSPURIOUSEMISSIONS......................................................................................................................17 6.1 EUT OPERATION...............................................................................................................................................17 6.2 TESTSETUP......................................................................................................................................................18 6.3 SPECTRUMANALYZERSETUP.........................................................................................................................19 6.4 TESTPROCEDURE.............................................................................................................................................20 6.5 SUMMARYOFTESTRESULTS..........................................................................................................................22 7 CONDUCTBANDEDGEAND SPURIOUSEMISSIONSMEASUREMENT....................................................29 7.1 TESTPROCEDURE.............................................................................................................................................29 7.2 TESTRESULT....................................................................................................................................................30 8 6DB BANDWIDTHMEASUREMENT....................................................................................................…

Text truncated - open the document above for the full version.

ReportNo.: PTC24010817401E-FC01 Page54 of 57 ReportNo.: PTC24010817401E-FC01 Page55 of 57 ReportNo.: PTC24010817401E-FC01 Page56 of 57 ReportNo.: PTC24010817401E-FC01 Page57 of 57 ******THEEND REPORT******

Page 1 of 79 FCC TEST REPORT FCC ID :2BFQB-SW0203 Product:SmartWall switch ModelName: SW0203,SW0203**,GE-SM39**,SW0202**, GE-SM38**,SW0201**,GE-SM37** Brand:Youngzuth ReportNo.:PTC24010817401E-FC02 Preparedfor ShenzhenYoungzuthTechnologyCo., Ltd D1, 4/F, DatangTimesCommercialComplex,No. 2203MeilongAvenue,Qinghua Community,LonghuaStreet,LonghuaDistrict,Shenzhen,China Preparedby PreciseTesting& CertificationCo., Ltd Building1, No. 6, TongxinRoad,DongchengStreet,Dongguan,Guangdong,China ReportNo.: PTC24010817401E-FC02 Page 2 of 79 1 TEST RESULT CERTIFICATION Applicant’s name:ShenzhenYoungzuthTechnologyCo., Ltd Address: D1, 4/F, DatangTimesCommercialComplex,No. 2203Meilong Avenue,QinghuaCommunity,LonghuaStreet,LonghuaDistrict, Shenzhen,China Manufacture'sname:ShenzhenYoungzuthTechnologyCo., Ltd Address: D1, 4/F, DatangTimesCommercialComplex,No. 2203Meilong Avenue,QinghuaCommunity,LonghuaStreet,LonghuaDistrict, Shenzhen,China Productname:SmartWall switch Modelname: SW0203,SW0203**,GE-SM39**,SW0202**,GE- SM38**,SW0201**,GE-SM37** Standards:FCC CFR47Part 15 Section15.247 Test procedure:ANSIC63.10:2013 Test Date:Mar 28, 2024to May 13, 2024 Dateof Issue:June29, 2024 Test Result:Pass This devicedescribedabovehas beentestedby PTC,and the test resultsshowthat the equipmentunder test (EUT)is in compliancewith the FCCrequirements.And it is applicableonly to the testedsample identifiedin the report. This reportshallnot be reproducedexceptin full, withoutthe writtenapprovalof PTC,this documentmay be alteredor revisedby PTC,personalonly,and shallbe notedin the revisionof the document. Test Engineer: Jackzhou/ Engineer TechnicalManager: SimonPu / Manager ReportNo.: PTC24010817401E-FC02 Page 3 of 79 Contents Page 1 TEST RESULT CERTIFICATION...............................................................................................................................2 2 TEST SUMMARY..........................................................................................................................................................5 3 GENERALINFORMATION..........................................................................................................................................6 3.1 GENERALDESCRIPTIONOFE.U.T.....................................................................................................................6 3.2 CHANNELLIST.....................................................................................................................................................7 3.3 TESTSITE............................................................................................................................................................8 4 EQUIPMENTDURINGTEST......................................................................................................................................9 4.1 EQUIPMENTSLIST...............................................................................................................................................9 4.2 MEASUREMENTUNCERTAINTY.........................................................................................................................11 4.3 DESCRIPTIONOFSUPPORTUNITS...................................................................................................................12 5 CONDUCTEDEMISSION..........................................................................................................................................13 5.1 E.U.T.OPERATION............................................................................................................................................13 5.2 EUT SETUP.......................................................................................................................................................13 5.3 TESTSET-UP(BLOCKDIAGRAMOFCONFIGURATION).................................................................................14 5.4 MEASUREMENTPROCEDURE............................................................................................................................14 5.5 CONDUCTEDEMISSIONLIMIT...........................................................................................................................14 5.6 MEASUREMENTDESCRIPTION..........................................................................................................................14 5.7 CONDUCTEDEMISSIONTESTRESULT.............................................................................................................14 6 RADIATEDSPURIOUSEMISSIONS......................................................................................................................17 6.1 EUT OPERATION...............................................................................................................................................17 6.2 TESTSETUP......................................................................................................................................................18 6.3 SPECTRUMANALYZERSETUP..........................................................................................................................19 6.4 TESTPROCEDURE.............................................................................................................................................20 6.5 SUMMARYOFTESTRESULTS...........................................................................................................................21 7 CONDUCTEDSPURIOUSEMISSION....................................................................................................................28 7.1 TESTPROCEDURE.............................................................................................................................................28 7.2 TESTSETUP......................................................................................................................................................28 7.3 TESTRESULT...................................................…

Text truncated - open the document above for the full version.

ReportNo.: PTC24010817401E-FC02 Page 47 of 79 11N40SISO-Ant1-2452-30~1000-PASS 11N40SISO-Ant1-2452-1000~26500-PASS ReportNo.: PTC24010817401E-FC02 Page 48 of 79 8 Band Edge Measurement Test Requirement:Section15.247(d)In addition,radiatedemissionswhichfall in the restrictedbands.as definedin Section15.205(a),mustalso complywith the radiatedemissionlimitsspecifiedin Section15.209(a)(see Section 15.205(c)). Test Method:ANSIC63.10:2013 Test Limit:Regulation15.247(d),In any 100 kHz bandwidthoutsidethe frequencybandin whichthe spreadspectrumor digitallymodulated intentionalradiatoris operating,the radiofrequencypowerthat is producedby the intentionalradiatorshallbe at least20 dB belowthat in the 100 kHz bandwidthwithinthe bandthat containsthe highestlevelof the desiredpower,basedon eitheran RF conductedor a radiated measurement,providedthe transmitterdemonstratescompliancewith the peakconductedpowerlimits.If the transmittercomplieswith the conductedpowerlimitsbasedon the use of RMSaveragingover a time interval,as permittedunderparagraph(b)(3)of this section,the attenuationrequiredunderthis paragraphshallbe 30 dB insteadof 20 dB. Attenuationbelowthe generallimitsspecifiedin §15.209(a)is not required.In addition,radiatedemissionswhichfall in the restrictedbands, as definedin §15.205(a),mustalso complywith the radiatedemission limitsspecifiedin §15.209(a)(see §15.205(c)). 8.1 Test Procedure 1. Removethe antennafrom the EUT and then connecta low RF cablefrom the antennaport to the spectrum; 2. Set the spectrumanalyzer:RBW= 100kHz,VBW= 300kHz, Sweep= auto Detectorfunction= peak , Trace= max hol d 8.2 Test Setup 8.3 Test Result TestModeAntennaCh NameFrequency[MHz ]RefLevel[dBm]Result[dBm]Limit[dBm]Verdict 11BAnt1Low24125.53-41.25≤-14.48PASS 11BAnt1High24623.57-45.68≤-16.43PASS 11GAnt1Low24123.19-39.45≤-16.81PASS 11GAnt1High24621.77-45.26≤-18.23PASS 11N20SISOAnt1Low24125.27-40.76≤-14.73PASS 11N20SISOAnt1High24622.64-42.95≤-17.36PASS 11N40SISOAnt1Low2422-1.75-43.42≤-21.75PASS 11N40SISOAnt1High2452-3.32-45.33≤-23.32PASS ReportNo.: PTC24010817401E-FC02 Page 49 of 79 Test Graphs: 1…

Text truncated - open the document above for the full version.
