2BFQH-JS59Wireless Headset

FCCWarning ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwo conditions: (1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptany interferencereceived,includinginterferencethatmaycauseundesiredoperation. NOTE1:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital device,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates, usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe instructions,maycauseharmfulinterferencetoradiocommunications.However,thereisno guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoes causeharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturning theequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneor moreofthefollowingmeasures: -Reorientorrelocatethereceivingantenna. -Increasetheseparationbetweentheequipmentandreceiver. -Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris connected. -Consultthedealeroranexperiencedradio/TVtechnicianforhelp. NOTE2:Anychangesormodificationstothisunitnotexpresslyapprovedbytheparty responsibleforcompliancecouldvoidtheuser'sauthoritytooperatetheequipment. ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.Thedevicecanbe usedinportableexposureconditionwithoutrestriction. OperatingFrequency Band:2402-2480MHz Maximum Radio-Frequency Power:≤10dBMI.Button Functions 1.PowerOn:Removetheearbudsfromthechargingcase,andtheywillutomaticallypoweronand pair.Alternatively,long-pressthetouchbuttonfor3-5secondstoturnon.2.PowerOff:Placetheearbudsback inthechargingcasetoturnthemoffautomatically,orlong-pressthetouchbuttonfor3-5secondstoturnoff. 3.Play/Pause:Whileplaying,taponeoftheearbuds'touchbuttonstopauseplayback.Inpausemode,tapagain toresumeplayback.4.Answer/EndCal:Whenthereisanincomingcall,taponeoftheearbuds'touchbuttonsto answer.Duringthecall,tapthesametouchbuttontoendthecall.5.RejectCall:Whenthereisanincoming call,long-pressthetouchbuttonfor2-3secondstorejectthecall. II.HowtoPowerOnandPairtheEarbuds 1.Removebothearbudsfromthechargingcasesimultaneously(Note:bothmustbetakenoutatthesame time).Theearbudswillautomaticallypoweronandbeginpairing.Waitfor5to30seconds.Whenoneearbud keepsflashingandtheothergoesoff,it indicatessuccessfulpairing.Then,turnonyourphone'swireless,searchforthecorrespondingearbuddevice name,andconnect. 2.Ifoneearbudisnotproducingsound(monomode),placebothearbudsbackinthechargingcase.Waitafew seconds,thentakethemoutagain.Waitfor5to30seconds.Turnonthewirelessonyourphone,findthe paireddevice,unpairit,andthenturn offandonthewirelesstoreconnect.3.Ifyourphonecannotfindtheearbuds,placebothearbudsbackinthe chargingcase,waitafewseconds,takethemoutagain,andwaitfor5to30seconds.Turnonwirelessonyour phone,searchfortheearbuds,andconnect. lIUsageNotes 1.Donottreattheproductwithforceorcrushitwithheavyobjects.Keepitawayfrom high-temperature,high-humidityenvironments.2.KeeptheproductawayfromWi-Firoutersandother high-frequencytransmittingdevices,asthismayaffectsignalreception,leadingtosoundlagordisconnection. 3.Usetheproductwithinaneffectiverange(10-15meters).Ensuretherearenophysicalobstructions(such aswalls)betweenthewirelessdeviceandtheearbuds.4.ThisproductdoesnotsupportUSBPDfastcharging. Thechargermustprovidepowerwithintherangeof1wattto5wattstoensuremaximumchargingspeed

Hangzhou banzi Trading Co., Ltd Covered Equipment Certification Attestation Letter 5/19/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BFQH-JS59 Hangzhou banzi Trading Co., Ltd (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Hangzhou banzi Trading Co., Ltd (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Hangzhou banzi Trading Co., Ltd (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: zhifeng wan Title: General Manager Company Name: Hangzhou banzi Trading Co., Ltd Date: 5/19/2026

Hangzhou banzi Trading Co., Ltd U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: May 19, 2026 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2BFQH-JS59 Hangzhou banzi Trading Co., Ltd(“the applicant”) certifies that, as of the date of the filing of the application, CLF Import and Export Limited (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. CLF Import and Export Limited ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: CLF Import and Export Limited FRN: 0033489683 Address: 1312 17th Street #692, Denver, CO 80202, United States Signature: Contact Person: David Chen Tel: +1 949 254 2565 Email: [email protected] Applicant Hangzhou banzi Trading Co., Ltd FRN: 0035247717 Address: No.C071, Building 1, Agricultural Products Park, Youyi Village, Yangxi Street, Jiande, China Signature: Contact Person: zhifeng wan Tel: +86 15013852535 Email: [email protected]

DATE: May 19, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen CCUT Quality Technology Co., Ltd. (1F, Building 35, Changxing Technology Indstrl Park Changzhen Community, Yutang Street,Shenzhen,China) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Hangzhou banzi Trading Co., Ltd (No.C071, Building 1, Agricultural Products Park, Youyi Village, Yangxi Street, Jiande, China). <Signature> Name: zhifeng wan Title: General Manager Applicant Company: Hangzhou banzi Trading Co., Ltd

Date: May 19, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: zhifeng wan Title: General Manager Company: Hangzhou banzi Trading Co., Ltd

DATE: May 19, 2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BFQH-JS59 Product Name: Wireless Headset Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: zhifeng wan Title: General Manager Company: Hangzhou banzi Trading Co., Ltd

Report No: SSP26040335-1E FCC ID: 2BFQH-JS59 Annex of Test Report Annex A. EUT External Photos EUT View 1 Model: JS59 EUT View 2 Report No: SSP26040335-1E FCC ID: 2BFQH-JS59 Annex of Test Report EUT View 3 EUT View 4 Report No: SSP26040335-1E FCC ID: 2BFQH-JS59 Annex of Test Report EUT View 5 EUT View 6 Report No: SSP26040335-1E FCC ID: 2BFQH-JS59 Annex of Test Report EUT View 7

Report No: SSP26040335-1E FCC ID: 2BFQH-JS59 Annex of Test Report Annex D. Label and Information FCC Label Sample Label Size:0.7cm*0.3cm FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

Report No: SSP26040335-1E FCC ID: 2BFQH-JS59 Annex of Test Report Annex B. EUT Internal Photos Model: JS59 EUT Internal View 1 EUT Internal View 2 SMD Antenna SMD Antenna Report No: SSP26040335-1E FCC ID: 2BFQH-JS59 Annex of Test Report EUT Internal View 3 EUT Internal View 4

FCC ID: 2BFQH-JS59 RF Exposure Evaluation According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. For BR+EDR Max Conducted Power(dBm) Tune-up Power(dBm) Max Tune-up Power(dBm) Max Power(mW) Frequency(MHz) Min. distance(mm) Calc. thresholds limit 1.95 1(±1) 2 1.585 2480 5 0.4992 3.0 So a SAR test is not required

Report No: SSP26040335-1E FCC Test Report Page 1 of 51 FCC TEST REPORT FCC ID: 2BFQH-JS59 Report No. : SSP26040335-1E Applicant : Hangzhou banzi Trading Co., Ltd Product Name : Wireless Headset Model Name : JS59 Test Standard : FCC Part 15.247 Date of Issue : 2026-04-22 Shenzhen CCUT Quality Technology Co., Ltd. 1F, Building 35, Changxing Technology Industrial Park, Yutang Street, Guangming District, Shenzhen, Guangdong, China; (Tel.:+86-755-23406590 website: www.ccuttest.com) This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd. Report No: SSP26040335-1E FCC Test Report Page 2 of 51 Test Report Basic Information Applicant..................................: Hangzhou banzi Trading Co., Ltd Address of Applicant...............: No.C071, Building 1, Agricultural Products Park, Youyi Village, Yangxi Street, Jiande, China Manufacturer..........................: Hangzhou banzi Trading Co., Ltd Address of Manufacturer........: No.C071, Building 1, Agricultural Products Park, Youyi Village, Yangxi Street, Jiande, China Product Name.........................: Wireless Headset Brand Name.............................: - Main Model..............................: JS59 Series Models..........................: - Test Standard..........................: FCC Part 15 Subpart C ANSI C63.4-2014 ANSI C63.10-2020 Date of Test .............................: 2026-04-14 to 2026-04-21 Test Result...............................: PASS Tested By ................................: (Coke Huang) Reviewed By............................: (Lorzix Luo) Authorized Signatory............: (Lahm Peng) Note : This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd.. All test data presented in this test report is only applicable to presented test sample. Report No: SSP26040335-1E FCC Test Report Page 3 of 51 CONTENTS 1. General Information ....................................................................................................................................................5 1.1 Product Information .............................................................................................................................................5 1.2 Test Setup Information..........................................................................................................................................6 1.3 Compliance Standards ...........................................................................................................................................7 1.4 Test Facilities ........................................................................................................................................................7 1.5 List of Measurement Instruments ..........................................................................................................................8 1.6 Measurement Uncertainty .....................................................................................................................................9 2. Summary of Test Results ........................................................................................................................................... 10 3. Antenna Requirement ............................................................................................................................................... 11 3.1 Standard and Limit.............................................................................................................................................. 11 3.2 Test Result .......................................................................................................................................................... 11 4. Conducted Emissions ................................................................................................................................................ 12 4.1 Standard and Limit.............................................................................................................................................. 12 4.2 Test Procedure.................................................................................................................................................... 12 4.3 Test Data and Results .......................................................................................................................................... 13 5. Radiated Emissions ................................................................................................................................................... 16 5.1 Standard and Limit.............................................................................................................................................. 16 5.2 Test Procedure.................................................................................................................................................... 16 5.3 Test Data and Results .......................................................................................................................................... 18 6. Band-edge Emissions(Radiated) ............................................................................................................................... 22 6.1 Standard and Limit.............................................................................................................................................. 22 6.2 Test Procedure.................................................................................................................................................... 22 6.3 Test Data and Results .......................................................................................................................................... 22 7. Frequency Hopping System ............................................…

Text truncated - open the document above for the full version.

2.4GHz 1608 SMD Antenna: RANT1608F245C04 _ Application: WLAN, 802.11b/g, Bluetooth, WLAN, etc... Features SMD, high reliability, ultra Impact, Omni-directional... Part number Information RANT1608F245C04 (A) (B) (C) (D)(E) (F) Electrical Specification Dimension and Terminal Configuration No.Terminal Name 1Feeding/GNG 2GND/Feeding (A)Product TypeSMD Antenna (B) Size Code 1.6x0.8mm( ± 0.1mm) (C) MaterialHigh K material (D) Frequency2.4 ~ 2.5GHz (E) Feeding modePIFA & Single Feeding (F) Antenna typeType=04 Working Frequency Range2400 ~2500 MHz Bandwidth120 MHz (Min.) Peak Gain2.7 dBi (Typ.) Impedance50 Ohm Return loss10 dB ( Min) PolarizationLinear Azimuth BeamwidthOmni-directional Operation Temperature( °C )-40 ~85 °C Resistance to Soldering Heats 10sec. ( @ 280 °C ) TerminationNi / Au (Leadless) Dimension (mm) L 1.60±0.10 W 0.80 ± 0.10 T 0.80 ± 0.10 Add: Room 707, Bui l di ng F, Tongan Zhi chuangyuan, xi xi ang st r eet , Baoan Di st r i ct , Shenzhen. 2.4GHz 1608 SMD Antenna: RANT1608F245C04 _ 1 Evaluation BoardReference PCB DimensionAntenna Layout Reference Unit :mm Electrical Characteristics Return Loss & Radiation ELECTRICAL CHARACTERISTICSS11 Radiation Electrical Characteristics Freque ncy Effic Percen Gain 2400-1.64 72.27% 2.38 2450-1.33 75.34%2.7 2500-1.59 72.98% 2.59 Add: Room 707, Bui l di ng F, Tongan Zhi chuangyuan, xi xi ang st r eet , Baoan Di st r i ct , Shenzhen. 2.4GHz 1608 SMD Antenna: RANT1608F245C04 _ Taping Specifications Reel and Taping Specification Reel Specification TYPESIZEABCD 16087” 4K/Reel 4.0±0.5 4.0±213.5±0.5178±2 Tapping Specification PackagingTypeABWEFGHTψDP Paper Type 1608 1.90±0.20 3.50±0.20 8.0±0.20 1.75±0.10 3.5±0.05 4.0±0.10 2.0±0.05 0.75±0.10 1.50±0.10 4.0±0.1 Add: Room 707, Bui l di ng F, Tongan Zhi chuangyuan, xi xi ang st r eet , Baoan Di st r i ct , Shenzhen. 2.4GHz 1608 SMD Antenna: RANT1608F245C04 _ Reliability Table Test ItemProcedure Requirements Ceramic Type Remark (Reference) Electrical Characterization Fulfill the electrical specification User Spec. Thermal Shock 1. Preconditioning: 50 ± 10°C/ 1 hr , then keep for 24 ± 1 hrs at room temp. 2. Initial measure: Spec: refer Initialspec. 3. Rapid change of temperature test: -30°Cto +85°C; 100 cycles; 15 minutes at Lower category temperature; 15 minutes at Upper category temperature. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 107 Temperature Cycling 1. Initial measure: Spec: refer Initialspec. 2. 100 Cycles (-30°Cto +85°C), Soak Mode=1 (2 Cycle/hours). 3. Measurement at 24 ± 2Hours after testcondition. No Visible Damage. Fulfill the electrical specification. JESD22 JA104 High Temperature Exposure 1. Initial measure: Spec: refer Initialspec. 2. Unpowered; 500hours @ T=+85°C. 3. Measurement at 24 ± 2 hours aftertest. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 108 Low Temperature Storage 1. Initial measure: Spec: refer Initialspec. 2. Unpowered: 500hours @ T=-30°C. 3. Measurement at 24 ± 2 hours aftertest. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 108 Solderability (SMD Bottom Side) Dipping method: a. Temperature: 235 ±5°C b. Dipping time: 3 ±0.5s The solder should cover over 95% of the critical area of bottom side. IEC 60384-21/22 4.10 Soldering Heat Resistance (RSH) Preheating temperature: 150 ± 10°C. Preheating time: 1~2 min. Solder temperature: 260 ± 5°C. Dipping time: 5 ± 0.5s No Visible Damage.IEC 60384-21/22 4.10 Vibration5g's for 20 min., 12 cycles each of 3 orientations Note: Use 8"X5" PCB .031" thick 7 secure points on, one long side and 2 secure points at corners of opposite sides. Parts mounted within 2" from any secure point. Test from 10-2000 Hz. No Visible Damage.MIL-STD-202 Method 204 Mechanical Shock Three shocks in each direction shall be applied along the three mutually perpendicular axes of the test specimen (18 shocks) Peak value: 1,500g’s Duration: 0.5ms Velocity change: 15.4 ft/s Waveform: Half-sine No Visible Damage.MIL-STD-202 Method 213 Humidity Bias 1. Humidity: 85% R.H., Temperature:85 ± 2 °C. 2. Time: 500 ± 24hours. 3. Measurement at 24 ± 2hrs after testcondition. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 Method 106 Add: Room 707, Bui l di ng F, Tongan Zhi chuangyuan, xi xi ang st r eet , Baoan Di st r i ct , Shenzhen. 2.4GHz 1 6 0 8 SMD Antenna: RANT1608F245C04 _ Board Flex (SMD) 1. Mounting method: IR-Reflow. PCB Size (L:100 × W:40 × T:1.6mm) 2. Apply the load in direction of the arrow until bending reaches 2 mm. No Visible Damage.AEC-Q200 005 AdhesionForce of 1.8Kg for 60 seconds. No Visible Damage Magnification of 20X or greater may be employed for inspection of the mechanical integrity of the device body terminals and body/terminal junction. AEC-Q200 006 Physical Dimension Any applicable method using x10 magnification, micrometers, calipers, gauges, contour projectors, or other measuring equipment, capable of determining the actual specimen dimensions. In accordance with specification. JESD22 JB100 Revision History RevisionDateContent 12019/03/01 New Datasheet 22020/02/22 Add 2D radiation characteristic Add: Room 707, Bui l di ng F, Tongan Zhi chuangyuan, xi xi ang st r eet , Baoan Di st r i ct , Shenzhen.

Report No: SSP26040335-1E FCC ID: 2BFQH-JS59 Annex of Test Report Annex C. Test Photos Conducted Emission Test View 1 Radiated Emission Test View Below 1GHz Report No: SSP26040335-1E FCC ID: 2BFQH-JS59 Annex of Test Report Radiated Emission Test View Above 1GHz
