THINKWARE R0.0.9, 2023. 08.3 KG S&C-AUDIO Product Description: Product nameSmart Audio ModelH1RU 1 KG S&C 1 §Production type : LCD integrated type §LCD : 12.3” (1920 × 720) TFT LCD §Silver Box : 1 DIN §Touch type : Touchscreen §Radio : AM/FM/RDS §Function : USB(USB 2.0) 1CH, Bluetooth 4.2 , WI-FI, GPS §AMP Type : Internal 4CH AMP §RVC : HD级 (LVDS) §Phone Connectivity : CarPlay (Wired/wireless), Android Auto(Wired) §KEY : Full Touch KEY §Accessory : S/Wheel Remote Control, Antenna (Radio), MIC (0dB) vRVC : Rear View Camera KG S&C 1 MIC S/Wheel Remocon Rear View Camera Connectivity Speaker Multi-Box DPGS RDS E-CALL MUTE Support for multi ple Chinese Bluetooth Modu le FM/AM 12.3" TFT LCD Touchscreen ANDROID OS Handle Remoco n 내장 AMP CAN Network Radio ANT USB I/F HEAD UNIT CARPLAYANDRIOD AUTO DEFAULT CARPLAY ANDRIOD AUTO Wired/wireless WI-FI ANT GPS GPS ANT KG S&C 1 FUNCTION 电阻值 (ohm) OUTPUT VOLTAGE RANGE(V) VOL-1000 VOL+6490.4 MODE1.5K0.8 SEEK UP2.67K1.2 SEEK DOWN4.42K1.6 BT ON/OFF7.32K2.0 MUTE12.4K2.4 VOICE26.1K2.8 KG S&C 1 ITEMS-AUDIO output 备注 All-in-one display ● 12.3 inch LCD (1920 X 720) OSAndroid CPUCortex-A53 Quad Core AC8015 RAM2GB LPDDR4 ROM32GB eMMC Touch typeCapacitive(G-G) 12.3 inch AIR GAP Type (ESD spec AIR 15KV) Wi-Fi● CarPlay● Android Auto● USB● (1Port) Connected Multi-BOX, USB 2.0 以上 support CARBITX PHONE Connectivity Bluetooth● BT4.2以上, Support Blue phone call, Phone book and Bluetooth music. DPGS● Rear View Camera● LVDS CAMERA Audio AMP Built CAN Network● Reverse、speed pulse GPS● RDS ● RADIO RDS Clock ● Manual KEY ● Full Touch KEY E-CALL MUTE ●Hardwire Sound Mute Only National certificationoverseas Basic (CE, FCC), Brazil (ANATEL), Chile (SUBTEL) : Subsequent additions to the country are com municated separately Language ● 12 countries: English, French, Italian, German, Spanish, Dutch, Russian, Turkish, Portuguese, Chin ese KG S&C 1 Name of ParameterSpecRemarks Rated operational voltage12V Operating Voltage range 10V～16V Max current≤10A Max Power out put4 x 25 W Load R：4x4Ω Operating Temperature -20°C～70 °C Storage Temperature -30°C～80 °C Relative humidity≤90% Deep standby static current≤1mA Start Time≤15S Camera Response Time≤2S KG S&C 1 KG S&C 1 NO.IC/ModulePart NumberAEC-Q100ManufacturerCountryOperation TemperatureStorage Temperature 1SOCAC8015YESAutoChipsChina-40°C～85°C-40°C~125°C 2MCURH850YESRSChina-40°C~125°C-55°C~150°C 3LPDDR4FLXC2002G-N2/2GBNOLongsysChina-25°C～85°C-55°C～125°C 4eMMCKLMBG2JETD-B041/32GBNOSAMSUNGKorea-25°C～85°C-40°C～85°C 5DC TO DCMP9447GL-ZNOMPSU.S.A-40°C～125°C-55°C~150°C 6DC TO DCMPQ8633NOMPSU.S.A-40°C～125°C-55°C~150°C 7DC TO DCMPQ2143YESMPSU.S.A-40°C～125°C-55°C~150°C 8USB CHARGEMPQ4228YESMPSChina-40°C～105°C-40°C~150°C 9RESET ICSGM829-3.0XN5GNOSGMChina-40°C～125°C-40°C～125°C 10AMPTB2929HQNOToshibaJapan-40°C～85°C-55°C~150°C 11DACES7148NOEVERESTChina-40°C～85°C-65°C~150°C 12MFIMFI343S00177NOAPPLEU.S.A-40°C～85°C-55°C~125°C 13CANSIT1044QTK3YESSITChina-40°C～125°C-55°C~150°C 14RADIOSI47901YESSILICONLABSU.S.A-40°C～85°C-55°C~150°C 15BT / WIFII1433sp NOIVTChina-40°C～80°C-40°C~105°C 16DeserializersMAX9288NOMAXIMU.S.A-40°C～85°C-40°C~125°C 17Touch PanelBR11756R-123NOTouchtronicChina-30°C～85°C-30°C～85°C 18LCDHSD123JPW3NOHSDChina-30°C～85°C-40°C～85°C KG S&C 1 KG S&C THANK YOU ! This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
