User Manual Model：DC339S Foreword Thank you for buying our products. This product uses the original high performance chip, in the high dynamic picture continuity and low illumination of high definition image recording, small design style does not affect the overall car interior premise to give you the greatest safe driving experience. For the memory card used with this dash cam, please choose a U3 grade memory card. Please format the memory card in the local menu for first time use. This user manual will explain how to use it in detail and provide you with detailed information including operation and technical specifications. Please read this manual in detail and fully understand it before use. Please keep this manual properly. We sincerely hope that this product to meet your needs and long-term service with you. Contents 1. What's in the box 2. Product Diagram 3. Interface 4. Button 5. Video mode 6. Photo mode 7. Playback mode 8. Specifications 9.Buck cable connection method and rear camera wiring diagram 10.FAQ 11.Disclaimer 1. What’s in the box Front Camera Rear camera Charger User manual Installation tools 说明书换一下封面 2. Product Diagram 1) Rear camera interface 2) Bracket 3) Type-C port 4) Display 5) Charging indicator 6) Lens 7) Working indicator 8) IR 9) Speaker 10) Front Camera 11) Micro card slot 12) Reset 13) Menu button/Mode button 14) UP 15) Down 16) Power Button/OK button 3. Interface 1. Rear camera interface: Plug in the rear camera cable to display the rear camera image in real time. 2.Type-c port: Plug in the matching car charger to power the camera. 3. Micro SD card slot: place memory cards. (You need to use a U3 grade Micro SD card and format it locally.) 4.Reset : You can use a fine needle or other object to briefly press the reset button to force the device to restart. 4. Button Mode Button Procedure Mode Button Procedure Video Mode(recor ding not started) Short press to enter the menu; Long press to switch to playback mode Start recording status Short press to lock the video Long press to take a photo Short press to switch screen display Short press to switch screen display Turn the microphone on or off Turn the microphone on or off Short press to start recording; Long press to shut down Short press to stop recording; Long press to shut down Mode Button Procedure Mode Button Procedure Playback mode Press once to return to the previous menu; In the playback file list, press and hold to pop up the delete menu Menu Settings Return to the previous menu or exit the menu Short press to move up an option or switch Move menu options up Short press to move down an option or switch Move menu options down Confirm options or play the files you would like to check; Long press to shut down Short press to enter the sub-menu or confirm settings; Long press to shut down 5.Recording mode （Note: The icon will be automatically hidden in 5 seconds after the recording starts.） 1.Video resolution 2. Date and time 3. Remaining recording time of the memory card 4. Battery icon 5. License plate 6. Microphone 7. Take photo 8. Recording 9. Settings 10. Playback 11. Video status 12. Rear camera Select video resolution. 4K(Default)/ 2K (Optional) Loop Record：1 minute（Default）/2minutes / 3minutes. The time each video is recorded. This feature allows the camera to record continuously. When the memory card is going to run flat, the camera will automatically delete the oldest files. Time-lapse: Off（Default) / 1 second/ 2 seconds/ 3 seconds. This function requires a step-down line, which should be connected to the camera. After activated, select 1/2/3 seconds, then each time the vehicle is turned off and parked, a frame of video will be recorded at the corresponding time. Note that the time-lapse video will last up to 24 hours after each parking. For the step-down line instructions, please refer to Item 8 in this manual. License：Off（Default）/ On. After turning it on, you can customize the license plate watermark consisting of letters and numbers, which will be recorded and displayed in each video clip. Motion Detect: Off（Default）/ On. After activated, the device will start recording only when it detects movement in the picture, and will stop recording when it is still. Audio record: On（Default）/ Off. Recording video, the sound will be recorded at the same time. Date stamp： On（Default）, When it is on, the system date and time will be displayed on the video and photo files. When it is off, there will be no date on the video or photo files. G-sensor：Off (Default) / Low / Medium / High(Optional). G-sensor is a 3-axis shock-gravity accelerometer designed to detect physical forces and gravity on the camera. Once the G-sensor is triggered due to physical or gravity impact on the camera, the current video file will be locked as an emergency file and will not be overwritten by the loop recording function. The higher the G-Sensor sensitivity, the less force is required to trigger the automatic file protection. (If this function is on, it is recommended to format the memory card regularly to avoid running out of space, provided there are no files that need to keep. Parking：Off (Default) / Low / Medium / High(Optional). After activated, the camera will automatically turn off the screen after a set time without any operation. Pressing any button will wake up the screen again. Auto power off：Off（Default）/1minutes / 3minutes/ 5minutes. After turning on this function, the camera will automatically turn off the screen after a set time without any operation. Pressing any button will wake up the screen again. Screen saver：Off（Default）)/ 10 seconds/ 30seconds/ 60 seconds. After activated, the camera will automatically turn off the screen after a set time without any operation. Pressing any button will wake up the screen again. Frequency: 50Hz(Default)/60Hz. According to the frequency specifications used in your country/region. 60HZ- Applicable to the United States, North America 50HZ- Applicable to the Europe, most Asian cou…

Text truncated - open the document above for the full version.

Dongguan HDKing Smart Technoiogy Co.Ltd Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/24/2024 U.S. Agent Designation Dongguan HDKing Smart Technoiogy Co.Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BFWQ-DC339S): Name and company of U.S. agent: FCC US Agent, LLC Physical U.S. address of agent: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN of U.S. agent: 0033402884 Email address of U.S. agent: [email protected] FCC US Agent, LLC acknowledges their obligation to accept service of process on behalf of Dongguan HDKing Smart Technoiogy Co.Ltd. Dongguan HDKing Smart Technoiogy Co.Ltd with the FRN 0035295294 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. S incerely, Signature Weiqiang Yang Manager Dongguan HDKing Smart Technoiogy Co.Ltd Signature Tim Payne Manager FCC US Agent, LLC 48_[model] US_Agent_2.911(d)(7)-U, V05

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2BFWQ-DC339S DC339S, DC316S, DC339CW, DC339DW, DC359CW, DC359DW, DC339S, DC60S, DC90S, FT-VD004, S100 We, Applicant Company Name: Dongguan HDKing Smart Technoiogy Co., Ltd Address: No.8. hechang Road Shatou Area Changan Town, Dongguan, Guangdong 523000, China Phone: +86-755-82591330 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. This includes the cybersecurity and anti-virus software produced or provided by Kaspersky Lab, Inc.. We certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-09-24 Signature Date Name / Title: Weiqiang Yang / Manager Company: Dongguan HDKing Smart Technoiogy Co., Ltd Address: No.8. hechang Road Shatou Area Changan Town, Dongguan, Guangdong 523000, China Phone: +86-755-82591330 Fax: +86-755-82591330 E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2BFWQ-DC339S DC339S, DC316S, DC339CW, DC339DW, DC359CW, DC359DW, DC339S, DC60S, DC90S, FT-VD004, S100 For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-09-24 Signature Date Name / Title: Weiqiang Yang / Manager Company: Dongguan HDKing Smart Technoiogy Co., Ltd Address: No.8. hechang Road Shatou Area Changan Town, Dongguan, Guangdong 523000, China Phone: +86-755-82591330 Fax: +86-755-82591330 E-Mail: [email protected]

Page 1 of 1 Rev.2.0 Dongguan HDKing Smart Technoiogy Co., Ltd WIFI Channel 12 and 13 Declaration Letter We declare the equipment identified below with regards to Channel 12 and 13 capabilities for FCC ID: 2BFWQ-DC339S Declaration Product hardware does not have the capability to operate on Channel 12 and 13. Product hardware has the capability to operate on Channel 12 and 13. However, these two channels will be disabled via software and will not be accessible to user. Product hardware has the capability to operate on Channel 12 and 13. However, all the operated channels can’t be changed in the RF parameter via software. All channels have complied with all of the requirements sets out in FCC Part 15.247. Product hardware has the capability to operate on WiFi Channel 12 and 13, and meets the requirements of KDB 594280 D01 v02r01. Please note: 1.) By default, this device operates in a mode that is compliant with the U.S. requirements. 2.) This device will also use supplemental information such as geo- location data to determine that it is operating outside the U.S., if necessary, to change its power. Such supplemental data will be derived from the following: Global Navigation Satellite System (GNSS)7 sensors in the device Mobile Country Code (MCC),8 or MCC with a Mobile Network code (MNC), received from a CMRS9 carrier and received directly by a receiver on the device Country information derived from multiple adjacent access points (for example using IEEE Std 802.11d provisions) may be permitted on case-by-case basis Other suitable geo-location data based on IP addresses or other reliable source. Name / Title: Weiqiang Yang / Manager Signature: Phone: +86-755-82591330 Email: [email protected] Date: 2024-09-24

Dongguan HDKing Smart Technoiogy Co., Ltd No.8. hechang Road Shatou Area Changan Town, Dongguan, Guangdong 523000, China Date: September 24, 2024 FCC ID: 2BFWQ-DC339S Model Number: DC339S, DC316S, DC339CW, DC339DW, DC359CW, DC359DW, DC339S, DC60S, DC90S, FT-VD004, S100 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Dongguan HDKing Smart Technoiogy Co., Ltd hereby declare that our product (Dash Camera) Model Number: DC339S, DC316S, DC339CW, DC339DW, DC359CW, DC359DW, DC339S, DC60S, DC90S, FT-VD004, S100 board, Schematic, Hardware version, Software version, structure and internal photos are same, named and appearance differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: Weiqiang Yang / Manager Company: Dongguan HDKing Smart Technology Co., Ltd Address: No.8. hechang Road Shatou Area Changan Town, Dongguan, Guangdong 523000, China Phone: +86-755-82591330 Fax Number: +86-755-82591330 E-Mail: [email protected]

Page 1 of 4 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 4 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 4 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8

Page 1 of 1 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Label and Location Material: Tagboard Gule: adhesive sticker Font color: Black Label color: White (Size: L: 3.0cm x W:2.0cm) Label Location Dash Camera Model: DC339S FCC ID: 2BFWQ-DC339S

Page 1 of 9 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 9 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 9 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 9 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 9 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9 Fig. 10 Page 6 of 9 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 11 Fig. 12 Page 7 of 9 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 13 Fig. 14 Page 8 of 9 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 15 Fig. 16 WIFI Antenna Page 9 of 9 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 17

Page 1 of 4 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Maximum Permissible Exposure Report 1. Product Information FCC ID : 2BFWQ-DC339S EUT : Dash Camera Test Model : DC339S Additional Model No. : DC316S, DC339CW, DC339DW, DC359CW, DC359DW, DC339S, DC60S, DC90S, FT-VD004, S100 Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested Ratings : Input: DC 5V, 2.5A DC 3.7V by Battery, 180mAh Hardware Version : V1.0 Software Version : / WIFI(2.4G Band) : Frequency Range : 2412MHz-2462MHz Channel Spacing : 5MHz Channel Number : 11 Channels for 20MHz bandwidth (2412~2462MHz) Modulation Type : IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Description : Ceramic Antenna, 3.8dBi(Max.) Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Mobile Device Page 2 of 4 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Uncontrolled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density Page 3 of 4 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information EUT can only use antennas certificated as follows provided by manufacturer; Internal/External Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Notes Internal Antenna Ceramic Antenna 2412MHz~2462MHz 3.8dBi WIFI Antenna 6. Conducted Power [2.4G WLAN] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) IEEE 802.11b 1 2412 15.29 6 2437 15.24 11 2462 15.51 IEEE 802.11g 1 2412 14.67 6 2437 14.62 11 2462 14.16 IEEE 802.11n HT20 1 2412 13.29 6 2437 13.04 11 2462 13.56 Page 4 of 4 FCC ID: 2BFWQ-DC339S Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 7. Manufacturing Tolerance [2.4G WLAN] IEEE 802.11b(P…
