2BFX8ZN-WW-1DECT RADIO MODULE

Datasheet for RTX1090 DECT communication module – support for multi-level modulation RTX1090 DECT module datasheet Proprietary and confidential Version 1.3 Page 2 of 21 Contents 1 Document info ....................................................................................................................... 5 1.1 Document scope .................................................................................................................................. 5 1.2 References ........................................................................................................................................... 5 1.3 Terms and abbreviations ..................................................................................................................... 5 1.4 Document history ................................................................................................................................ 6 2 Concept .................................................................................................................................. 7 2.1 Module description .............................................................................................................................. 7 3 Module features .................................................................................................................... 8 3.1 Zero Blind Slot ...................................................................................................................................... 9 3.2 Multi-level modulation ........................................................................................................................ 9 4 Mechanical specification ..................................................................................................... 10 5 Hardware specification ........................................................................................................ 12 5.1 Electrical specification........................................................................................................................ 12 5.1.1 Current consumption .................................................................................................................... 12 5.1.2 Recommended operating conditions ............................................................................................ 13 5.1.3 DC characteristics .......................................................................................................................... 13 5.1.4 Common electrical specifications – GPIO pads ............................................................................. 13 5.1.5 Electrical specifications – DC characteristics ................................................................................. 14 5.2 Module pin specification .................................................................................................................... 14 6 Design guidelines ................................................................................................................. 17 6.1 External parts ..................................................................................................................................... 17 6.1.1 Antennas ....................................................................................................................................... 17 6.1.2 Module placement on carrier board ............................................................................................. 17 6.1.3 Power supply ................................................................................................................................. 17 6.2 Radio performance ............................................................................................................................ 17 6.3 Test interface ..................................................................................................................................... 18 7 Soldering profile .................................................................................................................. 19 7.1 Preheat ............................................................................................................................................... 19 7.2 Soak or dry-out .................................................................................................................................. 19 7.3 Reflow ................................................................................................................................................ 19 7.4 Cooling ............................................................................................................................................... 19 8 Packaging of module ........................................................................................................... 19 9 Standard and approvals ....................................................................................................... 20 9.1 Radio, EMC, and safety ...................................................................................................................... 20 9.2 Environmental .................................................................................................................................... 20 10 Product labeling ................................................................................................................... 21 10.1 Serial number definition .................................................................................................................... 21 10.2 Barcode .............................................................................................................................................. 21 11 Tape and reel specification .................................................................................................. 22 12 Environmental declaration ...............................................................................…

Text truncated - open the document above for the full version.

RACING FORCE S.p.A 2024/06/26 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BFX8ZN-WW-1) RACING FORCE S.p.A (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: giovanna morgavi

RACING FORCE S.p.A 2024/6/26 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BFX8ZN-WW-1) RACING FORCE S.p.A (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: giovanna morgavi

Attestation Statements 2024/06/26 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: 2BFX8ZN-WW-1) RACING FORCE S.p.A, the undersigned, hereby authorize Racing Force USA Inc. to act as our designated U.S. agent for service of process, Racing Force USA Inc. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Racing Force USA Inc. accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: RACING FORCE S.p.A Contact Name: giovanna morgavi Address: Via E. Bazzano, 5 – 16019 Ronco Scrivia (GE) - ITALY FRN: 0035301548 Telephone No: 00390109650130 Email: [email protected] Signature: giovanna morgavi U.S. Agent Information: Company Name: Racing Force USA Inc. Address: 137 Knob Hill RoadMOORESVILLE,NC 28117 USA FRN: 0035636174 Contact Name: Eric Ziegler Telephone No: (303)681-1553 Email: [email protected] Signature: Eric Ziegler

RACING FORCE S.p.A Agent Authorization Company: RACING FORCE S.p.A Address: Via E. Bazzano, 5 – 16019 Ronco Scrivia (GE) - ITALY Product Name: DECT RADIO MODULE Model Number(s): RTX1090 DECT Product Description: DECT RADIO MODULE FCC ID: 2BFX8ZN-WW-1 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2024.06.26 Name: giovanna morgavi Title: Group Chief Operating Officier Company: RACING FORCE S.p.A

RACING FORCE S.p.A Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024.06.26 Subject; Request for Confidentiality FCC ID: 2BFX8ZN-WW-1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES Part List In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: RACING FORCE S.p.A Title: Group Chief Operating Officier

Page 1 of 1 Report No.: LGT24E075 Appendix - External Photographs of EUT Constructional Details Model: RTX1090 DECT Photo 1 Photo 2

Label DECT RADIO MODULE Model: RTX1090 DECT FCC ID: 2BFX8ZN-WW-1

Page 1 of 3 Report No.: LGT24E075 Appendix - Internal Photographs of EUT Constructional Details Model: RTX1090 DECT Photo 1 Photo 2 Page 2 of 3 Report No.: LGT24E075 Photo 3 Photo 4 Page 3 of 3 Report No.: LGT24E075 Photo 5

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China SAR TEST REPORT Product Name: DECT RADIO MODULE Model Name: RTX1090 DECT FCC ID: 2BFX8ZN-WW-1 Issued For : RACING FORCE S.p.A Via E. Bazzano, 5 – 16019 Ronco Scrivia (GE) - ITALY Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24E075HA01 Sample Received Date: May 17, 2024 Date of Test: Jun. 15, 2024 Date of Issue: Jun. 18, 2024 Max. SAR (1g): Body: 0.249 W/kg Report No.: LGT24E075HA01 Page 2 of 27 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2. Test Standards and Limits 7 3. SAR Measurement System 8 3.1 Definition of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 13 5.1 Validation System 13 5.2 Validation Result 13 6. SAR Evaluation Procedures 14 7. EUT Test Position 15 7.1 Body-worn Position Conditions 15 8. Uncertainty 16 8.1 Measurement Uncertainty 16 9. Conducted Power Measurement 17 9.1 Test Result: 17 10. EUT and Test Setup Photo 18 10.1 EUT Photos 18 10.2 Setup Photos 19 11. SAR Result Summary 21 11.1 Body-worn SAR 21 12. Equipment List 22 Appendix A. System Validation Plots 23 Appendix B. SAR Test Plots 25 Appendix C. Probe Calibration and Dipole Calibration Report 27 Report No.: LGT24E075HA01 Page 3 of 27 Revision History Rev. Issue Date Contents 00 Jun. 18, 2024 Initial Issue Report No.: LGT24E075HA01 Page 4 of 27 TEST REPORT CERTIFICATION Applicant RACING FORCE S.p.A Address Via E. Bazzano, 5 – 16019 Ronco Scrivia (GE) - ITALY Manufacture RACING FORCE S.p.A Address Via E. Bazzano, 5 – 16019 Ronco Scrivia (GE) - ITALY Product Name DECT RADIO MODULE Trademark RTX Model Name RTX1090 DECT Sample number LGT2406040-3 APPLICABLE STANDARDS STANDARD TEST RESULTS ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 (2.1093) IEEE 1528: 2013 PASS Prepared by: Approved by: Della He Engineer Vita Li Manager Report No.: LGT24E075HA01 Page 5 of 27 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name DECT RADIO MODULE Trademark RTX Model Name RTX1090 DECT Series Model N/A Model Difference N/A Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version N/A Software Version N/A Frequency Range DECT: 1921.536 MHz ~ 1928.448 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Test distance: 0mm Mode Body Worn(W/kg)) DECT-PP ANT 1 0.249 DECT-PP ANT 2 0.211 Rating DC 5V Operating Mode: DECT: GFSK Antenna Specification FPC Antenna Operating Mode Maximum continuous output Hotspot Mode Not Support DTM Mode Not Support Report No.: LGT24E075HA01 Page 6 of 27 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate FCC Registration No.: 746540 A2LA Certificate No.: 6727.01 IC Registration No.: CN0136 Report No.: LGT24E075HA01 Page 7 of 27 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial- Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v06 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r02 RF Exposure Reporting (A). Limits for Occupational/Controlled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.4 8.0 20.0 (B). Limits for General Population/Uncontrolled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.08 1.6 4.0 NOTE: Whole-Body SAR is averaged over the entire body, partial-body SAR is averaged over any 1 gram of tissue defined as a tissue volume in the shape of a cube. SAR for hands, wrists, feet and ankles is averaged over any 10 grams of tissue defined as a tissue volume in the shape of a cube. Population/Uncontrolled Environments: Are defined as locations where there is the exposure of individuals who have no knowledge or control of their exposure. Occupational/Controlled Environments: Are defined as locations where there is exposure that may be incurred by people who are aware of the potential for exposure, (i.e. as a result of employment or occupation). NOTE GENERAL POPULATION/UNCONTROLLED EXPOSURE PARTIAL BODY LIMIT 1.6 W/kg Report No.: LGT24E075HA01 Page 8 of 27 3. SAR Measurement System 3.1 Definition of Specific Absorption Rate (SAR) SAR is related to the rate at which energy is absorbed per unit mass in an object exposed to a radio field. The…

Text truncated - open the document above for the full version.

Manufacturer Zeronoise Product Name ZN-1.9 Antenna Type Strip antenna Date 08/05/2024 Version 1 Antenna appearence Frequency [MHz] 1915 1925 1935 Return Loss -6.4 -6 -6 VSWR 2.8 3.0 3.0 Radiation patterns: Figure 1 - 1915 MHz - xy plane plot – Horizontal polarization Figure 2 - 1925 MHz - xy plane plot – Horizontal polarization Figure 3 - 1935 MHz - xy plane plot – Horizontal polarization Figure 4 - 1915 MHz - xy plane plot – Vertical polarization Figure 5 - 1925 MHz - xy plane plot – Vertical polarization Figure 6 - 1935 MHz - xy plane plot – Vertical polarization Figure 7 - 1915 MHz - yz plane plot – Horizontal polarization Figure 8 - 1925 MHz - yz plane plot – Horizontal polarization Figure 9 - 1935 MHz - yz plane plot – Horizontal polarization Figure 10 - 1915 MHz - yz plane plot – Vertical polarization Figure 11 - 1925 MHz - yz plane plot – Vertical polarization Figure 12 - 1935 MHz - yz plane plot – Vertical polarization Figure 13 - 1915 MHz - zx plane plot – Horizontal polarization Figure 14 - 1925 MHz - zx plane plot – Horizontal polarization Figure 15 - 1935 MHz - zx plane plot – Horizontal polarization Figure 16 - 1915 MHz - zx plane plot – Vertical polarization Figure 17 - 1925 MHz - zx plane plot – Vertical polarization Figure 18 - 1935 MHz - zx plane plot – Vertical polarization Gain and efficiency Test state Frequency[MHz] Gain[dB] Efffciency[%] Free space 1915 -0,33 33.42 1925 0,68 42.19 1935 1,34 49.04 Test setup with x, y, z axes highlighted Antenna dimensions

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China RF TEST REPORT Product Name: DECT RADIO MODULE Model Name: RTX1090 DECT FCC ID: 2BFX8ZN-WW-1 Issued For : RACING FORCE S.p.A Via E. Bazzano, 5 – 16019 Ronco Scrivia (GE) - ITALY Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24E075RF01 Sample Received Date: May 17, 2024 Date of Test: May 17, 2024 – Jun. 13, 2024 Date of Issue: Jun. 13, 2024 Report No.: LGT24E075RF01 Page 2 of 67 TEST REPORT CERTIFICATION Applicant RACING FORCE S.p.A Address Via E. Bazzano, 5 – 16019 Ronco Scrivia (GE) - ITALY Manufacturer RTX A/S Address Stroemmen 6, DK-9400 Noerresundby Denmark Product Name DECT RADIO MODULE Trademark RTX Model Name RTX1090 DECT Sample Status Normal APPLICABLE STANDARDS STANDARD TEST RESULTS 47 CFR Part 15 Subpart D ANSI C63.17-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24E075RF01 Page 3 of 67 TABLE OF CONTENTS Page 1.SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2 PRODUCT INFORMATION 8 3 TEST MODE 9 3.1 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 9 3.2 TEST SOFTWARE AND POWER LEVEL 9 3.3 SYSTEM TEST CONFIGURATION 10 4 MEASUREMENT INSTRUMENTS 11 5 TEST ITEMS 12 5.1 ANTENNA REQUIREMENT 12 5.2 MODULATION TECHNIQUES 12 5.3 EMISSION BANDWIDTH 13 5.4 PEAK TRANSMIT POWER 20 5.5 POWER SPECTRAL DENSITY 25 5.6 POWER ADJUSTMENT FOR ANTENNA GAIN 28 5.7 AUTOMATICALLY DISCONTINUE TRANSMISSION 29 5.8 SYSTEM ACKNOWLEDGE-MENT TEST 30 5.9 MONITORING THRESHOLD 31 5.10 DURATION OF TRANSMISSION 32 5.11 SELECTED CHANNEL CONFIRMATION, POWER ACCURACY, SEGMENT OCCUPANCY 33 5.12 RANDOM WAITING 35 5.13 MONITORING REQUIREMENTS 36 5.14 MONITORING ANTENNA 37 5.15 DUPLEX CONNECTIONS 37 5.16 ALTERNATIVE MONITORING INTERVAL FOR CO-LOCATED DEVICES 38 5.17 FAIR ACCESS 38 5.18 SPURIOUS EMISSIONS 39 5.19 FRAME PERIOD 47 5.20 FREQUENCY STABILITY 48 5.21 CONDUCTED EMISSION MEASUREMENT 50 5.22 RADIATED SPURIOUS EMISSION 54 APPENDIX I - TEST SETUP 67 Report No.: LGT24E075RF01 Page 4 of 67 Revision History Rev. Issue Date Revisions 00 Jun. 13, 2024 Initial Issue Report No.: LGT24E075RF01 Page 5 of 67 1.SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The following tests were conducted on a sample of the equipment for the purpose of demonstrating com- pliance with 47 CFR Part 15 Subpart D. Requirement FCC Part Test Procedure Result Emission Bandwidth 15.323 (a) 6.1.3 Compliant Labeling Requirements 15.19(a)(3) -- Compliant Conducted Emissions 15.315 & 15.207 ANSI C63.4 Compliant Antenna Requirements 15.317 & 15.203 Declaration Compliant Use digital modulation 15.319 (b) 6.1.4 Compliant Peak transmit power 15.319 (c) 6.1.2 Compliant Power spectral den- sity 15.319 (d) 6.1.5 Compliant Power adjustment for an- tenna gain 15.319 (e) 4.3.1 Compliant Automatically dis- continue transmis- sion 15.319 (f) -- Compliant Spurious emissions conducted 15.323 (d) (1) & 15.323 (d) (2) 6.1.6 Compliant RF Exposure 15.319 (i) & 1.1307(b), 2.1091 and 2.1093 ANSI/IEEE C95.1 Compliant (The test data please refer to RF exposure report) Monitoring time 15.323 (c)(1) 7.3.4 Compliant Monitoring threshold 15.323 (c)(2) 7.3 Compliant Duration of transmission 15.323 (c)(3) 8.2.2 Compliant System acknowledgment test 15.323(c)(4) 8.2.1 Compliant Channel confirmation, Power accuracy, Segment occupancy 15.323 (c)(5) 7.3.3 & 7.3.4 Compliant Random waiting 15.323 (c)(6) 8.1.3 Not Applicable Report No.: LGT24E075RF01 Page 6 of 67 Monitoring bandwidth 15.323 (c)(7) 7.4 Compliant Monitoring reaction time 15.323 (c)(1 ) 7.5 Compliant Monitoring antenna 15.323 (c)(8) 4 Compliant Monitoring threshold relaxation 15.323 (c)(9) 4 Compliant Duplex connections 15.323 (c)(10) 8.3 Compliant Alternate monitoring interval 15.323 (c)(11) 8.4 Not Applicable Fair access 15.323 (c)(12) Declaration Not Applicable Frame period 15.323 (e) 6.2.2 & 6.2.3 Compliant Frequency stability 15.323 (f) 6.2.1 Compliant Radiated Out of Band Emissions 15.319 (g), 15.309 (b) & FCC Part 15 Subpart B, 15.109 and 15.209 -- Compliant Report No.: LGT24E075RF01 Page 7 of 67 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a stand- ard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF Output Power, Conducted ±0.71dB 2 Unwanted Emission, Conducted ±0.63dB 3 All Emissions, Radiated (0.009-30MHz) ±2.16dB 4 All Emissions, Radiated (30MHz-1GHz) ±4.40dB 5 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 6 Conducted Emission (150KHz-30MHz) ±2.80dB Report No.: LGT24E075RF01 Page 8 of 67 2 PRODUCT INFORMATION Product Name DECT RADIO MODULE Trademark RTX Model Name RTX1090 DECT Series Model N/A Model Difference N/A EUT Frequency Ranges 1921.536-1928.448MHz Modulation Type: GFSK, π/2-DBPSK Number of Channels 5 CH. Please see Note 2. Antenna Type Chip antenna Antenna Gain ANT 1: 1.34dBi ANT 2: 1.34dBi Rated Input DC 5V Hardware version N/A Software version N/A Note 1: For a…

Text truncated - open the document above for the full version.

FCC ID_SAR Setup photos Body Front side (separation distance is 0mm) Body Back side (separation distance 0mm)

Page 1 of 2 Report No.: LGT24E075 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Page 2 of 2 Report No.: LGT24E075 Set-up for Conducted Emission
