2BG2A-WK9DCSmart permanent outdoor light

Smartpermanentoutdoorlight usermanual Features Diagram (Thepictureisforreferenceonly,itwillsubjecttotheactualproduct). Supporttimer,countdown, sharingandmemoryfunctions SupportvoicecontrollikeAlexa, GoogleAssistantetc. Thelampbodyissuitableforany placeinstallation,andtheinstallation issimpleandquick WiFi+BLEdualmodefaster connecting,supportAPPoperation Elegantroundshape design,exquisiteappearance AdopthighbrightLEDsaslightsource, excellentconsistentlightcolor Waterproofdesignandfilledwithglue forbetterIPgrade AdoptPCmaterialaslightguide, widebeamangle 16millioncolors,optional brightnessandlightingmodes available Themusicmodeisoptional Productparameters Productfunctioninstructions 1.Functionbutton:singlepress-turnonlight-modeswitch Doublepress-turnofflight Longpressforover5secondstoreset 2.Poweroutput Item72Lamps36Lamps30Lamps15Lamps Adapter 12-60W/DC24V Color RGBRGB+W Controlway ButtonsTurnON/OFF 、 Networkpairing Beamangle≥100° Workingtemperature-20-40°C IPgradeIP67 APP+RF433remote + Wiringprogram 1.Checkeverypartsincludepowersupplyandlightsandmakesureeverypartsareallingood condition. 2.Fixthepositionofeachlightaccordingtotheuser'sapplicationscenario,checkwhetherthe tailplugistightened,andthenconnecttheadapterplugandtightenthescrewCap,installation complete. 3.Doublecheckifthewiringandinstallationiscorrect,thenpowerontoenjoythelightingafter everythingiscorrect. Installation Fixedbyadhesivetape: suitablefortemporaryfix,orfixonsmoothwallslikeglass,metalandsmoothwoodpanelsetc. 1.Findtherightpositionforinstallation.(Therecommendeddistancefromthecorneris2-4inches). 2.Cleanthesurfaceofthewall. 3.Sticktheadhesivetapeonbackofthelight,teaofthereleasepaperfromtheadhesivetape. 4.Fixthelightonwallandpressforover5seconds. 5.Connectthewaterproofconnector. Fixedbyscrews: suitableforlongpermanentfixing,orusedforroughorirregularwalls. 1.Findtherightpositionforinstallation.(Therecommendeddistancefromthecorneris2-4inches). 2.Drillthecrewholesaccordingtotheinstallationpositiononwall. 3.Fixthelightswiththescrewsthroughtheholes. 4.Connectthewaterproofconnectors. Notes: 1:Pleasemakesurefullycleanthesurfaceofthewallsbeforeusingtheadhesivetape,andfully pressthelightsafterstickingthelightswithadhesivetape. 2:Don'tusetheadhesivetapetofixthelightsonlimewalls,wallpapersandotherirregularwalls. 3:Ifyouneedtoextendthelightswithtwoormorestrings,justconnecttheendofthefirststring withheadofthesecondstringthroughthewaterproofconnector. Andmakesuretochooseahigherpowersupplyforthelights.(Suchasthe36bulbsrequire 24Wpowersupply,and72bulbswillrequire60Wofpowersupply). DownloadAPP 1:Search"SmartLife"fromAppstoreorGoogleplay. 2:ScantheQRcodefromthelabelorusermanual. TheAPPiscompatiblewithAndroid5.0andl0S10.0andhigherversion. Login/Registeraccountnumber OpentheAPP,signupforanewaccountorloginwithanexistingaccount. APPconnection 1.Preparation:PowerontheLEDlightsandenterthehomeofApp,MakesuretheWiFisignalisgood andstable. 2.TheLEDlightswillstartquickflashwhenitispoweredon.Thenclickthe"Adddevices"tomanually addthedevices,followthestepsuntilthedevicesandAPParepairingsuccess. 3.IftheLEDlightnotquickflashafterpoweredonthelight,pleaselongpresstheswitchbuttonof thecontrollerformorethan5secondstoreset,WhentheLEDlightsstartquickflash,Thenclickthe "Adddevices"tomanuallyaddthedevices,followthestepsuntilthedevicesandAPParepairing success. UIIntroduction 4.Interfacesforbasicadjustmentyoucansetthoquantityofbulbs,lightcolors,colorpalette combinationcolortemperatureandbrightnessonthisUI. Smeartoning:Fillthewholesectionwithapaintbucketthroughthointeractivemethodofpainting, andthenyoucanchangethecolorofthepaintingthroughthecolorpen,andusetheeraserto extinguishitindependently. DIYSceneMode Customizethescenewithacombinationofmotionandcolor. Paintbucketbutton:16millioncoloradjustmentsfortheentirelight Eraserbutton:Clicktheerasertoclearthecolor,thenthesegmentwill notlightup.Clickonthedeviceparagraphtoadjustthe colorinsegmentsandyoucanalsosmearseveral paragraphsforcoloring Brightnessbar.Dragthebrightnessbartoadjustthebrightnessofthelightcolor (saturationsetting) Allbutton:Togglebetweensingleandmultipleselection. Singleselectionisforcontrollingasinglelight,whilemultiple selectionisforcontrollingallthelights. MusicalRhythm Thecolorandbrightnessofthelightswilljumpwiththerhythmandvolumeofthemusic. Countdowntoturnoffthelights. Instructionsofremote Briefintroduction: Throughthe12-keyRF433remote,youcanremotecontrolandgetvariouslightingeffectssuchas dimming,colorswitching,waterflow,rainbow,flowinglightandcoloretc Parameters: 2*AAAPowersupplyway 10MRemotecontroldistance [Important]RequestCodeMatchingBeforeUsingtheRemoteCotroller 1.Poweronthelightandpairtheremotecontrollerwiththelightwithin5minutes. 2.Andpressthebuttonof"Multi"+"Random"forover5secondsatthesametime. 3.Whenthelightsflash,itmeansthepairingsuccessfully. 1ONON 2 OFF OFF 3BrightnessIncrease 4BrightnessReduction 5+SpeedUp 6- SpeedDown 7StaticColor 8Multi8colorsfixed 9Random8colorsflashrandomly 10Strobe Switchable&randommode withbackgroundcolor 11Breath Optional8-colorbreath +automatic8-colorbreath 12Flash Switchable8-colorflash+ automatic8-colorflash FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between…

Text truncated - open the document above for the full version.

Shenzhen Juhong Microelectronics Technology Co., Ltd. Building B, No. 115, Guangqiao North Road, Xinhu Street, Xinqiang community, Guangming District,Shenzhen City, Guangdong Province China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-6-29 To whom it may concern: We, Shenzhen Juhong Microelectronics Technology Co., Ltd., hereby certify that the equipment for which authorization is sought (FCC ID: 2BG2A-WK9DC) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Senlin Bai Manager Shenzhen Juhong Microelectronics Technology Co., Ltd. 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

Shenzhen Juhong Microelectronics Technology Co., Ltd. Add: Building B, No. 115, Guangqiao North Road, Xinhu Street, Xinqiang community, Guangming District,Shenzhen City, Guangdong Province China Date: 2024-6-29 FCC ID: 2BG2A-WK9DC Dear Sir/Madam, We, Shenzhen Juhong Microelectronics Technology Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Smart permanent outdoor light Model no.: WK9DC-433S-72L, WK9DC-433S-36L, WK9DC-433S-30L, WK9DC-433S-18L, WK9DC-433S-15L, WK9DC-433S-12L, WK9DC-433S-10L Sincerely, Name/Title： Senlin Bai/Manager Company: Shenzhen Juhong Microelectronics Technology Co., Ltd. Address: Building B, No. 115, Guangqiao North Road, Xinhu Street, Xinqiang community, Guangming District,Shenzhen City, Guangdong Province China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-6-29> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BG2A-WK9DC WK9DC-433S-72L For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Senlin Bai/Manager Company: Shenzhen Juhong Microelectronics Technology Co., Ltd. Address: Building B, No. 115, Guangqiao North Road, Xinhu Street, Xinqiang community, Guangming District,Shenzhen City, Guangdong Province China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

Shenzhen Juhong Microelectronics Technology Co., Ltd. Building B, No. 115, Guangqiao North Road, Xinhu Street, Xinqiang community, Guangming District,Shenzhen City, Guangdong Province China Date: 2024-6-29 FCC ID: 2BG2A-WK9DC Model Number: WK9DC-433S-72L To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Shenzhen Juhong Microelectronics Technology Co., Ltd., declare that this EUT (FCC ID: 2BG2A-WK9DC) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Senlin Bai/Manager Company: Shenzhen Juhong Microelectronics Technology Co., Ltd. Address: Building B, No. 115, Guangqiao North Road, Xinhu Street, Xinqiang community, Guangming District,Shenzhen City, Guangdong Province China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

Shenzhen Juhong Microelectronics Technology Co., Ltd. Building B, No. 115, Guangqiao North Road, Xinhu Street, Xinqiang community, Guangming District,Shenzhen City, Guangdong Province China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-6-29 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BG2A-WK9DC including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Senlin Bai/Manager Company: Shenzhen Juhong Microelectronics Technology Co., Ltd. Address: Building B, No. 115, Guangqiao North Road, Xinhu Street, Xinqiang community, Guangming District,Shenzhen City, Guangdong Province China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202406155 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 4 Product Name: Smart permanent outdoor light Model No.: WK9DC-433S-72L EUT Constructional Details External Photo Report No.: HTT202406155 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 4 Report No.: HTT202406155 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 4 Report No.: HTT202406155 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 4 of 4 ------End------

Label and Location Size: L: 3.0cm*W: 2.0cm Label and Location FCC ID : 2BG2A-WK9DC

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202406155 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 2 Product Name: Smart permanent outdoor light Model No.: WK9DC-433S-72L EUT Constructional Details Internal Photo Report No.: HTT202406155 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 2 ------End------

RF Exposure evaluation FCC ID: 2BG2A-WK9DC Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information WK9DC-433S-72L can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: BT/2.4GWIFI / PCB antenna 2.21dBi for 2400-2500MHz; 5. Manufacturing Tolerance BLE GFSK(Peak) Channel Channel 00 Channel 19 Channel 39 Target (dBm) 5.0 4.0 3.0 Tolerance ±(dB) 1.0 1.0 1.0 WIFI(Peak) Frequency (MHz) 11b 2412 2437 2462 Target (dBm) 16.0 16.0 16.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11g 2412 2437 2462 Target (dBm) 21.0 20.0 20.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11n(HT20) 2412 2437 2462 Target (dBm) 20.0 20.0 20.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11n(HT40) 2422 2437 2452 Target (dBm) 18.0 18.0 18.0 Tolerance ± (dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is 2.21dBi, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW BLE 6.0 3.9811 2.21 1.6634 0.0013 1.0000 2.4GWIFI 22.0 158.4893 2.21 1.6634 0.0525 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------
