SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240500056102 Page: 1 of 10 FCC ID: 2BG366000CG61 Ricky Liu Manager RF EXPOSURE EVALUATION REPORT Application No.: GZCR2405000561MD Applicant:Maxphotonics Co., Ltd. Address of Applicant:Maxphotonics Industrial Park, Third Furong Road Furong Industrial Area, Shajing Town, BaoAn District Shenzhen, Guangdong, China. Manufacturer:Maxphotonics Co., Ltd. Address of Manufacturer:Maxphotonics Industrial Park, Third Furong Road Furong Industrial Area, Shajing Town, BaoAn District Shenzhen, Guangdong, China. Factory:Maxphotonics Co., Ltd. Address of Factory:Maxphotonics Industrial Park, Third Furong Road Furong Industrial Area, Shajing Town, BaoAn District Shenzhen, Guangdong, China. Product Name:MFSC 6000C(G6.1) CW Fiber Laser Series Model No.: MFSC-6000C-BKW6.1, MFSC-####**-**W*.** (‘####’=1000, 1500, 2000, 3000, 6000; the first‘*’=H, M, X, C, W, W_Pro, plus, HW; the second‘*’=(W), (C), (HMB) or blank space; the third‘*’=A, B, C, D, E, F, G, H; the fourth‘*’= A, B, C, D, E, F, G, H, I, J, K, L, M, X; the fifth‘*’=1-99; the sixth‘*’=0-99; the seventh‘*’= C or Blank space)   Please refer to section 2 of this report which indicates which item was actually tested and which were electrically identical. Trade Mark: , Standard(s) : 47 CFR Part 1.1310 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2024-05-27 Date of Evaluation: 2024-06-04 to 2024-06-25 Date of Issue: 2024-07-04 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240500056102 Page: 2 of 10 Revision Record VersionReport No.DateRemark 01GZCR2405000561022024-07-04Original Authorized for issue by: Luke Lin/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240500056102 Page: 3 of 10 2Evaluation Summary ItemStandardMethodRequirementResult RF Exposure KDB447498D01 General RF Exposure Guidance v06 KDB447498D01 General RF Exposure Guidance v06 47 CFR Part 1.1310Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section.  Declaration of EUT Family Grouping: Model No.: MFSC-6000C-BKW6.1, MFSC-####**-**W*.** (‘####’=1000, 1500, 2000, 3000, 6000; the first‘*’=H, M, X, C, W, W_Pro, plus, HW; the second‘*’=(W), (C), (HMB) or blank space; the third‘*’=A, B, C, D, E, F, G, H; the fourth‘*’= A, B, C, D, E, F, G, H, I, J, K, L, M, X; the fifth‘*’=1-99; the sixth‘*’=0- 99; the seventh‘*’= C or Blank space) According to the declaration from the applicant, the electrical circuit design, layout, components used and internal wiring were identical for all models, with only difference being the model name. More details are shown in the table below. Therefore, only one model MFSC-6000C-BKW6.1 was tested in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240500056102 Page: 4 of 10 12345667891011 MFMC-####**-**W*.** Code F Code SC CodeCurrent(A) 100012 150018.5 200028 300012.5 600031 Code H M X C W W_Pro Plus HW Code (W) (C) (HMB) Code A B C D E F G H Code A B C D E F G H I J K L M X Code W Code 1 2 3 4 5 . . 97 98 99 Code 0 1 2 3 4 . . 97 98 99 Code C Model ： Characteristic Application direction Changes in appearance, color, handle, etc. Optical path design and software operation, etc. Customized Company Fiber Laser Code/ Water-cooling Kind Kind Kind Blank space 20M 25M 30M Other Cooling 4.0M 5.0M 10M 12M 15M 1.5M 1.9M 2.0M 2.5M 3.0M LOE QD Bare fiber D80 Cable Length Output type Collimator isolator QBH QCS SMA-905 3000 6000 Characteristic Application direction Blank space Single-module CW Power （ W ） 1000 1500 2000 MFSC-####* MFSC-####**-**W*.** Kind Fiber laser Application Power Characteri stic Application direction / Output type Cable Length Cooling Optical path design and software operation, etc. / Changes in appearance, color, handle, etc. Version SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240500056102 Page: 5 of 10 3Contents Page 1Cover Page...............................................................................................................................................1 2Evaluation Summary................................................................................................................................3 3Contents....................................................................................................................................................5 4General Information.................................................................................................................................6 4.1Details of E.U.T.................................................................................................................................6 4.2Evaluating Location...........................................................................................................................6 4.3Facility...............................................................................................................................................7 4.4Deviation from Standards..................................................................................................................7 4.5Abnormalities from Standard Conditions...........................................................................................7 5Technical Requirements Specification..................................................................................................8 5.1General Description of Applied Standards........................................................................................8 5.2RF Exposure Evaluation......................…

Text truncated - open the document above for the full version.

公司地址：深圳市龙岗区嶂背社区创业四路5号汉光科技园4栋5楼 电话：0755-89985492 公司网址：www.szsdtx.com 承 认 书 SPECIFICATION FOR APPROVAL 客 户 名 称 CUSTOMER NAME: 产 品 名 称 PRODUCT NAME:2.4G 双注塑锥形天线 料号 CUSTOMER P/N: SD0034MG0001 晟达产品型号 SDP/N:TDZ-24Z03-006REV: A MANUFACTURER SIGNATURE CUSTOMER SIGNATURE CHECKED BY: APPROVED BY: DATE: 2022/06/29 5th Floor, Building 4, Hanguang Technology Park, No. 5 Chuangye 4th Road, Zhangbei Community, Longgang District, Shenzhen 公司地址：深圳市龙岗区嶂背社区创业四路5号汉光科技园4栋5楼 电话：0755-89985492 公司网址：www.szsdtx.com Contents ltemDescription 1--------------------------------------------------------------------规格表 2--------------------------------------------------------------------成品图 3--------------------------------------------------------------------测试报告 公司地址：深圳市龙岗区嶂背社区创业四路5号汉光科技园4栋5楼 电话：0755-89985492 公司网址：www.szsdtx.com 1.规格表: 产品主要技术参数 主要技术指标Maintechnicalspecifications 频率范围 （MHZ） 2400-2500 FrequencyRange (MHZ) 2400-2500 特性阻抗(Ω) 50Impedance(Ω)50 增益(dBi) 4（max） Gain(dBi) 4（max） 输出电压 驻波比 ≤2.0VSWR≤2.0 最大功率 10WAdmittedPower10W 极化方式 垂直极化 PolarizationVertical 连接方式 SMA公头 ConnectorTypeSMA-J 物理性能 PhysicalProperties 天线本体材料 PP+PVCAntennaBasePP+PVC 天线尺寸 (mm)/重量 /Weight φ28mm*31mm 工作温度 -20°C~+65°COperatingTemp-20°C~+65°C 公司地址：深圳市龙岗区嶂背社区创业四路5号汉光科技园4栋5楼 电话：0755-89985492 公司网址：www.szsdtx.com 2. 成品图： 颜色：白色 3.测试报告 3.1：网络分析仪测试报告 公司地址：深圳市龙岗区嶂背社区创业四路5号汉光科技园4栋5楼 电话：0755-89985492 公司网址：www.szsdtx.com 3.2 测试方向图 公司地址：深圳市龙岗区嶂背社区创业四路5号汉光科技园4栋5楼 电话：0755-89985492 公司网址：www.szsdtx.com 公司地址：深圳市龙岗区嶂背社区创业四路5号汉光科技园4栋5楼 电话：0755-89985492 公司网址：www.szsdtx.com

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 1 of 65 FCC ID: 2BG366000CG61 Ricky Liu Manager TEST REPORT Application No.: GZCR2405000561MD Applicant: Maxphotonics Co., Ltd. Address of Applicant: Maxphotonics Industrial Park, Third Furong Road Furong Industrial Area, Shajing Town, BaoAn District Shenzhen, Guangdong, China. Manufacturer: Maxphotonics Co., Ltd. Address of Manufacturer: Maxphotonics Industrial Park, Third Furong Road Furong Industrial Area, Shajing Town, BaoAn District Shenzhen, Guangdong, China. Factory: Maxphotonics Co., Ltd. Address of Factory: Maxphotonics Industrial Park, Third Furong Road Furong Industrial Area, Shajing Town, BaoAn District Shenzhen, Guangdong, China. Product Name: MFSC 6000C(G6.1) CW Fiber Laser Series Model No.: MFSC-6000C-BKW6.1, MFSC-####**-**W*.** (‘####’=1000, 1500, 2000, 3000, 6000; the first‘*’=H, M, X, C, W, W_Pro, plus, HW; the second‘*’=(W), (C), (HMB) or blank space; the third‘*’=A, B, C, D, E, F, G, H; the fourth‘*’= A, B, C, D, E, F, G, H, I, J, K, L, M, X; the fifth‘*’=1-99; the sixth‘*’=0-99; the seventh‘*’= C or Blank space) ♣ ♣ Please refer to section 2 of this report which indicates which item was actually tested and which were electrically identical. Trade Mark: , Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2024-05-27 Date of Test: 2024-06-04 to 2024-06-25 Date of Issue: 2024-07-04 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 2 of 65 Revision Record Version Report No. Date Remark 01 GZCR240500056101 2024-07-04 Original Authorized for issue by: Luke Lin/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 3 of 65 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass** Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass **: The EUT passed Radiated Spurious Emissions Below 1GHz test after modification. Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 4 of 65 ♣ Declaration of EUT Family Grouping: Model No.: MFSC-6000C-BKW6.1, MFSC-####**-**W*.** (‘####’=1000, 1500, 2000, 3000, 6000; the first‘*’=H, M, X, C, W, W_Pro, plus, HW; the second‘*’=(W), (C), (HMB) or blank space; the third‘*’=A, B, C, D, E, F, G, H; the fourth‘*’= A, B, C, D, E, F, G, H, I, J, K, L, M, X; the fifth‘*’=1-99; the sixth‘*’=0- 99; the seventh‘*’= C or Blank space) According to the declaration from the applicant, the electrical circuit design, layout, components used and internal wiring were identical for all models, with only difference being the model name. More details are shown in the table below. Therefore, only one model MFSC-6000C-BKW6.1 was tested in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 5 of 65 12345667891011 MFMC-####**-**W*.** Code F Code SC CodeCurrent(A) 100012 150018.5 200028 300012.5 600031 Code H M X C W W_Pro Plus HW Code (W) (C) (HMB) Code A B C D E F G H Code A B C D E F G H I J K L M X Code W Code 1 2 3 4 5 . . 97 98 99 Code 0 1 2 3 4 . . 97 98 99 Code C Model： Characteristic Application direction Changes in appearance, color, handle, etc. Optical path design and software operation, etc. Customized Company Fiber Laser Code/ Water-cooling Kind Kind Kind Blank space 20M 25M 30M Other Cooling 4.0M 5.0M 10M 12M 15M 1.5M 1.9M 2.0M 2.5M 3.0M LOE QD Bare fiber D80 Cable Length Output type Collimator isolator QBH QCS SMA-905 3000 6000 Characteristic Application direction Blank space Single-module CW Power （ W ） 1000 1500 2000 MFSC-####* MFSC-####**-**W*.** Kind Fiber laser Application Power Characteri stic Application direction / Output type Cable Length Cooling Optical path design and software operation, etc. / Changes in appearance, color, handle, etc. Version SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 6 of 65 3 Contents Page 1 Cover Page ........................................................................................................................................... 1 2 Test Summary ....................................................................................................................................... 3 3 Contents ......................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 44 of 65 10 Appendix 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 1M SISO 2402 0.107 0.625 17.12 7.66 0.00 2440 0.107 0.625 17.12 7.66 0.00 2480 0.108 0.625 17.28 7.62 0.03 2M SISO 2402 0.065 0.625 10.40 9.83 0.00 2440 0.066 0.625 10.56 9.76 0.03 2480 0.065 0.625 10.40 9.83 0.03 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 45 of 65 1.2 Test Graph 1.2.1 Ant1 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 46 of 65 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 47 of 65 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 48 of 65 2. Bandwidth 2.1 Test Result 2.1.1 6dB BW Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 0.689 >=0.5 Pass 2440 1 0.689 >=0.5 Pass 2480 1 0.689 >=0.5 Pass 2M SISO 2402 1 1.180 >=0.5 Pass 2440 1 1.182 >=0.5 Pass 2480 1 1.183 >=0.5 Pass SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 49 of 65 2.2 Test Graph 2.2.1 6dB BW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 50 of 65 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 51 of 65 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 52 of 65 3. Maximum Conducted Output Power 3.1 Test Result 3.1.1 Power Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 1M SISO 2402 -0.28 <=30 Pass 2440 -0.13 <=30 Pass 2480 -0.16 <=30 Pass 2M SISO 2402 -0.27 <=30 Pass 2440 -0.12 <=30 Pass 2480 -0.14 <=30 Pass Note1: Antenna Gain: Ant1: 4.63dBi; SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 53 of 65 4. Maximum Power Spectral Density 4.1 Test Result 4.1.1 PSD Mode TX Type Frequency (MHz) Maximum PSD (dBm/3kHz) Verdict ANT1 Limit 1M SISO 2402 -17.89 <=8 Pass 2440 -17.75 <=8 Pass 2480 -17.81 <=8 Pass 2M SISO 2402 -19.74 <=8 Pass 2440 -19.58 <=8 Pass 2480 -19.74 <=8 Pass Note1: Antenna Gain: Ant1: 4.63dBi; SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 54 of 65 4.2 Test Graph 4.2.1 PSD 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 55 of 65 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 56 of 65 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 57 of 65 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Test Result 5.1.1 Ref Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 1M SISO 2402 1 -0.38 2440 1 -0.23 2480 1 -0.25 2M SISO 2402 1 -0.37 2440 1 -0.22 2480 1 -0.27 Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2013, the channel contains the maximum PSD level was used to establish the reference level. 5.1.2 CSE and Band Edges Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 1M SISO 2402 1 -0.23 -20.23 Pass 2440 1 -0.23 -20.23 Pass 2480 1 -0.23 -20.23 Pass 2M SISO 2402 1 -0.22 -20.22 Pass 2440 1 -0.22 -20.22 Pass 2480 1 -0.22 -20.22 Pass Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2013, the channel contains the maximum PSD level was used to establish the reference level. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 58 of 65 5.2 Test Graph 5.2.1 Ref 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 59 of 65 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 60 of 65 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 61 of 65 5.2.2 CSE and Band Edges 1M_LCH_2402MHz_Ant1_NTNV 1M_LCH_2402MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 62 of 65 1M_MCH_2440MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 63 of 65 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 64 of 65 2M_LCH_2402MHz_Ant1_NTNV 2M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500056101 Page: 65 of 65 2M_HCH_2480MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV - End of the Report -

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 1 of 4 Appendix Test Setup Photo for GZCR240500056101 Test Model No.: MFSC-6000C-BKW6.1 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 2 of 4 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) Radiated Emissions which fall in the restricted bands & Radiated Spurious Emissions Above 1GHz SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 3 of 4 Radiated Spurious Emissions Below 1GHz SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-04 Rev 1.1 Page: 4 of 4 - End of the Appendix -
