2BG8P-UN1A48Electric Vehicle Charging Station

USER MANUAL 1 TABLE OF CONTENTS 1. IMPORTANT SAFETY INSTRUCTIONS ........................................... 2 2. PRODUCT INTRODUCTIONS .............................................................. 6 3. VERIFY CONTENTS ................................................................................ 9 4. GATHER TOOLS..................................................................................... 11 4. PLAN THE MOUNTING ........................................................................ 12 5. MOUNT THE CHARGING STATION ................................................ 13 6. WIRE THE CIRCUIT ............................................................................... 13 7. OPERATE YOUR DEVICE ................................................................... 14 8. LIGHT CODES ......................................................................................... 19 9. SMART APP GUIDE (OPTIONAL) .................................................... 20 10. FCC STATEMENT ................................................................................... 20 11. WARRANTY AND MAINTENANCE .................................................. 21 USER MANUAL 2 I 1. IMPORTANT SAFETY INS TRUCTIONS 1.1 Overall Warnings & Cautions WARNING: To avoid fire, injury or death, carefully read and follow the instructions during installation, operation and maintenance. - DO NOT put fingers into the electric vehicle connector. - DO NOT use this product if the flexible power cord or EV cable is frayed, insulation-broken, or any other signs of damage. - DO NOT use this product if the enclosure or the EV connector is broken, cracked, open, or shows any other indication of damage. - DO NOT remove cover or attempt to open the enclosure because of risk of electric shock. WARNING: This device should be supervised when used around children. WARNING: This device must be grounded. WARNING: To avoid a risk of fire or electric shock, do not use this device with an extension cord. WARNING: The suitability of the use of flexible cord in accordance with CE code, part I, rule 4-012, is to be determined by the local inspection authority. WARNING: To reduce the risk of fire, connect only to a circuit provided branch circuit over-current protection in accordance with the CSA C22.1–15 Canadian Electrical Code, Part 1 (Canada) or NOM-001-SEDE Electrical installations (utility) (Mexico) or ANSI / NFPA 70 National Electrical Code (USA). Circuit Breaker Options table Output Amperage (A) 16A 32A 40A 48A Circuit Breaker Options (A) 20A 40A 50A 60A WARNING & CAUTION USER MANUAL 3 1.2 Installation Requirements WARNING: Disconnect electrical power prior to installing the charging station. WARNING: Be sure to preview the user manual and ensure local building and electrical codes are reviewed before installing the AC charger. WARNING: The AC charger should be installed by a qualified technician according to the user manual and local safety regulations. CAUTION: Use appropriate protection when connecting to the main power distribution cable. CAUTION: Type B, C or D breaker with the rating current for table should be installed in the upstream AC distribution box. CAUTION: Disconnect switch for each ungrounded conductor of AC input shall be provided by others in accordance with the National Electric Code, ANSI/NFPA70. CAUTION: The device shall be mounted at height between 2 feet (600 mm) and 4 feet (1200 mm) from ground. CAUTION: Please keep the charger in a clean area with low humidity. Not recommended to be installed in coastal environments with high humidity or high dust. 1.3 Daily Maintenance CAUTION: Avoid moisture or water in the charger. If there is water or moisture ingress in the charger, it is necessary to immediately power off to avoid immediate danger, and notify the professionals to carry out maintenance before next use. CAUTION: Please use the charger properly. Do not hit or press hard on the enclosure. If it is damaged, please contact a professional technician. CAUTION: Avoid placing the charger near hot objects and at high temperature locations and away from dangerous substances such as flammable gases and corrosive materials. CAUTION: Do not put heavy objects on the charger to avoid danger. Consignes De Sécurité Importantes 1.1 Avertissement & Mise En Garde Généraux AVERTISSEMENT : Pour éviter les risques d’incendie, de blessure ou de mort, il faut lire et suivre soigneusement les instructions pendant l’installation, l’utilisation et WARNING & CAUTION WARNING & CAUTION USER MANUAL 4 l’entretien. - Ne mettez pas les doigts dans le connecteur du véhicule électrique. - N'utilisez pas ce produit si le cordon d'alimentation flexible ou le câble EV est effiloché, isolé ou présentant tout autre signe de dommage. - N'utilisez pas ce produit si le boîtier ou le connecteur EV est cassé, fissuré, ouvert ou montre toute autre indication de dommage. Ne retirez pas le couvercle et n'essayez pas d'ouvrir le boîtier en raison du risque de choc électrique. AVERTISSEMENT : Cet appareil doit être surveillé lorsqu'il est utilisé à proximité d'enfants. AVERTISSEMENT : Cet appareil doit être mis à la terre. AVERTISSEMENT : Pour éviter tout risque d'incendie ou de choc électrique, n'utilisez pas cet appareil avec une rallonge électrique.AVERTISSEMENT : L'adéquation de l'utilisation du cordon flexible conformément au code ce, partie i, règle 4-012, doit être déterminée par l'autorité d'inspection locale compétente . AVERTISSEMENT : Pour réduire les risques d'incendie, ne connecter qu'à un circuit protection contre les surintensités des circuits de dérivation conformément à la norme canadienne CSA C22.1-15 Code électrique, partie 1 (Canada) ou NOM-001-SEDE Installations électriques (Mexique) ou ANSI / NFPA 70 National Electrical Code (États-Unis). Tableau Des Options Du Disjoncteur Courant De Sortie (A) 16A 32A 40A 48A Options De Disjoncteur (A) 20A 40A 50A 60A USER MANUAL 5 1.2 Exigence Avant L’installation AVERTISSEMENT : Assurez-vous de co…

Text truncated - open the document above for the full version.

FuzhouUlandpowerTechnologyCO.,LTD 022423-17rev6 CertificationApplicationAttestationStatements Date:August27,2024 AmericanCertificationBody,Inc. 313ParkAvenue Suite300 FallsChurch,VA22046 ToWhomItMayConcern: Statementfor47CFRsection2.911(d)(5)(i) ______FuzhouUlandpowerTechnologyCO.,LTD______certifiesthatasofthedateofthe applicationtheequipmentforwhichauthorizationissoughtisnot“covered”equipment 1 prohibited fromreceivinganequipmentauthorizationpursuanttosection2.903oftheFCCrules. Iftheequipmentforwhichtheapplicantseeksauthorizationisproducedbyanyoftheentities identifiedonthecurrentCoveredList,includingaffiliatesorsubsidiariesofthenamedcompanies,the applicantmustincludeanexplanationonwhytheequipmentisnot“covered”equipment. AdditionalExplanation:<N/A> Statementfor47CFRsection2.911(d)(5)(ii) ____FuzhouUlandpowerTechnologyCO.,LTD_______(“theapplicant”)certifiesthat,asofthedate ofthefilingofthisapplication,theapplicant☐-is/■-isnot identifiedontheCoveredListasanentityproducing“covered”equipment. Thankyou, By:___________________________________JonZhang________ (Signature 2 )(Printname) Title:___________CEO_______________ Company:__FuzhouUlandpowerTechnologyCO.,LTD__Telephone:__+8615375912091_ 1 -TheCommission’sCoveredListispublishedbythePublicSafetyandHomelandSecurityBureauandpostedontheCommission’swebsite.This CoveredList,whichisperiodicallyupdated,identifiesparticularequipment,producedbyparticularentities,thatconstitutes“covered”equipment. https://www.fcc.gov/supplychain/coveredlist. 2 -Lettersmustbeplacedonappropriateletterhead.

FCC US Agent, LLC U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: FCC US Agent, LLC Contact Name: Tim Payne Street Address: 3722 Illinois Avenue City/Province/Zip: Saint Charles, IL, 60174, USA Telephone No: 708-571-3148 Email: [email protected] FRN #: 0033402884 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: 2024-09-02 Signed by (Printed Name/Title): Tim Payne/Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Fuzhou Ulandpower Technology CO., LTD Grantee Code: 2BG8P FRN #: 0035605831 Contact Name: Jon Zhang Street Address: 902, Building 1, Wanfu Center, High tech Zone, Minhou County City/Province/Zip: Fuzhou/Fujian/350108 Telephone No: +86-15375912091 Email: [email protected] FCC ID: 2BG8P-UN1A48 Applicant Signature 1 : Date: 2024-09-02 Signed by (Printed Name/Title): Jon Zhang/CEO 1 - Letters must be placed on appropriate letterhead. The signee for the applicant must be one of the following: Applicant (grantee) contact of record in the FCC’s authorization system, or authorized officers or employee of the applicant (grantee).

Fuzhou Ulandpower Technology CO., LTD 050222-17 Authority to Act as Agent Date: September 13, 2024 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: ______ Intertek Testing Services (Shanghai FTZ) Co., Ltd.______ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: _____ 2024-12-31 _____ By: __________________________ _____Jon Zhang_______ (Signature 1 ) (Print name) Title: _______CEO___________________ On behalf of: ___Fuzhou Ulandpower Technology CO., LTD_____ (Company Name) Telephone: ___+8615375912091_______________ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Fuzhou Ulandpower Technology CO., LTD 050222-17 Request for Confidentiality Date: September 13, 2024 Subject: Confidentiality Request for: _FCC ID: 2BG8P-UN1A48______ Pursuant to FCC 47 CFR 0.457(d) and 0.459 and/or IC RSP-100, Section 12.4, the applicant requests that a part of the subject application(s) be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term --------------------------- External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term --------------------------- Test Setup Photos ☐ Short Term ☐ Permanent * 1 User’s Manual __Fuzhou Ulandpower Technology CO., LTD___ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of __ (specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as short term confidential be withheld from public view until: (specify ISED expiration date / date of marketing) . Sincerely, By: ________ _________Jon Zhang______________ (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

External Photo

Model：UN1-A48 Rated Voltage:240Vac（L1+L2+GND） Rated Power：11.5KW Rated Current：48A Power Frequency：50-60Hz Protection Level:Type3 Ambient Temperature：-30°C~55°C Certified to: UL Std.2594 Certified to: CSA Std.C22.2#280 For use with Electric Vehicles Ventilation Not Required Production Date:24-20 Fuzhou ULANDPOWER Technology Co., Ltd ULANDPOWER FCC ID: 2BG8P-UN1A48 00100114824180000 5030031 Label Location

Internal Photo RFID Antenna Bluetooth Antenna

Fuzhou Ulandpower Technology Co., Ltd. MPE ASSESSMENT REPORT Report Type: FCC MPE assessment report MODEL: UN1-A48 REPORT NUMBER: 2405B2009SHA-003 ISSUE DATE: September 13, 2024 DOCUMENT CONTROL NUMBER: TTRFFCCMPE-01_V1 © 2018 Intertek Intertek Testing Services (Shanghai FTZ) Co., Ltd. Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRFFCCMPE-01_V1© 2018 Intertek Page 2 of 8 Report no.: 2405B2009SHA-003 Applicant: Fuzhou Ulandpower Technology Co., Ltd. 902, Building 1, Wanfu Center, High tech Zone, Minhou County, Fuzhou City, Fujian, China Manufacturer: Fuzhou Ulandpower Technology Co., Ltd. 902, Building 1, Wanfu Center, High tech Zone, Minhou County, Fuzhou City, Fujian, China Factory: Fuzhou Ulandpower Technology Co., Ltd. 902, Building 1, Wanfu Center, High tech Zone, Minhou County, Fuzhou City, Fujian, China FCC ID: 2BG8P-UN1A48 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: KDB447498 D01 General RF Exposure Guidance v06 FCC Part2.1091, FCC Part2.1093 FCC Part1.1307(b) PREPARED BY: REVIEWED BY: Project Engineer Sky Yang Reviewer Eric Li Report No.: 2405B2009SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 3 of 8 Revision History Report No. Version Description Issued Date 2405B2009SHA-003 Rev. 01 Initial issue of report September 13, 2024 Report No.: 2405B2009SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 4 of 8 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test (EUT) Product name: Electric Vehicle Charging Station Type/Model: UN1-A48 Description of EUT: The EUT is an electric vehicle charger with Bluetooth and RFID function. Rating: 240VAC, 50/60Hz, 48A Max Category of EUT: Class A EUT type: Table top Floor standing Software Version: - Hardware Version: - Serial numbers: A240506-38 Sample received date: May 6, 2024 Date of test: May 31, 2024 ~ July 9, 2024 1.2 Technical Specification Frequency Band: 2400MHz ~ 2483.5MHz Support Standards: Bluetooth LE 4.2 Type of Modulation: GFSK Channel Number: 40 Data Rate: 1Mbps, 2Mbps Channel Separation: 2MHz Antenna Information: 2.5dBi, chip Antenna Frequency Range: 13.56 MHz ~ 13.56 MHz Modulation: ASK Antenna gain: PCB antenna Report No.: 2405B2009SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 5 of 8 1.3 Description of Test Facility Name: Intertek Testing Services (Shanghai FTZ) Co., Ltd. Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Telephone: 86 21 61278200 Telefax: 86 21 54262353 The test facility is recognized, certified, or accredited by these organizations: CNAS Accreditation Lab Registration No. CNAS L21189 FCC Accredited Lab Designation Number: CN0175 IC Registration Lab CAB identifier.: CN0014 VCCI Registration Lab Member No.: 3598 (Registration No.: R-14243, G-10845, C-14723, T-12252) A2LA Accreditation Lab Certificate Number: 3309.02 Report No.: 2405B2009SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 6 of 8 2 MPE Assessment Test result: Pass 2.1 MPE Assessment Limit Mobile device exposure for standalone operations: According to§1.1310, the limit for general population/uncontrolled exposures Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm2) Averaging time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f2) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 Note: Limit for 13.56MHz is 60.77 V/m Mobile device exposure for simultaneous transmission operations: the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in a host device is ≤ 1.0 Report No.: 2405B2009SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 7 of 8 2.2 Assessment Results Power density (S) is calculated according to the formula: S = PG / (4πR²) Where S = power density in mW/cm² P = Power in mW G = numeric gain of transmit antenna R = distance (cm) For RFID function, as we can see from the test report 2405B2009SHA-002: 58.3dBuV/m@3m, @20cm=@3m+40log(3/0.2)=105.34dBuV/m=0.185V/m<60.77. For Bluetooth function, as we can see from the test report 2405B2009SHA-001: The calculations in the table below use the highest gain of antenna for client EUT. These calculations represent worst case in terms of the exposure levels. Frequency Range P G R S Limits (MHz) (dBm) (mW) (dBi) (numeric) (cm) (mW/cm2) (mW/cm2) Bluetooth LE(1M) 6.83 4.82 2.5 1.78 20 0.00171 1 Bluetooth LE(2M) 6.77 4.75 2.5 1.78 20 0.00168 1 Note: 1 mW/cm2 from 1.310 Table 1. RFID and Bluetooth can transmit simultaneously, so the maximum rate of MPE is, 0.185/60.77+0.00171/1=0.00475 <1.0. Report No.: 2405B2009SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 8 of 8 Appendix I Definition below must be outlined in the User Manual: To satisfy FCC RF exposure requirements, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during device operation. To ensure compliance, operations at closer than …

Text truncated - open the document above for the full version.

September 2016 Multilayer Antenna For 2400-2484MHz ANT016008LCS2442MA2 1.6x0.8mm [EIA 0603]* * Dimensions Code JIS[EIA] RF Components RF Components • All specifications are subject to change without notice. • Before using these products, be sure to request the delivery specifications. 20160926 / rf_ant_ant016008lcs2442ma2_summary Multilayer Antenna For 2400-2484MHz SHAPES AND DIMENSIONS RECOMMENDED LAND PATTERNSOLDER RESIST PATTERN ANT016008LCS2442MA2 Conformity to RoHS Directive 1.60±0.10 ( 0.1 ) ( 0.1 ) 0.40max. 0.80±0.10 0.63±0.10 0.215± 0.10 0.25± 0.10 0.20± 0.10 Dimensions in mm [Top view] [Bottom view] 1 Radiator electrode 2 Dummy pad 3 Dummy pad 4 Feed point 5 Dummy pad 6 Dummy pad Terminal functions ( 1 ) ( 4 ) ( 5 )( 6 ) ( 2 )( 3 ) Dimensions in mm 0.6 0.9 1.6 0.21 0.73 0.8 Dimensions in mm 0.7 3 0.60 0.90 1.53 0.11 RoHS Directive Compliant Product: See the following for more details.https://product.tdk.com/info/en/environment/rohs/index.html RF Components • All specifications are subject to change without notice. • Before using these products, be sure to request the delivery specifications. 20160926 / rf_ant_ant016008lcs2442ma2_summary ANT016008LCS2442MA2 EVALUATION BOARD Measurement condition for Radiation Pattern PCB size : 50mm x 10mm x 1mm Antenna area : 6 x 2.5 mm Ft-1 Mt 2.0nH(MLG060 3P2N0:TDK) 3.0nH(MLG0603P3N0:TDK) Component P/N Mt ANT016008LCS2442MA2 Ft-1 PCB Z Y X Er θ Eθ Eø ø Chip antenna RF Components • All specifications are subject to change without notice. • Before using these products, be sure to request the delivery specifications. 20160926 / rf_ant_ant016008lcs2442ma2_summary ANT016008LCS2442MA2 ELECTRICAL CHARACTERISTICS This is typical antenna performance with the standard PCB. TEMPERATURE RANGE FREQUENCY CHARACTERISTICS EFFICIENCY AND VSWR • Tested antenna has been soldered. Evaluation board size is 50x10x1 mm. Item Frequency Range (MHz) Min.Typ.Max. VSWR2400 to 2484—1.603.0 PolarizationLinear PCB size (mm)5010 Antenna keep-out area (mm)62.5 Characteristic Impedance ()50 (Nominal) Operating temperatureStorage temperature °C°C –40 to +85–40 to +85 –10 –9 –8 –6 –7 –3 –4 –1 –5 –2 0 Efficiency ( dB ) 1 11 10 9 8 7 6 5 4 3 2 VSWR Frequency ( GHz ) 2.3002.4002.5002.600 Efficiency Spec ( VSWR ) VSWR RF Components • All specifications are subject to change without notice. • Before using these products, be sure to request the delivery specifications. 20160926 / rf_ant_ant016008lcs2442ma2_summary ANT016008LCS2442MA2 RADIATION PATTERNS • Tested antenna has been soldered. Evaluation board size is 50x10x1 mm. 270 ̊90 ̊ 0 ̊ X Y Z 180° 270° 315° 135° 45° 225° 90° 0 –10 10 ( dBi ) –20 –30 –50 –40 0° Vertical polarization Frequency (MHz) Average ( dBi ) Maximum ( dBi ) Minimum ( dBi ) 2400 –16.1 –10.5 –26.9 2442 –16.0 –11.3 –26.5 2484 –16.4 –11.7 –31.9 2400MHz 2442MHz 2484MHz 180° 270° 315° 135° 45° 225° 90° 0 –10 10 ( dBi ) –20 –30 –50 –40 0° Vertical polarization Frequency (MHz) Average ( dBi ) Maximum ( dBi ) Minimum ( dBi ) 2400 –1.4 –0.5 –2.4 2442 –0.8 0.0 –2.1 2484 –1.6 –0.9 –3.0 2400MHz 2442MHz 2484MHz 270° 90° 0° Y X Z 180° 270° 315° 135° 45° 225° 90° 0 –10 10 ( dBi ) –20 –30 –50 –40 0° Vertical polarization Frequency (MHz) Average ( dBi ) Maximum ( dBi ) Minimum ( dBi ) 2400 –4.3 1.6 –21.9 2442 –3.6 2.5 –24.0 2484 –4.2 2.0 –25.5 2400MHz 2442MHz 2484MHz 180° 270° 315° 135° 45° 225° 90° 0 –10 10 ( dBi ) –20 –30 –50 –40 0° Vertical polarization Frequency (MHz) Average ( dBi ) Maximum ( dBi ) Minimum ( dBi ) 2400 –17.5 –11.1 –30.4 2442 –16.8 –10.4 –36.3 2484 –17.0 –10.4 –53.3 2400MHz 2442MHz 2484MHz 270 ̊ 90 ̊ 0 ̊ Y Z X 180° 270° 315° 135° 45° 225° 90° 0 –10 10 ( dBi ) –20 –30 –50 –40 0° Vertical polarization Frequency (MHz) Average ( dBi ) Maximum ( dBi ) Minimum ( dBi ) 2400 –3.9 –0.5 –29.4 2442 –3.3 0.2 –28.7 2484 –4.0 –0.3 –34.7 2400MHz 2442MHz 2484MHz 180° 270° 315° 135° 45° 225° 90° 0 –10 10 ( dBi ) –20 –30 –50 –40 0° Vertical polarization Frequency (MHz) Average ( dBi ) Maximum ( dBi ) Minimum ( dBi ) 2400 –18.7 –14.8 –26.3 2442 –18.6 –15.0 –25.3 2484 –19.8 –16.7 –29.1 2400MHz 2442MHz 2484MHz RF Components • All specifications are subject to change without notice. • Before using these products, be sure to request the delivery specifications. 20160926 / rf_ant_ant016008lcs2442ma2_summary ANT016008LCS2442MA2 RECOMMENDED REFLOW PROFILE SoakingWorkingSoldering Peak Temp.TimeTemp.TimeTemp.TimeTemp. T1T2t1T3t2T4t3T5 150°C180°C60 to 120s230°C30 to 60s247 to 253°Cwithin 10s260°C max. t3 t1 Soaking t2 Working T3T3 T4T4 T5 T2 T1 t: Time Soldering T: Temperature Peak RF Components • All specifications are subject to change without notice. • Before using these products, be sure to request the delivery specifications. 20160926 / rf_ant_ant016008lcs2442ma2_summary ANT016008LCS2442MA2 PACKAGING STYLE REEL DIMENSIONS TAPE DIMENSIONS PACKAGE QUANTITY Dimensions in mm ABCDEFGHJKt 0.97±0.05 1.8±0.058.0±0.23.5±0.05 1.75±0.14.0±0.12.0±0.054.0±0.1 1.5+0.1/-0 0.55max. 0.25±0.05 Standard package quantity (pieces/reel) 4,000 2.0±0.5 ø21±0.8 Dimensions in mm 13.0±1.0 9.0 +1.0 –0.0 ø180 +0 –1.5 ø13±0.2 ø 60 +1.0–0.0 C D t K E H F G J B A Material of carrier the tape: PS RF Components • All specifications are subject to change without notice. • Before using these products, be sure to request the delivery specifications. 20160926 / rf_ant_ant016008lcs2442ma2_summary REMINDERS FOR USING THESE PRODUCTS Before using these products, be sure to request the delivery specifications. SAFETY REMINDERS Please pay sufficient attention to the warnings for safe designing when using these products. The products listed on this catalog are intended for use in general electronic equipment (AV equipment, telecommunications equipment, home appliances, amusement equipment, computer equipment, personal equipment, office equipment, measurement equipment, industrial robots) under a normal operation and use condition. The products are not designed or warranted to meet the requirements of the applications listed…

Text truncated - open the document above for the full version.

Fuzhou Ulandpower Technology Co., Ltd. RF TEST REPORT Report Type: FCC Part 15.247 RF report MODEL: UN1-A48 REPORT NUMBER: 2405B2009SHA-001 ISSUE DATE: September 13, 2024 DOCUMENT CONTROL NUMBER: TTRF15.247-02_V1 © 2018 Intertek Intertek Testing Services (Shanghai FTZ) Co., Ltd. Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRF15.247-02_V1 © 2018 Intertek Page 2 of 55 Report no.: 2405B2009SHA-001 Applicant: Fuzhou Ulandpower Technology Co., Ltd. 902, Building 1, Wanfu Center, High tech Zone, Minhou County, Fuzhou City, Fujian, China Manufacturer: Fuzhou Ulandpower Technology Co., Ltd. 902, Building 1, Wanfu Center, High tech Zone, Minhou County, Fuzhou City, Fujian, China Factory: Fuzhou Ulandpower Technology Co., Ltd. 902, Building 1, Wanfu Center, High tech Zone, Minhou County, Fuzhou City, Fujian, China FCC ID: 2BG8P-UN1A48 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: 47CFR Part 15 (2023): Radio Frequency Devices (Subpart C) ANSI C63.10 (2020): American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices PREPARED BY: REVIEWED BY: Project Engineer Sky Yang Reviewer Eric Li Report No.: 2405B2009SHA-001 TEST REPORT TTRF15.247-02_V1 © 2018 Intertek Page 3 of 55 Content REVISION HISTORY................................................................................................................................................ 5 MEASUREMENT RESULT SUMMARY ..................................................................................................................... 6 1 GENERAL INFORMATION ............................................................................................................................. 7 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ......................................................................................................... 7 1.2 TECHNICAL SPECIFICATION ........................................................................................................................................ 7 1.3 DESCRIPTION OF TEST FACILITY .................................................................................................................................. 8 2 TEST SPECIFICATIONS ..........................................................…

Text truncated - open the document above for the full version.
