2BGDJ-H1smart helmet

Smart Helmet Operating Instructions H1 Quick Start Guide Operation Video Attach the remote to your handlebar. 3 Ride Safe! 4 2 Long press the for 3-5s to turn on the remote controller. “ ” Long press the power button to turn it on 1 Note: This product complies with U.S. CPSC 1203 safety standard. Please use it with confidence. ROHS to operat e the equipment. - -- Reorient or relocat e the rec eiving antenna. Operating Instructions •Open the rubber cover marked " " •Insert USB cable •Light Indicator: 1. Charging 2. Button Instructions ②① Open Power on / off Hold for 3–5 s to power off Voice: “Goodbye” — shut down successfully. Hold for 3–5 s to power on Voice: “Ready for Connection”, taillight flashes — start up successful. � - Red light on → Charging - Red Light turns off → Fully charged (Charge at least 1.5 hours) Indicator Charging Cable (Please charge before use) • •After •Turn o • does . • • •If • 4. Lighting Key Mode (If an abnormal condition occurs, please reset the device) 5. Alarm Alert Mode •How to adjust the headlight modes? Press the light button “ ” on the helmet Mode 1: “ ” Press once, Headlight steady on. Mode 2: “ ” Press once, Fast flashing. Mode 3: “ ” Press once, Slow flashing. Brake sharply, tail center light blinks. Mode 1: Fall, tail left and right lights flash. Mode 2: Right Side Tail Light Left Side Tail Light Helmet Headlight Note: When turning, use the " / " buttons on the remote to flash the left or right lights to alert people and vehicles in front of and behind you. � Helmet Tail Light Tail center light blinks Tail Center Light Left side tail light Tail lights flash left and right Right side tail light Double-press the power button “ ” consecutively. A voice prompt “Voice On / Off” will be played to enable or disable voice prompts. For detailed operation instructions, please refer to the operation video. Press the button five times consecutively to reset. Press and hold for more than 10 seconds to force a restart. •How to adjust the taillight modes? Press the light button “ ” on the helmet Press once, all lights steady on (Working time: 6 hours) Press once, center light flashes rapidly (Working time: 16 hours) Press once, center light flashing slowly (Working time: 28 hours) Press once, all lights off Mode 1: Mode 2: Mode 3: Mode 4: 6. Remote Controller Instructions � Multi-function Button 1. Hold for 3s: Power on/off (Green light on = power on; blinking then off = power off) 2. Press once: Emergency flasher (blinks for 15s with “didi” sound), press again to cancel 3. Press five times consecutively: Reset and automatically connect to the helmet (within 6 meters); voice prompt: “Remote Connected.” Volume + 1. Press once: Increase volume 2. Hold: Next track Volume – 1. Press once: Decrease volume 2. Hold: Previous track Left Turn Signal Press once: Signal left (blinks 15s with “di” sound), press again to cancel Right Turn Signal Press once: Signal right (blinks 15s with “di” sound), press again to cancel within 6M 7. Use, Maintenance, and After-Sales Service (1) Proper Wearing and Use � •Applicable Scenarios: Regular cycling, skateboarding, unicycling, and other common sports where wearing a helmet is required. •Non-Applicable Scenarios: This product is not suitable for extreme sports or other high-speed or high-risk activities. •Proper Helmet Wearing: ① The helmet should be worn level, with the front edge positioned appropriately above the forehead. ② Adjust the head circumference system and chin strap to ensure a secure fit without excessive pressure. ③ The helmet should not move noticeably when shaking your head. ④ Before each ride, please check the helmet shell, retention system, and electronic functions to ensure they are functioning properly. Safety Notice: This helmet has been certified in accordance with EN 1078�2012+A1�2012 and holds CPC certification. It meets the essential health and safety requirements (WGSA of Regulation (EU) 2016/425) as well as the U.S. CPSC safety standard for bicycle helmets for persons aged 5 years and older. However, no helmet can provide complete protection in all accidents. This product is designed to reduce the risk of head injuries but cannot guarantee the prevention of all injuries. (2) Cautions and Warnings •This helmet contains electronic components and provides limited splash resistance. Please do not use it for prolonged riding in rainy conditions. •After exposure to rain, water droplets may appear inside the rear warning light cover. Place the helmet in a well-ventilated area for 1–2 days, and the moisture will dissipate naturally. •This helmet contains a battery. Battery capacity may vary with temperature. When used in low-temperature environments or below 0°C, the operat- ing time may be reduced to varying degrees. •To maintain battery lifespan, if the helmet is to be stored for an extended period (over 3 months), it is recommended to fully charge the helmet before storage and recharge it every 3–6 months. Important Safety Warning: If the helmet experiences a severe impact, fall, or traffic accident during use, internal cushioning materials may be damaged even if no visible damage is present. Protective performance can no longer be guaranteed. Discontinue use immediately and replace the helmet with a new one. (3) Cleaning and Maintenance Instructions � •Store the helmet properly. Clean it with clean water only. Do not use alcohol, gasoline, organic solvents, or corrosive liquids such as acids or alkalis. Avoid impacts to the helmet. •Do not modify the structure of the helmet. Drilling holes in the shell or altering the internal foam liner is strictly prohibited, as this may impair its shock-absorption and penetration-resistance performance. •Under normal use and proper maintenance, the recommended service life of the helmet is 3–5 years. (4) Technical Specifications •Charging Port: Type-C USB •Electrical Rating: DC 5V / 1A •Charging Time: 1.5 hours •Waterproof Rating: IPX45 •Operating Time: Up to approximately 28 h…

Text truncated - open the document above for the full version.

ShenzhenlinkedsafeSportsTechnologyCo.,Ltd. 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE Company name:Shenzhen linkedsafe Sports Technology Co., Ltd. Address:Building C, Room 503, Huafeng Zhihui Innovation Park, Gushu 2nd Road, Gushu Community, Xixiang Street, Bao'an District, Shenzhen. Product Name:Smart Helmet FCC ID:2BGDJ-H1 Model(s):H1 2.911(d)(5)(i) Equipment Type We, [Shenzhen linkedsafe Sports Technology Co., Ltd.] certify that the equipment for which authorization is sought through certification is not: 1 Yourssincerely, Signature: Name:LiuhuomingDate: TitleandCompanyname 2026.4.21 :GeneralMANAGER/ShenzhenlinkedsafeSportsTechnologyCo.,Ltd. NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

ShenzhenlinkedsafeSportsTechnologyCo.,Ltd. 2.911(d)(5)(ii)ApplicantAttestationv1.2 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) 2.911(d)(5)(ii)Applicantfiling We,[ShenzhenlinkedsafeSportsTechnologyCo.,Ltd.]certifythat,asofthedateofthefilingofthe application,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 ,establishedpursuantto §1.50002ofthischapter,asanentityproducingcoveredcommunicationsequipment. Yourssincerely Company name:Shenzhen linkedsafe Sports Technology Co., Ltd. Address:Building C, Room 503, Huafeng Zhihui Innovation Park, Gushu 2nd Road, Gushu Community, Xixiang Street, Bao'an District, Shenzhen. Product Name:Smart Helmet FCCID:2BGDJ-H1 Model(s):H1 , Signature: Name:LiuhuomingDate: TitleandCompanyname:GeneralMANAGER/ShenzhenlinkedsafeSportsTechnologyCo.,Ltd 2026.4.21 . NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

S h enz h en l i n k e d sa f e S p o r t s T ec h no l o gy C o . , L t d . S ec t i o n 2 . 9 1 1 ( d ) ( 7 ) U S A A g e n t f o r S e rv i ce o f P r ocess 2 . 9 1 1 ( d )( 7 ) U S A D e s i g n a t e d A g e n t f o r S e rv i ce o f P r oces C o m p a n y n a m e : S h e n z h e n li n k e d s a f e S p or t s T e c h n o l o g y C o . L t d . A dd r e ss : B u i l d i n g C , R oo m 5 03 , H u a f e n g Z h ih u i I nn o va t i o n P a r k , G u s h u 2 n d R o a d , G u s h u C o mm u n i t y , X i x i a n g S t r ee t , B a o ' a n D i s t r i c t , S h e n z h e n . P r o d u c t N a m e : Smart He l m e t F CC I D : 2 B G D J - H 1 M o d e l ( s ) : H 1 s W e , [ S h en z h en l i n k e d sa f e S p or t s T e c h no l o g y C o , L t d ] ( t h e a pp l i c an t ) d es i g n a t e [ M IR A M O NT SOLU TI ON S LL C ] N O T E I f o r t h e p u r p o s e o f a cce p t i n g s er v i ce o f p r oce ss on b e h a lf o f t h e a pp l i can t . A pp li c a n t c o n se n t : W e a c k now l e d g e our con s en t t o a cce p t s e r v i ce o f p r ocess i n t h e U n i t e d S t a t es f o r m a t t e r s r e l a t e d t o t h e a pp l i c a bl e e q u i p me n t , a n d a t t h e p h y s i c a l U . S . a dd ress a n d e m a i l a dd r ess o f t h e d es i g n a t e d a g e n t a n d ac k n ow l e d g e ou r acce p t ance o f o ur o b l i g a t i o n t o m a i n t a i n a n a g e n t f o r se r v i ce o f p r ocess i n t h e U n i t e d S t a t es f o r no l ess t h an one y ear a f t e r e i t h e r we t h e g r an t ee h ave p er m ane n t l y t e r m i n a t e d a l l m ar k e t i n g an d i m p o r t a l t i o n o f t h e a pp l i c a bl e e q u i p me n t w i t h i n t h e U . S . , or a t t h e co n c l us i o n o f a n y C o m m i ss i on - r e l a t e d a d m i n i s t r a t i v e or j u d i c i a l p r ocee d i n g i n vo l v i n g t h e e q u i p m e n t , w h i c h eve r i s l a t e r . A g e n t o bl i g a t i o n : W e ac k now l e d g e o u r o bl i g a t i o n t o a cc e p t ser v i c e o f p r ocess i n t h e U n i t e d S t a t es f o r m a tt e r s r e l a t e d t o t h e a pp l i c a bl e e q u i p me n t a t o u r p h y s i c a l U . S . a d d r ess an d e m a il a d d r ess f o r no l e ss t h an o n e y ea r a f t e r e i t h e r t h e g r a n t e e h as p e r m a n e n t l y t e r m i n a t e d a l m a r k e t i n g an d i m p or t a t i on o f t h e a pp l i ca b l e e q u i p m e n t w i t h i n t h e U . S . , o r a t t h e conc l u s i on o f an y C o mm i ss i on - r e l a t e d a d m i n i s t r a t i ve o r j u d i c i a l p r oce e d i n g i n v o l v i n g t h e e q u i p m en t , w hi c h e v e r i s l a t e r . 2 . 9 11 ( d ) ( 7 ) U SAA g e n t v 1 . 5 1 / 2

ShenzhenlinkedsafeSportsTechnologyCo.,Ltd. AgentAuthorization WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown Company name:Shenzhen linkedsafe Sports Technology Co., Ltd. Address:Building C, Room 503, Huafeng Zhihui Innovation Park, Gushu 2nd Road, Gushu Community, Xixiang Street, Bao'an District, Shenzhen. Product Name:Smart Helmet Model(s): H1 . Signature: Name: Liuhuoming Title Date: 2026.4.21 : GeneralMANAGER Company: ShenzhenlinkedsafeSportsTechnologyCo.,Ltd.

ShenzhenlinkedsafeSportsTechnologyCo.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date: 2026.4.21 Subject; Request for Confidentiality FCC ID: 2BGDJ-H1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:Liuhuoming Title:GeneralMANAGER

FCCID:2BGDJ-H1

Label location: label size:60*30mm

FCC ID:2BGDJ-H1 Internal Photos of the EUT FCC ID:2BGDJ-H1 FCC ID:2BGDJ-H1 BT&BLE ANT FCC ID:2BGDJ-H1 FCC ID:2BGDJ-H1

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure evaluation Report Reference No. .................... : FCC ID. ........................................... : CTA26041400603 2BGDJ-H1 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Apr. 16, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : Shenzhen linkedsafe Sports Technology Co., Ltd. Address ............................................ : Building C, Room 503, Huafeng Zhihui Innovation Park,Gushu 2nd Road, Gushu Community, Xixiang Street, Bao'an District, Shenzhen, China Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Smart Helmet Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen linkedsafe Sports Technology Co., Ltd. Model/Type reference ...................... : H1 Listed Models ................................... : N/A Rating ............................................... : DC 3.7V From battery and DC 5.0V From external circuit Result ............................................... : PASS Report No.: CTA26041400603 Page 2 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Smart Helmet Model /Type : H1 Listed Models : N/A Applicant : Shenzhen linkedsafe Sports Technology Co., Ltd. Address : Building C, Room 503, Huafeng Zhihui Innovation Park,Gushu 2nd Road, Gushu Community, Xixiang Street, Bao'an District, Shenzhen, China Manufacturer : Shenzhen linkedsafe Sports Technology Co., Ltd. Address : Building C, Room 503, Huafeng Zhihui Innovation Park,Gushu 2nd Road, Gushu Community, Xixiang Street, Bao'an District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26041400603 Page 3 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks ..................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................. 5 2.4 Modifications ............................................................................................................ 5 3 TEST ENVIRONMENT ....................................................................................................... 6 3.1 Address of the test laboratory .................................................................................. 6 3.2 Test Facility .............................................................................................................. 6 3.3 Statement of the measurement uncertainty ............................................................. 6 4 Test limit .............................................................................................................................. 7 4.1 Requirement ............................................................................................................ 7 4.2 Conducted Power Results ....................................................................................... 7 4.3 Manufacturing tolerance .......................................................................................... 8 4.4 Evaluation Result ..................................................................................................... 8 4.5 Simultaneous Transmission for SAR Exclusion ...................................................... 8 5 Conclusion ........................................................................................................................... 8 Report No.: CTA26041400603 Page 4 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an…

Text truncated - open the document above for the full version.

ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 1 APPROVALSHEET OverAir TM SMDAntennaseries RoHSCompliance PN:OA-C15 2.4GHzISMbandantenna ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 2 FEATURES 1.SurfaceMountedDevices(SMD)withasmalldimensionof1.6X0.8X0.8mm 3 meet miniaturizationtrend. 2.Lowpowerlossandhighantennaefficiency. 3.HighstabilityinTemperatureandHumidityChange. APPLICATIONS 1.2.4GHzISMbandRFapplications 2.Bluetooth,ZigBee,Wireless,HomeRF CONSTRUCTION 1 1、AntennaFeeding DIMENSIONS FigureSymbolDimension(mm) L 1.6±0.1 W0.8±0.1 T0.8±0.1 WB0.3±0.1 ELECTRICALCHARACTERISTICS ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 3 OA-C15Specification WorkingFrequencyRange 2450±50MHz BandWidth>100MHz Impedance 50Ω Gain(dBi) 1.54（peak） VSWR<2.5 OperationTemperature -40°C~+85°C PowerCapacity3W Theworkingfrequencyneedbeadjustedto2.45GHzwithmatchingcircuit. SOLDERLANDPATTERNDESIGN Figure ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 4 Top ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 5 Bot Matchingcomponentvalue Series12pF Shunt16.2nH Series20Ω Shunt2NC AntennaonTestBoard(Thickness1.0mm) ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 6 AntennaS11onTestBoard AntennaVSWRonTestBoard ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 7 EfficiencyandRADIATIONPATTERN Efficiency，RadiationPatternandGainweredependentonmeasurementboarddesign.The specificationofOA-C15antennawasmeasuredbasedonthePCBsizeandinstallationpositionas showninthebelowfiguretestboard.ThetestresultsweretestedinETS3DChamber. GainandEfficiency 2Ddirectiondiagram Theta90°@2440Mhz Z Y X ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 8 Phi0°@2440Mhz Phi90°@2440Mhz ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 9 3Ddirectiondiagram SOLDERINGCONDITION Typicalexamplesofsolderingprocessesthatprovidereliablejointswithoutanydamageisas follows: ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 10 PACKAGING PlasticTapespecification(unit:mm) IndexABCDJ Dimension(mm) 1.10 ± 0.101.90 ± 0.108.00 ± 0.103.50 ± 0.051.500/ ± 0.10 IndexEFGHT Dimension(mm) 1.75±0.104.00±0.102.00±0.104.00±0.10 1.10Max ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 11 Reeldimensions IndexABC Dimension(mm)17850 13.5±0.5 TypingQuantity:4000piecesperreel. CAUTIONOFHANDLING Storageenvironmentcondition Productsshoudbestorageinthewarehouseonthefollowingconditions: Temperature:-10°C~+40°C Humidity:30%to70%relativehumidity Don’tkeepproductsincorrosivegasessuchassulfur.Chlorinegasoracidoritmay causeoxidizationofelectrode,resultinginpoorsolderability. Productsshouldbestorageonthepaletteforthepreventionoftheinfluencefrom humidity,dustandsoon. Productsshouldbestorageinthewarehousewithoutheatshock,vibration,direct sunlightandsoon. Productsshouldbestorageundertheairtightpackagedcondition.

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. ........................................... : CTA26041400602 2BGDJ-H1 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Apr. 16, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : Shenzhen linkedsafe Sports Technology Co., Ltd. Address ............................................ : Building C, Room 503, Huafeng Zhihui Innovation Park,Gushu 2nd Road, Gushu Community, Xixiang Street, Bao'an District, Shenzhen, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Smart Helmet Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen linkedsafe Sports Technology Co., Ltd. Model/Type reference ...................... : H1 Listed Models ................................... : N/A Modulation ....................................... : GFSK, Π/4DQPSK, 8DPSK Frequency ........................................ : From 2402MHz to 2480MHz Ratings ............................................. : DC 3.7V From battery and DC 5.0V From external circuit Result ............................................... : PASS Report No.: CTA26041400602 Page 2 of 32 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Smart Helmet Model /Type : H1 Listed Models : N/A Applicant : Shenzhen linkedsafe Sports Technology Co., Ltd. Address : Building C, Room 503, Huafeng Zhihui Innovation Park,Gushu 2nd Road, Gushu Community, Xixiang Street, Bao'an District, Shenzhen, China Manufacturer : Shenzhen linkedsafe Sports Technology Co., Ltd. Address : Building C, Room 503, Huafeng Zhihui Innovation Park,Gushu 2nd Road, Gushu Community, Xixiang Street, Bao'an District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26041400602 Page 3 of 32 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description ........................................................................................................................... 5 2.3 Equipment Under Test ....................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ...................................................................... 5 2.5 EUT configuration .............................................................................................................................. 6 2.6 EUT operation mode ......................................................................................................................... 6 2.7 Block Diagram of Test Setup ............................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) ......................................................................................................... 6 2.9 Modifications ...................................................................................................................................... 6 3 TEST ENVIRONMENT ................................................................................................................................. 7 3.1 Address of the test laboratory ........................................................................................................... 7 3.2 Test Facility........................................................................................................................................ 7 3.3 Environmental conditions ...........…

Text truncated - open the document above for the full version.

1 FCC Appendix RF Test Data for BT FCC ID : 2BGDJ-H1 Company : Shenzhen linkedsafe Sports Technology Co., Ltd. EUT : Smart Helmet Model Number : H1 Report No. : CTA26041400602 Reviewed By : Eric Wang 2 Appendix A: 20dB Emission Bandwidth Test Result TestMode Antenna Freq(MHz) 20dB EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.942 2401.553 2402.495 --- --- 2441 0.948 2440.544 2441.492 --- --- 2480 0.960 2479.547 2480.507 --- --- 2DH5 Ant1 2402 1.335 2401.343 2402.678 --- --- 2441 1.290 2440.376 2441.666 --- --- 2480 1.332 2479.349 2480.681 --- --- 3DH5 Ant1 2402 1.320 2401.355 2402.675 --- --- 2441 1.326 2440.352 2441.678 --- --- 2480 1.311 2479.358 2480.669 --- --- 3 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 4 2DH5_Ant1_2402 2DH5_Ant1_2441 5 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 6 3DH5_Ant1_2480 7 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.86367 2401.5811 2402.4448 --- --- 2441 0.85876 2440.5834 2441.4422 --- --- 2480 0.85697 …

Text truncated - open the document above for the full version.
