2BGFS-STR-FP-LED01Floor Lamp

Glass Display Shelf Floor Lamp User Manual Assembly Steps Package Content 1. Assemble the Bottom Board (1) Holding the Bottom Board(A) upside-down, insert 4 Screws(D) through each of the 4 corner holes. (2) Insert 4 Poles(C) onto the exposed part of 4 screws and tighten with screwdriver. (3) Align the hole slot and attach Cushion (F) to the bottom of the base plate. (4) Screw 4 Bolts(E)into each hole of 4 corners. 2. Assemble 4 Glass Shelves Please Note: Make sure the LED is facing down and the female receptor is on the right side. (1) Place Glass Shelf(B) onto the protruding bolts, then screw 4 Poles(C) onto protruding bolts tightly. (2) Assemble the middle glass shelves according to the previous method. (3) Place the top glass shelf onto poles and insert 4 Screws(D) through holes in the corners and tighten with screwdriver. 3. Connect Power (1) Plug in the Power Cord(G) into the LED Module. (2) Turn clockwise to connect the male and female connector and then plug the Power adapter (H) into outlet to get power. (3) You can use the Remote (I) or APP control to turn on the lamp. H G Assembly Instruction Video If you have any problems, feel free to contact us via amazon message with your order number or contact us via email: [email protected] A.Bottom Board 1 PCS4 PCS16 PCS8 PCS12 PCS 4 PCS1 PCS1 PCS1 PCS F.CushionGPower CordHPower AdapterIRemote B.Glass ShelfC.PoleD.ScrewE.Bolt C E D A F Bottom Board Bolt Cushion Pole Screw C G D B Pole Screw Glass Shelf Power Cord C G D B Pole Screw Glass Shelf Power Cord Power Cord Power Adapter C G D B Pole Power Cord Glass Shelf Screw B Glass Shelf Customer Service Remote APP Control Introduction APP Control Remote Control Please scan the QR code to download the APP 1. My Device First of all, the use of all the functions of the App requires the authorization of the relevant mobile phone system authority, and the consent to open the App can use all the functions of the App normally. Device list, showing the searched device,highlighted when connected. Connection status, click to connect /disconnect the device. Light switch button, in the connected state, click the light on / off. Set the button, click to jump to the settingpage Switch over the device list display mode Add the device / group / virtual device entry 2. Device Function 3. Settings 2.1 Adjust You can switch the color of the device by sliding the color disk or clicking on the color block Design a good combination of speed and brightness Support setting time on and time off Modify the device name and creating groups 2.2 Mode2.3 Schedule2.4 Device Editing Device connection state, including unconnected / empty(representing connected) Color disk option, click to switch between warm and cold light Color block, used to change the device color Color switch Brightness adjustment, sliding can set the brightness of the device Switch, used for turning the lights on / off Auto add devices. After checking it off, the APP will automatically search for nearby devices and add them to my device list Connect Auto Connect: After checking, it will automatically connect to my device list of devices Remember Connect State: When checked, the most recently connected device is automatically connected Manually Connect: after checking, you need to manually click on the correspond- ing device to connect Other Change Background: you can customize the APP background map Multi-language: you can switch to the APP language and follow the mobile phone system by default Share the APP: Download the QR code for the same series of APP Mode list, click to switch Speed adjustment, sliding can set the transformation speed of the mode Brightness adjustment, sliding to set the brightness of the light Switch Time selection Repeat, can set Monday to Sunday any time, support multiple selection Note: The APP will not save the timing time. After connecting the device, it will automatically read from the device Modify the device icon and name Create groups, a similar type of devices support creating groups, you can control multiple devices simultaneously Remove the device from my device list Brightness increase On/Off1 hour Timing Dimness 4000K100% brightness Cool Tone Warm Tone Cycle Mode 2700K/3000K/4000K/5000K/6000K Night Mode(2700K, 10% brightness) Nursery Mode(4000K, 50% brightness) Work Mode(2700K, 100% brightness) Study Mode(6000K, 100% brightness) Please use 1.5V AAA batteries, not included FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment compli…

Text truncated - open the document above for the full version.

Shenzhen Senter Ecommerce Co. Ltd Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 8/11/2024 U.S. Agent Designation Sh enzhen Senter Ecommerce Co. Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BGFS-STR-FP-LED01): Name and company of U.S. agent: FCC US Agent, LLC Physical U.S. address of agent: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN of U.S. agent: 0033402884 Email address of U.S. agent: [email protected] FCC US Agent, LLC acknowledges their obligation to accept service of process on behalf of Shenzhen Senter Ecommerce Co. Ltd. Shenzhen Senter Ecommerce Co. Ltd with the FRN 0035433309 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Since rely, Signature Yang Fang Ye Manager Shenzhen Senter Ecommerce Co. Ltd Signature Tim Payne Manager FCC US Agent, LLC 48_[model] US_Agent_2.911(d)(7)-U, V05

Covered Equipment Identification Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows: We, applicant Company Name: Shenzhen Senter Ecommerce Co., Ltd Address: 3B11B, Building 5, Zone A, Baoan Internet Industry Base, Oyster Industry Community, Xixiang Street, Baoan District, Shenzhen 518102, China Phone: +86-18775698353 certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-11 Signature Date Printed Name of Signee / Title: Yang Fang Ye / Manager Company: Shenzhen Senter Ecommerce Co., Ltd Address: 3B11B, Building 5, Zone A, Baoan Internet Industry Base, Oyster Industry Community, Xixiang Street, Baoan District, Shenzhen 518102, China Phone: +86-18775698353 Fax: +86-18775698353 Email: [email protected]

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2BGFS-STR-FP-LED01 STR-FP-LED01, STR-FP-LED02, STR-FP-LED03, STR-FP-LED04, STR-FP-LED05, STR-FP-LED06, STR-FP-LED07, STR-FP-LED08, STR-FP-LED09, STR-FP-LED10, STR-FP-LED11, STR-FP-LED12, STR-FP-LED13, STR-FP-LED14, STR-FP-LED15, STR-FP-LED16, STR-FP-LED17, STR-FP-LED18, STR-FP-LED19, STR-FP-LED20, STR-FP-LED21, STR-FP-LED22, STR-FP-LED23, STR-FP-LED24, STR-FP-LED25, STR-FP-LED26, STR-FP-LED27, STR-FP-LED28, STR-FP-LED29, STR-FP-LED30, STR-FP-LED31, STR-FP-LED32, STR-FP-LED33, STR-FP-LED34, STR-FP-LED35, STR-FP-LED36, STR-FP-LED37, STR-FP-LED38, STR-FP-LED39, STR-FP-LED40, STR-FP-LED41, STR-FP-LED42, STR-FP-LED43, STR-FP-LED44, STR-FP-LED45, STR-FP-LED46, STR-FP-LED47, STR-FP-LED48, STR-FP-LED49, STR-FP-LED50 We, applicant Company Name: Shenzhen Senter Ecommerce Co., Ltd Address: 3B11B, Building 5, Zone A, Baoan Internet Industry Base, Oyster Industry Community, Xixiang Street, Baoan District, Shenzhen 518102, China Phone: +86-18775698353 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-11 Signature Date Printed Name of Signee / Title: Yang Fang Ye / Manager Company: Shenzhen Senter Ecommerce Co., Ltd Address: 3B11B, Building 5, Zone A, Baoan Internet Industry Base, Oyster Industry Community, Xixiang Street, Baoan District, Shenzhen 518102, China Phone: +86-18775698353 Fax: +86-18775698353 Email: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2BGFS-STR-FP-LED01 STR-FP-LED01, STR-FP-LED02, STR-FP-LED03, STR-FP-LED04, STR-FP-LED05, STR-FP-LED06, STR-FP-LED07, STR-FP-LED08, STR-FP-LED09, STR-FP-LED10, STR-FP-LED11, STR-FP-LED12, STR-FP-LED13, STR-FP-LED14, STR-FP-LED15, STR-FP-LED16, STR-FP-LED17, STR-FP-LED18, STR-FP-LED19, STR-FP-LED20, STR-FP-LED21, STR-FP-LED22, STR-FP-LED23, STR-FP-LED24, STR-FP-LED25, STR-FP-LED26, STR-FP-LED27, STR-FP-LED28, STR-FP-LED29, STR-FP-LED30, STR-FP-LED31, STR-FP-LED32, STR-FP-LED33, STR-FP-LED34, STR-FP-LED35, STR-FP-LED36, STR-FP-LED37, STR-FP-LED38, STR-FP-LED39, STR-FP-LED40, STR-FP-LED41, STR-FP-LED42, STR-FP-LED43, STR-FP-LED44, STR-FP-LED45, STR-FP-LED46, STR-FP-LED47, STR-FP-LED48, STR-FP-LED49, STR-FP-LED50 For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Parts Lists • the Tune Up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-11 Signature Date Printed Name of Signee / Title: Yang Fang Ye / Manager Company: Shenzhen Senter Ecommerce Co., Ltd Address: 3B11B, Building 5, Zone A, Baoan Internet Industry Base, Oyster Industry Community, Xixiang Street, Baoan District, Shenzhen 518102, China Phone: +86-18775698353 Fax: +86-18775698353 Email: [email protected]

Shenzhen Senter Ecommerce Co., Ltd 3B11B, Building 5, Zone A, Baoan Internet Industry Base, Oyster Industry Community, Xixiang Street, Baoan District, Shenzhen 518102, China Date: August 11, 2024 FCC ID: 2BGFS-STR-FP-LED01 Model Number: STR-FP-LED01, STR-FP-LED02, STR-FP-LED03, STR-FP-LED04, STR-FP-LED05, STR-FP-LED06, STR-FP-LED07, STR-FP-LED08, STR-FP-LED09, STR-FP-LED10, STR-FP-LED11, STR-FP-LED12, STR-FP-LED13, STR-FP-LED14, STR-FP-LED15, STR-FP-LED16, STR-FP-LED17, STR-FP-LED18, STR-FP-LED19, STR-FP-LED20, STR-FP-LED21, STR-FP-LED22, STR-FP-LED23, STR-FP-LED24, STR-FP-LED25, STR-FP-LED26, STR-FP-LED27, STR-FP-LED28, STR-FP-LED29, STR-FP-LED30, STR-FP-LED31, STR-FP-LED32, STR-FP-LED33, STR-FP-LED34, STR-FP-LED35, STR-FP-LED36, STR-FP-LED37, STR-FP-LED38, STR-FP-LED39, STR-FP-LED40, STR-FP-LED41, STR-FP-LED42, STR-FP-LED43, STR-FP-LED44, STR-FP-LED45, STR-FP-LED46, STR-FP-LED47, STR-FP-LED48, STR-FP-LED49, STR-FP-LED50 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Shenzhen Senter Ecommerce Co., Ltd hereby declare that our product (Floor Lamp) Model Number: STR-FP-LED01, STR-FP-LED02, STR-FP-LED03, STR-FP-LED04, STR-FP-LED05, STR-FP-LED06, STR-FP-LED07, STR-FP-LED08, STR-FP-LED09, STR-FP-LED10, STR-FP-LED11, STR-FP-LED12, STR-FP-LED13, STR-FP-LED14, STR-FP-LED15, STR-FP-LED16, STR-FP-LED17, STR-FP-LED18, STR-FP-LED19, STR-FP-LED20, STR-FP-LED21, STR-FP-LED22, STR-FP-LED23, STR-FP-LED24, STR-FP-LED25, STR-FP-LED26, STR-FP-LED27, STR-FP-LED28, STR-FP-LED29, STR-FP-LED30, STR-FP-LED31, STR-FP-LED32, STR-FP-LED33, STR-FP-LED34, STR-FP-LED35, STR-FP-LED36, STR-FP-LED37, STR-FP-LED38, STR-FP-LED39, STR-FP-LED40, STR-FP-LED41, STR-FP-LED42, STR-FP-LED43, STR-FP-LED44, STR-FP-LED45, STR-FP-LED46, STR-FP-LED47, STR-FP-LED48, STR-FP-LED49, STR-FP-LED50 board, Schematic, Hardware version, Software version, structure and internal photos are same, named and appearance differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Shenzhen Senter Ecommerce Co., Ltd 3B11B, Building 5, Zone A, Baoan Internet Industry Base, Oyster Industry Community, Xixiang Street, Baoan District, Shenzhen 518102, China Sincerely, (Signed) Name / Title: Yang Fang Ye / Manager Company: Shenzhen Senter Ecommerce Co., Ltd Address: 3B11B, Building 5, Zone A, Baoan Internet Industry Base, Oyster Industry Community, Xixiang Street, Baoan District, Shenzhen 518102, China Phone: +86-18775698353 Fax Number: +86-18775698353 E-Mail: [email protected]

Page 1 of 1 FCC ID:2BGFS-STR-FP-LED01 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L3.0cm x 1.0cm) Label Location Floor Lamp Model: STR-FP-LED01 FCC ID:2BGFS-STR-FP-LED01

Page 1 of 2 FCC ID:2BGFS-STR-FP-LED01 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 2 FCC ID:2BGFS-STR-FP-LED01 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 BT ANT

Page 1 of 4 FCC ID:2BGFS-STR-FP-LED01 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Maximum Permissible Exposure Report 1. Product Information FCC ID : 2BGFS-STR-FP-LED01 EUT : Floor Lamp Test Model : STR-FP-LED01 Additional Model No. : STR-FP-LED02, STR-FP-LED03, STR-FP-LED04, STR-FP-LED05, STR-FP-LED06, STR-FP-LED07, STR-FP-LED08, STR-FP-LED09, STR-FP-LED10, STR-FP-LED11, STR-FP-LED12, STR-FP-LED13, STR-FP-LED14, STR-FP-LED15, STR-FP-LED16, STR-FP-LED17, STR-FP-LED18, STR-FP-LED19, STR-FP-LED20, STR-FP-LED21, STR-FP-LED22, STR-FP-LED23, STR-FP-LED24, STR-FP-LED25, STR-FP-LED26, STR-FP-LED27, STR-FP-LED28, STR-FP-LED29, STR-FP-LED30, STR-FP-LED31, STR-FP-LED32, STR-FP-LED33, STR-FP-LED34, STR-FP-LED35, STR-FP-LED36, STR-FP-LED37, STR-FP-LED38, STR-FP-LED39, STR-FP-LED40, STR-FP-LED41, STR-FP-LED42, STR-FP-LED43, STR-FP-LED44, STR-FP-LED45, STR-FP-LED46, STR-FP-LED47, STR-FP-LED48, STR-FP-LED49, STR-FP-LED50 Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power Supply : For Adapter: Input:120V~, 50/60Hz, 0.6A Output: 24V1250mA, 30W Hardware Version : / Software Version : / Bluetooth : Frequency Range : 2402MHz-2480MHz Channel Number : 40 channels for Bluetooth V5.2 (DTS) Channel Spacing : 2MHz for Bluetooth V5.2 (DTS) Modulation Type : GFSK for Bluetooth V5.2 (DTS) Bluetooth Version : V5.2 Antenna Description : PCB Antenna, 0dBi(Max.) Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Mobile Device Page 2 of 4 FCC ID:2BGFS-STR-FP-LED01 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Uncontrolled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density Page 3 of 4 FCC ID:2BGFS-STR-FP-LED01 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information EUT can only use antennas certificated as follows provided by manufacturer; Internal/External Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Notes Antenna PCB Antenna 2400-2500 MHz 0dBi Bluetooth Antenna 6. Conducted Power <BLE> Mode Channel Frequency (MHz) Peak Conducted O…

Text truncated - open the document above for the full version.

Antenna describe 1. Antenna describe: Antenna plate PCB ANTENNA Make name/model name PDT-002 Antenna gain 0dBi Frequency range 2.4GHZ-2.483GHZ Connector type direct Manufacturer Name: DONGGUANG XIAOKE INDUSTRLES.CO.,LTD Manufacture Address: NO. 227, DONGCHENG SECTION, GUANDONG ROAD, DONGCHENG STREET, DONGGUAN CITY,CHINA 2.External view drawing: Picture of antenna Antenna Dimensions L1 2.15 mm L2 1.20 mm W1 0.35 mm W2 0.35 mm D1 1.25 mm D1 1.25 mm D2 1.65 mm D3 0.50 mm 3.Antenna Radiation Pattern
