2BGFSSTR-HV-O01Smart Bathroom Fan With Light

Please SCAN the QR code to watch the installation video. SCAN the QR code to Download CINOTON APP. Questions or Support? Email: [email protected] Table of Contents Safety Information02 04 Accessory Drawing05 Before Installation06 Installation With Adjustable Bracket07 Remote Control Instructions12 Installation Without Adjustable Bracket10 How to Download CINOTON APP13 How to Connect Smart Bathroom Fan to CINOTON APP14 How to Connect Smart Bathroom Fan to Alexa15 How to Connect Smart Bathroom Fan to Google Assistant 16 Common Problems and Solutions17 18How to Troubleshoot the Connection Problem 19Customer Service Safety Information READ AND SAVE THESE INSTRUCTIONS 02 Power Disconnection: Always disconnect the power supply before servicing the fan, motor, or junction box to ensure safety. Compliance with Codes and Regulations: Adhere to all applicable local building, safety, and electrical codes, as well as the National Electrical Code (NEC) and Occupational Safety and Health Act (OSHA) requirements. The electrical service supply must be 100-240V, 60Hz. Grounding Connection: This product must be properly connected to the grounding conductor of the supply circuit to ensure safe operation. Power Wire Handling: Avoid bending or kinking the power wires during installation or maintenance. Control Device Restrictions: Apart from the included remote control, this exhaust fan must not be used with any solid-state control devices, including but not limited to other remote controls, dimmer switches, or certain timers. Please note that mechanical timers are not subject to this restriction, as they are not considered solid-state devices. Ceiling Insulation Limitation: Do not install this fan in ceilings with insulation exceeding an R50 rating. Ductwork Installation: Ductwork must be installed in a straight line with minimal bends to ensure optimal performance. Ductwork Sizing: The ductwork size must match the discharge size of the fan and must not be reduced. Reducing the duct size may result 1. 2. 3. 4. 5. 6. 7. 8. 9. Gentle Reminder: 03 WARNING: or injury to persons, observe the following: Check the appliance regularly and refer to TROUBLESHOOTING or contact our customer support if it shows any of the following signs: - Components or parts are damaged. - Loud noise or unusualsmel. For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors. Not for use in cooking areas. To reduce the risk of injury to persons, install Intended Use: This unit must be used only in the manner intended by the manufacturer. For any questions or concerns, please contact CINOTON customer service. Power Disconnection for Servicing or Cleaning: Before servicing or cleaning the unit, please power off at the service panel and lock the service disconnecting device to prevent accidental power restoration. If the service disconnecting device cannot be locked, securely attach a prominent warning device, such as a tag onto the service panel. All installation work and electrical wiring must fuel-burning equipment to prevent backdrafting. Follow the Guidelines: Adhere to the heating equipment manufacturer' s guidelines and safety standards, such as those published by the National Fire Protection Association (NFPA), the American Society for Heating, Refrigeration, and Air Conditioning Engineers (ASHRAE), and local code authorities. Cutting or Drilling Precautions: When cutting or drilling into walls or ceilings, take care to avoid damaging electrical wiring and other hidden utilities. Ducted fans must always be vented to the outdoors to ensure proper operation and safety. Installation Over Tubs or Showers: If this unit is installed over a tub or shower, it must be explicitly marked as suitable for such applications and connected to a Ground Fault Circuit Interrupter (GFCI)-protected branch circuit. 1. 2. 3. 4. 5. 6. 7. 8. Typical Installation 04 energy use of the fan. Use the shortest, straightest duct routing possible for best performance, and avoid installing the fan with smaller ducts than recommended. Insulation around the ducts can reduce energy loss and inhibit mold growth. Fans installed with existing ducts may not achieve their 2-3 feet straight run before the elbow WARNING: Wiring must comply with all applicable electrical codes. Turn OFF power before removing or installing connectors. WARNING: COPPER TO COPPER ONLY. Do not use Aluminum wire. Model No. Wattage of Fan Main light Bluetooth Speaker CCT: Voltage Wattage of Light Sound Output STR-HV-001 27W 1600Im Max.5W 2700-6500K+RGB 100V - 240V,60 Hz 23W 30-160 CFM 0.8 Sones Duct Diameter6 in 11.81 in. (L) x 11.02 in. (W). (30cm x28cm) If you have access to the attic, then you can vent a ceiling mounted exhaust fan through either a gable wall or the roof. Letting the fan exhaust into an open attic will cause moisture buildup on the underside of the roof. Avoid will exhaust out the duct and enter back into the attic WARNING Accessory Drawing 05 User Manual Quick Start Guide Fan housing × 1 Smart Bathroom Fan Light × 1 Flex bracket × 1 Drywall cutout template × 15 FT Duct × 1 Duct Clamp × 1 Joist screws × 4 Wire Connector × 1 Wall-mounted screw × 2 Remote Control Holder Anchors × 2 Remote Control TOOLS NEEDED(NOT INCLUDED) Before Installation 06 Essential Tools for a Successful Installation: Ladder Electrical tape Claw hammer Drill bits Flathead screwdriver Phillips head screwdriver Utility knife Electric drill Duct tape Goggles Gloves Pliers 07 Installation With Adjustable Bracket To prevent possible electrical shock, before installing the fan, disconnecting the power by removing fuses or turning off the circuit breakers to the outlet box associated with the wall switch location. Step 1: Insert the fan housing Carefully place the fan housing into the ceiling opening from below. Position it securely inside the ceiling, ensuring that the designated placement area on the side is properly aligned. Refer to the illustration for guidance…
