2BGGP-W09Wireless charging car mount

Page 1 Home page Car wireless charger "W09 Instruction Manual" Thank you for choosing this product. In order to bring you a better experience, please read this manual carefully before operating! Page 2 Function description/Interface diagram ■ Function description * Support mobile phone 5W/7.5W/10W/15W wireless charging * Support Magsafg magnetic function * Mobile phone stand function ■ Interface diagram 1. Wireless charging area 2. Type-C power supply port 3. Cd-pattern decoration 4. nut Page 3 Instructions for use ■ Instructions for use 1. Put the ball head into the nut and lock it, fix the air outlet clamp to the air outlet blade, and rotate the nut to tighten and fix firmly. 2. Insert the USB end of the power cable into the USB power port on the car, and insert the other end into the Type-C port of the wireless charger. When the blue light in the center area of the wireless charging panel is on, the connection is complete. 3. Put the mobile phone with wireless charging function on the wireless charging panel to charge the mobile phone wirelessly, and the charging status will be displayed on the mobile phone during the charging process (Note: the mobile phone needs to have magnetic absorption and wireless charging functions, and the magnet sheet installed separately on the back of the mobile phone needs to support wireless charging function). ■ Note: Wireless charging Type-C power supply try to choose a power supply with QC charging protocol, so that the charging efficiency of wireless charging is better. Page 4 Specifications/Precautions ■ Specifications Product name: Car wireless charge Product model: W09 Product material: ABS+PC/ hardware Product size: 110.2mm*60mm*30.12mm Net weight: about 115g Product color: Black Input voltage: 5V/2A; 9V/2A; 12V/2A Output power: 5W/7.5W/10W/15W ■ Precautions 1. If used in the car, please plug in the device after the car engine starts to charge! 2. Please do not use this product in humid environment and thunderstorm weather! 3. Please do not allow children to plug and play with products and charging cables! 4. Exceeding the product input voltage range will lead to product abnormality and damage! 5. If not used for a long time, please pull out the product and place it! 6. Do not use this product in areas with high voltage lines and strong magnetic fields! 7. Avoid collision. Do not scratch the surface of the product with sharp objects to avoid surface damage. 8. Do not let water or other liquid flow into the product, otherwise it will cause damage to the product, do not disassemble the product! Page 5 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 15cm between the radiator & your body.

Shenzhen Anqi Electronic Commerce Co., Ltd Covered Equipment Certification Attestation Letter 6/12/2024 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2BGGP-W09 Shenzhen Anqi E-Commerce Co., Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Shenzhen Anqi E-Commerce Co., Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Luo Xiangqun Title: CEO Company Name: Shenzhen Anqi Electronic Commerce Co., Ltd Date: 6/12/2024

Shenzhen Anqi Electronic Commerce Co., Ltd 2515, Building 4, Hongfa Center Building, Xin'an Street Bao'an District, Shenzhen, 518000 China Date: June 12, 2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BGGP-W09 FRN: 0035434398 US Agent – Attestation Statement / Part 2.911(d)(7) Shenzhen Anqi Electronic Commerce Co., Ltd certifies, that as of [June 12, 2024], we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2BGGP- W09. Shenzhen Anqi Electronic Commerce Co., Ltd, accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Shenzhen Anqi Electronic Commerce Co., Ltd for FCC ID: 2BGGP-W09. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company:Shenzhen Anqi E-Commerce Co., Ltd Designated Agent: FCC US Agent, LLC Company Representative: Luo Xiangqun Designated Agent Representative: Tim Payne Signature: Signature: Shenzhen Anqi Electronic Commerce Co., Ltd

June 12, 2024 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BGGP-W09 Product Name: Wireless charging car mount Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name Luo Xiangqun Position CEO Company Name Shenzhen Anqi E-Commerce Co., Ltd Address 2515, Building 4, Hongfa Center Building, Xin'an Street, Bao'an District, Shenzhen, China Tel +86 18219442192 Fax / Email [email protected]

June 12, 2024 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Alpha Product Testing Co., Ltd. Address: Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Person: Mark Zhu (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Shenzhen Anqi Electronic Commerce Co., Ltd Address: 2515, Building 4, Hongfa Center Building, Xin'an Street, Bao'an District, Shenzhen, China. ( applicant name and address). Signature: Name Luo Xiangqun Position CEO Company Name Shenzhen Anqi E-Commerce Co., Ltd Address 2515, Building 4, Hongfa Center Building, Xin'an Street, Bao'an District, Shenzhen, China Tel +86 18219442192 Fax / Email [email protected]

FCC ID: 2BGGP-W09 FCC ID: 2BGGP-W09 FCC ID: 2BGGP-W09 FCC ID: 2BGGP-W09

4.5cm 2.5cm Label Location FCC ID: 2BGGP-W09 Shenzhen Anqi E-Commerce Co., Ltd Product name: Wireless charging car mount Model No.: W09 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2BGGP-W09 FCC ID: 2BGGP-W09 ANT FCC ID: 2BGGP-W09 FCC ID: 2BGGP-W09 FCC ID: 2BGGP-W09

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008300895 Website: http://www.a-lab.cn/certificate FCC TEST REPORT FCC ID: 2BGGP-W09 On Behalf of Shenzhen Anqi Electronic Commerce Co., Ltd Wireless charging car mount Model No.:W09 Prepared for : Shenzhen Anqi Electronic Commerce Co., Ltd Address : 2515, Building 4, Hongfa Center Building, Xin’an Street, Bao’an District, Shenzhen, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2405024-C01-R02 Date of Receipt : May 14, 2024 Date of Test : May 14, 2024 – May 29, 2024 Date of Report : May 29, 2024 Version Number : V0 Test Result : Pass Page 2 of 18 Report No.: A2405024-C01-R02 TABLE OF CONTENTS Description Page 1 Test Result Summary ................................................................................................................................ 5 2 EUT Description ......................................................................................................................................... 6 2.1 Description of Device (EUT) ................................................................................................................ 6 2.2 Accessories of Device (EUT) .............................................................................................................. 7 2.3 Tested Supporting System Details ...................................................................................................... 7 2.4 Block Diagram of Connection between EUT and Simulators.............................................................. 7 2.5 Description of Test Modes................................................................................................................... 7 2.6 Test Conditions ................................................................................................................................... 7 2.7 Test Facility ......................................................................................................................................... 9 2.8 Measurement Uncertainty ................................................................................................................... 9 3 Test Results and Measurement Data ..................................................................................................... 10 3.1 RF Exposure Test ............................................................................................................................. 10 3.1.1 Test Specification .......................................................................................................................... 10 3.1.2 Test Instruments ........................................................................................................................... 11 3.1.3 Test data ....................................................................................................................................... 11 5 Photographs of EUT ................................................................................................................................ 18 Page 3 of 18 Report No.: A2405024-C01-R02 TEST REPORT DECLARATION Applicant : Shenzhen Anqi Electronic Commerce Co., Ltd Address : 2515, Building 4, Hongfa Center Building, Xin’an Street, Bao’an District, Shenzhen, China Manufacturer : Shenzhen Anqi Electronic Commerce Co., Ltd Address : 2515, Building 4, Hongfa Center Building, Xin’an Street, Bao’an District, Shenzhen, China EUT Description : Wireless charging car mount (A) Model No. : W09 (B) Trademark : N/A Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness test. Also, this report shows that the EUT is technically compliant with the KDB 680106 D01 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Yannis Wen Project Engineer Approved by (name + signature).......: Jack Xu Project Manager Date of issue...... .......................: May 29, 2024 Page 4 of 18 Report No.: A2405024-C01-R02 Revision History Revision Issue Date Revisions Revised By V0 May 29, 2024 Initial released Issue Yannis Wen Page 5 of 18 Report No.: A2405024-C01-R02 1 Test Result Summary Requirement CFR 47 Section Result RF EXPOSURE §1.1307(b)(1) & KDB680106 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Page 6 of 18 Report No.: A2405024-C01-R02 2 EUT Description 2.1 Description of Device (EUT) EUT Name : Wireless charging car mount Model No. : W09 DIFF. : N/A Power supply : DC 5V/9V/12V from adapter EUT information : Type-C Input: 5V2A, 9V2A, 12V2A Wireless Output: 5W/7.5W/10W/15W Operation frequency : 115~205KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi (This value is supplied by applicant). Software version : V1.0 Hardware version : V1.0 Connector cable loss : Max. coaxial cable loss:0.5dB (Cable loss value is provided by applicant.) Intend use environment : Residential, commercial and light industrial environment Page 7 of 18 Report No.: A…

Text truncated - open the document above for the full version.

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008-3008-95 Website: http://www.a-lab.cn FCC TEST REPORT FCC ID: 2BGGP-W09 On Behalf of Shenzhen Anqi Electronic Commerce Co., Ltd Wireless charging car mount Model No.: W09 Prepared for : Shenzhen Anqi Electronic Commerce Co., Ltd Address : 2515, Building 4, Hongfa Center Building, Xin’an Street, Bao’an District, Shenzhen, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2405024-C01-R01 Date of Receipt : May 14, 2024 Date of Test : May 14, 2024 – May 29, 2024 Date of Report : May 29, 2024 Version Number : V0 Test Result : Pass Page 2 of 34 Report No.: A2405024-C01-R01 TABLE OF CONTENTS Description Page 1. Test Result Summary ............................................................................................................................... 5 2. General Information .................................................................................................................................. 6 2.1. Description of Device (EUT) ............................................................................................................. 6 2.2. Accessories of Device (EUT) ............................................................................................................ 7 2.3. Tested Supporting System Details ................................................................................................... 7 2.4. Block Diagram of Connection between EUT and Simulators ........................................................... 7 2.5. Description of Test Modes ................................................................................................................ 7 2.6. Test Conditions ................................................................................................................................. 7 2.7. Test Facility ....................................................................................................................................... 8 2.8. Measurement Uncertainty................................................................................................................. 8 2.9. Test Equipment List .......................................................................................................................... 9 3. Test Results and Measurement Data .................................................................................................... 10 3.1. Conducted Emission ....................................................................................................................... 10 3.1.1. Test Specification ............................................................................................................... 10 3.1.2. Test Data ............................................................................................................................ 11 3.2. Radiated Spurious Emission Measurement ................................................................................... 14 3.2.1. Test Specification ............................................................................................................... 14 3.2.2. Test Data ............................................................................................................................ 17 3.3. Test Specification ........................................................................................................................... 23 3.3.1. Test Data ............................................................................................................................ 24 4. Photos of Test Setup .............................................................................................................................. 25 5. Photographs of EUT ............................................................................................................................... 27 Page 3 of 34 Report No.: A2405024-C01-R01 TEST REPORT DECLARATION Applicant : Shenzhen Anqi Electronic Commerce Co., Ltd Address : 2515, Building 4, Hongfa Center Building, Xin’an Street, Bao’an District, Shenzhen, China Manufacturer : Shenzhen Anqi Electronic Commerce Co., Ltd Address : 2515, Building 4, Hongfa Center Building, Xin’an Street, Bao’an District, Shenzhen, China EUT Description : Wireless charging car mount (A) Model No. : W09 (B) Trademark : N/A Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C Section 15.209 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness of test. Also, this report shows that the EUT is technically compliant with the FCC CFR Title 47 Part 15 Subpart C Section 15.209 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Yannis Wen Project Engineer Approved by (name + signature).......: Jack Xu Project Manager Date of issue...... .......................: May 29, 2024 Page 4 of 34 Report No.: A2405024-C01-R01 Revision History Revision Issue Date Revisions Revised By V0 May 29, 2024 Initial released Issue Yannis Wen Page 5 of 34 Report No.: A2405024-C01-R01 1. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Spurious Emission §15.209(a)(f) PASS Occupied …

Text truncated - open the document above for the full version.

Shenzhen Ruitong Qianye Technology Co., Ltd. 客户/Ciient Shenzhen Ruitong Qianye Technology Co., Ltd. 地址/Address 301, No. 30 Xinsheng Road, Xinzhuang Community, Matian Street, Guangming District, Shenzhen 名称/TYPE A11 Wireless charging transmitter coil 产品型号Model NO G43.5*0.8 Double slot perforated back adhesive thread length 25MM/0.08*105 产品编号Product number Part nunbering systey 日期/Date May 17, 2024 本公司工程部/For Enginer Departner Only 修改内容/Rrvised Cintent 认可日期/APProved Date 编制/Prepared 审核/Checked 认可/Approved 万纪美 万纪美 刘成昭 客户认可回签/Authorixed Signaturure Company Chop 工程/ Enginrer 认可/QC APProved 认可日期/APProved Shenzhen Ruitong Qianye Technology Co., Ltd. 一、 线圈工艺/Winding Procese: NO winding Wire gauge Number of turns Winding direction Remark 1 N1 2UEW-B-0.08*105P 12TS CCW 2 二．电气性能/FEATURES: 1.测试条件（Test conditions）：25°C,65%RH@100KHz/1V 1.1 电感量（Inductance） 1.11 L0A（单独线圈）=3.8uH±20% 1.12 L0A(线圈+磁片)=6.5uH±10% 1.2 Q值=90MIN 1.3 直流电阻（DCR）：60mΩ MAX 1.4 工作温度(Operating Temperature)：-25°C~85°C 2.测试仪器(Test instrument)：L:创达1068+1310;DCR:502BC;SIZE:Callipers 3.材料清单 N O item Material 1 WIRE ￠0.08*105p 2UEW- 2 FERRITE 43.5 * 5 * 0.8 L-shaped double slot perforated ferrite hard magnetic double-sided adhesive tape on the back 3 GLUE Water-based white glue 4 SOLDER HQ-996/JS-996 5 Tin Thousand Island Pure Tin 6 High temperature adhesive 8MMHigh temperature tape 7 8 Shenzhen Ruitong Qianye Technology Co., Ltd. 三．电路图/CIRCUIT DIAGRAM 单位： MM 四．外形图/OUTSIDE DIAGRA Note: Wrap 8MM (ref) high-temperature adhesive tape around the coil outlet position, and stick double- sided backing tape on the back of the magnetic disc. 标准 A B C D E F G STD 43.5±0.5 39±0.5 13.4±0.3 5±0.2 25±2 3±1 2.0±0.3 单位： MM Shenzhen Ruitong Qianye Technology Co., Ltd. 五．包装/PACKAGE 5.3包装以现有包装盘为参照标准，以实际出货包装为准，如有特殊要求可定制。 The packaging shall be based on the exusting packing plate and the actual delivery package shall prevail .If there is any requirement,we can customize it. Shenzhen Ruitong Qianye Technology Co., Ltd. 六、贮存和使用条件 Storage and Use condition 6.1 贮存条件 Storage condition 6.1.1 建议贮存条件：温度-25°C~ 85°C ，湿度70% (Max.) Recommended keeping conditions: -25°C ~85°C, 70%RH (Max.) 6.1.2 贮存期限：自生产之日起六个月内 Storage life : Within the limits of six months from being produced. 6.2 使用条件 Use condition 使用条件限制：温度=-25°C~ 85°C, 湿度≤ 90% Use condition limit: T=-25°C~85°C, RH≤ 90%.

FCC ID: 2BGGP-W09 Radiated Emission FCC ID: 2BGGP-W09 Conducted Emission
