2BGM4-FDfiner

Attestation Statement. Old Code: C5266091 24 New Code: 00015544 Ed.3 Change reason: FRN is added to the Applicant information section. 1/1 TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Dongguan Huachuang Electronic Co.,Ltd. Grantee code: 2BGM4 FCC ID: 2BGM4-FD FRN: 0035470855 Contact Name: Aimee You Address: No. 35, Rongfu Road, Shangsha Community, Chang'an Town, Dongguan, Guangdong Province Telephone No: 0769-85846870 Fax No: 0769-81512850 Email: [email protected] i. [Dongguan Huachuang Electronic Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Dongguan Huachuang Electronic Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Dongguan Huachuang Electronic Co.,Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 11.28.2024 Applicant’s Name: Aimee You Title: manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Dongguan Huachuang Electronic Co.,Ltd. Product Similarity Declaration Product name: finer Model name: FD11, FD11A, FD11S, FD12, FD13, FD15, FD16, FD17, FD18, FD19, FD20, FD21, FD22, FD23, FD25, FD26, FD28 FCC ID: 2BGM4-FD We (Dongguan Huachuang Electronic Co.,Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name. Signature: Name: Aimee You Title: manager Date: 11.28.2024

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Dongguan Huachuang Electronic Co.,Ltd. Address: No. 35, Rongfu Road, Shangsha Community, Chang'an Town, Dongguan, Guangdong Province Product Name: finer Model Number: FD11, FD11A, FD11S, FD12, FD13, FD15, FD16, FD17, FD18, FD19, FD20, FD21, FD22, FD23, FD25, FD26, FD28 FCC Identifier: 2BGM4-FD We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Aimee You Date: 11/28/2024 Title: manager Signature of applicant:

C5266091_X10_Ed.2 1/1 Dongguan Huachuang Electronic Co.,Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 11/28/2024 Subject: Request for Confidentiality FCC ID: 2BGM4-FD To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Aimee You Title: manager

Page 1 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the EUT (External Photos) Model: FD11 Page 2 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 3 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected]

Model:FD11 FCC ID:2BGM4-FD S/N:000000000000

Page 1 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the EUT (Internal Photos) Model: FD11 ANT Page 2 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected]

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) We b : http://www.mtitest.cn E-mail: [email protected] RF EXPOSURE Test Report Report No.: MTi241018008-06E2 Date of issue: 2024-11-11 Applicant: Dongguan Huachuang Electronic Co., Ltd Product: finer Model(s): FD11, FD11A, FD11S, FD12, FD13, FD15, FD16, FD17 , FD18, FD19, FD20, FD21, FD22, FD23, FD25, FD26, FD28 FCC ID: 2BGM4-FD Shenzhen Microtest Co., Ltd. http://www.mtitest.cn - Page 2 of 6- Report No.: MTi241018008-06E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) We b : http://www.mtitest.cn E-mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 6- Report No.: MTi241018008-06E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) We b : http://www.mtitest.cn E-mail: [email protected] TEST RESULT CERTIFICATION Applicant: Dongguan Huachuang Electronic Co., Ltd Address: 35th Rongfu Road, Shangsha Area, Chang'an Town, Dongguan City, Guangdong, China Manufacturer: Dongguan Huachuang Electronic Co., Ltd Address: 35th Rongfu Road, Shangsha Area, Chang'an Town, Dongguan City, Guangdong, China Product description Product name: finer Trademark: N/A Model Name: FD11 Serial Model FD11A, FD11S, FD12, FD13, FD15, FD16, FD17 , FD18, FD19, FD20, FD21, FD22, FD23, FD25, FD26, FD28 Standards: N/A Test procedure: KDB 447498 D01 v06 Date of Test Date (s) of performance of tests: 2024-11-04 to 2024-11-11 Test Result: Pass Test Engineer : (James Qin) Reviewed By : (David Lee) Approved By : (Leon Chen) - Page 4 of 6- Report No.: MTi241018008-06E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) We b : http://www.mtitest.cn E-mail: [email protected] Table of Contents 1. STANDALONE SAR TEST EXCLUSION CONSIDERATIONS ............................................................................................ 5 2. SAR TEST EXCLUCSION THRESHOLDS ........................................................................................................................ 6 - Page 5 of 6- Report No.: MTi241018008-06E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) We b : http://www.mtitest.cn E-mail: [email protected] 1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified, typically in the SAR measurement or SAR analysis report, by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting are required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions. a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where  f (GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison  The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. b) For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thr…

Text truncated - open the document above for the full version.

The test report is only used for customer scientific research, teaching, internal quality control and other purposes, and is for internal reference only. Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) We b : http://www.mtitest.cn E-mail: [email protected] Test Report Report No.: MTi241018008-06E1 Date of issue: 2024-11-11 Applicant: Dongguan Huachuang Electronic Co., Ltd Product name: finer Model(s): FD11, FD11A, FD11S, FD12, FD13, FD15, FD16, FD17 , FD18, FD19, FD20, FD21, FD22, FD23, FD25, FD26, FD28 FCC ID: 2BGM4-FD Shenzhen Microtest Co., Ltd. http://www.mtitest.cn Page 2 of 49 Report No.: MTi241018008-06E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) We b : http://www.mtitest.cn E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 49 Report No.: MTi241018008-06E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) We b : http://www.mtitest.cn E-mail: [email protected] Table of contents 1 General Description ......................................................................................................................... 5 1.1 Description of the EUT ............................................................................................................................... 5 1.2 Description of test modes .......................................................................................................................... 5 1.3 Environmental Conditions .......................................................................................................................... 7 1.4 Description of support units ....................................................................................................................... 7 1.5 Measurement uncertainty .......................................................................................................................... 7 2 Summary of Test Result .................................................................................................................. 8 3 Test Facilities and accreditations ................................................................................................... 9 3.1 Test laboratory ........................................................................................................................................... 9 4 List of test equipment .................................................................................................................... 10 5 Evaluation Results (Evaluation) .................................................................................................... 11 5.1 Antenna requirement ............................................................................................................................... 11 6 Radio Spectrum Matter Test Results (RF) .................................................................................... 12 6.1 Occupied Bandwidth ................................................................................................................................ 12 6.2 Maximum Conducted Output Power ........................................................................................................ 13 6.3 Power Spectral Density ........................................................................................................................... 14 6.4 RF conducted spurious emissions and band edge measurement .......................................................... 15 6.5 Band edge emissions (Radiated) ............................................................................................................ 16 6.6 Radiated emissions (below 1GHz) .......................................................................................................... 19 6.7 Radiated emissions (above 1GHz) .......................................................................................................... 23 Photographs of the test setup ............................................................................................................. 27 Photographs of the EUT....................................................................................................................... 28 Appendix A: DTS Bandwidth ............................................................................................................... 30 Appendix B: Maximum conducted output power ............................................................................... 33 Appendix C: Maximum power spectral density .................................................................................. 36 Appendix D: Band edge measurements ............................................................................................. 39 Appendix E: Conducted Spurious Emission ...................................................................................... 41 Appendix F: Duty Cycle ....................................................................................................................... 47 Page 4 of 49 Report No.: MTi241018008-06E1 Address: 101, No. 7, Zone 2, Xinxing…

Text truncated - open the document above for the full version.

ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 1 APPROVALSHEET OverAir TM SMDAntennaseries RoHSCompliance PN:OA-C15 2.4GHzISMbandantenna ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 2 FEATURES 1.SurfaceMountedDevices(SMD)withasmalldimensionof1.6X0.8X0.8mm 3 meet miniaturizationtrend. 2.Lowpowerlossandhighantennaefficiency. 3.HighstabilityinTemperatureandHumidityChange. APPLICATIONS 1.2.4GHzISMbandRFapplications 2.Bluetooth,ZigBee,Wireless,HomeRF CONSTRUCTION 1 1、AntennaFeeding DIMENSIONS FigureSymbolDimension(mm) L 1.6±0.1 W0.8±0.1 T0.8±0.1 WB0.3±0.1 ELECTRICALCHARACTERISTICS ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 3 OA-C15Specification WorkingFrequencyRange 2450±50MHz BandWidth>100MHz Impedance 50Ω Gain(dBi) 1.54（peak） VSWR<2.5 OperationTemperature -40°C~+85°C PowerCapacity3W Theworkingfrequencyneedbeadjustedto2.45GHzwithmatchingcircuit. SOLDERLANDPATTERNDESIGN Figure ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 4 Top ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 5 Bot Matchingcomponentvalue Series12pF Shunt16.2nH Series20Ω Shunt2NC AntennaonTestBoard(Thickness1.0mm) ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 6 AntennaS11onTestBoard AntennaVSWRonTestBoard ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 7 EfficiencyandRADIATIONPATTERN Efficiency，RadiationPatternandGainweredependentonmeasurementboarddesign.The specificationofOA-C15antennawasmeasuredbasedonthePCBsizeandinstallationpositionas showninthebelowfiguretestboard.ThetestresultsweretestedinETS3DChamber. GainandEfficiency Z Y X ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 8 3Ddirectiondiagram ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 9 SOLDERINGCONDITION Typicalexamplesofsolderingprocessesthatprovidereliablejointswithoutanydamageisas follows: ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 10 PACKAGING PlasticTapespecification(unit:mm) IndexABCDJ Dimension(mm) 1.10 ± 0.101.90 ± 0.108.00 ± 0.103.50 ± 0.051.500/ ± 0.10 IndexEFGHT Dimension(mm) 1.75±0.104.00±0.102.00±0.104.00±0.10 1.10Max ApprovalsheetGuangzhouHanwujiElectronicTechnologyCo.,Ltd OA-C15 11 Reeldimensions IndexABC Dimension(mm)17850 13.5±0.5 TypingQuantity:4000piecesperreel. CAUTIONOFHANDLING Storageenvironmentcondition Productsshoudbestorageinthewarehouseonthefollowingconditions: Temperature:-10°C~+40°C Humidity:30%to70%relativehumidity Don’tkeepproductsincorrosivegasessuchassulfur.Chlorinegasoracidoritmay causeoxidizationofelectrode,resultinginpoorsolderability. Productsshouldbestorageonthepaletteforthepreventionoftheinfluencefrom humidity,dustandsoon. Productsshouldbestorageinthewarehousewithoutheatshock,vibration,direct sunlightandsoon. Productsshouldbestorageundertheairtightpackagedcondition.

Page 1 of 1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the test setup Model: FD11 Radiation spurious (below 1GHz) Radiation spurious (above 1GHz)
