2BGNSDH4X0VDigital Portable Radio

DH460 VHF Quick Start Guide Digital Portable Radio GET TO KNOW YOUR RADIO Components 1. 1.1 1 No. Item Name No. Item Name 1 PTT key 13 Function key1 2 Side key 1 14 Speaker 3 Side key 2 15 Top key 4 LED indicator 16 Back key 5 Antenna 17 Home key 6 Channel selection rotary knob 18 Down key 7 Power /Volume rotary knob 19 Function key3 8 Microphone 20 Function key2 9 LCD 21 Battery button 10 Up key 22 Accessory interface 11 OK/Menu key 23 Battery 12 Call/Answer key 1.2 PROGRAMMABLE KEYS To facilitate operations, your radio provides six programmable keys (Side key 1, Side key 2, Top key, Function key 1, Function key 1 and Function key 3), and each programmable key can be assigned with one of the following functions by the product distributor through setting shown as the following table. NOTE: The functions of a programmable key may vary with the operation (press or press and hold). For details, contact the local distributor. STATUS INDICATOR LCD (Status Symbols) 2. 2.1 2 Icon Name Icon Status Description Signal strength No signal. The more signal bars, the stronger the signal. Message You have unread message. Message inbox is full. Scan Your radio is in scanning mode. Your radio has stopped scanning. Roaming Your radio is in roaming mode. Your radio has stopped roaming. Transmit power The transmit power of current channel is low-power mode. The transmit power of current channel is high-power mode. Battery The more battery bars, the more battery power. Speaker The speaker is on. No. Function Description 1 None Do not assign function 2 Keypad lock Lock or unlock keypad quickly 3 Adjust power level Adjust transmit power level quickly 4 Call log One key to enter call log menu 5 Contact One key to enter contact menu 6 Text message One key to enter text message menu 7 Channel up/down Switch channel through button 8 Scan on/off Enable or disable scanning function 9 Squelch on/off Enable or disable squelch function 10 Roaming on/off Enable or disable roaming function LED INDICATOR 2.2 BASIC OPERATIONS Power On/Off Your Radio To power on your radio, rotate the Power/Volume rotary knob clockwise until a click is heard. To power off your radio, rotate the Power/Volume rotary knob counterclockwise until a click is heard. Turn Up/down the Volume After powering on your radio, rotating the Power/Volume rotary knob clockwise can turn up the volume, and rotating the Power/ Volume rotary knob counterclockwise can turn down the volume. Select a Zone You can add channels in one zone to manage the channels efficiently. Your radio supports up to 32 zones. One zone contains up to 32 channels. After powering on radio, you can enter the zone menu through the menu key, press up/down key to select the needed zone, and press OK key to switch to selected zone. Select a Channel In radio standby interface, you can rotate the Channel selection rotary knob and switch the current working channel. Rotating clockwise can turn down the channel, and rotating counterclockwise can turn up the channel. Lock/Unlock the Keypad When you do not need to use the keypad, you can lock the keypad to prevent accidental operation. You can lock or unlock the keypad in the following ways: By programming key: If your dealer has set the keypad lock shortcut, you can press this key to lock or unlock the keypad. 3. 3.1 3.2 3.3 3.4 3.5 3 Indicator Radio Status Solid green Your radio is receiving voice signals. Solid red Your radio is transmitting voice signals. Blinking orange Your radio is in scanning status. Solid orange After a call is established, there is no voice transmitted or received in the service channel. You can press PTT key to speak. Call To ensure that the called party can hear you clearly, keep the microphone 2.5 cm to 5 cm away from your mouth when you speak. 4. 4.1 Private Call 4.1.1 Initiate a private call You can initiate a private call in the following ways: Through the contact or call log 1. Press Menu key to enter into the main menu; 2. Select Contact -> Contact list, or select call log to enter the Called/Received/Missed call list; 3. Use Up/Down key to select the private call contact needed; 4.Press PTT key to initiate the private call. Through the missed call in the prompt interface You can press PTT key to initiate a private call through the missed call in the prompt interface. 4.1.2 Answer a private call After receiving a private call, your radio shall establish the call automatically. After the call is successful, your radio plays the alert tone. If there is no answer, a missed call prompt is displayed to remind the user. 4.2 Group Call 4.2.1 Initiate a group call You can initiate a group call through one of the following ways: Initiate a group call to a preset group contact In radio standby interface, press the PTT key to initiate a group call to the transmit contact preset for the current channel. Initiate a group call via the group contact 1. In radio standby interface, press menu key to enter the main menu; 2. Select Contact -> Contact list, or select call log to enter the Called/Received/Missed call list; 3. Use Up/Down key to select the group call contact needed; 4. Press PTT key to initiate the group call. 4.2.2 Answer a call After receiving a group call, your radio shall establish the call automatically. After the call is established successful, your radio plays the alert tone. 4.2.3 Late entry After the group call is established, it is allowed that the member, which has not joined the group call, to be connected to the group call again during call communication. 4 The Third Party Application Notice If you use unlicensed third party software to upgrade the radio firmware and system, there may be security risks that the radio gets unavailable or your personal information gets revealed. Please use online upgrade or download the official software which matches your radio model to do upgrade. After your radio upgrade, all your personal information may be removed, please backup personal information before upgrade. 5.…

Text truncated - open the document above for the full version.

SATELRADIOTELECOMUNICACAOLTDA 2024-07-31 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:AttestationStatementsPart2.911(d)(5)(i)requestfor(FCCID:2BGNSDH4X0V) [SATELRADIOTELECOMUNICACAOLTDA](“theapplicant”)certifiesthattheequipment forwhichauthorizationissoughtisnot“covered”equipmentprohibitedfromreceiving anequipmentauthorizationpursuanttosection2.903oftheFCCrules. Sincerely, (Applicantsignature:) (Applicantprintedname:FrameLiu) SATELRADIOTELECOMUNICACAOLTDA 2024-07-31 EurofinsElectricaland ElectronicTestingNA, Inc. 914 WestPatapscoAvenue Baltimore,MD 21230 RE: AttestationStatementsPart 2.911(d)(5)(ii)requestfor(FCC ID : 2BGNSDH4X0V) [SATELRADIOTELECOMUNICACAOLTDA] (“the applicant”) certifiesthat,as of the date of the filingof the application,the applicantis not identifiedon the CoveredList as an entityproducing“covered” equipment. Sincerely, (Applicantsignature:) (Applicantprintedname: FrameLiu )

SATELRADIOTELECOMUNICACAOLTDA AV.FRANCISCOMATARAZZO,1752,SALAS516,AGUABRANCA,SAOPAULO/SP,BRAZIL Date:June17,2024 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 FCCID:2BGNSDH4X0V FRN:0035480193 USAgent–AttestationStatement/Part2.911(d)(7) SATELRADIOTELECOMUNICACAOLTDAcertifies,thatasofJune17,2024,wehave designatedFCCUSAgent,LLCtoacceptserviceofprocessonourbehalfforFCCID: 2BGNSDH4X0V. SATELRADIOTELECOMUNICACAOLTDA,acceptstomaintainanagentofserviceofprocess intheUnitedStatesfornolessthanoneyearaftereitherthegranteehaspermanentlyterminated allmarketingandimportationoftheapplicableequipmentwithintheU.S.,ortheconclusionofany Commission-relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheveris later. FCCUSAgent,LLC,acceptsasofthedateofthefilingofthisapplication,theobligationofbeing thedesignatedagentforthepurposeofacceptingserviceofprocessonbehalfofSATELRADIO TELECOMUNICACAOLTDAforFCCID:2BGNSDH4X0V. DesignatedAgentInformation: CompanyName:FCCUSAgent,LLC FRN:0033402884 Address:3722IllinoisAvenue,SaintCharles,IL,60174,USA ContactPerson:TimPayne Phone:708-571-3148 Email:[email protected] Sincerely, Company:SATELRADIO TELECOMUNICACAOLTDA DesignatedAgent:FCCUSAgent,LLC CompanyRepresentative:FrameLiuDesignatedAgentRepresentative:TimPayne Signature:Signature:

SATELRADIOTELECOMUNICACAOLTDA AV.FRANCISCOMATARAZZO,1752,SALAS516,AGUABRANCA,SAOPAULO/SP,BRAZIL Tel.: +86075526774767 Attestationletter FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 DearSir/Madam, We,SATELRADIOTELECOMUNICACAOLTDAherebydeclarethatourproduct: DigitalPortableRadio,FCCID: 2BGNSDH4X0V iscapableofsupportingavoice channelandaminimumdatarateof4800bitspersecondper6.25kHzofchannel bandwidth.DMRinterphone’sbandwidthis12.5kHz,andithasadoubletimeslot, oneisthespeechtimeslot,oneisthedatatimeslot,justlanguagesequenceis satisfiedwith4800bps/6.25kHzBW. ForPart90frequencyuser,theradioisdisabled25kHzchannelbandwidthmodeby radiofirmwareatfactoryinordertocomplywithFCCmandateforpart90 frequencies. Sincerely, FrameLiu Signature: 2024-06-07

Differencesdeclaration Towhomconcern: Ourcompany(SATELRADIOTELECOMUNICACAOLTDA) Herebydeclares: Multi-modeldifferencesareasfollows: Mainmodel: Listedmodel: DH460VHF Schematicdiagram 电路原理图 PCBlayout PCB走线 Appearance 外观结构 Modelname 型号命名 Other 其它 DH410VHF  ∆∆  Note: 1.Ifitisasame,markitas 如相同 , 则标识为  2.Ifthereisadifference,markitas∆;Iftherearedifferencesotherthanmodelnamedifferences, pleasedescribethemindetail 如有差异，则标注为 ∆; 除了型号命名差异外，如有其它差异则需要在下面详细描述 ModelNo.:Differencesdescribe DH460VHF DH410VHF TheonlydifferencebetweenDH460VHFandDH410VHFisthepresenceorabsenceofscreensand buttons.TheschematicdiagramandPCBlayoutarethesame. By: FrameLiu SignaturePrinted Title:CertificationManager Onbehalfof:SATELRADIOTELECOMUNICACAOLTDA

SATELRADIO TELECOMUNICACAO LTDA 2024-08-08 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (EUT NAME: Digital Portable Radio / MODEL: DH460 VHF, DH410 VHF / FCC ID: 2BGNSDH4X0V) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Schematics, Block Diagram, Parts List, Operational Description, Tune-up Procedure) required to be submitted with this application be permanently withheld from public review. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, (Applicant signature: ) (Applicant printed name: Frame Liu )

SATELRADIOTELECOMUNICACAOLTDA 2024-07-31 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorize(ShenzhenHuatongweiInternationalInspectionCo.,Ltd/ Building7,BaiwangIdeaFactory,No.1051,SongbaiRoad,YangguangCommunity,Xili Subdistrict,NanshanDistrict,Shenzhen,Guangdong,China/XuYang)toactonourbehalfinall mattersrelatingtoapplicationforequipmentauthorization,includingthesigningofalldocuments relatingtothesematters. Wealsoherebycertifythatnopartytotheapplicationauthorizedhereunderissubjecttothe denialofbenefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseAct of1988,21U.S.C.853(a). Thisagreementexpiresoneyearfromthecurrentdate. Sincerely, (Applicantsignature:) (Applicantprintedname:FrameLiu)

Report No.: CHTW24060034 Page: 35 of 39 Issued: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05(2023-03) 7 EXTERNAL AND INTERNAL PHOTOS 7.1 External photos ANT Antenna access port Report No.: CHTW24060034 Page: 36 of 39 Issued: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05(2023-03)

Report No.: CHTW24060034 Page: 37 of 39 Issued: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05(2023-03) 7.2 Internal photos Report No.: CHTW24060034 Page: 38 of 39 Issued: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05(2023-03) Report No.: CHTW24060034 Page: 39 of 39 Issued: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05(2023-03) 8 APPENDIX REPORT

Page: 1 of 22 TEST REPORT For FCC Part15B Report No. .......................................: CHTW24060035 Report verification: Project No. ..................................: SHT2406041701W FCC ID ............................................. : 2BGNSDH4X0V Applicant’s name ........................... : SATELRADIO TELECOMUNICACAO LTDA Address ............................................. : AV.FRANCISCO MATARAZZO, 1752, SALAS 516, AGUA BRANCA, SAO PAULO/SP, BRAZIL Product Name ................................ : Digital Portable Radio Trade Mark ....................................... : - Model No. ......................................... : DH460 VHF Listed Model(s) ................................. : DH410 VHF Standard ......................................... : FCC CFR Title 47 Part 15 Subpart B Date of receipt of test sample...........: May.12, 2023 Date of testing..............................: May.12, 2023- May.30, 2023 Date of issue...............................: Jun.14, 2024 Result .................. ........................: Pass Compiled by (Position-Printed name-Signature) : File administrators Caspar Chen Supervised by (Position-Printed name-Signature) : Project Engineer Caspar Chen Approved by (position+printed name+signature) ... : RF Manager Xu Yang Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely corresponds to the test sample. Report No.: CHTW24060035 Page: 2 of 22 Date of issue: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) Contents 1. TEST STANDARDS AND REPORT VERSION ........................................... 3 1.1. Test Standards 3 1.2. Report version information 3 2. TEST DESCRIPTION .................................................................... 4 3. SUMMARY ............................................................................... 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Testing Laboratory Information 6 4. TEST CONFIGURATION ................................................................. 7 4.1. Descriptions of test mode 7 5.1. Configuration of Tested System 7 5.2. Support unit used in test configuration 7 5.3. Environmental conditions 8 5.4. Statement of the measurement uncertainty 8 5.5. Equipments Used during the Test 9 6. TEST CONDITIONS AND RESULTS ................................................... 10 6.1. Conducted Emissions 10 6.2. Radiated Emissions 13 7. TEST SETUP PHOTOS OF THE EUT .................................................. 19 8. EXTERNAL AND INTERNAL PHOTOS OF THE EUT .................................. 22 Report No.: CHTW24060035 Page: 3 of 22 Date of issue: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 1. TEST STANDARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: FCC CFR Title 47 Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2014 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz 1.2. Report version information Revision No. Date of issue Description N/A 2024-06-14 Original Report No.: CHTW24060035 Page: 4 of 22 Date of issue: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 2. TEST DESCRIPTION Section Test Item Section in CFR 47 Result #1 Test Engineer 5.1 Conducted Emissions 15.107(a) PASS Yongjin Lin 5.2 Radiated Emissions 15.109(a) PASS Yifan Wang Note: #1: The test result does not include measurement uncertainty value Report No.: CHTW24060035 Page: 5 of 22 Date of issue: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 3. SUMMARY 3.1. Client Information Applicant: SATELRADIO TELECOMUNICACAO LTDA Address: AV.FRANCISCO MATARAZZO, 1752, SALAS 516, AGUA BRANCA, SAO PAULO/SP, BRAZIL Manufacturer: SATELRADIO TELECOMUNICACAO LTDA Address: AV.FRANCISCO MATARAZZO, 1752, SALAS 516, AGUA BRANCA, SAO PAULO/SP, BRAZIL 3.2. Product Description Main unit information: Product Name: Digital Portable Radio Trade Mark: - Model No.: DH460 VHF Listed Model(s): DH410 VHF Power supply: DC7.4V from battery Hardware version: DH400MB_A Software version: V1.06.06B03 Accessory unit information: Battery information: Model: AB591 DC7.4V 2500mAh/18.5Wh Charger information: Model: AC700 Input: 12V 1A Adapter information: Model:ES085H-X120100XYF 100-240V~50/60Hz 0.5A Output: 12.0V 1000mA Note: The only difference between DH460 VHF and DH410 VHF is the presence or absence of screens and buttons. The schematic diagram and PCB layout are the same. Report No.: CHTW24060035 Page: 6 of 22 Date of issue: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 3.3. Testing Laboratory Information Laboratory Name Shenzhen Huatongwei International Inspection Co., Ltd. Laboratory Location 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Contact information: Tel: 86-755-26715499 E-mail: [email protected] http://www.szhtw.com.cn Qualifications Type Accreditation Number FCC 762235 Report No.: CHTW24060035 Page: 7 of 22 Date of issue: 2024-06-1…

Text truncated - open the document above for the full version.

Report No.: CHTW24060035 Page: 18 of 21 Date of issue: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 7. TEST SETUP PHOTOS OF THE EUT Model: DH460 VHF Conducted Emissions (AC Mains) Radiated Emissions (30MHz-1GHz) Report No.: CHTW24060035 Page: 19 of 21 Date of issue: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) Radiated Emissions (Above 1GHz) Report No.: CHTW24060035 Page: 20 of 21 Date of issue: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) Model: DH410 VHF Conducted Emissions (AC Mains) Radiated Emissions (30MHz-1GHz) Report No.: CHTW24060035 Page: 21 of 21 Date of issue: 2024-06-14 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) Radiated Emissions (Above 1GHz) 8. EXTERNAL AND INTERNAL PHOTOS OF THE EUT Refer to the test report No.: CHTW24060034 --------End of Report--------
