User Manual Aspire 5 A514-54H 1  FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interfer ence. 2. This device must accept any interference received, includ- ing interference that may cause undesired operation. About this Concise User Guide This quick guide is a brief introduction to getting your system started. Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure (or re-install) portions of the system, refer to the User’s Manual. Trademarks AMD is a trademark/registered trademark of AMD Corporation. Windows is a registered trademark of Microsoft Corporation. To Check the name of importer, registration certificate number and thickness of plastic packaging under Plastic Waste Management Rules, 2016, scan the below QR Code: 2 Instructions for Care and Operation The computer is quite rugged, but it can be damaged. To pre- vent this, follow these suggestions: •Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. •Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating element. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged. •Avoid interferen ce. Keep the computer away from high ca pacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. •Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work. Remember to periodically save your data as data may be lost. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service person- nel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the fol- lowing conditions: • When the power cord or Tpec-C adapter is damaged or frayed. • If the computer has been exposed to any liquids. • If the computer does not work normally when you follow the operating instructions. • If the computer has been dropped or damaged (do not touch the poisonous liquid if the panel breaks). • If t h ere is an unusual odor, heat or smoke coming from your com-puter. Safety Information • Only use an Type-C adapter approved for use with this computer. • Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a da maged battery in place, it may cause circuit damage, which may possibly result in fire. • Make sure that your computer is completely powered off before putting it into a travel bag (or any such container). • Before cleaning the computer, make sure it is disconnected from any external power supplies, peripherals and cables. • Use a soft clean cloth to clean the computer, but do not apply cleaner directly to the computer. D o not use volatile (petroleum d istillates) or abrasive cleaners on any part of the computer. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel. •Avoid placing any other items in the carrying bag which may rub against the top of the computer during transport. If any such wear and tear develops contact your service center. 3 Polymer/Lithium-Ion Battery Precautions Note the following information which is specific to Polymer/ Lithium-Ion batteries only, and where applicable, this over- rides the general battery precaution information. • Polymer/Lithium-Ion batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mechanism and is not a cause for concern. • Use proper handling procedures when using Polymer/Lithium-Ion batteries. Do not use Polymer/Lithium-Ion batteries in high ambi- ent temperature environments, and do not store unused batteries for extended periods. • If you are working in areas of low temperature use the AC/DC adapter to power the computer.  Battery Disposal & Caution The product that you have purchased contains a recharge- able battery. The battery is recyclable. At the end of its use- ful life, under various state and local laws, it may be illegal to dispose of this battery into the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal. Danger of explosion if battery is incorrectly replaced. Re- place only with the same or equivalent type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions. RTC battery Warning: "Do not ingest battery, Chemical Burn Hazard" Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. To check the EPR Registration No. of Acer India Pvt. Ltd. under Battery Waste Management Rules, 2022, scan below: 4 6\VWHP 6WDUWXS 1. Remove all packing materials. 2. Place the computer on a stable surface. 3. Securely attach any peripherals you want to use with the computer (e.g. keyboard and mouse) to their ports. 4.:KHQ ILUVW VHWWLQJ XS WKH FRPSXWHU XVH WKH IROORZLQJ SURFHGXUH(as to safeguard the computer during shipping, the battery will be locked to not power the system until first connected to the adapter and initially set up as below): • Attach the adapter cord to the charging jack on the left of the computer, the…

Text truncated - open the document above for the full version.

STS2601404W04_Appendix 5G WIFI_U-NII-1 Band Edge NVNT n20 5180MHz Low Ant B Band Edge NVNT n20 5240MHz High Ant B STS2601404W04_Appendix 5G WIFI_U-NII-1 Band Edge NVNT n40 5190MHz Low Ant B Band Edge NVNT n40 5230MHz High Ant B STS2601404W04_Appendix 5G WIFI_U-NII-1 Band Edge NVNT ac20 5180MHz Low Ant B Band Edge NVNT ac20 5240MHz High Ant B STS2601404W04_Appendix 5G WIFI_U-NII-1 Band Edge NVNT ac40 5190MHz Low Ant B Band Edge NVNT ac40 5230MHz High Ant B STS2601404W04_Appendix 5G WIFI_U-NII-1 Band Edge NVNT ac80 5210MHz High Ant B Band Edge NVNT ac80 5210MHz Low Ant B STS2601404W04_Appendix 5G WIFI_U-NII-1 Band Edge NVNT ax20 5180MHz Low Ant B Band Edge NVNT ax20 5240MHz High Ant B STS2601404W04_Appendix 5G WIFI_U-NII-1 Band Edge NVNT ax40 5190MHz Low Ant B Band Edge NVNT ax40 5230MHz High Ant B STS2601404W04_Appendix 5G WIFI_U-NII-1 Band Edge NVNT ax80 5210MHz High Ant B Band Edge NVNT ax80 5210MHz Low Ant B STS2601404W04_Appendix 5G WIFI_U-NII-1 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBm) Limit (dBm) Verdict NVNT a 5180 Ant B -43.21 -27 Pass 5200 -33.36 -27 Pass 5240 -33.16 -27 Pass n20 5180 -32.36 -27 Pass 5200 -33.61 -27 Pass 5240 -32.99 -27 Pass n40 5190 -33.71 -27 Pass 5230 -33.61 -27 Pass ac20 5180 -33.34 -27 Pass 5200 -32.29 -27 Pass 5240 -33.16 -27 Pass ac40 5190 -34.1 -27 Pass 5230 -33.33 -27 Pass ac80 5210 -33.56 -27 Pass ax20 5180 -33.16 -27 Pass 5200 -33.07 -27 Pass 5240 -33.74 -27 Pass ax40 5190 -32.4 -27 Pass 5230 -32.33 -27 Pass ax80 5210 -32.26 -27 Pass STS2601404W04_Appendix 5G WIFI_U-NII-1 Test Graphs Tx. Spurious NVNT a 5180MHz Ant B Emission Tx. Spurious NVNT a 5200MHz Ant B Emission STS2601404W04_Appendix 5G WIFI_U-NII-1 Tx. Spurious NVNT a 5240MHz Ant B Emission Tx. Spurious NVNT n20 5180MHz Ant B Emission STS2601404W04_Appendix 5G WIFI_U-NII-1 Tx. Spurious NVNT n20 5200MHz Ant B Emission Tx. Spurious NVNT n20 5240MHz Ant B Emission STS2601404W04_Appendix 5G WIFI_U-NII-1 Tx. Spurious NVNT n40 5190MHz Ant B Emission Tx. Spurious NVNT n40 5230MHz Ant B Emission STS2601404W04_Appendix 5G WIFI_U-NII-1 Tx. Spurious NVNT ac20 5180MHz Ant B Emission Tx. Spurious NVNT ac20 5200MHz Ant B Emission STS2601404W04_Appendix 5G WIFI_U-NII-1 Tx. Spurious NVNT ac20 5240MHz Ant B Emission Tx. Spurious NVNT ac40 5190MHz Ant B Emission STS2601404W04_Appendix 5G WIFI_U-NII-1 Tx. Spurious NVNT ac40 5230MHz Ant B Emission Tx. Spurious NVNT ac80 5210MHz Ant B Emission STS2601404W04_Appendix 5G WIFI_U-NII-1 Tx. Spurious NVNT ax20 5180MHz Ant B Emission Tx. Spurious NVNT ax20 5200MHz Ant B Emission STS2601404W04_Appendix 5G WIFI_U-NII-1 Tx. Spurious NVNT ax20 5240MHz Ant B Emission Tx. Spurious NVNT ax40 5190MHz Ant B Emission STS2601404W04_Appendix 5G WIFI_U-NII-1 Tx. Spurious NVNT ax40 5230MHz Ant B Emission Tx. Spurious NVNT ax80 5210MHz Ant B Emission

SAR Setup photos for FCC ID: 2BGQ7-A514-54H Body Back side(separation distance is 0mm)

Page 1 of 2 FCC ID: 2BGQ7-A514-54H Conducted emissions 30MHz-1GHz Page 2 of 2 FCC ID: 2BGQ7-A514-54H Spurious emissions

深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 承认书 SPECIFICATIONFORAPPROVAL 审批/Approval客户批准/CustomerApproval 制作 PreparedBy 审核 CheckedBy 批准 ApprovalBy 审核 CheckedBy 批准 ApprovalBy 签章 Signature 黄宗宝夏承磊陈华明 日期 Date 2026.01.052026.01.052026.01.05 修订履历/ChangeLog 版本 Version 修订内容 ChangeDescription 责任人 PersoninCharge 核准 ApprovalBy 日期 Date 客户名称 CustomerName 昱科 客户项目名Customer ProjectName ME1463WB-A 顺达成项目名 SDCProjectName ME1463WB-A 客户编码 CustomerP/N A03016000000453 顺达成料号 SDCP/N WF5998B-0814R-200副(灰) 频段 Band WIFI2.4G/5.8G/BT 版本号 Version A0 设计人信息/DesignerInformation 射频工程师 RFEngineer 伍文载 研发主管 R&DDiretor 夏承磊 结构工程师 MEEngineer 黄宗宝 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 目录/Catalogue 序号 No. 项目 Item 页码 PageNo. 1 图纸或实物图片 DrawingorProductImage 3 2 尺寸测量报告 DimensionsTestReport 4 3 射频性能测试报告 RFPerformanceTestReport 5-8 4 可靠性测试报告 ReliabilityTestReport1 9 5 包装文件 PackageDocument 10 6 环境有害物质管控一览表 RoHSControllistforSample 11 7 安装事宜或其它 InstallWizard orOther 11 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 产品图纸或实物图片 DrawingorProductImage D E S C R I P T I O N N O Q ' T Y 2 1 3 1 R E M A R K 2 0 0 C a b l e ? 0 . 8 1 C a b l e G r e y , 5 0 Ω F P C - 黑 油 黑 字 一 对 半 基 材 ， 做 抗 氧 化 处 理 3 M 9 4 7 1 背 胶 F P C 6 5 4 3 2 1 A B X X . X . . X X . X X X . X C H E C K E D ± 1 . 0 D R A W I N G ± 0 . 1 ± 0 . 5 A P P R O V E D ± 3 . 0 ± 5 F I L E : S H E E T : P A R T N A M E : R E V A 0 U N I T m / m C U S T O M E R : 2 / 2 6 5 4 C D E 3 2 2 0 2 5 . 1 2 . 1 9 A 0 F R E V D A T E N e w I s s u e G D E S C R I P T I O N 1 深 圳 市 顺 达 成 科 技 有 限 公 司 S D C P / N O : W I F I 副 天 线 （ M E 1 4 6 3 W B - A ) F P C ( 丝 印 S D C A L 1 5 0 7 Y D - E 1 W F 副 ) + 0 . 8 1 灰 色 线 + I P E X 4 右 L = 2 0 0 m m 昱 科 端 子 I P E X 4 1 符 学 荣 李 瑶 娜 李 瑶 娜 注 ： 6 0 m m 以 内 的 线 材 ， 若 无 客 户 要 求 则 默 认 端 子 头 朝 下 W F 5 9 9 8 B - 0 8 1 4 R - 2 0 0 副 ( 灰 ) 全 部 为 通 孔 看 到 的    手 撕 位 手 撕 位 S D C A L 1 5 0 7 Y D - E 1 W F 副 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 样品尺寸测量报告 SampleDimensionsTestReport 测试日期 TestDate 2026.01.05 样品数量 SampleQty. 3 测试人 Inspector 许燕芳 尺寸编号 DimensionNo. 标准 Standard 样品1 Sample1 样品2 Sample2 样品3 Sample3 Pass/NG ①长度28±0.2mm2828.128 Pass ②宽度25±0.2mm252525.1 Pass ③厚度0.1±0.03mm0.10.10.1 Pass ④线长200±2mm200201200 Pass 最终结论 Conclusion PASS 测试人&日期 Inspector&Date 许燕芳2026.01.05 批准&日期 Approval&Date 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 射频性能测量报告 RFPerformanceTestReport 天线测试设备简介 AntennaTestEquipmentIntroduction 测试天线输入特性使用AgilentE5071CandAgilent5062A矢量网络分析仪；辐射特性利用 广屏三维近场暗室进行测试，并分别使用8960E5515和AgilentE4438C进行了分析。暗房的测试坐 标如下: TestofantennainputcharacteristicsusingAgilentE5071CandAgilent5062Avectornetwork analyzer;Theradiationpatternoftheantennaaretestedusingtheguangping3DnearfieldAnechoicChamber, andtheinstrumentisusedtoagilent8960E5515andAgilentE4438C.Thetestcoordinatesofthedarkroomare asfollows: 1.S11参数测量/S11Parameter-VSWR 使用一根50Ω同轴电缆连接到天线，然后该电缆连接到网络分析仪测量S11参数，被测量产品远离金属至少 20厘米。 MeasuringMethodisa50 Ω coaxialcableisconnectedtotheantenna.Thenthiscableisconnectedtoanetworkanalyzerto measuretheS11parameter,Keepingthisfixtureawayfrommetalatleast20cm. 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 S11Parameter-VSWR 2.天线匹配网络/ AntennaMatchingNetwork 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 3.Gain&Efficiency WIFI副天线 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 4.WIFIOTAData

深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 承认书 SPECIFICATIONFORAPPROVAL 审批/Approval客户批准/CustomerApproval 制作 PreparedBy 审核 CheckedBy 批准 ApprovalBy 审核 CheckedBy 批准 ApprovalBy 签章 Signature 黄宗宝夏承磊陈华明 日期 Date 2026.01.052026.01.052026.01.05 修订履历/ChangeLog 版本 Version 修订内容 ChangeDescription 责任人 PersoninCharge 核准 ApprovalBy 日期 Date 客户名称 CustomerName 昱科 客户项目名Customer ProjectName ME1463WB-A 顺达成项目名 SDCProjectName ME1463WB-A 客户编码 CustomerP/N A03016000000454 顺达成料号 SDCP/N WF5998B-0814L-275主(黑) 频段 Band WIFI2.4G/5.8G/BT 版本号 Version A0 设计人信息/DesignerInformation 射频工程师 RFEngineer 伍文载 研发主管 R&DDiretor 夏承磊 结构工程师 MEEngineer 黄宗宝 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 目录/Catalogue 序号 No. 项目 Item 页码 PageNo. 1 图纸或实物图片 DrawingorProductImage 3 2 尺寸测量报告 DimensionsTestReport 4 3 射频性能测试报告 RFPerformanceTestReport 5-8 4 可靠性测试报告 ReliabilityTestReport1 9 5 包装文件 PackageDocument 10 6 环境有害物质管控一览表 RoHSControllistforSample 11 7 安装事宜或其它 InstallWizard orOther 11 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 产品图纸或实物图片 DrawingorProductImage D E S C R I P T I O N N O Q ' T Y 2 1 3 1 R E M A R K 2 7 5 C a b l e ? 0 . 8 1 C a b l e B l a c k , 5 0 Ω F P C - 黑 油 黑 字 一 对 半 基 材 ， 做 抗 氧 化 处 理 3 M 9 4 7 1 背 胶 F P C 6 5 4 3 2 1 A B X X . X . . X X . X X X . X C H E C K E D ± 1 . 0 D R A W I N G ± 0 . 1 ± 0 . 5 A P P R O V E D ± 3 . 0 ± 5 F I L E : S H E E T : P A R T N A M E : R E V A 0 U N I T m / m C U S T O M E R : 1 / 2 6 5 4 C D E 3 2 2 0 2 5 . 1 2 . 1 9 A 0 F R E V D A T E N e w I s s u e G D E S C R I P T I O N 1 深 圳 市 顺 达 成 科 技 有 限 公 司 S D C P / N O : W I F I 主 天 线 （ M E 1 4 6 3 W B - A ) F P C ( 丝 印 S D C A L 1 5 0 7 Y D - E 1 W F 主 ) + 0 . 8 1 黑 色 线 + I P E X 4 左 L = 2 7 5 m m 昱 科 端 子 I P E X 4 1 符 学 荣 李 瑶 娜 李 瑶 娜 注 ： 6 0 m m 以 内 的 线 材 ， 若 无 客 户 要 求 则 默 认 端 子 头 朝 下  W F 5 9 9 8 B - 0 8 1 4 L - 2 7 5 主 ( 黑 ) 全 部 为 通 孔 看 到 的 手 撕 位   S D C A L 1 5 0 7 Y D - E 1 W F 主 手 撕 位 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 样品尺寸测量报告 SampleDimensionsTestReport 测试日期 TestDate 2026.01.05 样品数量 SampleQty. 3 测试人 Inspector 许燕芳 尺寸编号 DimensionNo. 标准 Standard 样品1 Sample1 样品2 Sample2 样品3 Sample3 Pass/NG ①长度25.1±0.2mm25.125.225.2 Pass ②宽度25±0.2mm2525.125 Pass ③厚度0.1±0.03mm0.10.10.1 Pass ④线长275±2mm275276275 Pass 最终结论 Conclusion PASS 测试人&日期 Inspector&Date 许燕芳2026.01.05 批准&日期 Approval&Date 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 射频性能测量报告 RFPerformanceTestReport 天线测试设备简介 AntennaTestEquipmentIntroduction 测试天线输入特性使用AgilentE5071CandAgilent5062A矢量网络分析仪；辐射特性利用 广屏三维近场暗室进行测试，并分别使用8960E5515和AgilentE4438C进行了分析。暗房的测试坐 标如下: TestofantennainputcharacteristicsusingAgilentE5071CandAgilent5062Avectornetwork analyzer;Theradiationpatternoftheantennaaretestedusingtheguangping3DnearfieldAnechoicChamber, andtheinstrumentisusedtoagilent8960E5515andAgilentE4438C.Thetestcoordinatesofthedarkroomare asfollows: 1.S11参数测量/S11Parameter-VSWR 使用一根50Ω同轴电缆连接到天线，然后该电缆连接到网络分析仪测量S11参数，被测量产品远离金属至少 20厘米。 MeasuringMethodisa50 Ω coaxialcableisconnectedtotheantenna.Thenthiscableisconnectedtoanetworkanalyzerto measuretheS11parameter,Keepingthisfixtureawayfrommetalatleast20cm. 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 S11Parameter-VSWR 2.天线匹配网络/ AntennaMatchingNetwork 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 3.Gain&Efficiency WIFI主天线 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址： 深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 4.WIFIOTAData

STS2601404W04_Appendix 5G WIFI_U-NII-1 Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) NVNT a 5180 Ant A 97.66 0.1 NVNT n20 5180 Ant A 98.76 0 NVNT n40 5190 Ant A 98.76 0 NVNT ac20 5180 Ant A 98.75 0 NVNT ac40 5190 Ant A 98.75 0 NVNT ac80 5210 Ant A 98.75 0 NVNT ax20 5180 Ant A 98.76 0 NVNT ax40 5190 Ant A 98.76 0 NVNT ax80 5210 Ant A 99.01 0 STS2601404W04_Appendix 5G WIFI_U-NII-1 Test Graphs Duty Cycle NVNT a 5180MHz Ant A Duty Cycle NVNT n20 5180MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Duty Cycle NVNT n40 5190MHz Ant A Duty Cycle NVNT ac20 5180MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Duty Cycle NVNT ac40 5190MHz Ant A Duty Cycle NVNT ac80 5210MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Duty Cycle NVNT ax20 5180MHz Ant A Duty Cycle NVNT ax40 5190MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Duty Cycle NVNT ax80 5210MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT a 5180 Ant A 11.23 24 Pass NVNT a 5200 Ant A 10.92 24 Pass NVNT a 5240 Ant A 10.95 24 Pass NVNT n20 5180 Ant A 10.65 24 Pass NVNT n20 5200 Ant A 10.4 24 Pass NVNT n20 5240 Ant A 9.78 24 Pass NVNT n40 5190 Ant A 9.36 24 Pass NVNT n40 5230 Ant A 8.34 24 Pass NVNT ac20 5180 Ant A 10.64 24 Pass NVNT ac20 5200 Ant A 10.27 24 Pass NVNT ac20 5240 Ant A 10.07 24 Pass NVNT ac40 5190 Ant A 9.36 24 Pass NVNT ac40 5230 Ant A 8.63 24 Pass NVNT ac80 5210 Ant A 8.32 24 Pass NVNT ax20 5180 Ant A 10.45 24 Pass NVNT ax20 5200 Ant A 10.21 24 Pass NVNT ax20 5240 Ant A 9.86 24 Pass NVNT ax40 5190 Ant A 9.22 24 Pass NVNT ax40 5230 Ant A 9.05 24 Pass NVNT ax80 5210 Ant A 7.87 24 Pass STS2601404W04_Appendix 5G WIFI_U-NII-1 Test Graphs Power NVNT a 5180MHz Ant A Power NVNT a 5200MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Power NVNT a 5240MHz Ant A Power NVNT n20 5180MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Power NVNT n20 5200MHz Ant A Power NVNT n20 5240MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Power NVNT n40 5190MHz Ant A Power NVNT n40 5230MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Power NVNT ac20 5180MHz Ant A Power NVNT ac20 5200MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Power NVNT ac20 5240MHz Ant A Power NVNT ac40 5190MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Power NVNT ac40 5230MHz Ant A Power NVNT ac80 5210MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Power NVNT ax20 5180MHz Ant A Power NVNT ax20 5200MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Power NVNT ax20 5240MHz Ant A Power NVNT ax40 5190MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Power NVNT ax40 5230MHz Ant A Power NVNT ax80 5210MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 -26dB Bandwidth Condition Mode Frequency (MHz) Antenna -26 dB Bandwidth (MHz) Limit -26 dB Bandwidth (MHz) Verdict NVNT a 5180 Ant A 21.989 0.5 Pass 5200 22.474 0.5 Pass 5240 22.253 0.5 Pass n20 5180 22.408 0.5 Pass 5200 23.47 0.5 Pass 5240 22.182 0.5 Pass n40 5190 44.088 0.5 Pass 5230 43.045 0.5 Pass ac20 5180 22.993 0.5 Pass 5200 22.364 0.5 Pass 5240 23.515 0.5 Pass ac40 5190 42.82 0.5 Pass 5230 42.99 0.5 Pass ac80 5210 84.205 0.5 Pass ax20 5180 22.579 0.5 Pass 5200 23.293 0.5 Pass 5240 23.189 0.5 Pass ax40 5190 42.853 0.5 Pass 5230 42.106 0.5 Pass ax80 5210 83.393 0.5 Pass STS2601404W04_Appendix 5G WIFI_U-NII-1 Test Graphs -26dB Bandwidth NVNT a 5180MHz Ant A -26dB Bandwidth NVNT a 5200MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT a 5240MHz Ant A -26dB Bandwidth NVNT n20 5180MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT n20 5200MHz Ant A -26dB Bandwidth NVNT n20 5240MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT n40 5190MHz Ant A -26dB Bandwidth NVNT n40 5230MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ac20 5180MHz Ant A -26dB Bandwidth NVNT ac20 5200MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ac20 5240MHz Ant A -26dB Bandwidth NVNT ac40 5190MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ac40 5230MHz Ant A -26dB Bandwidth NVNT ac80 5210MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ax20 5180MHz Ant A -26dB Bandwidth NVNT ax20 5200MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ax20 5240MHz Ant A -26dB Bandwidth NVNT ax40 5190MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ax40 5230MHz Ant A -26dB Bandwidth NVNT ax80 5210MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT a 5180 Ant A 16.576 5200 16.53 5240 16.532 n20 5180 17.665 5200 17.663 5240 17.681 n40 5190 36.012 5230 36.035 ac20 5180 17.678 5200 17.673 5240 17.669 ac40 5190 36.006 5230 36.018 ac80 5210 75.125 ax20 5180 18.883 5200 18.88 5240 18.882 ax40 5190 37.462 5230 37.472 ax80 5210 76.645 STS2601404W04_Appendix 5G WIFI_U-NII-1 Test Graphs OBW NVNT a 5180MHz Ant A OBW NVNT a 5200MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 OBW NVNT a 5240MHz Ant A OBW NVNT n20 5180MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 OBW NVNT n20 5200MHz Ant A OBW NVNT n20 5240MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 OBW NVNT n40 5190MHz Ant A OBW NVNT n40 5230MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 OBW NVNT ac20 5180MHz Ant A OBW NVNT ac20 5200MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 OBW NVNT ac20 5240MHz Ant A OBW NVNT ac40 5190MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 OBW NVNT ac40 5230MHz Ant A OBW NVNT ac80 5210MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 OBW NVNT ax20 5180MHz Ant A OBW NVNT ax20 5200MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 OBW NVNT ax20 5240MHz Ant A OBW NVNT ax40 5190MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 OBW NVNT ax40 5230MHz Ant A OBW NVNT ax80 5210MHz Ant A STS2601404W04_Appendix 5G WIFI_U-NII-1 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Con…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.: STS2601404W04 Issued for Acer India Private Limited Embassy Heights 6th floor, No.13 Magrath Road(Next to Hosmat Hospital) Bengaluru, 560025, India Product Name: Laptop Brand Name: Model Name: Aspire 5 A514-54H Series Model(s): N/A FCC ID: 2BGQ7-A514-54H Test Standards: FCC Part15.407 Page 2 of 47 Report No.: STS2601404W04 TEST REPORT Applicant’s Name ................. : Acer India Private Limited Address ................................. : Embassy Heights 6th floor, No.13 Magrath Road(Next to Hosmat Hospital) Bengaluru, 560025, India Manufacturer's Name ........... : Acer India Private Limited Address ................................. : Embassy Heights 6th floor, No.13 Magrath Road(Next to Hosmat Hospital) Bengaluru, 560025, India Product Description Product Name ........................ : Laptop Brand Name ........................... : Model Name .......................... : Aspire 5 A514-54H Series Model(s) .................... : N/A Test Standards ..................... : FCC Part15.407 Test Procedure ............................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 17 Jan. 2026 Date (s) of performance of tests ............. : 17 Jan. 2026 to 02 Feb. 2026 Date of Issue .......................................... : 03 Feb. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 47 Report No.: STS2601404W04 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 11 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 13 2.6 EQUIPMENTS LIST 14 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION AND MEASUREMENT 19 4. POWER SPECTRAL DENSITY TEST 38 4.1 LIMIT 38 4.2 TEST PROCEDURE 38 4.3 DEVIATION FROM STANDARD 39 4.4 TEST SETUP 39 4.5 EUT OPERATION CONDITIONS 39 4.6 TEST RESULTS 39 5. DUTY CYCLE 40 5.1 TEST STANDARD 40 5.2 TEST PROCEDURE 40 5.3 DEVIATION FROM STANDARD 40 5.4 TEST SETUP 40 5.5 EUT OPERATION CONDITIONS 40 5.6 TEST RESULTS 40 6. BANDWIDTH MEASUREMENT 41 6.1 EMISSION BANDWIDTH (EBW) 26 BANDWID PROCEDURES / LIMIT 41 6.2 OCCUPIED BANDWIDTH ( 99%) TEST APPLIED PROCEDURES / LIMIT 42 6.3 MINIMUM EMISSION BANDWIDTH(6 DB) PROCEDURES / LIMIT 43 7. MAXIMUM OUTPUT POWER 44 7.1 LIMIT 44 7.2 TEST PROCEDURE 44 7.3 DEVIATION FROM STANDARD 44 Page 4 of 47 Report No.: STS2601404W04 Table of Contents Page 7.4 TEST SETUP 44 7.5 EUT OPERATION CONDITIONS 44 7.6 TEST RESULTS 44 8. AUTOMATICALLY DISCONTINUE TRANSMISSION 45 8.1 LIMIT OF AUTOMATICALLY DISCONTINUE TRANSMISSION 45 8.2 TEST RESULT OF AUTOMATICALLY DISCONTINUE TRANSMISSION 45 9. ANTENNA REQUIREMENT 46 9.1 STANDARD REQUIREMENT 46 9.2 EUT ANTENNA 46 APPENDIX - PHOTOS OF TEST SETUP 47 Page 5 of 47 Report No.: STS2601404W04 Revision History Rev. Issue Date Report No. Effect Page Contents 00 03 Feb. 2026 STS2601404W04 ALL Initial Issue Page 6 of 47 Report No.: STS2601404W04 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: § 15.407,KDB 789033 D02 General U-NII Test Procedures New Rules v02r01 FCC Part 15.407 FCC standard Test Item Results 15.207 AC Conducted Emission PASS 15.407 (a) /15.407 (e) 26dB/6dB &99% Bandwidth PASS 15.407(a) Maximum Conducted Output Power PASS 15.407(b)/15.209 Radiated Emission And (bandedge Emissions) Measurement PASS 15.407(a) Power Spectral Density PASS 15.407(c) Automatically Discontinue Transmission PASS 15.203/15.204 Antenna Requirement PASS Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 47 Report No.: STS2601404W04 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add.: 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 47 Report No.: STS2601404W04 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Laptop Brand Name Model Name Aspire 5 A514-54H Series Model(s) N/A Model Difference N/A Product Description The EUT is a Laptop Operation Frequency: IEEE 802.11a/ n(HT20)/ac(VHT20)/ax(HE20): 5.180GHz-5.240GHz IEEE 802.11n(HT40)/ac(VHT40)/ax(HE40): 5.190GHz-5.230G…
