1 EAW Fokus HD 50 DE Benutzerhandbuch / EN User Manual 32 Deutsch 4 – 29 English 30 – 55 54 Inhalt 1. Vorsichtsmaßnahmen und Beachtung 2. Funktionale Elemente 3. Bedienung und Menüsteuerung 4. Multifunktionale Verwendung (3in1) 5. Bedienung und Funktionen 6. Vorsatzgeräte-Ausrichtung 7. Zielfernrohr-Modus 7.1 Einschießen und Ballistikfunktionen 7.1.1 Einschießen bei Geräten ohne Laserentfernungsmesser 7.1.2 Einschießen bei Geräten mit Laserentfernungsmesser 7.2 Absehen 8. Allgemeine Informationen 9. Technische Daten DEDE – 76DE – 1. VORSICHTSMASSNAHMEN UND BEACHTUNG • Die sachgemäße Verwendung des Gerätes ist wichtig für eine siche- re Nutzung! Lesen Sie daher die vorliegende Anleitung sorgfältig durch! • Wenn das Gerät vor der Nutzung längere Zeit gelagert wurde, über - prüfen Sie seine Funktionsfähigkeit. • Die Demontage des Geräts ist verboten, außer im autorisierten Herstellerbetrieb. • Die äußeren optischen Flächen sollten immer sauber sein. Das Be - rühren der optischen Flächen mit bloßen Händen sollte vermieden werden. • Sand und Meerwasser können die optischen Beschichtungen be - schädigen! • Richten Sie das Gerät nicht direkt auf die Sonne! Dies kann perma- nenten Schäden am Sensor hervorrufen. • Die Bildleistung hängt von der Landschaft und den atmosphäri - schen Bedingungen ab. Der Kontrast im selben Bild kann je nach Tageszeit aufgrund der Sonneneinstrahlung variieren. Zum Beispiel haben Objekte bei Sonnenuntergang unterschiedlich viel Wärme absorbiert, was zu größeren Temperaturunterschieden und einem besseren Kontrast führt. • Wenn Sie das Gerät tragen oder transportieren, setzen Sie den Objektivschutzdeckel auf! • Temperaturwechsel können zur Bildung von Kondenswasser auf den äußeren optischen Flächen führen. •ReinigenSiedieLinsenoberflächenmitdembeigefügtenReini - gungstuch oder einem für Optik geeigneten Tuch. RECHTLICHE HINWEISE: PrüfenSievorderAnbringunganWaffendieregionalengesetzlichenBe- stimmungenimEinsatzgebiet.DieBefestigunganeinerWaffeliegtimmer in der alleinigen Verantwortung des Benutzers. Diese Anleitung basiert auf dem heutigen Stand der Technik. Alle Abbildungen und Angaben sind ohne Gewähr. Änderungen sowie alle Rechte vorbehalten. Die Vervielfältigung der Anleitung, auch auszugs- weise, egal über welches Medium, ist ohne schriftliche Genehmigung der Ernst Apel GmbH untersagt. GARANTIEBEDINGUNGEN: Die Garantie beträgt 2 Jahre auf die Optoelektronik (Teile wie Elektronik, Akku und optische Komponenten), sowie 30 Jahre auf die Gehäuseteile. USB-VERBINDUNG: Für die korrekte Verbindung des Gerätes mit einem Computer, kann ein Neustart des Gerätes erforderlich sein. Im ersten Schritt das Gerät mit dem USB-Kabel und Computer verbinden, danach das Gerät einschalten. DATENÜBERTRAGUNG IOS: Bei Verbindung mit iOS-Geräten kann zusätzliche Software notwendig sein, um auf den Speicher des Gerätes zugreifen zu können (beispiels - weise OpenMTP). – DE 98 12 H G F E D C B A J K L M N P Q R A B C D E F G H J K L M N P Q 1110987654321131415161718192021222324 12345678910111213141516171819 20 ALL RIGHTS STRICTLY RESERVED. REPRODUCTION OR ISSUE TO THIRD PARTIES IN ANY FORM WHATEVER IS NOT PERMITTED WITHOUT WRITTEN AUTHORITY FROM THE PROPRIETOR. PROJECTION: gWEIGHT: mm UNITS: SURFACE TREATMENT: 1 1 A0 ISO 2768-mH 2:1 000000-0000-000 OF SHEET: SCALE: DRAWING NUMBER: DESCRIPTION: MATERIAL: NAME DATE Released Checked Drawn by GENERAL TOLERANCES: NAME DATEMODIFICATIONREV 12 HGFEDCBAJKLMNPQR ABCDEFGHJKLMNPQ 11 10 9 8 7 6 5 4 3 2 1 13 14 15 16 17 18 19 20 21 22 23 24 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 ALL RIGHTS STRICTLY RESERVED. REPRODUCTION OR ISSUE TO THIRD PARTIES IN ANYFORM WHATEVER IS NOT PERMITTED WITHOUT WRITTEN AUTHORITY FROM THE PROPRIETOR. PROJECTION: g WEIGHT: mm UNITS: SURFACE TREATMENT: 1 1 A0 ISO 2768-mH 2:1 000000-0000-000 OF SHEET: SCALE: DRAWING NUMBER:DESCRIPTION: MATERIAL: NAME DATE Released Checked Drawn by GENERALTOLERANCES: NAME DATE MODIFICATION REV 2. FUNKTIONALE ELEMENTE3. BEDIENUNG UND MENÜSTEUERUNG 5-Tasten-Bedientastatur Lade-LED Dioptrien-Einstellung Ladeanschluss USB-C Laser Entfernungsmesser Unterseite, Tragegurtschlaufe Fokussierring Das Fokus HD50 verfügt über 5 Tasten für die Bedienung. Jede Taste verfügt über einen kurze Druckfunktion und eine lange Druckfunktion. * Nur bei montiertem LRF verfügbar. ** Nur wenn Modus verfügbar Knopf:kurze Druckfunktionlange Druckfunktion Ein/Aus:Ein-/AusschaltenDigitaler Zoom (1x/2x/4x) Auf:Hauptmenü aufrufen / verlassenFarbmodus Einstellung Auf Ab Links Ein/Aus Rechts Rechts:Videoaufzeichnung starten / stoppenFoto aufnehmen Ab:LRF-Scan-Modus*Einzelne LRF-Messung* Links: Umschaltung: Vorsatzgerät / Monokular / Zielgerät** NUC DE – – DE 1110 4. MULTIFUNKTIONALE VERWENDUNG (3IN1) Das Fokus HD 50 bietet Ihnen vielfältige Einsatzmöglichkeiten als Mo - nokular, Vorsatzgerät für Zielfernrohre und als eigenständiges Wärme- bildzielgerät. Abhängig von der Softwareversion und den gesetzlichen Einschränkungen in den jeweiligen Ländern können einige dieser Funk - tionen nicht verfügbar sein oder durch ein Software-Update zusätzlich erworben werden. Monokularer Modus In diesem Modus wird das Wärmebild auf dem Mikrodisplay im Vollbild- modus angezeigt. Bitte verwenden Sie die am Okular befestigte Gummi- augenmuschel und stellen Sie die Dioptrien auf Ihren Bedürfnissen ein. Vorsatzgeräte-Modus In diesem Modus wird das Wärmebild kleiner dargestellt, um auch die Verwendung von vergrößernder Optik zu ermöglichen. Für eine einwandfreie Funktion im Clip-On-Modus muss das Okular auf 0 Dioptrien und parallaxenfreie Position eingestellt werden. Diese Position ist auf den Okular und dem hinteren Gehäuse markiert. Achten Sie darauf, dass die T-Markierung mit dem Ende des Gehäuses überein - stimmt und verwenden Sie die Augenmuschel wie auf dem Bild gezeigt, um die beste Bildqualität zu erzielen. Abhängig von Ihrer Optik und Ihrer persönlichen Präfererenz kann eine kleine Nachjustierung erforderli…

Text truncated - open the document above for the full version.

Ernst Apel GmbH Am Kirschberg 3, 97218 Gerbrunn, Germany Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024/06/01 To whom it may concern: We, FLUX Inc., hereby certify that the equipment for which authorization is sought (FCC ID: 2BGQW- FOKUSHD50) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Alice Yan Manager Ernst Apel GmbH 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

Attestation Statements (2024/06/19) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (2BGQW-FOKUSHD50) (Ernst Apel GmbH), the undersigned, hereby authorize (Sig Sauer, Inc.) to act as our designated U.S. agent for service of process, (Sig Sauer, Inc) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (Sig Sauer, Inc) accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Ernst Apel GmbH Contact Name: Alice Yan Address: Am Kirschberg 3, 97218 Gerbrunn, Germany Telephone No: 13310875860 Email: [email protected] Signature Alice Yan U.S. Agent Information: Company Name: Sig Sauer, Inc. Address: 12100 SW Tualatin Rd Tualatin, OR 97062 FRN: 0026202853 Contact Name: Aaron J Schooley Telephone No: (603) 610-3889 Email: [email protected] Signature Aaron J Schooley

Ernst Apel GmbH Model Difference Model: Fokus HD50, Fokus HD50 with Laser Rangefinder, Fokus HD50 without Laser Rangefinder All the models are the same circuit and RF module, except the models names. Regards Sincerely, Client’s signature Client’s signature: Client’s name / title : Alice Yan/ Manager Am Kirschberg 3, 97218 Gerbrunn, Germany

Ernst Apel GmbH 06/01/2024 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Fokus HD 50 Thermal Camera / # AND FCC ID: 2BGQW-FOKUSHD50 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Alice Yan/ Manager Am Kirschberg 3, 97218 Gerbrunn, Germany

Ernst Apel GmbH 06/01/2024 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTA Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Alice Yan/ Manager Am Kirschberg 3, 97218 Gerbrunn, Germany

FCC ID: 2BGQW-FOKUSHD50 External Photos of the EUT FCC ID: 2BGQW-FOKUSHD50

0.7*1.5cm

FCC ID: 2BGQW-FOKUSHD50 Internal Photos of the EUT FCC ID: 2BGQW-FOKUSHD50 FCC ID: 2BGQW-FOKUSHD50 FCC ID: 2BGQW-FOKUSHD50 FCC ID: 2BGQW-FOKUSHD50 ANT FCC ID: 2BGQW-FOKUSHD50 FCC ID: 2BGQW-FOKUSHD50 FCC ID: 2BGQW-FOKUSHD50 FCC ID: 2BGQW-FOKUSHD50 FCC ID: 2BGQW-FOKUSHD50 FCC ID: 2BGQW-FOKUSHD50

RF Exposure evaluation FCC ID: 2BGQW-FOKUSHD50 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance 802.11b Channel Channel 1 Channel 07 Channel 11 Target (dBm) 6 5 5 Tolerance ±(dB) 1.0 1.0 1.0 802.11g Channel Channel 1 Channel 07 Channel 11 Target (dBm) 6 3 3 Tolerance ±(dB) 1.0 1.0 1.0 802.11n Channel Channel 1 Channel 07 Channel 11 Target (dBm) 6 3 3 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW WIFI 2.450 5 7.0 5.01 1.56<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

1. Antenna Description: Antenna type PIFA antenna Model Fokus HD50 Frequency range 2400-2500MHz Manufacturer Ernst Apel GmbH ANT Peak Gain 0.65 dBi 2. Antenna Photo: Length 25.17mm Width:9.80mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : CTA24051700401 2BGQW-FOKUSHD50 Compiled by ( position+printed name+signature) . : File administrators Jinghua Xiao Supervised by ( position+printed name+signature) . : Project Engineer Lushan Kong Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : May. 20, 2024 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : Ernst Apel GmbH Address ............................................ : Am Kirschberg 3, 97218 Gerbrunn, Germany Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Fokus HD 50 Thermal Camera Trade Mark ....................................... : Manufacturer .................................... : Ernst Apel GmbH Model/Type reference ...................... : Fokus HD50 Listed Models .................................. : Fokus HD50 with Laser Rangefinder, Fokus HD50 without Laser Rangefinder Modulation Type ............................... : CCK/DSSS/OFDM Operation Frequency ........................ : From 2412 - 2462MHz Rating ............................................... : DC 3.7V From battery and DC 5.0V From external circuit Result ............................................... : PASS Report No.: CTA24051700401 Page 2 of 48 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Fokus HD 50 Thermal Camera Model /Type : Fokus HD50 Listed Models : Fokus HD50 with Laser Rangefinder, Fokus HD50 without Laser Rangefinder Applicant : Ernst Apel GmbH Address : Am Kirschberg 3, 97218 Gerbrunn, Germany Manufacturer : Ernst Apel GmbH Address : Am Kirschberg 3, 97218 Gerbrunn, Germany Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA24051700401 Page 3 of 48 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Test Description 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 11 4.1 AC Power Conducted Emission 11 4.2 Radiated Emission 14 4.3 Maximum Peak Conducted Output Power 20 4.4 Power Spectral Density 21 4.5 6dB Bandwidth 24 4.6 Out-of-band Emissions 27 4.7 Antenna Requirement 34 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 35 6 P H O T O S O F T H E E U T ........................................................... 36 Report No.: CTA24051700401 Page 4 of 48 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: CTA24051700401 Page 5 of 48 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 …
