2BGTO-C1Tablet

C1 User Manual Tablet **Specifications and this manual are subject to change without prior notice. •Conforms to AEEE directive. This product complies with the European CE Directives 2014/53 / EU (Electromagnetic Compatibility Directive). This device complies with the Directive on Control of Waste Electrical and Electronic Equipment. Google, Android, Google Play and other brands Google Inc. is the trademark of the foundation. Processor: SC9863A Operating System: Android 14 RAM: 3GB DDR Storage: 64GB Screen: 8inch 800x1280 Display: IPS Screen and 10 points touch screen Music: MP3, AAC, AAC+, AMR-NB,etc. Video: MP4, OGM, 3GP, AVI. Etc Picture: JPG, JPEG, GIF, BMP, PNG, etc. Battery: 4000mAh, 3.8V Adapter: TYPE-C Charging, 5V, 2A Camera: Front 5.0 MP, Rear 8.0 MP Wi-Fi: 2.4G Bluetooth: BT4.2 Ports: Micro TF/Micro SIM/Type-C, 3.5mm Headphone Temperature:-10~45 Troubleshooting If you detect an unusual condition on your device, you can try to solve the problem in the description of the table. Product Box Content Tablet (Battery integrated in the device), Charger, USB Cable, User Manual General View In this user manual, the specifications given in the visuals and the parts indicated in the box contents may differ according to the model. The images are representative. 1.Volume +/Volume - 3.Mic hole 2.Front Camera 4.Power button 5.Rear Camera 6.SIM & TF Card slot 7.Speaker 8.Speaker 9.TYPE-C port 10.Headphone 6 7 8 9 10 1 2 3 4 5 Disposal of your device in an environmentally friendly manner This symbol on the product or on its packaging indicates that the product must not be treated as household waste. Instead of and delivered to the current collection point which recycles electronic equipment. This product is correct, you will be able to prevent the potential negative consequences of environment and human health arising from waste treatment of the product. Recycling of materials will help to conserve natural resources. For more information about recycling this product, please contact your local municipality, the household waste disposal service or the shop where you purchased the product. Suggestions for Energy Saving When you do not use it, turn off the device like wi-fi, blue tooth. If necessary, disable unnecessary sounds such as application notification and key sound. Depending on what you need, reducing the brightness and volume will enable you to use energy efficiently. Proper Battery Disposal (For countries with separate collection systems) The marking on the battery, the guide and the luggage compartment indicate that this pile of battery should not be disposed with other household waste. Hg, Cd or Pb chemical symbols indicate that the battery contains mercury, cadmium or lead above the ref erence values specified in EC Directive 2006/66. The battery supplied with this product can not be changed by the user. For detailed inf ormation on replacement, please contact your service provider. Do not try to remove the battery or throw it into the fire. Do not disassemble, crush or punch. If you intend to dispose of the product, necessary measures will be taken in the field of waste FCC warning: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. IC warning • English: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. • French: L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) L’appareil ne doit pas produire de brouillage; 2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. The Tablet C1 has been tested for body-worn Specific Absorption Rate (SAR) compliance. The FCC/IC has established detailed SAR requirements and has established that these requirements. RF Exposure Information The radio module has been evaluated under FCC Bulletin C95.1 and IEC/IEEE 62209-1528 and found to be compliant to RF Exposure from radio frequency devices. This model meets the applicable government requirements for exposure to radio frequency waves. The highest reported SAR level for usage near the body (0mm) is 1.44W/kg. CE Requirements: • (Simple EU declara…

Text truncated - open the document above for the full version.

Shenzhen Redbeat Technology Co., LTD 302, Building 27, Qiaocheng East Street, Xiangshan Community, Shahe Street, Nanshan District, Shenzhen Date: Jun7.2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BGTO-C1 Company:ShenzhenRedbeatTechnologyCo., LTD DesignatedAgent:FCCUSAgent,LL DesignatedAgentInformation: CompanyName:FCCUSAgent,LLC FRN:0033402884 Address:3722IllinoisAvenue,SaintCharles,IL,60174,USA ContactPerson:TimPayne Phone:708-571-3148 Email:[email protected] Sincerely US Agent – Attestation Statement / Part 2.911(d)(7) [Shenzhen Redbeat Technology Co., LTD ] certifies, that as of [Aug 7.2024 ], we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: [2BGTO-C1]. [Shenzhen Redbeat Technology Co., LTD], w i t h t h e F R N [ 0 0 3 5 5 1 4 0 5 8 ] accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of [Shenzhen Redbeat Technology Co., LTD] for FCC ID: [2BGTO-C1]. , C CompanyRepresentative:DavidChangDesignatedAgentRepresentative:TimPayne Signature:Signature:

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-9-19> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BGTO-C1 C1 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： David Chang/N/A Company: Shenzhen Redbeat Technology Co.,LTD Address: 302,Building 27,Qiaocheng East Street,Xiangshan Community,Shahe Street,Nanshan District,Shenzhen, China Phone: 18503078999 Fax: N/A E-Mail: [email protected]

Page: 1 of 3 PHOTOGRAPHSOFEUT FCCID:2BGTO-C1 Page: 2 of 3 Page: 3 of 3

Note:ThelabelisprintedontheproductbymeansofSpraypaint. Tablet FCC ID：2BGTO-C1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page: 1 of 4 PHOTOGRAPHSOFEUT FCCID:2BGTO-C1 Page: 2 of 4 Page: 3 of 4 Page: 4 of 4

Page 1 of 14 FCC ID: 2BGTO-C1 Report No.: LCSA07234085E001 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix B Detailed Test Results 1. GSM GSM850 for Body GSM1900 for Body 2. WCDMA WCDMA Band II for Body WCDMA Band IV for Body WCDMA Band V for Body 3. LTE LTE Band 2 for Body LTE Band 5 for Body LTE Band 7 for Body LTE Band 12 for Body LTE Band 40 for Body LTE Band 41 for Body LTE Band 66 for Body 4. WIFI WIFI 2.4GHz for Body Page 2 of 14 FCC ID: 2BGTO-C1 Report No.: LCSA07234085E001 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/7/25 Test Laboratory: LCS-SAR Lab GSM 850 GPRS 3TS 251CH Rear side 0mm DUT: Tablet ; Type: C1; Serial: A240723040-1 Communication System: UID 0, GPRS (0); Frequency: 848.8 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 848.8 MHz; σ = 0.933 S/m; ε r = 41.215; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(9.26, 9.26, 9.26); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: ELI v5.0; Type: ELI; Serial: 2010  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (9x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.822 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.224 V/m; Power Drift = 0.03 dB Peak SAR (extrapolated) = 1.74W/kg SAR(1 g) = 0.532 W/kg; SAR(10 g) = 0.248 W/kg Maximum value of SAR (measured) = 0.833 W/kg 0 dB = 0.833 W/kg = -0.79 dBW/kg Page 3 of 14 FCC ID: 2BGTO-C1 Report No.: LCSA07234085E001 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/7/29 Test Laboratory: LCS-SAR Lab GSM 1900 GPRS 3TS 512CH Rear side 0mm DUT: Tablet ; Type: C1; Serial: A240723040-1 Communication System: UID 0, GPRS (0); Frequency: 1850.2 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1850.2 MHz; σ = 1.441 S/m; ε r = 39.669; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(7.85, 7.85, 7.85); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: ELI v5.0; Type: ELI; Serial: 2010  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (9x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.815 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 9.987 V/m; Power Drift = 0.18 dB Peak SAR (extrapolated) = 1.63 W/kg SAR(1 g) = 0.498 W/kg; SAR(10 g) = 0.232 W/kg Maximum value of SAR (measured) = 0.804 W/kg 0 dB = 0.804 W/kg = -0.95 dBW/kg Page 4 of 14 FCC ID: 2BGTO-C1 Report No.: LCSA07234085E001 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/7/29 Test Laboratory: LCS-SAR Lab WCDMA Band II RMC 9538CH Rear side 0mm DUT: Tablet ; Type: C1; Serial: A240723040-1 Communication System: UID 0, WCDMA (0); Frequency: 1907.6 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 1907.6 MHz; σ = 1.432 S/m; ε r = 39.111; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(7.85, 7.85, 7.85); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: ELI v5.0; Type: ELI; Serial: 2010  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (9x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.914 W/kg Configuration/Unnamed procedure/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 10.45 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 1.36 W/kg SAR(1 g) = 0.612 W/kg; SAR(10 g) = 0.425 W/kg Maximum value of SAR (measured) = 0.903 W/kg 0 dB = 0.903 W/kg = -0.44 dBW/kg Page 5 of 14 FCC ID: 2BGTO-C1 Report No.: LCSA07234085E001 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/7/26 Test Laboratory: LCS-SAR Lab WCDMA Band IV RMC 1513CH Rear side 0mm DUT: Tablet ; Type: C1; Serial: A240723040-1 Communication System: UID 0, WCDMA (0); Frequency: 1752.6 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 1752.6 MHz; σ = 1.362 S/m; ε r = 41.875; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(8.16, 8.16, 8.16); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: ELI v5.0; Type: ELI; Serial: 2010  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (9x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.542…
