2BGX7-S18TWS Earphone

FCC Information This device comp怡swith pa rt 15 of the FCC Rules. Operation is subject to the following two conditions: (1) thisd创ice may not cause harmful i nterference, and (2) this device must accept arr-f interference received, including interference that may cause undesired operation. A叩changesor modifications not expressly ap prCNed by the party responsible for compliance could void the user's author时to operate t陌equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital d创心 ， pursuantto Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance wtth the instructions, may cause harmful interference to radio c ommunications. Ho,函er, there is no guarantee that interference will not occur in a pa rticular installatio八 If this equipment does cause harmful i nterfe•ence to radio ()(te厄1ision reception, which can be determined oy tuming t心equipment 011 and on, tne user iS encouraged to try to correct tne interference by one or more of the following measures: ·• Re()(ient or relocate the receiving antenna. •· In crease the se paration between the equipment and receiver. •· Connect the equipment into an outlet on a ci「cuit different from that to which the receiv呵is con nected. •—Consult the dealer or an experienced radio/ TV technician for help. IC Information 嚣s device contains licence-exempt transmitter(s)/receiver(s)妇t comply with Innovation, Science and Economic Development Can幻a'slicence-exempt RSS(s). Operation is subject to the following two conditions: 1.Thisd创icemay not cause interference. 2.This d创icemust accept any interference, including interference that m羽cause undesired operation of the device. FR L'emetteur/recepteur exempt de licence contenu dans le pr蕊entap pa reil est contorme aJx CNR d'lnnovation, Sciences et D如eloppementeconomique Ganada ap p比ablesaux appareils radio exempts de licence. L'exploitation est autoris 怂auxdeux cond巾onssuivantes 1. L' appa reil ne dolt pas produire de brouillage; 2. L' appa reil doit accepter tout brouilla g e ra业冷lectriquesubi, meme si le brouillage est susceptible d'en compromettre le fonctionnement. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Co mpany Name: TECHNITY SOLUTIONS USA INC FRN: 0028473106 Contact Name: Jerry Kao AddresS: 155 FEDERAL ST STE 700 BOSTON, MA 02110 Telephone +1(905)948-8828 Email: [email protected] Th is letter is to confirm that the US Agent for Service of Process accepts responsibility to act as a local representative on behalf of Shenzhen Ivante Technology Co., Ltd Th e US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Applicant: Company name: Shenzhen Ivante Technology Co., Ltd Product Description: TWS Earphone Grantee code: 2BGX7 FCC ID:2BGX7-S18 Contact Name: Address:401, Building A5, Area A, Fangxing Science and Technology Park,No. 13 BaonanRoad, Longgang Street, Longgang District, Shenzhen, Telephone No: +86-13751173973 Email:[email protected] The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024/07/17 Applicant’s Name:Zhongquan Yu US Agent for Service of Process’s Name: Jerry Kao Title:manager Title: Director Signature Signature Zhongquan Yu 1/1

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Ivante Technology Co., Ltd FRN:0035552124 Grantee code:2BGX7 FCC ID:2BGX7-S18 Contact Name:TWS Earphone Address:401, Building A5, Area A, Fangxing Science and Technology Park,No. 13 BaonanRoad, Longgang Street, Longgang District, Shenzhen,China Telephone No: +86-13751173973 Fax No:+86-13751173973 Email:[email protected] i.[Shenzhen Ivante Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii.[Shenzhen Ivante Technology Co., Ltd (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Ivante Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered” equipment. Date: 2024/07/17 Applicant’s Name:Zhongquan Yu Title:manager Signature 1 The Commission’sCovered Listis published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment.https://www.fcc.gov/supplychain/coveredlist

申请号： Explanation of the differences between models The application model is: S18,S19,S29,S39,S40, S41, S25,S36,S43,S45,S39P FCC ID: 2BGX7-S18 The difference between the models is only named according to market demand, and their structures and key components are exactly the same. It does not affect the safety and electromagnetic compatibility performance of the product. ShenZhen Ivante Technology Co.,Ltd 2024---07--04

C5266091_X8_Ed.1 1/1 Letter of Authorization <Shenzhen Ivante Technology Co., Ltd> Company:Shenzhen Ivante Technology Co., Ltd Address:401, Building A5, Area A, Fangxing Science and Technology Park,No. 13 BaonanRoad,Longgang Street, Longgang District, Shenzhen,China Product Name: TWS Earphone Model Number: S18,S19,S29,S39,S40, S41, S25,S36,S43,S45,S39P FCC Identifier: 2BGX7-S18 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Zhongquan YuDate: 07/17/2024 Title:manager Signature of applicant:

C5266091_X10_Ed.2 1/1 <ShenzhenIvanteTechnologyCo.,Ltd> Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 07/19/2024 Subject: Request for Confidentiality FCC ID: 2BGX7-S18 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/LocationNoNo Attestation StatementNoNo External PhotosNo ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test ReportNoNo Test Setup PhotosNo ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure InfoNoNo Operational Description ☒ ☐ Cover Letter(s)NoNo SDR Software / Security InfoNo NOTE1:Long-TermConfidentialitymaybepermittedunderspecialconditions(SeeII.LONG-TERMCONFIDENTIALITY,Section3of KDB726920,uselastinforce) NOTE2:Short-TermConfidentialitycanberequestedforamaximumof180daysfromthedateofthegrant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. ☐ C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name:Zhongquan Yu Title:manager

FCC ID: 2BGX7-S18 Page 1 / 4 EUT EXTERNAL PHOTO EUT Photo FCC ID: 2BGX7-S18 Page 2 / 4 EUT Photo EUT Photo FCC ID: 2BGX7-S18 Page 3 / 4 EUT Photo EUT Photo FCC ID: 2BGX7-S18 Page 4 / 4 EUT Photo EUT Photo

FCCID:2BGX7-S18

FCC ID: 2BGX7-S18 Page 1 / 2 EUT INTERNAL PHOTOS EUT Photo EUT Photo Geomagnetic Antenna FCC ID: 2BGX7-S18 Page 2 / 2 EUT Photo EUT Photo

HY-FCC RF EXPOSURE Ver.1.1 Page 1 of 6 Report No.: RF240625011-01-004 FCC RF EXPOSURE REPORT FCC ID: 2BGX7-S18 Test Report No...........:RF240625011-01-004 Product(s) Name.........:TWS Earphone Model(s)....................:S18, S19, S29, S39, S40, S41, S25, S36, S43, S45, S39P Trade Mark................:IVANTE Applicant...................:ShenZhen Ivante Technology Co., Ltd Address....................:Room 401, Building A5, Area A, Fangxing Science and Technology Park, No. 13 Baonan Road, Longgang Street, Longgang District, Shenzhen Receipt Date..............:2024.07.01 Test Date...................:2024.07.02~2024.07.19 Issued Date................:2024.07.19 Standards..................:CFR47 FCC Part 2: Section 2.1093; CFR47 FCC Part 1: Section 1.1310 FCC KDB Publication 447498 v06 Testing Laboratory......:Shenzhen Haiyun Standard Technical Co., Ltd. Prepared By:Checked By:Approved By: Jason huangTim zhangMisue Su HY-FCC RF EXPOSURE Ver.1.1 Page 2 of 6 Report No.: RF240625011-01-004 History of this test report Original Report Issue Date: 2024.07.19 ● No additional attachment ○ Additional attachments were issued following record Attachment No.Issue DateDescription HY-FCC RF EXPOSURE Ver.1.1 Page 3 of 6 Report No.: RF240625011-01-004 1.. TEST FACILITY Company: Shenzhen Haiyun Standard Technical CO., Ltd. Address: No. 110-113, 115, 116, Block B, Jinyuan Business Building, Bao'an District, Shenzhen, China CNAS Registration Number:CNAS L18252 CAB identifier:CN0145 A2LA Certificate Number:6823.01 Telephone: 0755-26024411 HY-FCC RF EXPOSURE Ver.1.1 Page 4 of 6 Report No.: RF240625011-01-004 2.. MPE CALCULATION METHOD For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√ f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR,30 where  f(GHz) is the RF channel transmit frequency in GHz HY-FCC RF EXPOSURE Ver.1.1 Page 5 of 6 Report No.: RF240625011-01-004 TEST RESULTS Table for Filed Antenna For BDR+EDR Ant.BrandAntenna TypeConnectorGain (dBi) 1N/AGeomagneticN/A3.00 Frequency Conducted Peak Powert Conducted Peak Powert Operating Mode (MHz)(dBm)(mW) BDR+EDR2402-2480-0.110.97 Measurement Record: The minimum distance for the EUT is less than 5mm. Since maximum peak output power of the transmitter is -0.11 dBm ≈ 0.97 mW < = 9.52 mW. Hence the EUT is excluded from SAR evaluation according to FCC KDB Publication 447498 D01 General RF Exposure Guidance v06. Conclusion Result: Complies HY-FCC RF EXPOSURE Ver.1.1 Page 6 of 6 Report No.: RF240625011-01-004 Statement 1. The report is invalid without the official seal or special seal of Shenzhen Haiyun Standard Technology Co., Ltd. (hereinafter referred to as the unit). 2. The report is invalid without the signature of the approver. 3. The report is invalid if altered arbitrarily. 4. The report shall not be partially copied without the written approval of the unit. 5. The reported test results are only valid for the tested samples. 6. If there is any objection to the test report, it shall be submitted to the test unit within 15 days from the date of receiving the report, and the overdue shall not be accepted. Shenzhen Haiyun Standard Technology Co., Ltd. Address: Room 110, 111, 112, 113, 115, 116, Block B, Jinyuan Business Building, No. 302, Xixiang Avenue, Labor Community, Xixiang Street, Baoan District, Shenzhen, China Tel: 0755-26024411 Email: [email protected] （END OF REPORT）
