2BGZ8-EB621Magnetic Wireless Power Bank

Design in California Manufactured in China User Manual Strong Magnetic Smart ChipSafety Protection Digital Display This wireless charger is not compatible with non-MagSafe phone cases, such as Otterbox Defender cases. Do not use an adapter with an output of 5V/1A (5W) or less. Both the protective phone case and the position of your device on the wireless charger will affect the charging speed. The farther it is placed from Wireless chargers make charging more convenient than wired chargers, but confined by current wireless technology, their charging speed is slower than that of wired chargers. High temperatures will reduce charging speed and restrict power, which is something that happens to all wireless chargers. It is recommended that you charge your device in environments with temperatures below 25°C / 77°F. the center of the wireless charger, the slower the charging speed will be. EB621 (with TYPE-C and Lightning Cable) Product Name: EB621 Magnetic Power Bank Cell Type: Lithium Polymer Battery Type-C Port Input: DC5V-3A / 9V-2.2A / 12V-1.5A Type-C Cable Output: DC5V-3A / 9V-2.2A / 12V-1.5A Lightning Cable Output: DC5V-3A / 9V-2.2A / 12V-1. 5A Wireless Output: 2.5W / 7.5W / 10W / 15W LED Dispaly Lightning Cable Type-C Cable IMPORTANT SAFETY INSTRUCTIONS When using this product, basic precautions should always be followed, including the following: 1) Store the product in a cool, dry place. 2) Do not store the product in a hot or humid environment. 3) Use of a power supply or charger not recommended or sold by the product manufacturer may result in a risk of fire or injury to persons. 4) Operating temperature should be between 0°C to 40°C / 32°F to 104°F. 5) Do not disassemble the product. Take it to a qualified service person when service or repair is required. Incorrect reassembly may result in a risk of fire or injury to persons. 6) If the product is not used for long periods of time, you should charge and discharge it once every three months. 7) When charging a device, the product may feel warm. This is a normal operating condition and should not be a cause for concern. 8) In normal conditions, the battery performance will decline over several years. 9) Do not dispose of the product in heat or fire. 10) Do not clean the product with harmful chemicals or detergents. 11) Misuse, dropping, or excessive force may cause product damage. 12) When disposing of secondary cells or batteries, keep cells or batteries of different electrochemical systems separate from each other. 13) Be aware that a discharged battery may cause fire or smoke. Tape the terminals to insulate them. User Guide : 1.Can be used as a magnetic wireless power bank, compatible with iPhone, Android phone, smart watch and other devices that support wireless charging. 2.Functions as a universal wireless charging power bank, compatible with all QI wireless charging protocol phones, including OP, HW, XM, SAM, and more. 3.Serves as a portable and compact power bank, supporting charging for over 99% of phones. Packing List ►Power Bank *1 ►User Manual *1 ►Charging Cable *1 Product Features ►15W wireless output, magnetic wireless fast charging ►PD+QC 22.5W fast charging ►Simultaneous charging and discharging, synchronous fast charging for both phone and power bank ►LED digital power indicator, accurately displays battery level. High FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio / TV technician for help. quality polymer battery cells for safety and peace of mind. ★Thank you for choosing our product. ★For the best experience, please read this manual carefully. ★If you need support, contact us anytime. ★We value your feedback. Your suggestions help us improve. Reach out to us at: Email: [email protected] ★Thanks again for your trust and support. ★Enjoy your product!

ShenzhenEchargertechnologyCo.,LTD. 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:ShenzhenEchargertechnologyCo.,LTD. Address:No.12,YulingWestRoad,LongchengStreet,LonggangDistrict,Shenzhen,Guangdong Province,China ProductName:MagneticWirelessPowerBank FCCID:2BGZ8-EB621 Model(s):EB621 2.911(d)(5)(i)EquipmentType We,[ShenzhenEchargertechnologyCo.,LTD.](“theapplicant”)certifythattheequipmentfor whichauthorizationissoughtthroughcertificationisnot:  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:ArkayHuangDate:2024-06-21 TitleandCompanyname:sales/ShenzhenEchargertechnologyCo.,LTD. NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

ShenzhenEchargertechnologyCo.,LTD. 2.911(d)(5)(ii)ApplicantAttestationv1.3 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:ShenzhenEchargertechnologyCo.,LTD. Address:No.12,YulingWestRoad,LongchengStreet,LonggangDistrict,Shenzhen,Guangdong Province,China ProductName:MagneticWirelessPowerBank FCCID:2BGZ8-EB621 Model(s):EB621 2.911(d)(5)(ii)Applicantfiling We,[ShenzhenEchargertechnologyCo.,LTD.](“theapplicant”)certifythat,asofthedateofthe filingoftheapplication,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 ,established pursuantto§1.50002ofthischapter,asanentityproducingcoveredcommunicationsequipment. Yourssincerely, Name:ArkayHuangDate:2024-06-21 TitleandCompanyname:sales/ShenzhenEchargertechnologyCo.,LTD. NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the ShenzhenEchargertechnologyCo.,LTD. 2.911(d)(5)(ii)ApplicantAttestationv1.3

Shenzhen Echarger technology Co., LTD. U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (Baihetian Innovative Solutions) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: June 27, 2024 Signed by (Printed Name/Title): Kenneth Young/Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Shenzhen Echarger technology Co., LTD. FRN: 0035567478 Grantee Code: 2BGZ8 Contact Name: ArkayHuang Street Address: No. 12, Yuling West Road, Longcheng Street, Longgang District City/Province/Zip: Shenzhen, Guangdong Province, China Telephone No: 8615814462693 Email: [email protected] Applicant Signature: Date:2024-06-26 Signed by (Printed Name/Title): ArkayHuang / sales FCC ID: 2BGZ8-EB621 June 2024

ShenzhenEchargertechnologyCo.,LTD. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2024-06-21 Subject;RequestforLongTermConfidentiality FCCID:2BGZ8-EB621 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:ArkayHuang Title:sales

ShenzhenEchargertechnologyCo.,LTD. AgentAuthorization Company:ShenzhenEchargertechnologyCo.,LTD. Address:No.12,YulingWestRoad,LongchengStreet,LonggangDistrict, Shenzhen,GuangdongProvince,China ProductName:MagneticWirelessPowerBank ModelNumber(s):EB621 ProductDescription:MagneticWirelessPowerBank WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2024-06-21 Name:ArkayHuang Title:sales Company:ShenzhenEchargertechnologyCo.,LTD.

clientShenzhenEchargertechnologyCo.,LTD. TYPEWirelesschargingandtransmittingcoils ModelNOA11 Date2024.6.5 1.WindingProcese: NOwindingSpecifications Number ofturns Winding direction remark 1N12UEW-B-0.08*24*2P12TSCCW 2 2．FEATURES: 1.Testconditions）：25°C,65%RH@100KHz/1V 1.1Inductance 1.11L0A(Coil+magneticsheet)=7.0uH±5% 1.2Q=50MIN 1.3DCR：60mΩMAX 1.4OperatingTemperature：-25°C~85°C 2.Testinstrument：L:Chuangda1068+1310;DCR:502BC;SIZE:Callipers 3.BillofMaterials 3．CIRCUITDIAGRAM Unit:MM 4．OUTSIDEDIAGRA ABCDEFG STD 43.5±0.538.5±0.514±0.28±0.240±23±11.8±0.3 N O projectmaterial 1WIRE￠ 0.08*24*2p2UEW- 2FERRITE 43.5*8*0.8L 3GLUEWater-basedwhiteglue 4SOLDERHQ-996/JS-996 5TinPureTin 6 High temperature adhesive 5MMHightemperaturetape 7 8 Unit:MM 5.PACKAGE 5.2 Thepackagingshallbebasedontheexustingpackingplateandtheactualdeliverypackage shallprevail.Ifthereisanyrequirement,wecancustomizeit. 6、StorageandUsecondition 6.1Storagecondition 6.1.1 Recommendedkeepingconditions:-25°C~85°C,70%RH(Max.) 6.1.2 Storagelife:Withinthelimitsofsixmonthsfrombeing produced. 6.2Usecondition Useconditionlimit:T=-25°C~85°C,RH≤90%.

Page 1 of 3 Appendix B: Photographs of EUT Product: Magnetic Wireless Power Bank Model: EB621 External Photos Page 2 of 3 Page 3 of 3

LabelArtworkandLocation Model:EB621 Label: Size:L*W=20*14mm MagneticWirelessPowerBank Model:EB621 Capacity:10000mAh（3.85V/38.5WH） USB-CInput:5V-3A/9V-2.2A/12V-1.5A（Max） USB-CCableInput:5V-3A/9V-2.2A/12V-1.5A（Max） USB-CCableOutput:5V-3A/9V-2.2A/12V-1.5A（Max） LightningCableOutput:5V-3A/9V-2.2A/12V-1.5A（Max） WirelesschargerOutput:2.5W/5W/7.5W/10W/15W ShenzhenEchargerTechnologyCo.,Ltd. CEROHSFCCPSE(株式会社技研) MADEINCHINA FCCID:2BGZ8-EB621 Location

Page 1 of 3 Appendix B: Photographs of EUT Product: Magnetic Wireless Power Bank Model: EB621 Internal Photos Page 2 of 3 Antenna Page 3 of 3

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2BGZ8-EB621 Test Report No. ............... : TCT240607E023 Date of issue ................... : Jun. 21, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory, Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen Echarger technology Co., LTD. Address ........................... : No. 12, Yuling West Road, Longcheng Street, Longgang District, Shenzhen, Guangdong Province, China Manufacturer's name ... : Shenzhen Echarger technology Co., LTD. Address ........................... : No. 12, Yuling West Road, Longcheng Street, Longgang District, Shenzhen, Guangdong Province, China Standard(s) ..................... : FCC CFR Title 47 Part 1.1310 KDB 680106 D01 RF Exposure Wireless Charging App v04 Product Name ................. : Magnetic Wireless Power Bank Trade Mark ...................... : N/A Model/Type reference..... : EB621 Rating(s).......................... : Rechargeable Li-ion Battery DC 3.85V Date of receipt of test item ......................................... : Jun. 07, 2024 Date (s) of performance of test ................................... : Jun. 07, 2024 ~ Jun. 21, 2024 Tested by (+signature) ... : Onnado YE Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240607E023 Page 2 of 17 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Technical Requirements Specification .................................................. 6 4.1. Requirements ......................................................................................................... 6 4.2. Test Setup .............................................................................................................. 7 4.3. Test Procedure ...................................................................................................... 8 4.4. Test Instruments List ............................................................................................ 8 4.5. Test Result ............................................................................................................. 9 4.6. Test Set-up Photo ................................................................................................ 12 Report No.: TCT240607E023 Page 3 of 17 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Magnetic Wireless Power Bank Model/Type reference........... : EB621 Sample Number....................: TCT240607E022-0101 Operation Frequency ........... : 115.38kHz ~ 135.90kHz Output power.....................: 15W Modulation Technology ....... : Load modulation Antenna Type ........................ : Inductive loop coil Antenna Rating(s)................................ : Rechargeable Li-ion Battery DC 3.85V 1.2. Model(s) list None. Report No.: TCT240607E023 Page 4 of 17 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Operating Environment: Condition Conducted Emission Radiated Emission Temperature: 22.8 C 24.6 C Humidity: 49 % RH 49 % RH Atmospheric Pressure: 1010 mbar 1010 mbar Test Mode: AC mode Type-C Input + wireless discharging (battery status>95%) Type-C Input + wireless discharging (battery status<50%) Type-C Input + wireless discharging (battery status<1%) Internal Battery Mode Wireless charging (battery status>95%) Wireless charging (battery status<50%) Wireless charging (battery status<1%) The sample was placed 0.8m for the measurement below 1GHz above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating the turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case(Z axis) are shown in Test Results of the following pages. Report No.: TCT240607E023 Page 5 of 17 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, certified, or accredited by the following organi…

Text truncated - open the document above for the full version.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2BGZ8-EB621 Test Report No. ............... : TCT240607E022 Date of issue ................... : Jun. 21, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory, Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen Echarger technology Co., LTD. Address ........................... : No. 12, Yuling West Road, Longcheng Street, Longgang District, Shenzhen, Guangdong Province, China Manufacturer's name ... : Shenzhen Echarger technology Co., LTD. Address ........................... : No. 12, Yuling West Road, Longcheng Street, Longgang District, Shenzhen, Guangdong Province, China Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart C Product Name ................. : Magnetic Wireless Power Bank Trade Mark ...................... : N/A Model/Type reference..... : EB621 Rating(s).......................... : Rechargeable Li-ion Battery DC 3.85V Date of receipt of test item ......................................... : Jun. 07, 2024 Date (s) of performance of test ................................... : Jun. 07, 2024 ~ Jun. 21, 2024 Tested by (+signature) ... : Onnado YE Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240607E022 Page 2 of 28 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. Test Result Summary .............................................................................. 4 3. General Information ................................................................................. 5 3.1. Test environment and mode ................................................................................. 5 3.2. Description of Support Units ................................................................................ 5 4. Facilities and Accreditations .................................................................. 6 4.1. Facilities ................................................................................................................. 6 4.2. Location ................................................................................................................. 6 4.3. Measurement Uncertainty ..................................................................................... 6 5. Test Results and Measurement Data ..................................................... 7 5.1. Antenna requirement ............................................................................................ 7 5.2. Conducted Emission ............................................................................................. 8 5.3. Radiated Spurious Emission Measurement ...................................................... 12 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT240607E022 Page 3 of 28 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Magnetic Wireless Power Bank Model/Type reference........... : EB621 Sample Number....................: TCT240607E022-0101 Operation Frequency ........... : 115.38kHz ~ 135.90kHz Output power ........................ : 15W Modulation Technology ....... : Load modulation Antenna Type ........................ : Inductive loop coil Antenna Rating(s)...............................: Rechargeable Li-ion Battery DC 3.85V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. Report No.: TCT240607E022 Page 4 of 28 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Spurious Emission §15.209(a)(f) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT240607E022 Page 5 of 28 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. General Information 3.1. Test environment and mode Operating Environment: Condition Conducted Emission Radiated Emission Temperature: 22.8 C 24.6 C Humidity: 49 % RH 49 % RH Atmospheric Pressure: 1010 mbar 1010 mbar Test Mode: Mode 1 AC/DC adapter(DC 9V) + EUT + Mobile Phone (battery status>95%) Mode 2 AC/DC adapter(DC 9V) + EUT + Mobile Phone (battery status<50%) Mode 3 AC/DC adapter(DC 9V) + EUT + Mobile Phone (battery status<1%) Remark All modes have been tested. The worst mode (Mode 1) reported for Conducted emission test and The worst mode (Mode 1) reported for Radiated emission test The sample was placed 0.8m for the measurement below above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: h…

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Magnetic Wireless Power Bank Model: EB621 Radiated Emission Page 2 of 2 Conducted Emission
