2BGZI-L969IINE Wireless Controller

IINE Athena Wireless Controller in White Instructions Before Use Before using the controller, it is important to follow these preparation steps to ensure optimal performance and functionality. Compatibility Switch,Phone,Pad,PC Note: Can only support native gamepad games on iOS APP Store Check steps 1.Package Checking Before commencing the use of this controller, it is essential to check its integrity. Open the packaging and carefully inspect the product's appearance and accessories for completeness. In the event of any damage or omission, please contact customer service. 2.Controller Inspection Before proceeding with the setup, check that the controller min good condition and has no operate seamlessly.obvious damage or cracks. 3.Check the Hardware Check if the buttons are not sticking, the joysticks rotate smoothly, and the trigger buttons Reconne 4.Reading the Product Manual Before using the product, carefully read the instruction manual. It provides essential information, usage guidelines, and important considerations. Thoroughly understanding the manual helps grasp the product's features, functions, and prevents unnecessary mistakes. Hold the with vibr 5.Power Supply and Charging Cable Checking The LED ligh If reconnectExamine the included charging cable for any issues. Firstly, inspect its appearance for abnormalities. Next, connect the charging cable to the charger and assess its functionality to ensure there are no issues. 6.Environment When using this product, it's crucial to ensure the safety of the operating environment. For instance, extreme temperatures or high humidity may impact its performance. Before usage, assess the operating environment and take necessary safety precautions. 7.Installation Match the installation with the corresponding model and refrain from forcefully installing it on models not intended for this product. Follow the specified instructions for a proper and correct installation. How to Connect Switch First Connection ●Press and hold the [Pairing] button for 5s, LED1-LED4 lights will flash rapidly. ●Select [Controller] - [Change Grip/Order] to complete the pairing, the LED light will stay on steadily. Reconnect to Switch ●Hold the [HOME] button for 2s until the LED lights up; with vibration feedback upon successful pairing. (The LED light flash, automatically connecting to the paired Switch console. If reconnection fails within 10s, it will automatically enter sleep mode.) Controller Automatically Sleeps ●The console screen goes off, and the controller goes to sleep on its own. ●If there's no activity for 5 minutes, the controller will enter sleep mode automatically. ●In Bluetooth mode, hold down the [HOME] button for 3s, choose the console's sleep option, and go into sleep mode. Wake-up the Controller ●Wake up the console by pressing the (HOME] button for 2s. (The SWITCH console is in sleep mode (not in airplane mode). PC Connection Wireless Connections 1.Press and hold the [Pairing] + [X] button for 3s. 2. Open the computer system settings, select Bluetooth and other devices and connect. 3. Choose the Xbox Wireless Controller, and upon successful connection, the LED3 will always on. Wired Connections 1.1.Plug USB into the computer and automatically identify the PC platform 2. After successful connection, LED 1 and LED 4 will flash. (By default, it is in Xinput mode. In Xinput mode, long-press the '-' and '+' buttons for 3s to switch to Dinput mode.) Phone/Tablet Connection Android 1.Open phone settings and select Bluetooth 2.Long-press the [Pairing] +[Y] buttons for 3s to enter pairing mode. Upon successful connection, LED4 will stay on (Compatible with games like Don't Starve, Minecraft, and Wreckfest, etc.) IOS 1.Open phone settings and select Bluetooth 2.Long-press the [Pairing]+[X] buttons for 3s to enter pairing mode. Upon successful connection, LED3 will stay on (Compatible with iOS native games such as Don't Starve, Minecraft, Wreckfest, etc.) Controller Function Settings Controller macro function (set macros for one-button combo execution) 1.Hold the [XR] or [XL] button for 3s until the controller vibrates to enter macro custom recording. 2. Press the action button which you need to set in turn (Support to record the time interval between buttons.) 3. Press [XR] or [XL] button to complete the macro setting. 4. Hold down [XR]/[XL] for 8s to clean all macro settings. How to Setup Macro Functions? Press forXR/XL3s MR/ML can be set as a combination key, simultaneously remembering the buttons and intervals. Once configured, it allows for one-button execution of combo moves.(XL/XR supports recording 63 key values each.) Turbo/Auto-fire Settings 1.Hold down [Turbo] + any action button for manual fire setup; 2.Repeat the first step to set auto fire; 3.Repeat the operation for the third time to cancel the Turbo. Hold [Turbo] for 5s (with vibration feedback) to clean all turbo settings. Long press Turbo Set the Auto-fire to realize automatic combos with controller Burst Rate Adjustment: Long brest [Turbo] + [+] buttons to vibrate and accelerate the firing rate.) (Press [Turbo] + [-] buttons to vibrate and decelerate the firing rate.) 1st gear: 5/s 2nd gear: 12/s 3rd gear: 20/s Vibration Adjustment Default 0%-30%-50%-70%-100% Upshift:Long press [Turbo] + push up [Left Joystick] Downshift:Long press [Turbo] + push down [Left Joystick] Switching ABXY Layout ●Hold the [Turbo] + [Left Joystick] for 2s to change to XBOX button layout. (Successful switch will have vibration feedback.) Charging Instructions (Controller Off Status) Charging (LED4 flashes) Full Charge (LED4 always on) Charging (Indicator light flashes) Full Charge Full Charge (Indicator light always on) Routine maintenance ●About Charging: Recommend to use the 5V 1A charger to prevent damage to the controller circuit, and avoid high-power or PD fast charging chargers due to different charging protocols. ●Dust Prevention: To prevent joystick drifting caused by dust, use a storage bag or other protect…

Text truncated - open the document above for the full version.

(Dongguan Liangzhi Electronic Co., Ltd.) (2024.6.25) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BGZI-L969) [Dongguan Liangzhi Electronic Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) YongXin Shan (Dongguan Liangzhi Electronic Co., Ltd.) (2024.6.25) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BGZI-L969) [Dongguan Liangzhi Electronic Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) YongXin Shan

Dongguan Liangzhi Electronic Co., Ltd. 2024.6.25 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: IINE Wireless Controller Trademark: IINE MODEL: L969 FCC ID: 2BGZI-L969 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : YongXin Shan / Product manager Contact information / address: Room 1409, Building 3, NO.2, Research And Development Fifth Road, Songshan Lake District, Dongguan City, Guangdong Province, China

Dongguan Liangzhi Electronic Co., Ltd. Model Difference 2024/6/25 EUT NAME: IINE Wireless Controller Trademark: IINE MODEL: L969 L972, L1001, L1002, L1003 FCC ID: 2BGZI-L969 All the models are the same circuit and RF module, except model names and appearance of the color. Regards Sincerely Client’s signature: Client’s name / title : YongXin Shan / Product manager Contact information / address: Room 1409, Building 3, NO.2, Research And Development Fifth Road, Songshan Lake District, Dongguan City, Guangdong Province, China

External Photos

Label & label location Label: FCC ID: 2BGZI-L969

DongguanLiangzhiElectronicCo.,Ltd. 2024.6.25 EurofinsElectricalandElectronicTestingNA,Inc. 914W.PatapscoAvenue Baltimore,MD21230 USA RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorizeShenzhenBCTCTestingCo.,Ltdtoactonourbehalfinall mattersrelatingtoapplicationforequipmentauthorization,includingthesigningofalldocuments relatingtothesematters. Wealsoherebycertifythatnopartytotheapplicationauthorizedhereunderissubjecttothe denialofbenefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseAct of1988,21U.S.C.853(a). Thisagreementexpiresoneyearfromthecurrentdate. Sincerely, Client’ssignature: Client’sname/title:YongXinShan/Productmanager Contactinformation/address:Room1409,Building3,NO.2,ResearchAndDevelopmentFifth Road,SongshanLakeDistrict,DongguanCity,GuangdongProvince,China

Internal Photos Antenna

RF EXPOSURE EVALUATION METHOD FCC ID: 2BGZI-L969 Applicable standard： In accordance with FCC 47 CFR part 2 (2.1093) this device has been defined as a portable device which is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable devices must be evaluated using the specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEEC95.1-1992. and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528-2003. Per FCC KDB 447498 D01 v06, the 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances s 50 mm are determined by: SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BLE Frequency Maximum Conducted Output Power(PK) Conducted Output Power Limit (MHz) (dBm) dBm GFSK 2402 1.14 30 2440 -2.35 30 2480 -3.42 30 max possible output power (PK,conducted)：1±1dBm 2dBm=1.58mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 6.31/5*√2.402=0.490≤3.0 2440MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 6.31/5*√2.44=0.494≤3.0 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 6.31/5*√2.48=0.498≤3.0 Conclusion: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0. 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required. BT Frequency Maximum Conducted Output Power(PK) Conducted Output Power Limit (MHz) (dBm) dBm GFSK 2402 -1.98 21 2441 -2.41 21 2480 -2.79 21 π/ 4 DQPSK 2402 1.12 21 2441 0.6 21 2480 -0.41 21 8DPSK 2402 1.61 21 2441 1.18 21 2480 0.11 21 max possible output power (PK,conducted)：2±1dBm 3dBm=2mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 6.31/5*√2.402=0.620≤3.0 2441MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 6.31/5*√2.441=0.625≤3.0 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 6.31/5*√2.48=0.630≤3.0 Conclusion: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0. 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required.

Antenna Specification Item Specification Model Name PCB-Antenna ZXD1888 Frequency 2400-2500MHz Manufacture Shenzhen Zhixu Technology Co., LTD Dimensions 11.8*5.4 mm B.1 3D Pattern B.2 1D Radiation Pattern B2.1 PHI=0 B2.2 PHI=90 B2.3 THETA=90
