2BH22BSE-D2Bidirectional remote control

B3003OperatingManual （220919_V1.0） Instructionsondisplaysofthepanelinthestandby mode: Longpressthepowerbuttontopoweronafterconnectingthebatteryforthefirsttime. Display:Pleasewaittoconnectthehost. Screenwillturnoffafternopressfor15Sandpressanybuttontowakeup. Afterthecodematchingissuccessfullyfinished,paneldisplaysmaininterface(shortpresstheconfirmbuttontoswitch displayandcanbeswitchedcyclically): Displayofambienttemperature→displayofpowersupplyvoltage→displayofgear/temperaturesetting→displayofshell temperature. Instructionsonbutton operating Standbymode Longpressthepowerbutton:poweronandthepaneldisplaysstart. Shortpresstheconfirmbutton:cyclicallyswitchthedisplays. Shortpresstheupbutton:temperature/gear+1. Shortpressthedownbutton:temperature/gear-1. Poweronmode Shortpresstheconfirmbutton:cyclicallyswitchthedisplays. Shortpresstheupbutton:temperature/gear+1. Shortpressthedownbutton:temperature/gear-1. Longpressthepowerbutton:poweroffandthepaneldisplaysshutdown. Instructionsonremotecontrol codematching Standbymode Pressthepowerbuttonandconfirmbuttonatthesametimeforremotecontrolcodematching,anditwillenterthemain interfaceafterthecodematchingissuccessfullyfinished.Incaseofcodematchingfailure,exitwithin20secondsorpressthe confirmbuttontoexit,andthencodematchingcanbereperformed. Instructionsonmanualgear controlmode/autoconstant temperaturemode Standbymode/power onmode Presstheupbuttonanddownbuttonatthesametimetoentertheconstanttemperaturemodeinwhichthepaneldisplays Auto.Pressagaintoswitchtothemanualgearcontrolmode,andthedisplayonthepanelismanual(defaultforthemanual mode). LanguageSwitching Instructions Standbymode Longpressthe“confirmbutton”toentertheEnglishmode,ChinesemodeandRussianmode,whichcanbeswitched cyclically. InstructionsonscreenoffInthepoweron/offmode,thescreenwillturnoffafternopressfor15Sandpressanybuttontowakeup. FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Wen’an County Luerda Automotive Parts Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-08-29 FCC ID: 2BH22BSE-D2 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Wen’an County Luerda Automotive Parts Co., Ltd certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Wen’an County Luerda Automotive Parts Co., Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: Wen’an County Luerda Automotive Parts Co., Ltd Address: Bosha’er Auto Parts, Huangli Village, Daliu Town, Wen’an County, Langfang City, Hebei Province, China Contact Person: Jianhua Liu Tel.: 13790607805 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2024-09-03 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2BH22BSE-D2) Wen’an County Luerda Automotive Parts Co., Ltd, the undersigned, hereby authorize REP America LLC to act as our designated U.S. agent for service of process, Wen’an County Luerda Automotive Parts Co., Ltd accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. REP America LLC accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Wen’an County Luerda Automotive Parts Co., Ltd Contact Name: Jianhua Liu Address: Bosha’er Auto Parts, Huangli Village, Daliu Town, Wen’an County, Langfang City, Hebei Province, China Telephone No: 13790607805 Email: [email protected] FRN: 0035757210 Signature: Jianhua Liu U.S. Agent Information: Company Name: REP America LLC Address: REP America LLC, Ben XU, 6510 S Academy Blvd, Ste A #523, Colorado Springs,C0 80906 FRN: 0034192500 Contact Name: BenXu

Summary ANTENNA SPECIFICATION ITEM ANT SPEC Model Name 433MHz ANT Antenna plate Spring antenna FREQUENCE RANGE 400‐470MHz Gain 6DBI Polarization Horizontal and Vertical Impedance 50 Ohm SWR ≦2 Antenna Photo & Length (mm) SWR:1.875 (CENTER FREQ:433MHz)

Wen’an County Luerda Automotive Parts Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 29, 2024 Subject; Request for Confidentiality FCC ID: 2BH22BSE-D2 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jianhua Liu Title: Manager

Page 1 of 3 Report No.: LGT24G155 Appendix - External Photographs of EUT Constructional Details Model: BSE-D2 Photo 1 Photo 2 Page 2 of 3 Report No.: LGT24G155 Photo 3 Photo 4 Page 3 of 3 Report No.: LGT24G155 Photo 5 Photo 6

Page 1 of 2 Report No.: LGT24G155 Appendix - Internal Photographs of EUT Constructional Details Model: BSE-D2 Photo 1 Photo 2 Antenna Page 2 of 2 Report No.: LGT24G155 Photo 3

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: Bidirectional remote control Model Name: BSE-D2 FCC ID: 2BH22BSE-D2 Issued For : Wen'an County Luerda Automotive Parts Co., Ltd Bosha'er Auto Parts, Huangli Village, Daliu Town, Wen'an County, Langfang City, Hebei Province Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24G155HA01 Sample Received Date: Jul. 23, 2024 Date of Test: Jul. 23, 2024 – Aug. 28, 2024 Date of Issue: Aug. 28, 2024 Report No.: LGT24G155HA01 Page 2 of 9 TEST REPORT CERTIFICATION Applicant: Wen'an County Luerda Automotive Parts Co., Ltd Address: Bosha'er Auto Parts, Huangli Village, Daliu Town, Wen'an County, Langfang City, Hebei Province Manufacture: Wen'an County Luerda Automotive Parts Co., Ltd Address: Bosha'er Auto Parts, Huangli Village, Daliu Town, Wen'an County, Langfang City, Hebei Province Product Name: Bidirectional remote control Trademark: N/A Model Name: BSE-D2 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24G155HA01 Page 3 of 9 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 APPENDIX I - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS 9 Report No.: LGT24G155HA01 Page 4 of 9 Revision History Rev. Issue Date Revisions 00 Aug. 28, 2024 Initial Issue Report No.: LGT24G155HA01 Page 5 of 9 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: Bidirectional remote control Trademark: N/A Model Name: BSE-D2 Series Model: N/A Model Difference: N/A Frequency Bands: 433.917MHz Battery: Rated Voltage: 3.0V Hardware Version: N/A Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT24G155HA01 Page 6 of 9 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Report No.: LGT24G155HA01 Page 7 of 9 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT24G155HA01 Page 8 of 9 2.3 TEST RESULT Turn up Result Worse case is as below: Note:The maximum Equivalent Isotropic Radiated Power : 84.06dBuV/m-95.2=-11.14dBm (refer to C63.10, section 10.3.9)(433.93MHz) Mode Turn up Power 433.9MHz -11±1dBm The MPE result of worst mode: Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) Estimated SAR Limit Ratio Result 433.9 -10.00 0.10 0.013 3 0.004 Pass Note: 1. The estimated SAR≤ 3.0 for 1-g SAR, Separation distance ≤ 5mm, complies with the exemption requirements. Report No.: LGT24G155HA01 Page 9 of 9 APPENDIX I - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Note: Please see the attached BSE-D2_External Photos and BSE-D2_Internal Photos. ※※※※※END OF THE REPORT※※※※※

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: Bidirectional remote control Model Name: BSE-D2 FCC ID: 2BH22BSE-D2 Issued For : Wen'an County Luerda Automotive Parts Co., Ltd Bosha'er Auto Parts, Huangli Village, Daliu Town, Wen'an County, Langfang City, Hebei Province Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24G155RF01 Sample Received Date: Jul. 23, 2024 Date of Test: Jul. 23, 2024 –Sep. 03, 2024 Date of Issue: Sep. 03, 2024 Report No.: LGT24G155RF01 Page 2 of 31 TEST REPORT CERTIFICATION Applicant: Wen'an County Luerda Automotive Parts Co., Ltd Address: Bosha'er Auto Parts, Huangli Village, Daliu Town, Wen'an County, Langfang City, Hebei Province Manufacture: Wen'an County Luerda Automotive Parts Co., Ltd Address: Bosha'er Auto Parts, Huangli Village, Daliu Town, Wen'an County, Langfang City, Hebei Province Product Name: Bidirectional remote control Trademark: N/A Model Name: BSE-D2 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.231, Subpart C ANSI C63.10-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24G155RF01 Page 3 of 31 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 14 4.1 RADIATED EMISSION LIMITS 14 4.2 TEST PROCEDURE 16 4.3 DEVIATION FROM TEST STANDARD 16 4.4 TEST SETUP 17 4.5 EUT OPERATING CONDITIONS 18 4.6 TEST RESULTS 18 4.7 FIELD STRENGTH CALCULATION 19 5. BANDWIDTH TEST 23 5.1 LIMIT 23 5.2 TEST REQUIREMENTS 23 5.3 TEST PROCEDURE 23 5.4 TEST SETUP 23 5.5 EUT OPERATION CONDITIONS 23 5.6 TEST RESULTS 24 6. DUTY CYCLE 25 6.1 TEST PROCEDURE 25 6.2 TEST SETUP 25 6.3 EUT OPERATION CONDITIONS 25 6.4 TEST RESULTS 26 Report No.: LGT24G155RF01 Page 4 of 31 TABLE OF CONTENTS Page 7. AUTOMATICALLY DEACTIVATE 28 7.1 STANDARD REQUIREMENT 28 7.2 TEST PROCEDURE 28 8. ANTENNA REQUIREMENT 30 8.1 STANDARD REQUIREMENT 30 8.2 EUT ANTENNA 30 APPENDIX I - PHOTOS OF TEST SETUP 31 Report No.: LGT24G155RF01 Page 5 of 31 Revision History Rev. Issue Date Revisions 00 Sep. 03, 2024 Initial Issue Report No.: LGT24G155RF01 Page 6 of 31 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part 15.231, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A -- 15.205(a)/15.209/ 15.231.(b) Radiated Spurious Emission PASS -- 15.231(a)(1)/ 15.231(b)(2) Transmission requirement PASS -- 15.231(C) 20 dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Report No.: LGT24G155RF01 Page 7 of 31 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. Parameter Uncertainty RF Output Power, Conducted ±0.71dB Unwanted Emission, Conducted ±0.63dB Conducted emission ±2.80dB All Emissions, Radiated (0.009-30MHz) ±2.16dB All Emissions, Radiated (30MHz-1GHz) ±4.40dB All Emissions, Radiated (1GHz-18GHz) ±5.49dB Note: The measurement uncertainty is not included in the test result. Report No.: LGT24G155RF01 Page 8 of 31 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: Bidirectional remote control Trademark: N/A Model Name: BSE-D2 Series Model: N/A Model Difference: N/A Frequency band: 433.917MHz Battery: Rated Voltage: 3.0V Modulation Type: FSK Antenna Type: Spring-loaded Antenna Antenna Gain: 6dBi Hardware version: N/A Software version: N/A Connecting I/O Port(s): Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications orthe User Manual. 2. The antenna information refers to the manufacturer provide report, applicable only to the tested sample identified in the report. Due to the incorrect antenna information, a series of problems such as the accuracy of the test results will be borne by the customer. Report No.: LGT24G155RF01 Page 9 of 31 2.2 DESCRIPTION OF THE TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 TX Mode For Radiated Emission Final Test Mode Description Mode 1 TX Mode 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED During tes…

Text truncated - open the document above for the full version.

Page 1 of 1 Report No.: LGT24G155 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz
