2BH2L-XPLORISXploris

One stop shop for k-6 STEAM Xploris Unique STEAM solution Xplrois does it all: An orchestra of STEAM learning in a compact, hand-held disc By creating pixel-art images/animations. Through Blockly and Python languages. Experimentation with Xploris 5 built in sensors. By producing various control outputs. Engineering Science & Math Coding Art Xploris –ports and controls Voltage sensor, Voltage output source, Dry contact switch Full color 256 pixels display 4 sensors select keys On/Off and 2 display keys Voltage sensor, Voltage output source, Dry contact switch USB-C port Sound sensor Distance sensor Temperature probe input Light sensor Speaker 2 Robotics Servo engine output Hardware features Sensing & Data logging ■5 sensors: Light, Temperature, Sound, Distance, Voltage. ■Displaying numeric sensor value and sensor bar graph. Art ■16x16 RGB LED matrix. ■Using the full color pixel matrix for creating graphics and animations. Coding ■Internal processor directly supporting Python and Blocks. Control ■2 on/off outputs. ■2 voltage output. ■2 servo engine outputs. XploriLab -full suite of STEAM apps Science senssing, datalogging, coding, control and art. For science & math For coding 300 0 0 15 151 1 75 For control & engineering For art Pedagogic coverage Full integration of all STEAM subjects Science & Math ■Data visualization: gauges, pictographs, bar graphs, tables, line graphs. ■Data analysis:markers, annotations, linear regressions, Export to EXCEL. Art ■Introduction to: colors, drawing, pixel art and character creation. ■Covering: frame by frame animation, shapes and geometry, sensors and code controlled animation. Coding ■Platforms: Blockly, and Python editor. ■Covering: data types, variables, logical operators, If/else conditions, loops, Input and output operations. Control ■Method: sensors based output levels. ■Controlling: animation speed, servo speed, servo angle, contact open/close, 5V output on/off. Xploris offers students an integrated end-to-end STEAM experience, from creating a pixel art flower animation to apply coding that opens the flower’s leaves when sunlight is projected on a light sensor” Thank you! FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF Exposure Information The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Globisens Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: April 23, 2024 FCC ID: 2BH2L-XPLORIS Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Globisens Ltd certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Globisens Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: Globisens Ltd Address: Hacharoshet 27 Kiriat gat 8202138 KIRIAT GAT ISRAEL Contact Person: Dov Bruker/CEO Tel.: +972-3-9191801 Email: [email protected] Sincerely, Signature:

Ceramic Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 240MHz2500MHz2400MHz240MHz2500MHz Center Frequency -1.26-0.76-0.5-5.25-2.46-1.86 MAX. Gain -0.5dB PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD No.333, Kexing Road, Nanping Town, Zhuhai, China Horizontal:2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB)Frequency (MHz) MaxMinAvg 2400-1.26174-30.0801-7.18716 2450-0.765802-36.5604-7.48023 2500-0.5582-22.0315-6.59127 Vertical:2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) MaxMin A vg 2400-5.2537-22.1424-12.4294 2450-2.4652-24.5837-10.4702 2500-1.86120-29.5214-9.20432 ANT Test Labs˖Attestation of Global Compliance Co., Ltd.

Globisens Ltd Date：2024-08-05 Product :Xploris FCC ID：2BH2L-XPLORIS To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by ORGANIZATION. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: CEO Name: Dov Bruker Email: [email protected] Telephone: 972544575265 On behalf of: Globisens Ltd

Globisens Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 6, 2024 Subject:Request for Confidentiality FCC ID: 2BH2L-XPLORIS To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Dov Bruker Title: CEO

Report No.: BTEK240625003AE Page: 1 of 3 Appendix EUT Photos for BTEK240625003AE Report No.: BTEK240625003AE Page: 2 of 3 EUT Constructional Details (EUT Photos) EUT View 1 EUT View 2 EUT View 3 Report No.: BTEK240625003AE Page: 3 of 3 EUT View 4 EUT View 5 EUT View 6

Report No.: BTEK240520005AE Page: 1 of 1 LABEL AND LOCATION FCC ID: 2BH2L-XPLORIS

Report No.: BTEK240625003AE Page: 1 of 3 Appendix EUT Photos for BTEK240625003AE Report No.: BTEK240625003AE Page: 2 of 3 EUT Constructional Details (EUT Photos) EUT View 7 EUT View 8 EUT View 9 ceramic antenna Report No.: BTEK240625003AE Page: 3 of 3 EUT View 10 EUT View 11

Report No.: BTEK240625003AE002 Page: 1 of 5 TEST REPORT Application No.: BTEK240625003AE Applicant: Globisens Ltd Address of Applicant: Hacharoshet 27 Kiriat gat 8202138 KIRIAT GAT ISRAEL Manufacturer: SMT Technologies Ltd Address of Manufacturer: Hacharoshet 27 Kiriat gat 8202138 KIRIAT GAT ISRAEL Equipment Under Test (EUT): EUT Name: Xploris Test Model.: Xploris rev-4 Trade Mark: Xploris FCC ID: 2BH2L-XPLORIS Standard(s) : 47 CFR Part 2 Subpart J Section 2.1093 447498 D01 General RF Exposure Guidance v06 Date of Receipt: 2024-06-25 Date of Test: 2024-06-25 to 2024-07-22 Date of Issue: 2024-07-23 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Lion Cai/ Approved & Authorized EMC Laboratory Manager Report No.: BTEK240625003AE002 Page: 2 of 5 Revision Record Version Chapter Date Modifier Remark V0 2024-07-23 Original Authorized for issue by Zora Huang/Project Engineer June Li/Reviewer Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Report No.: BTEK240625003AE002 Page: 3 of 5 2 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Contents .................................................................................................................................................... 3 3 General Information .................................................................................................................................. 4 3.1 Details of E.U.T. ................................................................................................................................. 4 3.2 Description of Support Units .............................................................................................................. 4 3.3 Test Location ...................................................................................................................................... 4 3.4 Deviation from Standards ................................................................................................................... 4 3.5 Abnormalities from Standard Conditions ........................................................................................... 4 4 Test Requirement ........................................................................................................................................... 5 4.1Assessment Result..................................................................................................................................... 5 Report No.: BTEK240625003AE002 Page: 4 of 5 General Information 3.1 Details of E.U.T. Power supply: DC 3.7V from battery Frequency Range: 2402MHz to 2480MHz Bluetooth Version: V4.2 Modulation Type: GFSK, Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: ceramic antenna Antenna Gain: -0.5 dBi Sample No.: BTEK240625001AE-01 Remark: The information in this section is provided by the applicant or manufacturer, BANTEK is not liable to the accuracy, suitability, reliability or/and integrity of the information. 3.2 Description of Support Units Description Manufacturer Model No. Serial No. / / / / 3.3 Test Location All tests were performed at: Shenzhen BANTEK Testing Co., Ltd., A5&A6, Building B1&B2, No.45 Gangtou Road, Bogang Community, Shajing Street, Bao'an District, Shenzhen, Guangdong, China 518103 Tel:0755-2334 4200 Fax: 0755-2334 4200 FCC Registration Number: 264293 Designation Number: CN1356 No tests were sub-contracted. 3.4 Deviation from Standards None 3.5 Abnormalities from Standard Conditions None Report No.: BTEK240625003AE002 Page: 5 of 5 4 Test Requirement KDB447498 D01 General RF Exposure Guidance v06, Clause 4.3.1(b) [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 Where -f(GHz) is the RF channel transmit frequency in GHz -Power and distance are rounded to the nearest mW and mm before calculation -The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. 4.1Assessment Result Passed Not Applicable Type Frequency (MHz) Conducted Power (dBm) Maximum Tune-up (dBm) Calculating data Limit Result BLE 2440 6.88 7.0 1.57 3.0 Pass Note: The exposure evaluation safety distance is 5mm. - End of the Report -

Report No.: BTEK240625003AE001 Page: 1 of 27 Appendix Test Data for BTEK240625003AE Start date 2024/7/22 Finish date 2024/7/22 Temperature 23.1°C Humidity 63% RF specifications BLE Test Engineer Zora Report No.: BTEK240625003AE001 Page: 2 of 27 Table of Contents 1. -6dB Bandwidth .......................................................................................................................................................... 3 2. 99% Occupied Bandwidth .......................................................................................................................................... 6 3. Duty Cycle ................................................................................................................................................................... 9 4. Peak Output Power................................................................................................................................................... 12 5. Power Spectral Density ............................................................................................................................................. 15 6. Bandedge .................................................................................................................................................................. 18 7. Spurious Emission ..................................................................................................................................................... 22 Report No.: BTEK240625003AE001 Page: 3 of 27 1. -6dB Bandwidth Condition Antenna Rate Frequency (MHz) -6dB BW(kHz) limit(kHz) Result NVNT ANT1 1Mbps 2402.00 671.59 500 Pass NVNT ANT1 1Mbps 2440.00 670.69 500 Pass NVNT ANT1 1Mbps 2480.00 678.20 500 Pass NVNT ANT1 2Mbps 2402.00 1156.73 500 Pass NVNT ANT1 2Mbps 2440.00 1153.36 500 Pass NVNT ANT1 2Mbps 2480.00 1156.93 500 Pass -6dB_Bandwidth_NVNT_ANT1_1Mbps_2402 -6dB_Bandwidth_NVNT_ANT1_1Mbps_2440 -6dB_Bandwidth_NVNT_ANT1_1Mbps_2480 Report No.: BTEK240625003AE001 Page: 4 of 27 -6dB_Bandwidth_NVNT_ANT1_2Mbps_2402 -6dB_Bandwidth_NVNT_ANT1_2Mbps_2440 Report No.: BTEK240625003AE001 Page: 5 of 27 -6dB_Bandwidth_NVNT_ANT1_2Mbps_2480 Report No.: BTEK240625003AE001 Page: 6 of 27 2. 99% Occupied Bandwidth Condition Antenna Rate Frequency (MHz) 99%%BW(MHz) NVNT ANT1 1Mbps 2402.00 1.019 NVNT ANT1 1Mbps 2440.00 1.018 NVNT ANT1 1Mbps 2480.00 1.018 NVNT ANT1 2Mbps 2402.00 1.999 NVNT ANT1 2Mbps 2440.00 2.001 NVNT ANT1 2Mbps 2480.00 2.001 99%_Occupied_Bandwidth_NVNT_ANT1_1Mbps_2402 99%_Occupied_Bandwidth_NVNT_ANT1_1Mbps_2440 99%_Occupied_Bandwidth_NVNT_ANT1_1Mbps_2480 Report No.: BTEK240625003AE001 Page: 7 of 27 99%_Occupied_Bandwidth_NVNT_ANT1_2Mbps_2402 99%_Occupied_Bandwidth_NVNT_ANT1_2Mbps_2440 Report No.: BTEK240625003AE001 Page: 8 of 27 99%_Occupied_Bandwidth_NVNT_ANT1_2Mbps_2480 Report No.: BTEK240625003AE001 Page: 9 of 27 3. Duty Cycle Condition Antenna Rate Frequency (MHz) Dutycycle(%) Duty_factor NVNT ANT1 1Mbps 2402.00 70.97 1.49 NVNT ANT1 1Mbps 2440.00 74.19 1.30 NVNT ANT1 1Mbps 2480.00 70.97 1.49 NVNT ANT1 2Mbps 2402.00 41.94 3.77 NVNT ANT1 2Mbps 2440.00 40.62 3.91 NVNT ANT1 2Mbps 2480.00 45.16 3.45 Duty_Cycle_NVNT_ANT1_1Mbps_2402 Duty_Cycle_NVNT_ANT1_1Mbps_2440 Duty_Cycle_NVNT_ANT1_1Mbps_2480 Report No.: BTEK240625003AE001 Page: 10 of 27 Duty_Cycle_NVNT_ANT1_2Mbps_2402 Duty_Cycle_NVNT_ANT1_2Mbps_2440 Report No.: BTEK240625003AE001 Page: 11 of 27 Duty_Cycle_NVNT_ANT1_2Mbps_2480 Report No.: BTEK240625003AE001 Page: 12 of 27 4. Peak Output Power Condition Antenna Rate Frequency (MHz) Max. Conducted Power(dBm) Max. Conducted Power(mW) Limit(mW) Result NVNT ANT1 1Mbps 2402.00 6.84 4.83 1000 Pass NVNT ANT1 1Mbps 2440.00 6.79 4.78 1000 Pass NVNT ANT1 1Mbps 2480.00 6.30 4.27 1000 Pass NVNT ANT1 2Mbps 2402.00 6.81 4.80 1000 Pass NVNT ANT1 2Mbps 2440.00 6.88 4.88 1000 Pass NVNT ANT1 2Mbps 2480.00 6.41 4.37 1000 Pass Peak_Output_Power_NVNT_ANT1_1Mbps_2402 Peak_Output_Power_NVNT_ANT1_1Mbps_2440 Peak_Output_Power_NVNT_ANT1_1Mbps_2480 Report No.: BTEK240625003AE001 Page: 13 of 27 Peak_Output_Power_NVNT_ANT1_2Mbps_2402 Peak_Output_Power_NVNT_ANT1_2Mbps_2440 Report No.: BTEK240625003AE001 Page: 14 of 27 Peak_Output_Power_NVNT_ANT1_2Mbps_2480 Report No.: BTEK240625003AE001 Page: 15 of 27 5. Power Spectral Density Condition Antenna Rate Frequency (MHz) Power Spectral Density(dBm) Limit(dBm/3kHz) Result NVNT ANT1 1Mbps 2402.00 -3.00 8 Pass NVNT ANT1 1Mbps 2440.00 -3.12 8 Pass NVNT ANT1 1Mbps 2480.00 -3.43 8 Pass NVNT ANT1 2Mbps 2402.00 -3.65 8 Pass NVNT ANT1 2Mbps 2440.00 -3.55 8 Pass NVNT ANT1 2Mbps 2480.00 -3.92 8 Pass Power_Spectral_Density_NVNT_ANT1_1Mbps_2402 Power_Spectral_Density_NVNT_ANT1_1Mbps_2440 Power_Spectral_Density_NVNT_ANT1_1Mbps_2480 Report No.: BTEK240625003AE001 Page: 16 of 27 Power_Spectral_Density_NVNT_ANT1_2Mbps_2402 Power_Spectral_Density_NVNT_ANT1_2Mbps_2440 Report No.: BTEK240625003AE001 Page: 17 of 27 Power_Spectral_Density_NVNT_ANT1_2Mbps_2480 Report No.: BTEK240625003AE001 Page: 18 of 27 6. Bandedge Condition Antenna Rate TX_Frequency (MHz) Max. Mark Frequency (MHz) Spurious level(dBm) limit(dBm) Result NVNT ANT1 1Mbps 2402.00 2395.975 -29.995 -13.229 Pass NVNT ANT1 1Mbps 2480.00 2486.000 -37.331 -13.775 Pass NVNT ANT1 2Mbps 2402.00 2399.965 -26.625 -13.274 Pass NVNT ANT1 2Mbps 2480.00 2486.000 -37.156 -13.713 Pass 1_Reference_Level_NVNT_ANT1_1Mbps_2402 2_Bandedge_NVNT_ANT1_1Mbps_2402 1_Reference_Level_NVNT_ANT1_1Mbps_2480 Report No.: BTEK240625003AE001 Page: 19 of 27 2_Bandedge_NVNT_ANT1_1Mbps_2480 1_Reference_Level_NVNT_ANT1_2Mbps_2402 Report No.: BTEK240625003AE001 Page: 20 of 27 2_Bandedge_NVNT_ANT1_2Mbps_2402 1_Reference_Level_NVNT_ANT1_2Mbps_2480 Report No.: BTEK240625003AE001 Page: 21 of 27 2_Bandedge_NVNT_ANT1_2Mbps_2480 Report No.: BTEK240625003AE001 Page: 22 of 27 7. Spurious Emission Condition Antenna Rate TX_Frequency(MHz) Spurious MAX.Value(dBm) Limit Result NVNT ANT1 1Mbps 2402.00 -32.389 -13.229 Pass NVNT ANT1 1Mbps 2440.00 -31.953 -13.265 Pass NVNT ANT1 1Mbps 2480.00 -…

Text truncated - open the document above for the full version.

Report No.: BTEK240625003AE001 Page: 1 of 26 TEST REPORT Application No.: BTEK240625003AE Applicant: Globisens Ltd Address of Applicant: Hacharoshet 27 Kiriat gat 8202138 KIRIAT GAT ISRAEL Manufacturer: SMT Technologies Ltd Address of Manufacturer: Hacharoshet 27 Kiriat gat 8202138 KIRIAT GAT ISRAEL Equipment Under Test (EUT): EUT Name: Xploris Test Model.: Xploris rev-4 Trade Mark: Xploris FCC ID: 2BH2L-XPLORIS Standard(s) : 47 CFR Part 15, Subpart C 15.247 KDB558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 Date of Receipt: 2024-06-25 Date of Test: 2024-06-25 to 2024-07-22 Date of Issue: 2024-07-23 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Lion Cai/ Approved & Authorized EMC Laboratory Manager Report No.: BTEK240625003AE001 Page: 2 of 26 Revision Record Version Chapter Date Modifier Remark V0 2024-07-23 Original Authorized for issue by Zora Huang/Project Engineer June Li/Reviewer Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Report No.: BTEK240625003AE001 Page: 3 of 26 2 Test Summary Radio Spectrum Technical Requirement Standard Item Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result 47 CFR Part 15, Subpart C 15.247 Conducted Emissions at AC Power Line (150kHz-30MHz) ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.1.3 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. N/A: Mean’s not application. Report No.: BTEK240625003AE001 Page: 4 of 26 3 Contents Page 1 Cover Page ...................................................................................................................................................... 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 5 4.1 Details of E.U.T. .............................................................................................................................................. 5 4.2 EUT Test Mode and Test Condition ............................................................................................................ 5 4.3 Measurement Uncertainty ............................................................................................................................. 5 4.4 Test Location ................................................................................................................................................... 6 4.5 Deviation from Standards .............................................................................................................................. 6 4.6 Abnormalities from Standard Conditions .................................................................................................... 6 5 Equipment List .......................................................................................................................................... 7 6 Radio Spectrum Technical Requirement ............................................................................................... 9 6.1 Antenna Requirement .................................................................................................................................... 9 6.1.1 Test Requirement: ..................................................................................................................................... 9 6.1.2 Conclusion .................................................................................................................................................. 9 7 Radio Spectrum Matter Test Results .................................................................................................... 10 7.1 Conducted Emissions at AC Power Line (150kHz-30MHz) ................................................................... 10 7.1.1 Test Setup Diagram ................................................................................................................................ 10 7.1.2 Measurement Procedure and Data ...................................................................................................... 10 7.2 Conducted Peak Output Power .................................................................................................................. 13 7.2.1 Test Setup Diagram ...........................................................................................................................…

Text truncated - open the document above for the full version.
