2BH2N-C1SEMP3 player

C1SE Manual Guide Thanks for choosing KeenPlus! Please read this instruction manual before using this product. This guide will help you set it up and get you up with the operations you’ll use everyday! Warm advice 1. To protect the new machine, we have attached a protective film to the MP3 player. If you want the best visual and operational experience, it is recommended to remove it. 2. The player has many built-in Internet applications, which will be better experienced in the WiFi environment. Of course, choosing to use it offline is definitely not a problem. 3. It is recommended to apply for a Google account before use, so that most Internet applications can use it to log in. Follow the link below to learn how to create a Google Account. https://edu.gcfglobal.org/en/googleaccount/creating-a-goog le-account/1/ 4. It is recommended not to execute too many large-scale applications at the same time, which will easily cause the machine to heat up. Periodically clean up background executors manually or through clean software. 5. If the MP3 player will not be used for a short period of time, it is recommended to manually shut down the system to prevent excessive power consumption. 6. The MP3 player provides Google Store, you can download applications at will, but many applications are charged, please use with caution. 7. If the player crashes, insert the pointer into the reset hole to reset the system and restart the MP3 player. If the player still cannot power on, please check if the product is powered off. 8. Android operating system and Google input method support multiple languages, you can choose the language you need through system settings. 9. It is recommended to turn down the volume of the unit before using,headphones,and gradually increase the volume after you start listening until it is suitable. Don't turn up the volume too high to protect your hearing, (Doctors point out that listening at high volume for extended periods of time, will damage the listener's hearing). When tinnitus occurs, turn down the volume or stop using it. 10. It is recommended to back up the personal data stored in the player, before formatting. 11. Over-voltage：Power cable strain,bending or squeezing by heavy,objects is not allowed to avoid overheating or fire disaster. 12. Please keep the product away from the electromagnetic environment,excessive humidity,smoke and other harsh envir onments. 13. Do not immerse the product in water,and do not use any c orrosive or abrasive cleaners to clean. 14. Do not expose the product to moisture or rain.It may cause equipment,failure or even hard to repair because of wa ter and moisture penetration. 15. Do not use headphones while driving,riding,operating mac hinery,or,doing work that requires attention to outside sounds. 16. There is an automatic shutdown function in setting. The following conditions must be met for achieving this function: A. No programs running automatically in the background. B.Can not be in the charging state. Note:The automatic shutdown timer starts after the screen is completely turned off. 17. If the actual setting and using method of this product are inconsistent,with this manual due to firmware upgrade,please contact us. Open the Package Buttons Introduction ① Power on / off, Screen on/off ②Volume+ ③Volume- ④Rest hole ⑤Trumpet ⑥micro SD Card Slot ⑦ Microphone ⑧Charge port⑨Earphone slot Basic Operation 1. Power on/off:Hold the power button ① to turn on/off the player.Short press button ①to turn on/off the screen. 2. Main screen Introduction: A.Status Bar:When entering the specific function menu,the to p column of the screen is the status bar, which displays these information:time,battery power,Wireless and WIFI. B.Function Icons:In the main screen, the system comes with multiple icons. Directly click the icon to enter various functions or related settings for this equipment. 3. Volume Adjustment A.Press button ② to increase volume. B.Press button ③ to decrease volume. C.Touch:When the volume bar pops up. you can adjust the volume by dragging the slider. 4. Reset: If the player crashes, insert the pointer into the reset hole to reset the system and restart the MP3 player. If the player still cannot power on, please check if the product is powered off. 5. Recovery: If you forget the password or cannot enter the system, you can try to restore the factory state through the recovery mode. Press and hold the [Power key①] + [Volume Up key③] at the same time to enter recovery mode,or you can use the universal password 1235789 to access your MP3 Player and reset your password. 6. Return:Swipe from right to left or tap the upper right butt on””. 7. Virtual Function Keys Operation:At the bottom of the scre en, display the navigation bar. 8. You can insert a micro SD card into the micro SD Card Slot 【⑥】 to expand the capacity of the device. .Display background hidden files screens. . Return to main screen. .Return to previous menu. Notes 1. After the device is operated for a long time,especially in a high temperature environment,it is a normal phenomenon that the surface might be hot,when you feel it is hot,please stop suing and charging,turn off some functions as well as moving the device to a cool place,please try to avoid prolonged high temperatures on the equipment. 2. If you do not use this MP3 player for a long time, please charge and discharge it at least once a month to prevent battery damage. Configuration of New Device Connect to Wi-Fi Network 1. Swipe down from the status bar to open the notifications b ar or find,“Wi-Fi”in settings. 2. Turn on the "Wi Fi" switch and the system will list all the WiFi and networks found. 3. Tap the Wi-Fi network you want to connect to. If you choose an encrypted network,you will need to enter a password for access connection. Connect to Wireless 1. Swipe down from the status bar to open the notifications panel or find “Wireless”in setting. 2. Turn on"Wireless"switch,enter the Wireless settings screen and click to…

Text truncated - open the document above for the full version.

DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road Nancheng Street Dongguan, Guangdong China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-8-15 To whom it may concern: We, DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl, hereby certify that the equipment for which authorization is sought (FCC ID: 2BH2N-C1SE) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Lei Wang Manager DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Add: Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road Nancheng Street Dongguan, Guangdong China Date: 2024-8-15 FCC ID: 2BH2N-C1SE Dear Sir/Madam, We, DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: MP3 player Model no.: C1SE, C1, C1PLUS, C2, C3, C4, C5, C5 PRO, C6, C7,C8, C9, C10, U1, U2, U3, U4, U5, U6, U7, U8, U9, U10 Sincerely, Name/Title： Lei Wang/Manager Company: DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Address: Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road Nancheng Street Dongguan, Guangdong China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-8-15> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BH2N-C1SE C1SE For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Lei Wang/Manager Company: DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Address: Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road Nancheng Street Dongguan, Guangdong China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road Nancheng Street Dongguan, Guangdong China Date: 2024-8-15 FCC ID: 2BH2N-C1SE Model Number: C1SE To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl, declare that this EUT (FCC ID: 2BH2N-C1SE) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Lei Wang/Manager Company: DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Address: Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road Nancheng Street Dongguan, Guangdong China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road Nancheng Street Dongguan, Guangdong China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-8-15 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BH2N-C1SE including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Lei Wang/Manager Company: DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Address: Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road Nancheng Street Dongguan, Guangdong China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202407396 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 3 Product Name: MP3 player Model No.: C1SE EUT Constructional Details External Photo Report No.: HTT202407396 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 3 Report No.: HTT202407396 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 3 ------End------

Label and Location Size: L: 3.0cm*W: 2.0cm Label and Location Model No.: C1SE FCC ID : 2BH2N-C1SE

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202407396 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 3 Product Name: MP3 player Model No.: C1SE EUT Constructional Details Internal Photo ANTENNA Report No.: HTT202407396 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 3 Report No.: HTT202407396 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 3 ------End------

RF Exposure evaluation FCC ID: 2BH2N-C1SE 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance Mode Max. Peak Conducted Output Power (dBm) Max. tune-up BT 3.58 3.0±1 BLE 6.47 6.0±1 2.4GWIFI 6.51 6.0±1 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.450 5 4.0 2.5119 0.7863<3.0 Yes BLE 2.450 5 7.0 5.0119 1.5690<3.0 Yes 2.4GWIFI 2.450 5 7.0 5.0119 1.5690<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

无源测试数据： 2.4G-2D图 2.4G - 3D图 5G - 2D图 5G - 3D图

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202407396F02 This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 30 TEST Report Applicant: DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Address of Applicant: Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road, Nancheng Street,Dongguan, Guangdong, CHINA 518000 Manufacturer : DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Address of Manufacturer : Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road, Nancheng Street,Dongguan, Guangdong, CHINA 518000 Equipment Under Test (EUT) Product Name: MP3 player Model No.: C1SE Series model: C1, C1PLUS, C2, C3, C4, C5, C5 PRO, C6, C7, C8, C9, C10, U1, U2, U3, U4, U5, U6, U7, U8, U9, U10 Trade Mark: keenplus FCC ID: 2BH2N-C1SE Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: Jul. 24, 2024 Date of Test: Jul. 24, 2024 ~ Jul. 30, 2024 Date of report issued: Jul. 30, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: HTT202407396F02 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 2 of 30 1. Version Version No. Date Description 00 Jul. 30, 2024 Original Tested/ Prepared By Date: Jul.30,2023 Project Engineer Check By: Date: Jul.30,2023 Reviewer Approved By : Date: Jul.30,2023 Authorized Signature Report No.: HTT202407396F02 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 3 of 30 2. Contents Page 1. VERSION ........................................................................................................................................................ 2 2. CONTENTS .................................................................................................................................................... 3 3. TEST SUMMARY ........................................................................................................................................... 4 4. GENERAL INFORMATION ............................................................................................................................ 5 4.1. GENERAL DESCRIPTION OF EUT ................................................................................................................ 5 4.2. TEST MODE ............................................................................................................................................... 7 4.3. DESCRIPTION OF SUPPORT UNITS .............................................................................................................. 7 4.4. DEVIATION FROM STANDARDS .................................................................................................................... 7 4.5. ABNORMALITIES FROM STANDARD CONDITIONS ........................................................................................... 7 4.6. TEST FACILITY ........................................................................................................................................... 7 4.7. TEST LOCATION ......................................................................................................................................... 7 4.8. ADDITIONAL INSTRUCTIONS ........................................................................................................................ 7 5. TEST INSTRUMENTS LIST ........................................................................................................................... 8 6. TEST RESULTS AND MEASUREMENT DATA ........................................................................................... 9 6.1. CONDUCTED EMISSIONS ............................................................................................................................ 9 6.2. CONDUCTED OUTPUT POWER .................................................................................................................. 12 6.3. CHANNEL BANDWIDTH .............................................................................................................................. 13 6.4. POWER SPECTRAL DENSITY ..................................................................................................................... 15 6.5. BAND EDGES ........................................................................................................................................... 17 6.5.1 Conducted Emission Method .......................................................................................................... 17 6.5.2 Radiated Emission Method ............................................................................................................. 18 6.6. SPURIOUS EMISSION ................................................................................................................................ 20 6.6.1 Conducted Emission Method .......................................................................................................... 20 6.6.2 Radiated Emission Method ............................................................................................................. 22 6.7. ANTENNA REQUIREMENT .......................................................................................................................... 29 7. TEST SETUP PHOTO .................................................................................................................................. 30 8. EUT CONSTRUCTIONAL DETAILS ...............…

Text truncated - open the document above for the full version.

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202407396F03 This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 37 TEST Report Applicant: DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Address of Applicant: Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road, Nancheng Street,Dongguan, Guangdong, CHINA 518000 Manufacturer : DONGGUANSHI PADI DIANZI KEJI YOUXIAN GONGSl Address of Manufacturer : Room 1327-1328, 3rd Floor, Block A,No.7 Xinji Road, Nancheng Street,Dongguan, Guangdong, CHINA 518000 Equipment Under Test (EUT) Product Name: MP3 player Model No.: C1SE Series model: C1, C1PLUS, C2, C3, C4, C5, C5 PRO, C6, C7, C8, C9, C10, U1, U2, U3, U4, U5, U6, U7, U8, U9, U10 Trade Mark: keenplus FCC ID: 2BH2N-C1SE Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: Jul. 24, 2024 Date of Test: Jul. 24, 2024 ~ Jul. 30, 2024 Date of report issued: Jul. 30, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: HTT202407396F03 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 2 of 37 1. Version Version No. Date Description 00 Jul. 30, 2024 Original Tested/ Prepared By Date: Jul. 30, 2024 Project Engineer Check By: Date: Jul. 30, 2024 Reviewer Approved By : Date: Jul. 30, 2024 Authorized Signature Report No.: HTT202407396F03 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 3 of 37 2. Contents Page 1. VERSION ........................................................................................................................................................ 2 2. CONTENTS .................................................................................................................................................... 3 3. TEST SUMMARY ........................................................................................................................................... 4 4. GENERAL INFORMATION ............................................................................................................................ 5 4.1. GENERAL DESCRIPTION OF EUT ................................................................................................................ 5 4.2. TEST MODE ............................................................................................................................................... 7 4.3. DESCRIPTION OF SUPPORT UNITS .............................................................................................................. 7 4.4. DEVIATION FROM STANDARDS .................................................................................................................... 7 4.5. ABNORMALITIES FROM STANDARD CONDITIONS ........................................................................................... 7 4.6. TEST FACILITY ........................................................................................................................................... 7 4.7. TEST LOCATION ......................................................................................................................................... 7 4.8. ADDITIONAL INSTRUCTIONS ........................................................................................................................ 7 5. TEST INSTRUMENTS LIST ........................................................................................................................... 7 6. TEST RESULTS AND MEASUREMENT DATA ........................................................................................... 9 6.1. CONDUCTED EMISSIONS ............................................................................................................................ 9 6.2. CONDUCTED PEAK OUTPUT POWER ......................................................................................................... 12 6.3. CHANNEL BANDWIDTH .............................................................................................................................. 13 6.4. POWER SPECTRAL DENSITY ..................................................................................................................... 16 6.5. BAND EDGE ............................................................................................................................................. 19 6.5.1. Conducted Emission Method ......................................................................................................... 19 6.5.2. Radiated Emission Method ............................................................................................................ 22 6.6. SPURIOUS EMISSION ................................................................................................................................ 24 6.6.1. Conducted Emission Method ......................................................................................................... 24 6.6.2. Radiated Emission Method ............................................................................................................ 29 6.7. ANTENNA REQUIREMENT .......................................................................................................................... 36 7. TEST SETUP PHOTO .................................................................................................................................. 37 8. EUT CONSTRUCTIONAL DETAILS ............…

Text truncated - open the document above for the full version.
