2BH3M-GEN12Body Worn Camera

LensLock Gen 12.5 BWC Operation GEN 12.5 Design GEN 12.5 Design 1.LCD Screen 2.Status LED 3.Photo Button 4.Power Button 5.Speaker 6.Infrared Lights (IR) 7.Microphone 8.Lens 9. Record Button 10. Mini-USB Connector/Reset 11. Function/WiFi Button 12. Stealth Button 13. Mute Button 14. Castellation Mount 15. Docking Plate 2 1 3 4 5 6 7 8 9 10 11 12 13 14 15 SideSideFront Bottom Top Back Hold To power on the Gen 12.5 BWC, press and hold the blue power button for 3-4 seconds. The BWC will emit a vibrate and the LED screen will illuminate. The LED screen will remain illuminated until it has reached 30 seconds of inactivity. Activation of any button will illuminate the LED screen. To power off the Gen 12.5 BWC, press and hold the blue power button for 3-4 seconds. GEN 12.5 Power On/Off Storage Bluetooth Battery WiFi Audio GPS Hold The on the LED screen indicates the BWC is powered on and currently set in pre-record. The BWCs are configured with a 30-second pre-record feature. Upon activating a recording, the recording will include an additional 30-seconds of video prior to the recording activation. While 30-seconds of video will be included prior to the recording activation, audio will be muted during the 30-second pre- record. Once a recording is activated, video and audio will be present until the recording has concluded. GEN 12.5 Pre-Record Storage Bluetooth Battery WiFi Audio GPS x1 To start a recording, single press the center record button. The BWC will emit a single vibration, will appear on the LED screen, as well as a red LED on top of the BWC. In addition, the recording duration will appear on the LED screen. After 30 seconds of inactivity, the LED screen will appear dormant, however the red LED on top of the BWC will remain while recording. While recording, a vibration notifier at a select interval will alert the user that a recording is present. GEN 12.5 Start Recording Storage Bluetooth Battery WiFi Audio GPS x2 To stop a recording, double press the center record button. The BWC will emit three vibrations, will reappear on the LED screen, and the red LED will disappear on top of the BWC. The recording duration will revert to 00:00:00 on the LED screen. GEN 12.5 Stop Recording Storage Bluetooth Battery WiFi Audio GPS x1 To capture a photo, single press the photo button located above the power button. The BWC will emit a single vibration and a still-image will be captured via the BWC. GEN 12.5 Photo Capture You may capture a photo while in pre-record and/or while recording. Hold To enable WiFi to access the mobile application, press and hold the Fn (function) button for 2-3 seconds. The BWC will emit two vibration and will appear on the LED screen to indicate WiFi is enabled. To disable WiFi, press and hold the Fn (function) button. will appear on the LED screen indicating the WiFi is disabled. GEN 12.5 Enable/Disable WiFi (*to connect to the mobile application) Enabling WiFi will dimmish the battery life on the BWC. Storage Bluetooth Battery WiFi Audio GPS *Please locate the Mobile Application training document for connection instructions x2 To toggle between the Device ID on the BWC as well as the firmware version on the BWC, double press the Fn (function) button. The Device ID and firmware version will appear on the LED screen. To revert to the normal LED screen, double press the Fn (function) button. GEN 12.5 Device/Firmware Device ID: BWC0001 FW: S31_231031_v1.1 Hold Stealth Mode will disable all LED indicators (LED screen/LED) and audio tones/chirps. Vibration alerts will remain while in stealth mode. To toggle the BWC to stealth mode, press and hold the “eye” icon for 2-3 seconds. Repeat to toggle out of stealth mode. GEN 12.5 Stealth Mode If your BWC emits a vibration when you attempt to power on, however the LED screen does not illuminate, it is most likely in stealth mode. Press and hold the “eye” icon and the LED screen should illuminate. Hold To mute the audio during a recording, press and hold the “microphone” icon for 2-3 seconds. The LED screen will display indicating that the BWC is recording, however audio is currently muted. To resume audio, press and hold the “microphone” icon for 2-3 seconds where will reappear, indicating the recording has resumed with audio. GEN 12.5 Mute Function Storage Bluetooth Battery WiFi Audio GPS In addition to charging while docked within the LensLock docking station, the BWC can be charged remotely via a USB mini-USB connector cable. Insert the mini-USB into the input located within the USB cover. Located within the USB cover, is a small reset button. If you are having issues with your BWC, please insert a fine tip tool into the reset button and press for one second. The BWC should run through a power reset. GEN 12.5 USB Mini-USB Charging/Reset Button Remote ChargingReset Button GEN 12.5 Accessories Bundle Castellation MountMagnet MountAlligator Clip *Slide Bracket Required Molle MountUSB Mini-USB Cable GEN 12.5 Troubleshooting LensLock Support •The LensLock Support team is ready and available for any questions that may arise. •To reach the support team via email, please send a detailed email to [email protected] and a representative will promptly get back with you. •To reach the support team via phone, please contact 866-LENSLOCK and press “3” for Client Support. •To reach the support team via Live Chat, please access the Live Chat feature located within the LensLocker Portal. FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipm…

Text truncated - open the document above for the full version.

SHELL GROUP CO., LIMITED Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road Hongkong China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-8-21 To whom it may concern: We, SHELL GROUP CO., LIMITED , hereby certify that the equipment for which authorization is sought (FCC ID: 2BH3M-GEN12) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Alan Chen Manager SHELL GROUP CO., LIMITED 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

SHELL GROUP CO., LIMITED Add: Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road Hongkong China Date: 2024-8-21 FCC ID: 2BH3M-GEN12 Dear Sir/Madam, We, SHELL GROUP CO., LIMITED Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Body Worn Camera Model no.: Gen12.5, Gen12 Sincerely, Name/Title： Alan Chen/Manager Company: SHELL GROUP CO., LIMITED Address: Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road Hongkong China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-8-21> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BH3M-GEN12 Gen12.5 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Alan Chen/Manager Company: SHELL GROUP CO., LIMITED Address: Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road Hongkong China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

SHELL GROUP CO., LIMITED Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road Hongkong China Date: 2024-8-21 FCC ID: 2BH3M-GEN12 Model Number: Gen12.5 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, SHELL GROUP CO., LIMITED , declare that this EUT (FCC ID: 2BH3M-GEN12) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Alan Chen/Manager Company: SHELL GROUP CO., LIMITED Address: Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road Hongkong China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

SHELL GROUP CO., LIMITED Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road Hongkong China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-8-21 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BH3M-GEN12 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Alan Chen/Manager Company: SHELL GROUP CO., LIMITED Address: Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road Hongkong China Phone: 13603034005 Fax: N/A E-Mail: [email protected]

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202407428 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 4 Product Name: Body Worn Camera Model No.: Gen12.5 EUT Constructional Details External Photo Report No.: HTT202407428 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 4 Report No.: HTT202407428 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 4 Report No.: HTT202407428 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 4 of 4 ------End------

Label and Location Size: L: 3.0cm*W: 2.0cm Label and Location FCC ID : 2BH3M-GEN12

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202407428 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 3 Product Name: Body Worn Camera Model No.: Gen12.5 EUT Constructional Details Internal Photo ANTENNA Report No.: HTT202407428 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 3 Report No.: HTT202407428 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 3 ------End------

RF Exposure evaluation FCC ID: 2BH3M-GEN12 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) 0.0 0.0 0.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 Frequency (MHz) 11b 2412 2437 2462 Target (dBm) 5.0 5.0 5.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11g 2412 2437 2462 Target (dBm) 7.0 7.0 7.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11n(HT20) 2412 2437 2462 Target (dBm) 7.0 7.0 7.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11n(HT40) 2422 2437 2452 Target (dBm) 6.0 6.0 6.0 Tolerance ± (dB) 1.0 1.0 1.0 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BLE 2.450 5 1.0 1.2589 0.3941<3.0 Yes 2.4GWIFI 2.450 5 8.0 6.3096 1.9752<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 天线测试报告 Antenna Test Report TC：万汇芯源 MN：S31 RF：戴进平 MD：黄清清 MP：19918388579 1 2 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 测试信息 Test information Main ANT Antenna bandAntenna state Antenna form Matchc hanges Note 2G NO3G 4G AUX ANT BT/WIFI2.4GFPCPIFANO GPSNO DIVNO 3 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 测试环境 Test environment 测试项目测试设备 S参数 （S-parameter) 1.电压驻波比(VSWR) 2.回波损耗（Rrtun Loss) 网络分析仪：Agilent8753ES 2.有源测试 (Active) 1.发射功率（TRP) 2.接收灵敏度（TIS） 3.屏灭/屏亮 1.暗室：5*3*3m（3D）Chamber 2.综测仪：Agilent8960 CMW500 3.无源测试 （Passive) 1.天线增益(Gain) 2.天线效率（Efficiency) 1.暗室：5*3*3m（3D）Chamber 2.网络分析仪：Agilent 8753ES CMW500 4 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 天线位置 Antenna position 5 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 匹配电路 Matching circuit 电容（PF）电感（NH） E1(0402) E2(0402) E3(0402) E4(0402) 匹配电路原理图&位号图 6 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 无源测试数据 Passive test data Frequency(MHZ)240024502500 VSWR 1.671.071.72 Return Loss(DB) -11.9-29.09-11.48 ANT1 S11-VSWR&Return Loss 7 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 无源测试数据 Passive test data 8 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 无源测试数据 Passive test data 9

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202407428F01 This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 30 TEST Report Applicant: SHELL GROUP CO., LIMITED Address of Applicant: Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road, Hongkong Manufacturer : SHELL GROUP CO., LIMITED Address of Manufacturer : Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road, Hongkong Equipment Under Test (EUT) Product Name: Body Worn Camera Model No.: Gen12.5 Series model: Gen12 Trade Mark: N/A FCC ID: 2BH3M-GEN12 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: Jul. 16, 2024 Date of Test: Jul. 16, 2024 ~ Jul. 24, 2024 Date of report issued: Jul. 24, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: HTT202407428F01 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 2 of 30 1. Version Version No. Date Description 00 Jul. 24, 2024 Original Tested/ Prepared By Date: Jul. 24, 2024 Project Engineer Check By: Date: Jul. 24, 2024 Reviewer Approved By : Date: Jul. 24, 2024 Authorized Signature Report No.: HTT202407428F01 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 3 of 30 2. Contents Page 1. VERSION ........................................................................................................................................................ 2 2. CONTENTS .................................................................................................................................................... 3 3. TEST SUMMARY ........................................................................................................................................... 4 4. GENERAL INFORMATION ............................................................................................................................ 5 4.1. GENERAL DESCRIPTION OF EUT ................................................................................................................ 5 4.2. TEST MODE ............................................................................................................................................... 7 4.3. DESCRIPTION OF SUPPORT UNITS .............................................................................................................. 7 4.4. DEVIATION FROM STANDARDS .................................................................................................................... 7 4.5. ABNORMALITIES FROM STANDARD CONDITIONS ........................................................................................... 7 4.6. TEST FACILITY ........................................................................................................................................... 7 4.7. TEST LOCATION ......................................................................................................................................... 7 4.8. ADDITIONAL INSTRUCTIONS ........................................................................................................................ 7 5. TEST INSTRUMENTS LIST ........................................................................................................................... 8 6. TEST RESULTS AND MEASUREMENT DATA ........................................................................................... 9 6.1. CONDUCTED EMISSIONS ............................................................................................................................ 9 6.2. CONDUCTED OUTPUT POWER .................................................................................................................. 12 6.3. CHANNEL BANDWIDTH .............................................................................................................................. 13 6.4. POWER SPECTRAL DENSITY ..................................................................................................................... 15 6.5. BAND EDGES ........................................................................................................................................... 17 6.5.1 Conducted Emission Method .......................................................................................................... 17 6.5.2 Radiated Emission Method ............................................................................................................. 18 6.6. SPURIOUS EMISSION ................................................................................................................................ 20 6.6.1 Conducted Emission Method .......................................................................................................... 20 6.6.2 Radiated Emission Method ............................................................................................................. 22 6.7. ANTENNA REQUIREMENT .......................................................................................................................... 29 7. TEST SETUP PHOTO .................................................................................................................................. 30 8. EUT CONSTRUCTIONAL DETAILS ........................................................................................................... 30 Report No.: HTT202407428F01 Shen…

Text truncated - open the document above for the full version.

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202407428F02 This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 37 TEST Report Applicant: SHELL GROUP CO., LIMITED Address of Applicant: Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road, Hongkong Manufacturer : SHELL GROUP CO., LIMITED Address of Manufacturer : Flat D, 12/F, On Fuk Industrial Building 41-45 Kwai Fung Crescent, Container Port Road, Hongkong Equipment Under Test (EUT) Product Name: Body Worn Camera Model No.: Gen12.5 Series model: Gen12 Trade Mark: N/A FCC ID: 2BH3M-GEN12 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: Jul. 16, 2024 Date of Test: Jul. 16, 2024 ~ Jul. 24, 2024 Date of report issued: Jul. 24, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: HTT202407428F02 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 2 of 37 1. Version Version No. Date Description 00 Jul. 24, 2024 Original Tested/ Prepared By Date: Jul. 24, 2024 Project Engineer Check By: Date: Jul. 24, 2024 Reviewer Approved By : Date: Jul. 24, 2024 Authorized Signature Report No.: HTT202407428F02 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 3 of 37 2. Contents Page 1. VERSION ........................................................................................................................................................ 2 2. CONTENTS .................................................................................................................................................... 3 3. TEST SUMMARY ........................................................................................................................................... 4 4. GENERAL INFORMATION ............................................................................................................................ 5 4.1. GENERAL DESCRIPTION OF EUT ................................................................................................................ 5 4.2. TEST MODE ............................................................................................................................................... 7 4.3. DESCRIPTION OF SUPPORT UNITS .............................................................................................................. 7 4.4. DEVIATION FROM STANDARDS .................................................................................................................... 7 4.5. ABNORMALITIES FROM STANDARD CONDITIONS ........................................................................................... 7 4.6. TEST FACILITY ........................................................................................................................................... 7 4.7. TEST LOCATION ......................................................................................................................................... 7 4.8. ADDITIONAL INSTRUCTIONS ........................................................................................................................ 7 5. TEST INSTRUMENTS LIST ........................................................................................................................... 7 6. TEST RESULTS AND MEASUREMENT DATA ........................................................................................... 9 6.1. CONDUCTED EMISSIONS ............................................................................................................................ 9 6.2. CONDUCTED PEAK OUTPUT POWER ......................................................................................................... 12 6.3. CHANNEL BANDWIDTH .............................................................................................................................. 13 6.4. POWER SPECTRAL DENSITY ..................................................................................................................... 16 6.5. BAND EDGE ...................................................................................................................…

Text truncated - open the document above for the full version.
