MRT Technology (Suzhou) Co., Ltd. Report No.: R25S1047089-U204 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2025-11-18 Template Version: 2.1 1 of 217 RF MEASUREMENT REPORT FCC ID: 2BH7FAXE75 Applicant: TP-Link Systems Inc. Product: AXE5400 Tri-Band Wi-Fi 6E Router Model No.: Archer AXE75 Serial Model No.: Archer AXE5400 Brand Name: tp-link FCC Classification: 15E 6 GHz Low Power Indoor Access Point (6ID) FCC Rule Part(s): Part 15 Subpart E (Section 15.407) Result: Complies Received Date: 2025-08-22 Test Date: 2025-09-02 ~ 2025-10-27 Reviewed By: Kevin Guo Approved By: Robin Wu The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report. Testing was performed in accordance with the applicable measurement procedures. The test results reported herein apply only to the specific item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: R25S1047089-U204 2 of 217 Revision History Report No. Version Description Issue Date Note R25S1047089-U204 V01 Initial Report 2025-11-18 Valid Report No.: R25S1047089-U204 3 of 217 CONTENTS Description Page 1. General Information ................................................................................................................................ 6 1.1. Applicant ..................................................................................................................................... 6 1.2. Manufacturer............................................................................................................................... 6 1.3. Testing Facility ............................................................................................................................ 6 1.4. Product Information .................................................................................................................... 7 1.5. Radio Specification under Test ................................................................................................... 7 1.6. Working Frequencies .................................................................................................................. 8 1.7. Antenna Details .......................................................................................................................... 9 2. Test Configuration ................................................................................................................................. 10 2.1. Test Mode ................................................................................................................................. 10 2.2. Test System Connection Diagram ............................................................................................. 11 2.3. Test Software ............................................................................................................................. 11 2.4. Applied Standards ..........................................................................…
