2BH7FC545DOutdoor Dual Lens Pan/Tilt Security Camera

Quick Start Guide *Images may differ from actual products.7100001294 REV1.0.1 Plug in the adapter to power up your camera. 1. Download the App Press two release latches to detach the camera from the mounting bracket. Download the Tapo app from the App Store or Google Play. Open the app and log in with your TP-Link ID. If you don't have an account, create one first. 2. Power Up 3. Set Up Tap the button > Add Device in the app and select your model. Follow the app instructions to set up your camera. My Home OR Insert four anchors into the holes and use the screws to affix the bracket over the anchors. 2. Install the Bracket Route the cable through one of the base's three notches according to the direction of your power outlet. 3. Route the Cable 4. Secure the Camera Insert two anchors into the holes and use the screws to affix the bracket over the anchors. 2. Install the Bracket Route the cable through one of the base's three notches according to the direction of your power outlet. 3. Route the Cable 4. Secure the Camera Route the cable through one of the base's three notches according to the direction of your power outlet. 2. Route the Cable 3. Secure the Camera 2. Install Waterproof Cable Attachments Install the waterproof cable attachments for the network interface. Make sure each part is securely attached and the waterproof rings are flush to keep out water. 1. Install the Waterproof Seal for Power Connectors Install the waterproof seal for the power connectors. Male Power Connector Waterproof Seal Female Power Connector When the Ethernet port connects to a network device 1) Route the network cable through the following components in order: fix nut, waterproof ring, and then the waterproof jacket. 2) Insert the waterproof ring into the waterproof jacket. 3) Fix the O-ring to the network interface of the camera and connect the network cables. 4) Attach the network interface with the waterproof jacket, then twist to lock. Rotate the fix nut to secure it to the waterproof jacket. Fix Nut Waterproof Ring O-ring Network Interface Waterproof Jacket When the Ethernet port does not connect to a network device Fix Nut Waterproof Ring + Plug Network Interface Waterproof Jacket O-ring 1) Insert the waterproof plug into the waterproof ring, then insert them into the waterproof jacket. 2) Fix the O-ring to the network interface of the camera. Attach the network interface with the waterproof jacket, then twist to lock. Rotate the fix nut to secure it to the waterproof jacket. Align and slide the camera onto the camera bracket until it clicks into place. Align and slide the camera onto the camera bracket until it clicks into place. Align and slide the camera onto the camera bracket until it clicks into place. Option 2: Eave Mount Stick the mounting template to the desired place. Drill two screw holes according to the template. 1. Drill Holes Outdoor Dual Lens Pan/Tilt Security Camera Tapo C545D/TC47 Before You Start 1 Set Up Your Camera 2 3 Option 1: Wall Mount Stick the mounting template to the desired place. Drill four screw holes according to the mounting template. 1. Drill Holes Mount Your Camera 3 Install Waterproof Accessories 4 Option 3: Pole Mount 1. Install the Bracket Mount the bracket on the pole using two pole-mounting loops* (loop width ≤ 12 mm). Pole-mounting Loops (Not Included) Back Side Mounting Bracket Release Latches A B C A B C A B C Wall Mount: 1-4 Φ=6 mm (15/64 in.) Eave Mount: 1-2 or 3-4 Φ=6 mm (15/64 in.) Appearance RESET Button Open the silicone cover. While the camera is powered on, press and hold the RESET button to reset the camera. • Press and hold for 5 seconds: Reset Wi-Fi settings only • Press and hold for 10 seconds: Reset to factory settings microSD Card Slot Open the silicone cover and insert a microSD card.* Initialize it on the Tapo app for local recording. *microSD card not included. Button ExplanationSystem LED Indication Blinking red and green (for Wi-Fi setup) Blinking red slowly (for Wi-Fi setup) Solid amber Blinking red quickly Solid red Solid green Blinking green quickly Starting up Connected to the cloud Ready for setup Connecting to Wi-Fi Connected to Wi-Fi or wired network Camera resetting Camera updating Safety Information • Do not use damaged charger or USB cable to charge the device. • Do not use any other chargers than those recommended. • Do not use the device where wireless devices are not allowed. • Adapter shall be easily accessible. • Use only power supplies which are provided by manufacturer and in the original packing of this product. If you have any questions, please don't hesitate to contact us. • Keep the device away from fire or hot environments. DO NOT immerse in water or any other liquid. • Do not disassemble, repair or modify the product. • Do not use the product if the casing has been broken. Danger of electric shock. • Never touch the product with wet hands. • Do not place near automatically controlled devices such as fire alarms. Radio waves emitted from this product may cause such devices to malfunction resulting in an accident. • Observe restrictions on using wireless products in fuel depots, chemical plants or when blasting operations are in progress. • Do not use liquid to clean the product. Only use a dry cloth. • Never put metal objects inside the product. If a metal object enters the product turn off the circuit breaker and contact an authorised electrician. • This product is not intended to be used when providing medical care. Consult the manufacturer of any personal medical devices, such as pacemakers or hearing aids to determine if they are adequality shielded from external RF (radio frequency) energy. • Do not use this product in health care facilities. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy. • Do not place heavy objects on top of the product. • When you leave the product unused for a long time unplug the product from the power outlet. • This product may int…

Text truncated - open the document above for the full version.

Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 12 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 13 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 14 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 15 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 16 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 17 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 18 of 38

Appendix No.: TP-2508C295-1 APPENDIX-TEST PHOTOS Project No.: 2508C295 Page 1 of 4 AC Power Line Conducted Emissions test photos Appendix No.: TP-2508C295-1 APPENDIX-TEST PHOTOS Project No.: 2508C295 Page 2 of 4 Radiated emissions test photos 30 MHz to 1 GHz Appendix No.: TP-2508C295-1 APPENDIX-TEST PHOTOS Project No.: 2508C295 Page 3 of 4 Radiated emissions test photos 1 GHz to 18 GHz Appendix No.: TP-2508C295-1 APPENDIX-TEST PHOTOS Project No.: 2508C295 Page 4 of 4 Radiated emissions test photos Above 18 GHz

Report No.: BTL-FCCP-2-2508C295 Page 1 of 71 Page 1 of 71 Project No.: 2508C295 Report Version: R01 FCC Radio Test Report FCC ID: 2BH7FC545D Report No. : BTL-FCCP-2-2508C295 Equipment : Outdoor Dual Lens Pan/Tilt Security Camera Model Name : Tapo C545D, TC47 Brand Name : tp-link Applicant : TP-Link Systems Inc. Address : 10 Mauchly, Irvine, CA 92618 Manufacturer : TP-Link Systems Inc. Address : 10 Mauchly, Irvine, CA 92618 Factory : Lianzhou International Co., Ltd. Guangming Branch Address : Room -101, 1F-8F, C901, C1001, C1101, C1201, No.198, Kelian Road, Yutang Community, Yutang Street, Guangming District, Shenzhen City, Guangdong Province, P.R.China Radio Function : WLAN 2.4GHz FCC Rule Part(s) : FCC CFR Title 47, Part 15, Subpart C (15.247) Measurement Procedure(s) : ANSI C63.10-2020 Date of Receipt : 2025/8/25 Date of Test : 2025/8/26 ~ 2025/8/29 Issued Date : 2025/9/28 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Poken Huang, Engineer Approved by : Peter Chen, Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-2-2508C295 Page 2 of 71 Page 2 of 71 Project No.: 2508C295 Report Version: R01 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-2-2508C295 Page 3 of 71 Page 3 of 71 Project No.: 2508C295 Report Version: R01 Table of Contents Page REVISION HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 8 2 . GENERAL INFORMATION 9 2.1 GENERAL DESCRIPTION OF EUT 9 2.2 DESCRIPTION OF TEST MODES 10 2.3 PARAMETERS OF TEST SOFTWARE 10 2.4 DUTY CYCLE 11 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 2.6 SUPPORT UNITS 14 3 . AC POWER LINE CONDUCTED EMISSIONS 15 3.1 LIMIT 15 3.2 TEST PROCEDURE 15 3.3 DEVIATION FROM TEST STANDARD 15 3.4 TEST SETUP 16 3.5 EUT OPERATION CONDITIONS 16 3.6 TEST RESULTS 16 4 . RADIATED EMISSIONS 17 4.1 LIMIT 17 4.2 TEST PROCEDURE 18 4.3 DEVIATION FROM TEST STANDARD 19 4.4 TEST SETUP 19 4.5 EUT OPERATION CONDITIONS 21 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ 21 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 21 4.8 TEST RESULTS - ABOVE 1000 MHZ 21 5 . BANDWIDTH 22 5.1 LIMIT 22 5.2 TEST PROCEDURE 22 5.3 DEVIATION FROM STANDARD 22 5.4 TEST SETUP 22 Report No.: BTL-FCCP-2-2508C295 Page 4 of 71 Page 4 of 71 Project No.: 2508C295 Report Version: R01 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 22 5.6 TEST RESULTS 22 6 . OUTPUT POWER 23 6.1 LIMIT 23 6.2 TEST PROCEDURE 23 6.3 DEVIATION FROM STANDARD 23 6.4 TEST SETUP 23 6.5 EUT OPERATION CONDITIONS 23 6.6 TEST RESULTS 23 7 . CONDUCTED SPURIOUS EMISSIONS 24 7.1 LIMIT 24 7.2 TEST PROCEDURE 24 7.3 DEVIATION FROM STANDARD 24 7.4 TEST SETUP 24 7.5 EUT OPERATION CONDITIONS 24 7.6 TEST RESULTS 24 8 . POWER SPECTRAL DENSITY 25 8.1 LIMIT 25 8.2 TEST PROCEDURE 25 8.3 DEVIATION FROM STANDARD 25 8.4 TEST SETUP 25 8.5 EUT OPERATION CONDITIONS 25 8.6 TEST RESULTS 25 9 . MEASUREMENT INSTRUMENTS LIST 26 10 . EUT TEST PHOTO 28 11 . EUT PHOTOS 28 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 29 APPENDIX B - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 32 APPENDIX C - RADIATED EMISSION- ABOVE 1000 MHZ 35 APPENDIX D - BANDWIDTH 57 APPENDIX E - OUTPUT POWER 62 APPENDIX F - CONDUCTED SPURIOUS EMISSIONS 64 Report No.: BTL-FCCP-2-2508C295 Page 5 of 71 Page 5 of 71 Project No.: 2508C295 Report Version: R01 Table of Contents Page APPENDIX G - POWER SPECTRAL DENSITY 69 Report No.: BTL-FCCP-2-2508C295 Page 6 of 71 Page 6 of 71 Project No.: 2508C295 Report Version: R01 REVISION HISTORY Report No. Version Description Issued Date Note BTL-FCCP-2-2508C295 R00 Original Report. 2025/9/19 Invalid BTL-FCCP-2-2508C295 R01 This report corrected the test procedure in chapter 6.2. It is a revision of the report BTL-FCCP-2-2508C295 R00. This is a newly released report, replacing the BTL-FCCP-2-2508C295 R00 report. 2025/9/28 Valid Report No.: BTL-FCCP-2-2508C295 Page 7 of 71 Page 7 of 71 Project No.: 2508C295 Report Version: R01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC CFR Title 47, Part 15, Subp…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-2508C295 Page 1 of 48 Report Version: R00 Project No.: 2508C295 FCC Radio Test Report FCC ID: 2BH7FC545D Report No. : BTL-FCCP-1-2508C295 Equipment : Outdoor Dual Lens Pan/Tilt Security Camera Model Name : Tapo C545D, TC47 Brand Name : tp-link Applicant : TP-Link Systems Inc. Address : 10 Mauchly, Irvine, CA 92618 Manufacturer : TP-Link Systems Inc. Address : 10 Mauchly, Irvine, CA 92618 Factory : Lianzhou International Co., Ltd. Guangming Branch Address : Room -101, 1F-8F, C901, C1001, C1101, C1201, No.198, Kelian Road, Yutang Community, Yutang Street, Guangming District, Shenzhen City, Guangdong Province, P.R.China Radio Function : Bluetooth Low Energy FCC Rule Part(s) : FCC CFR Title 47, Part 15, Subpart C (15.247) Measurement Procedure(s) : ANSI C63.10-2020 Date of Receipt : 2025/8/25 Date of Test : 2025/8/26 ~ 2025/8/29 Issued Date : 2025/9/19 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Poken Huang, Engineer Approved by : Peter Chen, Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-1-2508C295 Page 2 of 48 Report Version: R00 Project No.: 2508C295 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the Customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-2508C295 Page 3 of 48 Report Version: R00 Project No.: 2508C295 CONTENTS REVISION HISTORY 5 1 SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 1.3 TEST ENVIRONMENT CONDITIONS 7 1.4 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 8 2 GENERAL INFORMATION 9 2.1 DESCRIPTION OF EUT 9 2.2 TEST MODES 11 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 2.4 SUPPORT UNITS 13 3 AC POWER LINE CONDUCTED EMISSIONS TEST 14 3.1 LIMIT 14 3.2 TEST PROCEDURE 14 3.3 DEVIATION FROM TEST STANDARD 14 3.4 TEST SETUP 15 3.5 TEST RESULT 15 4 RADIATED EMISSIONS TEST 16 4.1 LIMIT 16 4.2 TEST PROCEDURE 17 4.3 DEVIATION FROM TEST STANDARD 17 4.4 TEST SETUP 18 4.5 EUT OPERATING CONDITIONS 20 4.6 TEST RESULT – BELOW 30 MHZ 20 4.7 TEST RESULT – 30 MHZ TO 1 GHZ 20 4.8 TEST RESULT – ABOVE 1 GHZ 20 5 BANDWIDTH TEST 21 5.1 APPLIED PROCEDURES / LIMIT 21 5.2 TEST PROCEDURE 21 5.3 DEVIATION FROM STANDARD 21 5.4 TEST SETUP 21 5.5 EUT OPERATION CONDITIONS 21 5.6 TEST RESULTS 21 6 OUTPUT POWER TEST 22 6.1 APPLIED PROCEDURES / LIMIT 22 6.2 TEST PROCEDURE 22 6.3 DEVIATION FROM STANDARD 22 6.4 TEST SETUP 22 6.5 EUT OPERATION CONDITIONS 22 6.6 TEST RESULTS 22 7 POWER SPECTRAL DENSITY TEST 23 7.1 APPLIED PROCEDURES / LIMIT 23 7.2 TEST PROCEDURE 23 7.3 DEVIATION FROM STANDARD 23 7.4 TEST SETUP 23 7.5 EUT OPERATION CONDITIONS 23 7.6 TEST RESULTS 23 Report No.: BTL-FCCP-1-2508C295 Page 4 of 48 Report Version: R00 Project No.: 2508C295 8 ANTENNA CONDUCTED SPURIOUS EMISSION 24 8.1 APPLIED PROCEDURES / LIMIT 24 8.2 TEST PROCEDURE 24 8.3 DEVIATION FROM STANDARD 24 8.4 TEST SETUP 24 8.5 EUT OPERATION CONDITIONS 24 8.6 TEST RESULTS 24 9 LIST OF MEASURING EQUIPMENTS 25 10 EUT TEST PHOTO 27 11 EUT PHOTOS 27 APPENDIX A AC POWER LINE CONDUCTED EMISSIONS 28 APPENDIX B RADIATED EMISSIONS - 30 MHZ TO 1 GHZ 31 APPENDIX C RADIATED EMISSIONS - ABOVE 1 GHZ 34 APPENDIX D BANDWIDTH 41 APPENDIX E OUTPUT POWER 43 APPENDIX F POWER SPECTRAL DENSITY TEST 45 APPENDIX G ANTENNA CONDUCTED SPURIOUS EMISSION 47 Report No.: BTL-FCCP-1-2508C295 Page 5 of 48 Report Version: R00 Project No.: 2508C295 REVISION HISTORY Report No. Version Description Issued Date Note BTL-FCCP-1-2508C295 R00 Original Report. 2025/9/19 Valid Report No.: BTL-FCCP-1-2508C295 Page 6 of 48 Report Version: R00 Project No.: 2508C295 1 SUMMARY OF TEST RESULTS Test procedures according to the technical standards. Standard(s) Section Description Test Result Judgement Remark 15.207 AC Power Line Conducted Emissions APPENDIX A Pass ------ 15.205 15.209 15.407(b) Radiated Emissions APPENDIX B APPENDIX C Pass ------ 15.247(a)(2) Bandwidth APPENDIX D Pass ------ 15.247(b)(3) Output Power APPENDIX E Pass ------ 15.247(e) Power Spectral Density APPENDIX F Pass ------ 15.247(d) Antenna conducted Spurious Emission APPENDIX G Pass ------ 15.203 Anten…

Text truncated - open the document above for the full version.

Product Model： Tapo C520WS Manufacturer： TP-Link Systems Inc. Date： 2024.8.14 Checked By： Fang Chao TP-Link Systems Inc. 10 Mauchly, Irvine, CA 92618 Index 1. Antenna Distribution ........................................................................................ 3 2. Electrical Characteristics ................................................................................ 3 3. S Parameter Test Data ..................................................................................... 4 4. Antenna Peak Gain........................................................................................... 5 5. Antenna Radiation Pattern .............................................................................. 5 Page 3 1. Antenna Distribution Tapo C520WS 2. Electrical Characteristics Ant1 Frequency 2400~2500MHz Impedance 50Ohm Antenna Type dipole Antenna Gain 0.5dBi Radiation pattern Omni-Directional Ant2 Frequency 2400~2500MHz Impedance 50Ohm Antenna Type dipole Antenna Gain 0.5dBi Page 4 Radiation pattern Omni-Directional 3. S Parameter Test Data Ant1 Ant2 Page 5 4. Antenna Gain 4.1 Peak Gain Frequency(GHz) 2.45GHz 2400~2500MHz Ant1 MaxGain(dBi) 0.5 Ant2 MaxGain(dBi) 0.5 Ant1 Polarization/Φ (°)/θ(°) Theta/90/90 Ant2 Polarization/Φ (°)/θ(°) Theta/120/110 Max Gain(dBi) 0.50 5. Antenna Radiation Pattern Ant1 Ant2

Report No.: BTL-FCCP-3-2508C295 Page 1 of 4 Project No.: 2508C295 Report Version: R01 FCC RF EXPOSURE REPORT FCC ID: 2BH7FC545D Report No. : BTL-FCCP-3-2508C295 Equipment : Outdoor Dual Lens Pan/Tilt Security Camera Model Name : Tapo C545D, TC47 Brand Name : tp-link Test Model : Tapo C545D Software Version : 1.X Hardware Version : 1.0 Applicant : TP-Link Systems Inc. Address : 10 Mauchly, Irvine, CA 92618 Manufacturer : TP-Link Systems Inc. Address : 10 Mauchly, Irvine, CA 92618 Factory : Lianzhou International Co., Ltd. Guangming Branch Address : Room -101, 1F-8F, C901, C1001, C1101, C1201, No.198, Kelian Road, Yutang Community, Yutang Street, Guangming District, Shenzhen City, Guangdong Province, P.R.China Radio Function : Bluetooth Low Energy, WLAN 2.4GHz FCC Rule Part(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 & KDB 447498 D01 v06 Date of Receipt : 2025/8/25 Date of Test : 2025/8/26 ~ 2025/8/29 Issued Date : 2025/9/28 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Poken Huang, Engineer Approved by : Peter Chen, Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-3-2508C295 Page 2 of 4 Project No.: 2508C295 Report Version: R01 REVISION HISTORY Report No. Version Description Issued Date Note BTL-FCCP-3-2508C295 R00 Original Report. 2025/9/19 Invalid BTL-FCCP-3-2508C295 R01 This report corrected the FCC ID in page 1. It is a revision of the report BTL-FCCP-3-2508C295 R00. This is a newly released report, replacing the BTL-FCCP-3-2508C295 R00 report. 2025/9/28 Valid Report No.: BTL-FCCP-3-2508C295 Page 3 of 4 Project No.: 2508C295 Report Version: R01 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 2. ANTENNA SPECIFICATION For BLE: Ant. Manufacturer Model Name Type Connector Gain (dBi) 1 TP-Link Systems Inc. N/A dipole N/A 0.5 For 2.4GHz: Ant. Manufacturer Model Name Type Connector Gain (dBi) 1 TP-Link Systems Inc. N/A dipole N/A 0.5 2 TP-Link Systems Inc. N/A dipole N/A 0.5 Note: Smart antenna system with two transmit/receive chains, but operating in a mode where only one transmit/receive chain is used. The worst case is Ant. 1 and recorded. The above Antenna information are derived from the antenna data sheet provided by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Report No.: BTL-FCCP-3-2508C295 Page 4 of 4 Project No.: 2508C295 Report Version: R01 3. CALCULATED RESULT For BLE: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 0.5 1.1220 5.47 3.5237 0.00079 1 Complies For 2.4GHz: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 0.5 1.1220 19.38 86.6962 0.01936 1 Complies Note: (1) The calculated distance is 20 cm. (2) Ratio=Power Density (S) (mW/cm 2 )/Limit of Power Density (S) (mW/cm 2 ) (3) WLAN 2.4GHz and LE can not simultaneous transmission. End of Test Report

Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 37 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 38 of 38

Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 30 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 31 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 32 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 33 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 34 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 35 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 36 of 38

Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 22 of 38 2.4G WiFi Ant.2 LE&2.4G WiFi Ant.1 Model: TC47 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 23 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 24 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 25 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 26 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 27 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 28 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 29 of 38

TP-Link Systems Inc. CERTIFICATIONS CONCERNING “COVERED” EQUIPMENT Date: 2025-09-19 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2BH7FC545D To Whom It May Concern: As required by section 2.911(d)(5)(i), [TP-Link Systems Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. As required by section 2.911(d)(5)(ii), [TP-Link Systems Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment. Thank you for your attention to this matter. Sincerely yours, Signature Printed Name: Sarah Wang Company: TP-Link Systems Inc. Job Title: Regulatory Compliance Manager Email: [email protected] Telephone: 6263330234

Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 4 of 38 2.4G WiFi Ant.2 LE&2.4G WiFi Ant.1 Model: Tapo C545D Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 5 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 6 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 7 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 8 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 9 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 10 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 11 of 38

TC47

Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 1 of 38 Model: Tapo C545D Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 2 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 3 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 19 of 38 Model: TC47 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 20 of 38 Appendix No.: EP-2508C295-1 APPENDIX-EUT PHOTOS Project No.: 2508C295 Page 21 of 38

Declaration of Conformity We Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Irvine California United States 92618 Declare that: Product: Outdoor Dual Lens Pan/Tilt Security Camera FCC ID: 2BH7FC545D Model: Tapo C545D,TC47 Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2025-09-19

Model Declaration Letter We, the undersigning company Company Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Irvine California United States 92618 Hereby confirm that the following products: Product description: Outdoor Dual Lens Pan/Tilt Security Camera Type designation: Tapo C545D，TC47 HVIN: Tapo C545D，TC47 FCC ID: 2BH7FC545D IC: 32876-C545D Trademark: tp-link That All versions of the Model Tapo C545D and TC47 are electrically equal except the following difference: The two models only differ in model name and sales channels (TC47 is an online e-commerce model, while Tapo C545D is available both online and offline); there are no other differences. Name: Sarah Wang Telephone: 6263330234 E-mail: [email protected] Signature:

TP-Link Systems Inc. Wi-Fi Channel 12 and 13 Declaration Letter Date: 2025-09-19 We, the undersigned company Company Name: TP-Link Systems Inc. Address: 10 Mauchly, Irvine, CA 92618 Irvine California United States 92618 Declare that: Product description: Outdoor Dual Lens Pan/Tilt Security Camera Type designation: Tapo C545D,TC47 Brand: tp-link FCC ID: 2BH7FC545D Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Sarah Wang Tel: 6263330234 Email: [email protected]

TP-Link Systems Inc. 030122-15 Request for Confidentiality Date: September 22, 2025 Subject: Confidentiality Request for: 2BH7FC545D Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Perman…
